Pinnacle Speakers K60 User manual

Pinnacle Speakers owns the copyrights to the content of this literature which includes photographs, descriptive copy,
tradenames, logos, layouts etc. Any unauthorized use of this material is an infringement of our copyrights and we will protect
our copyrights to the fullest extent of the law.
K60 & K80
K60 & K80
2-Way, Acoustic Suspension
1” liquid cooled titanium eyeball tweeter
8” Kevlar®cone woofer with butyl surround
40 – 20 kHz (+/- 3 dB)
4 kHz
20 – 150 Watts RMS per channel
86 dB @ 1 Watt/1 Meter (2.83 Volts Pink Noise)
8 Ohms
10 1/8” W x 14 ¼ ” H x 3 11/16 D
(8 7/8” x 12 3/4” cutout)
White / Paintable
5 lbs. each
2-Way, Acoustic Suspension
1 ” liquid cooled titanium eyeball tweeter
6 1/2” Kevlar®cone woofer with butyl surround
50 – 20 kHz (+/- 3 dB)
4 kHz
20 – 150 Watts RMS per channel
87 dB @ 1 Watt/1 Meter (2.83 Volts Pink Noise)
8 Ohms
8 ¾ ” W x 12” H x 3 ¼ “ D
(7 5/8” x 10 7/8cutout)
White / Paintable
3 1/2lbs. each
System Type
Component Drivers
Frequency Response
Crossover Frequency
Recommended Amp Power
Sensitivity
Nominal Impedance
Dimensions
Finish
Weight
Specifications K 60 K 80
Our Kevlar®Series of custom in-wall and in-ceiling speakers are designed
for superior sound backed by “bulletproof” durability. Kevlar®, a
cutting edge polymer, is the material of choice for highly specialized applications where strength
and reliability is critical. Its superior acoustical qualities, when molded into speaker cones, are
further enhanced by our custom crafted crossover networks, known for their meticulous detail and
component quality. The result is unparalleled sound and performance from this series of superb
custom install speakers.
• Special Kevlar®cone for superior stability and detail at all power levels
• Custom crafted crossover networks reveal crisp, precise response
• Pivot-mount Titanium dome tweeter for the best performance and placement flexibility
• Automatic Overload Protection Circuit • Gold-plated binding posts
• Hardware in place for easy wall mount installation • Designed in the USA
• LIFETIME transferable warranty on parts & labor
Special Features
