Pioneer FH-P9200MP User manual

Operation Manual
¬©$
Multi-CD control DSP High power CD/MP3/WMA/MD
player with FM/AM tuner
FM/AM ¸©@ðCD è¸dDSP à%CD/
MP3/WMA/MD t´
FH-P9200MP
English \

Thank you for buying this Pioneer product.
Please read through these operating instructions so you will know how to operate
your model properly. After you have finished reading the instructions, put them away
in a safe place for future reference.
Before You Start
About this manual 5
Precautions 5
Features 5
About WMA 6
Switching the DSP setting mode 6
Resetting the microprocessor 6
About the demo mode 7
Reverse mode 7
Feature demo 7
About basic displays 7
SOF KEY operation 8
Switching the function of the multi-
function buttons 8
Example of multi-function button
operation 8
he difference between the BAND
button and the BACK button 9
Key guidance indicator 10
Setting the display angle 10
Use and care of the remote control 11
Installing the battery 11
Replacing the battery 11
Using the remote control 11
FUNC ION button and AUDIO
button 12
Whats What
Head unit 13
Remote control 14
Power ON/OFF
urning the unit on 15
Selecting a source 15
urning the unit off 15
Tuner
Listening to the radio 16
Introduction of advanced tuner
operation 16
Storing and recalling broadcast
frequencies 17
uning in strong signals 17
Storing the strongest broadcast
frequencies 17
Selecting stations from the preset channel
list 18
Bu lt- n CD Player
Playing a CD 19
Introduction of advanced built-in CD player
operation 20
Repeating play 20
Playing tracks in a random order 20
Scanning tracks of a CD 20
Selecting tracks from the track title list 21
Pausing CD playback 21
Selecting the search method 21
Searching every 10 track in the current
disc 21
Entering disc titles 22
Using disc title functions 22
MP3/WMA Player
Playing a MP3/WMA 23
Introduction of advanced built-in CD player
(MP3/WMA) operation 24
Repeating play 24
Playing tracks in a random order 25
Scanning folders and tracks 25
Pausing MP3/WMA playback 25
Selecting folders from the folder title list 26
Selecting the search method 26
Searching every 10 track in the current
folder 26
Switching the tag display 27
Using disc title functions 27
Bu lt- n MD Player
Playing an MD 28
Contents
En
2

Introduction of advanced built-in MD player
operation 29
Repeating play 29
Non group-recorded MD 29
Group-recorded MD 29
Playing tracks in a random order 29
Scanning tracks of a MD 30
Selecting tracks from the track title list 30
Selecting groups from the group title list 30
Pausing MD playback 31
Using disc title functions 31
Mult -CD Player
Playing a CD 32
50-disc multi-CD player 32
Selecting a disc directly 32
Introduction of advanced multi-CD player
operation 33
Repeating play 33
Playing tracks in a random order 33
Scanning CDs and tracks 34
Selecting tracks from the track title list 34
Selecting discs from the disc title list 34
Pausing CD playback 35
Using I S playlists 35
Creating a playlist with I S
programming 35
Playback from your I S playlist 36
Erasing a track from your I S
playlist 36
Erasing a CD from your I S
playlist 36
Entering disc titles 36
Using disc title functions 37
Using compression and bass emphasis 38
TV tuner
Using the V tuner 39
Introduction of advanced V tuner
operation 39
Storing and recalling broadcast stations 39
Selecting channels from the preset channel
list 40
DVD Player
Playing a disc 41
Introduction of advanced DVD player
operation 41
Repeating play 42
Playing tracks in a random order 42
Scanning tracks of a CD 42
Pausing disc playback 42
Using I S playlist, disc title input and disc
title list functions 42
Aud o Adjustments
Operation modes 43
Operation mode marks 43
3-way network mode 43
Standard mode 43
Adjusting the audio easily 43
Adjusting the audio finely 43
Extra functions 44
Introduction of audio adjustments 44
Using the position selector 44
Using balance adjustment 45
Using balance adjustment 45
Using the time alignment 45
Adjusting the time alignment 46
About the network function 47
Adjustable parameters 47
Points concerning network
adjustments 47
Muting the speaker unit (filter) 48
Adjusting network 48
Using subwoofer output 49
Adjusting subwoofer settings 49
Using the high pass filter 50
Setting the high pass filter for front
speakers 50
Setting the high pass filter for rear
speakers 50
En 3
English
Contents

