Pioneer RD-HWK100 User manual

Hard Wire Kit
RD-HWK100
Installation Manual
Thank you for buying this Pioneer product. Please read through
these instructions so you will know how to operate your model
properly. After you have finished reading the instructions, keep
this document in a safe place for future reference.
Be sure to disconnect the terminal of the vehicle’s
battery before connecting the power or AV cable.
Handling precautions
• Be sure to install this product correctly according to this
instruction manual. Installation other than specified may
cause an accident or injury. In this case, Pioneer does not
take any responsibility.
• When installing this product, also read the “Safety
Precautions” for the compatible Dash Camera to which this
product is to be installed.
Precautions before connecting the system
CAUTION
• Secure all wiring with cable clamps or electrical tape. Do
not allow any bare wiring to remain exposed.
• Make sure that the cables and wires will not interfere with
or become caught in any of the vehicle’s moving parts,
especially the steering wheel, gearstick, handbrake, sliding
seat tracks, doors, or any of the vehicle’s controls.
• Do not route wires where they will be exposed to high
temperatures. If the insulation heats up, wires may become
damaged, resulting in a short circuit or malfunction and
permanent damage to the product.
• Do not shorten any cables. If you do, the protection circuit
(fuse holder, fuse resistor or filter, etc.) may fail to work
properly.
• Never feed power to other electronic products by cutting
the insulation of the power supply cable of this product
and tapping into the cable. The current capacity of the
cable will be exceeded, causing overheating.
Important safeguards
WARNING
• Any obstruction of or other interference with the airbag,
either deployed or non-deployed, or with the clear view of
the road must be avoided and, accordingly, professional
installation is required.
• Do not allow this product to come into contact with liquids.
Electrical shock could result. Also, damage to the product,
smoke, and overheating could result from contact with
liquids.
• Do not disassemble or modify this product, as there are
high-voltage components inside which may cause an
electric shock. Be sure to consult your dealer or the nearest
authorised Pioneer Service Station for internal inspection,
adjustments or repairs.
• Do not use this product in locations subjected to high
temperatures of 60°C or higher, low temperatures of –10°C
or lower, or high humidity.
To prevent damage
WARNING
• When replacing the fuse, be sure to only use a fuse of the
rating prescribed on this product.
Precautions before installation (I)
CAUTION
• Never install this product in places where, or in a manner
that:
- Could injure the driver or passengers if the vehicle stops
suddenly.
- May interfere with the driver’s operation of the vehicle,
such as on the floor in front of the driver’s seat, or close to
the steering wheel or gearstick.
• To ensure proper installation, be sure to use the supplied
parts in the manner specified. If any parts are not supplied
with this product, use compatible parts in the manner
specified after you have the parts’ compatibility checked
by your dealer. If parts other than supplied or compatible
ones are used, they may damage internal parts of this
product or they may work loose and the product may
become detached.
English

English
Precautions before installation (II)
CAUTION
• Do not install this product where it may:
(i) obstruct the driver’s vision,
(ii) impair the performance of any of the vehicle’s operating
systems or safety features, including airbags, hazard lamp
buttons or
(iii) impair the driver’s ability to safely operate the vehicle.
• Consult with your nearest dealer if installation requires
drilling holes or other modifications of the vehicle.
• Before making a final installation of this product,
temporarily connect the wiring to confirm that the
connections are correct and the system works properly.
• Do not install this product in places subject to high
temperatures or humidity, such as:
- Places close to a heater, vent or air conditioner.
- Places that may be exposed to rain, such as close to the
door or on the vehicle’s floor.
Notes
• The security mode can be set to on or off.
→ “This Product Settings” - “Configurable Features” -
“Parking Mode” - “Security mode”
• In the security mode, this product runs in the low power
consumption mode to reduce the risk of the battery
running flat.
• When the battery voltage drops below 11.2 V, security
mode standby and recording are stopped.
• The security mode starts recording within three seconds of
detection of impact.
• Vibration that is detected for approximately three minutes
before the vehicle’s engine is turned on (ACC ON) is not
covered by the notification message display feature.
• The security mode is a feature for starting up and
activating this product after an impact is detected. For this
reason, the battery might wear more quickly if this product
is used in mechanical multi-story parking garages or
location subjected to lots of vibration. When parking in
locations such as these, set the security mode to off before
using this product.
• The parking mode (security mode allowing 24-hour, 365-
day surveillance) can be used by extracting
power directly from the vehicle by the power / AV cable.
You can also connect the product to navigation by the
power / AV cable to project realtime video from this
product or movies and photos that are being played back
on the screen of the navigation.
Disclaimer
• Given the large number of variables and conditions that
can be involved in an accident, Pioneer cannot guarantee
that every accident or occurrence will trigger the recording
feature in this device.
• Pioneer Corporation accepts no responsibility whatsoever
for product failures or damage that occur due to this
product.
24/7 Security Mode
• If the pre-set operation time elapses when the security
mode is turned ON, the security mode in which parking
surveillance is performed 24 hours per day, 365 days per
year is automatically activated. When this device detects
vehicle movement caused by vibration while the security
mode is activated, that event is saved for the set normal
video time after the moment of detection as a parking
mode file, and a notification message is displayed at the
next startup.

English
Installation
Ground (Black)
Securely connect to the metal part of the vehicle body. To prevent noise,
connect as close to the navigation unit as possible.
+ Battery power supply (Yellow)
Always connect to the power circuit supplied with power from the
battery, regardless of whether the vehicle engine switch is ON or OFF.
Accessory power supply (Red)
Connect to the power circuit supplied with power when the vehicle
engine switch is turned to the ACC position.
Never install the accessory power supply to a vehicle that does not have
an ACC position on the engine switch. Doing so may lead to a dead
battery.
Note: Connect the red and yellow lead wires to the terminals after
wiring through the vehicle’s fuse unit.
Video/audio output mini pin jack
Connect to the AUX input of the main unit of a Pioneer product with a
mini jack terminal compatible with video input.
Connection to main units of other brands with RCA input terminals is
also possible by using the included mini pin jack-RCA conversion cable
(figure below).
*After connecting, the following message is displayed: “Is the 3.5mm Audio/
Video Jack Connected?” Select “Yes” or “No”.
Connection Precautions
To prevent fuming and damage to the product, be sure to rst securely
connect the black lead wire (Ground) of this product to the metal part of
the vehicle body.
Connect separate black lead wires (Ground) for products with a high
current consumption such as a power amplier. When setting up
connections all at once, there is a risk of fuming or damage to the
product when screws loosen or come o completely.
The parking mode (security mode allowing 24-hour, 365-day surveillance) can be used by extracting power directly from the vehicle by the
power / AV cable. You can also connect the product to navigation by the power / AV cable to project realtime video from this product or
movies and photos that are being played back on the screen of the navigation.
PIONEER CORPORATION
28-8, Honkomagome 2-Chome,
Bunkyo-ku, Tokyo 113-0021
Japan
pioneer-car.eu
© 2020 PIONEER CORPORATION
PIONEER EUROPE NV
Haven 1087, Keetberglaan 1,
B-9120 Melsele
Belgium/Belgique
TEL: [phone]
Black 0.5 m
Yellow 0.5 m
Red 0.5 m
4.5 m
Fuse
(F 2 AL/250 V)
Fuse
(F 2 AL/250 V)
0.2 m
Wiring specification of this
product
Audio is recorded in monaural
sound.
Audio (L)
Audio (R)
Ground
Video
Yellow Video
White Audio (L)
Red Audio (R)
Black 5 m
Black lead wire (Ground)
Metal part of the vehicle body
*1 *1 Not supplied for this unit
