PINE64 PineBuds Pro User manual

1. Accessories
Earbuds
Microphones
Microphones
Charging case
LED
LEFT EARBUD RIGHT EARBUD
Left
button
LED
Left
button
Eartips
USB-A to USB-C charging cable
PineBuds Pro U s e r m a n u a l
LED
1
Small
Large
Medium
pre-mounted on
the earbuds

2. How to wear
Microphone
Insert each earbuds into your ear
and ensure the microphones are
pointed towards your mouth. The
earbud LED light are facing up.
2.1 Changing Eartips
For the optimal audio and ANC experience, it is recommended to try each of the
dierent eartips sizes. The fit should feel light and comfortable in your ear.
The medium eartips are pre-mounted on the earbuds.
When attaching a new eartips, ensure the oval mounting tip on the earbud is
aligned with the oval attachment on the eartips.
Press the eartips firmly onto the ear.
Right
2
LED

Get up to 5 hours on a single charge with ANC. Total charge of up to
20 hours with the charging case.
3.1 Charging the earbuds
Place the earbuds in the charging case and close the lid. It takes up to 1.5
hours to fully recharge the earbuds.
When the charging case is opened, the LEDs on the earbuds will light up red.
LED light dims when battery is fully charged.
3.2 Low Power Shut Off
When the battery voltage is below 3.2V,
the earbuds will turn o.
3. 3 Battery level
Battery status is indicated next to Bluetooth
Status on the connected phone.
3. How to charge
3

Charging RED LED lights up.
Full Charged RED LED Dims.
Earbuds Status
ON (Blue LED flashes every 1 second).
OFF (Red LED flashes 1 time and then o).
Charging case has 4 White LEDs flashing
indicating charging activity. When charging
reaches 100%, all 4 LEDs lit up and stop
flashing.
Factory reset success (Purple LED blinks)
Pairing mode: Left earbud Blue LED flashes
Pairing Success: Left earbud Blue LED goes dark
4. What the LEDs mean
4

5.1 Left/ Right mutually connects
Remove earbuds from case, go to your Smartphone settings and enable
Bluetooth pairing. Look for “PineBuds Pro” and establish the pairing process.
a. During peer pairing mode, Left earbud LED alternates in Red + Blue color.
Right earbud LED blinks Blue color every 5 seconds.
b. When Peer-pairing is successful, BOTH earbuds LED blinks Blue every 5 seconds.
5. How to pair
5.2 Peer - Connected
Power on the earbuds by removing them from the charging case. Left earbud
LED blinks Blue indicating awaiting pairing with device.
> Once pairing with phone is successful, LED blinks Blue color every 5 seconds.
5.3 Master/ Slave switching
1. Pair earbuds with phone, then place earbuds to charging case.
2. Then remove any singe earbud and becomes Master.
3. Insert Master earbud in charging case, and remove the Slave earbud, Slave
earbud will resume connection with phone.
5.4 Disconnect from pairing
1. Place earbuds in charging case.
> It will disconnect from the phone. Earbuds enters pairing mode and can be
paired with new device nearby.
> If the link loss is less than 5 minutes, earbuds try to reconnects with the
phone. If exceeds 5 minutes, earbuds will turn o.
5

6. How to use
> Blue LED flash 1 sec.
> Power ON.
To turn ON the earbuds, remove from the charging case.
6.1 Powering the Earbuds ON/ OFF
If not inside the charging case, press buttons for 5 seconds.
To turn OFF earbuds, place inside the charging case.
If not putting inside the charging case, press button for 5 seconds.
> Red LED flash 1 sec.
> Power OFF.
6.2 Music controls
Left earbud Function Right earbud Play/
Pause Tap right button twice
Volume up Tap right button once
Press right button
1 second
Tap left button once Volume down
Next track
Press left button Previous track
for 1 second
> Beeps when reaching maximum volume.
6

6.3 Call controls
Left earbud
Tap left or
right twice
Press left or
right for 1 second
Press left or
right for 1 second
Function Right earbud
Answer call
End/Reject call
Mute/unmute
microphone
Tap left or right Hang-up call
button twice
Tap left or right
button twice
continue How to use
Press left or
right for 2 second
Press left or
right for 2 second
Regular ANC Mode: Oers 25dB of Noise reduction.
Super ANC Mode: Oers 45dB of Noise reduction.
6.4Advanced ANC
3Tap on left button cycles through ANC modes:
ANC (25dB) On >ANC Off >HearThrough > SuperANC (45dB) On
Left button ANC
7
Tap left or
right twice

6.5 HearThrough
HearThrough lets you pay attention to your surroundings when engage in
conversation, or not on a call, without needing to remove the earbuds. The
microphones pick up surrounding sounds and transmit them to the speakers.
continue How to use
6.6Mono earbud use
Either earbud can be used individually for mono music playback or for
calls. When used as a mono earbud, the earbud retains its current
button functionality.
To use the either earbud as a mono earbud, place it in your ear and
place the other earbud in the charging case. You may need to tap the
button on the earbud to activate mono earbud use.
6.7 Sleep mode
To conserve battery, the earbuds will automatically power o when they
are out of range of your mobile device for more than 5 minutes and are
not in the charging case, or when they have been inactive for more than
5 minutes.To power the earbuds on, press the buttons for 5 seconds.
6.8Reset the earbuds
Resetting the earbuds clears the list of paired devices and resets all settings.
1. Return the Earbuds to the case.
2. Press RESET button in the case for 5 seconds.
3. Close the charging case lid to complete the reset ---> LED flashes purple.
8