Using the auto-equalizer 50
Recalling equalizer curves 50
Adjusting equalizer curves 51
Adjusting 13-band graphic equalizer 51
Using BBE sound 52
Adjusting BBE sound level 52
Adjusting loudness 52
Using sound field control and BBE sound
52
Recalling sound field programs 53
Adjusting BBE sound level 53
Using automatic sound levelizer 53
Adjusting source levels 53
Auto A and EQ (auto-time alignment and
auto-equalizing) 54
Before operating the auto A and EQ
function 54
Carrying out auto A and EQ 55
In t al Sett ngs
Adjusting initial settings 57
Using reverse mode 57
Using the feature demo 57
Switching the auxiliary setting 57
Selecting the digital attenuator 58
Switching the telephone muting/
attenuation 58
Setting the FM tuning step 58
Setting the AM tuning step 58
Other Funct ons
Attenuating volume 60
Displaying and setting the clock 60
urning the off clock display on or
off 60
Setting the date 60
Setting the clock 60
Matching the time to a time
signal 60
Setting the time signal display 61
Changing the display form 61
Adjusting the brightness 61
Switching the dimmer setting 61
Setting the flash light screen 61
Selecting the wall paper pattern 62
Switching the font 62
Using different entertainment displays 62
Setting the movie screen 62
Setting the level indicator display 62
Setting the ASL display 63
Setting the background visual 63
Setting the background still
picture 63
Canceling the entertainment
display 63
Using the AUX source 63
Selecting AUX as the source 63
Setting the AUX title 64
Add t onal Informat on
Understanding built-in CD player error
messages 65
Understanding built-in MD player error
messages 65
Understanding auto A and EQ error
messages 65
CD player and care 66
CD-R/CD-RW discs 67
MP3 and WMA files 67
MP3 additional information 68
WMA additional information 68
About folders and MP3/WMA files 68
MD player and care 69
DSP adjustment value record sheet 70
3-way network mode 70
Standard mode 70
Equalizer curves 70
erms 71
Specifications 72
Contents
En
4

About this manual
his unit features a number of sophisticated
functions ensuring superior reception and op-
eration. All the functions have been designed
for the easiest possible use, but many are not
self-explanatory. his operation manual will
help you benefit fully from this productspo-
tential and to maximize your listening enjoy-
ment.
We recommend that you familiarize yourself
with the functions and their operation by read-
ing through the manual before you begin
using this unit. It is especially important that
you read and observe precautions on this
page and in other sections.
Precautions
CAUTION:
USE OF CONT OL O ADJUSTMENT O
PE FO MANCE OF P OCEDU ES
OTHE THAN THOSE SPECIFIED HE EIN
MAY ESULT IN HAZA DOUS ADIATION
EXPOSU E.
CAUTION:
THE USE OF OPTICAL INST UMENTS
WITH THIS P ODUCT WILL INC EASE
EYE HAZA D.
!Keep this manual handy as a reference for
operating procedures and precautions.
!Always keep the volume low enough so you
can hear sounds outside of the car.
!Protect this product from moisture.
!If the battery is disconnected or dis-
charged, the preset memory will be erased
and must be reprogrammed.
!If this unit does not operate properly, con-
tact your dealer or nearest authorized Pio-
neer Service Station.
Features
CD playback
Music CD/CD-R/CD-RW playback is possible.
MP3 file playback
It is possible to play back MP3 files recorded
on CD-ROM/CD-R/CD-RW (ISO9660 Level 1/
Level 2 standard recordings).
!Supply of this product only conveys a li-
cense for private, non-commercial use and
does not convey a license nor imply any
right to use this product in any commercial
(i.e. revenue-generating) real time broad-
casting (terrestrial, satellite, cable and/or
any other media), broadcasting/streaming
via internet, intranets and/or other net-
works or in other electronic content distri-
bution systems, such as pay-audio or
audio-on-demand applications. An inde-
pendent license for such use is required.
For details, please visit
http://www.mp3licensing.com.
WMA file playback
It is possible to play back WMA files recorded
on CD-ROM/CD-R/CD-RW (ISO9660 Level 1/
Level 2 standard recordings).
Playback of MDs featuring long
recordings
his unit is MDLP compatible, so you can play-
back MDs featuring long recordings.
!MDLP is a data compression system that
lets you record on regular MDs for 2 or 4
times the length of time previously possi-
ble.
Group-recorded MD playback
Using a group-recorded MD, it is possible to
play back tracks by the desired group (albums,
artists, favorites, etc.).
Before ou Start
En 5
English
Section
01

