PIONEER DJ DJM-250MK2 Installation and operating instructions

DJM-250MK2
List of MIDI messages Version 1.00
1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
16
19
17
18
25
27
28
26
20
24
21
22
23
1

NOTE is a term used for MIDI to express that a key of a keyboard or a piano is pressed or your finger is released from it.
CC is an abbreviation of "Control Change".
Control Change is a kind of MIDI message used to communicate many kinds of control information such as sound quality and volume level.
User Interface Details(Data2) MIDI Type
CH1 Computer
35 00:OFF
7F:ON -
LINE
33 00:OFF
7F:ON -
PHONO
34 00:OFF
7F:ON -
2 TRIM rotate Bn 1 00(Min) - 7F(Max) -
3HI rotate Bn 2 00(Min) - 7F(Max) -
4 MID rotate Bn 3 00(Min) - 7F(Max) -
5 LOW rotate Bn 4 00(Min) - 7F(Max) -
6 COLOR rotate Bn 5 00(Min) - 7F(Max) -
7CUE press Bn 46 00:OFF
7F:ON Trigger/Toggle
8 CH FADER slide Bn 11 00(Min) - 7F(Max) -
CH2 Computer
39 00:OFF
7F:ON -
LINE
37 00:OFF
7F:ON -
PHONO
38 00:OFF
7F:ON -
10 TRIM rotate Bn 6 00(Min) - 7F(Max) -
11 HI rotate Bn 7 00(Min) - 7F(Max) -
12 MID rotate Bn 8 00(Min) - 7F(Max) -
13 LOW rotate Bn 9 00(Min) - 7F(Max) -
14 COLOR rotate Bn A 00(Min) - 7F(Max) -
15 CUE press Bn 47 00:OFF
7F:ON Trigger/Toggle
16 CH FADER slide Bn 12 00(Min) - 7F(Max) -
CROSS FADER LEFT
0 -
CENTER
40 -
RIGHT
7F -
OFF
0
ON
7F
19 CROSS FADER slide Bn B 00(Min) - 7F(Max) -
AUX Computer
9n 4A 00:OFF
7F:ON
LINE
9n 4B 00:OFF
7F:ON
21 TRIM rotate Bn 1C 00(Min) - 7F(Max)
22 LEVEL rotate Bn 1E 00(Min) - 7F(Max) -
23 TONE rotate Bn 1F 00(Min) - 7F(Max) -
SOUND COLOR FX
24 PARAMETER rotate Bn 6C 00(Min) - 7F(Max) -
25 FILTER press Bn 57 00:OFF
7F:ON Trigger/Toggle
MASTER
26 MASTER LEVEL rotate Bn 18 00(Min) - 7F(Max) -
27 MIXING rotate Bn 1B 00(Min) - 7F(Max) -
28 LEVEL rotate Bn 1A 00(Min) - 7F(Max) -
*1 n : value of channel No.
9n : Note
Bn : Control Change (CC)
*2 For alternate selection of the user interface (UI) control, the MIDI message will be sent as follows.
Previously selected: OFF
Newly selected: ON
9
INPUT SELECTOR *2
slide
9n
Group
Part
No.
MIDI-IN (to computer)
UI name
Trigger
Condition
(mode)
Status *1
(Hex)
Data 1
(Hex)
Data 2
(Hex)
1
INPUT SELECTOR *2
slide
9n
18
CROSS FADER REVERSE
slide
Bn
60
17
CROSS FADER CURVE
slide
Bn
5F
20
INPUT SELECTOR *2
slide
MIC
HEADPHONES
2