About WMA
he Windows Media"logo printed on the box
indicates that this unit can playback the WMA
data.
WMA is short for Windows Media Audio and
refers to an audio compression technology
that is developed by Microsoft Corporation.
WMA data can be encoded by using Windows
Media Player version 7, 7.1 or Windows Media
Player for Windows XP.
Microsoft, Windows Media, and the Windows
logo are trademarks, or registered trademarks
of Microsoft Corporation in the United States
and/or other countries.
Notes
!With some applications used to encode WMA
files, this unit may not operate correctly.
!With some applications used to encode WMA
files, album names and other text information
may not be correctly displayed.
Switching the DSP setting
mode
his unit features two operation modes: the 3-
way network mode (NW) and the standard
mode (S D). You can switch between modes
as desired. Initially, the DSP setting is set to
the standard mode (S D).
!After switching, reset the microprocessor.
WARNING
Do not use the unit in standard mode when a
speaker system for 3-way network mode is con-
nected to this unit. his may cause damage to
the speakers.
%Use a thin standard tip screwdriver to
switch the DSP switch on the side of this
unit.
Resetting the microprocessor
he microprocessor must be reset under the
following conditions:
!Prior to using this unit for the first time
after installation
!If the unit fails to operate properly
!When strange or incorrect messages ap-
pear on the display
%Press RESET on the head unit with a
pen tip or other pointed instrument.
RESET button
Before ou Start
En
6
Section
01

About the demo mode
his unit features two demonstration modes.
One is the reverse mode, the other is the fea-
ture demo mode.
!When the source is off, you can check the
location of 5and 6by turning on the fea-
ture demo.
Important
he red lead (ACC) of this unit should be con-
nected to a terminal coupled with ignition switch
on/off operations. If this is not done, the vehicle
battery may be drained.
Reverse mode
If you do not perform an operation within
about 30 seconds, screen indications start to
reverse, and then continue reversing every 10
seconds. Pressing 5numbered button when
power to this unit is turned off while the igni-
tion switch is set to ACC or ON cancels the re-
verse mode. Pressing 5numbered button
again to start the reverse mode.
Feature demo
he feature demo automatically starts when
power to this unit is turned off while the igni-
tion switch is set to ACC or ON. Pressing 6
numbered button during feature demo opera-
tion cancels the feature demo mode. Pressing
6numbered button again to start the feature
mode. Remember that if the feature demo
continues operating when the car engine is
turned off, it may drain battery power.
About basic displays
his unit is equipped with three forms of basic
display. You can select the desired display.
FORM1
FORM
FORM3
Note
For details, refer to Changing the display form on
page 61.
Before ou Start
En 7
English
Section
01

SOFT KE operation
SOF KEY operation means that the function
of a button changes as indicated on the dis-
play. he multi-function buttons provide SOF
KEY operation; the functions performed by the
buttons change according to the function or
setting that has been selected.
Function names

Multi-function buttons
he explanations given in this manual are
based on FORM1 display. If you have selected
FORM or FORM3, the functions of some of
the multi-function buttons may be different
from those indicated in the manual.
Important
In this manual, for operations using the multi-
function buttons the function displayed is used
as the name of the function button.
Switching the function of the
multi-function buttons
he dindicator shows that the multi-function
buttons have functions other than those cur-
rently displayed. When this indicator is visible,
press NEXT to switch through the functions of
the multi-function buttons.
%Press NEXT to display the desired func-
tions (e.g., built-in CD player).
Press NEXT repeatedly to switch between the
following functions:
Notes
!he number of functions or displays switched
through will differ according to the source or
menu selected.
!When no function is indicated for a button,
that button is not currently active.
Example of multi-function
button operation
Here the random play function of the built-in
CD player is used as an example to illustrate
operation of the multi-function buttons.
1 Press NEXT to display FUNC.
Press NEXT until FUNC appears.
Press FUNC to enter the function menu.
With the switch to the function menu, the
functions of the multi-function buttons also
change simultaneously.
3 Press RDM to select the random mode.
4 Press RDM to turn random play on.
he light illuminates.
#Press RDM again to turn random play off. he
light goes off.
Before ou Start
En
8
Section
01

5 Press BACK to exit the function menu.
When the function menu is exited, the func-
tions of the multi-function buttons also
change simultaneously.
Notes
!You can also turn random play on or off by
pressing aor bin the random mode.
!If you do not operate the function within about
30 seconds, the display is automatically re-
turned.
The difference between the BAND
button and the BACK button
BAND button
Pressing the BAND button immediately can-
cels the current menu or mode, and returns to
the basic displays.
!When the source is the tuner or television
and no menu or mode is selected, pressing
the BAND button has the effect of switch-
ing bands.
BACK button
Pressing the BACK button cancels the current
menu or mode and returns to the previously
selected menu or mode.
Before ou Start
En 9
English
Section
01

Display example (e.g., built-in CD player)
he number shows the current menu level.
Key guidance indicator
his units display features key guidance indi-
cators. hese light to indicate which of the a/
b/c/dbuttons you can use. When youre in
the function menu, audio menu or the other
menus, they also make it easy to see which a/
b/c/dbuttons you can use to switch func-
tions on or off, switch repeat selections and
perform other operations.
Key guidance indicators
Note
In this manual, operation for each mode is given
mainly in terms of the multi-function buttons.
However, in each mode, when the key guidance
indicators are lit it is also possible to use a/b/c/
dto operate the mode.
Setting the display angle
You can adjust front panel angle for easier op-
eration.
WARNING
!Do not use with the front panel left open. If
you do leave it open, it may result in injury in
the event of an accident.
Before ou Start
En
10
Section
01

!Be careful not to catch your finger in the front
panel when it is opening or closing.
%Press ANGLE to change the angle.
Each press of ANGLE changes the angle.
Notes
!While a disc is left partially inserted, you can-
not operate the angle.
!By pressing ANGLE and hold, you can open
or close the front panel.
Use and care of the remote
control
Installing the battery
Remove the cover on the back of the steering
remote control and insert the battery with the
plus (+) and minus () poles pointing in the
proper direction.
Replacing the battery
Remove the battery.
WARNING
Keep the battery out of the reach of children.
Should the battery be swallowed, immediately
consult a doctor.
CAUTION
!Use only one CR2032 (3 V) lithium battery.
!Remove the battery if the remote control is not
used for a month or longer.
!Do not recharge, disassemble, heat or dispose
of the battery in fire.
!Do not handle the battery with metallic tools.
!Do not store the battery with metallic materi-
als.
!In the event of battery leakage, wipe the re-
mote control completely clean and install a
new battery.
!When disposing of used batteries, please
comply with governmental regulations or en-
vironmental public institutions rules that
apply in your country/area.
Using the remote control
Important
!Do not operate this unit while manipulating
the steering wheel as it might result in a traffic
accident.
Before ou Start
En 11
English
Section
01

!If you have to operate this unit unavoidably
when driving, look ahead carefully to avoid the
risk of being involved in a traffic accident.
!If any of the following troubles occur, immedi-
ately stop using this unit and consult with the
dealer from whom you purchased it:
the unit is smoking.
the unit is emitting abnormal odor.
a foreign object has entered the unit.
liquid has been spilled on or into the unit.
If you continue to use this unit without finding
a remedy, the unit may be damaged badly, re-
sulting in a serious accident or fire.
!Do not leave this unit free (unattached) inside
the car. When the car stops or turns a curve,
the unit might drop on the floor. If the unit
rolls under the brake pedal, it might prevent
the driver from braking well, causing serious
trouble. Be sure to fix this unit to the steering
wheel.
!Do not disassemble or modify this unit. o do
so may cause a fault.
FUNCTION button and AUDIO button
Operation of the FUNCTION button and the
AUDIO button on the remote control differs
from the operation of the FUNC button and
the AUDIO button on the head unit. When op-
erating the head unit, use the FUNC button
and the AUDIO button to select the appropri-
ate menu, then use the multi-function buttons
to select the mode. When operating the re-
mote control, however, switch through the
modes as described below to select the mode.
FUNCTION button operation
%Press FUNCTION to select the desired
mode (e.g., built-in CD player).
Press FUNCTION repeatedly to switch be-
tween the following modes:
RPTRDMSCANT.LISTPAUSETTLin
R.SRCHT.READ
Note
Refer to Introduction of advanced built-in CD
player operation on page 20.
AUDIO button operation
%Press AUDIO to select the desired
mode.
Press AUDIO repeatedly to switch between
the following modes:
BALNWPOSIT.ALEQ 1EQ BBE
LOUDASLSLA
F/BLOUDSFCEQ 1EQ ASLPOSI
T.ALA.EQSW1SW HPF FHPF R
SLA
Note
Refer to Introduction of audio adjustments on
page 44.
Before ou Start
En
12
Section
01

Head unit
1ANGLE button
Press to change the display angle.
2Multi-function buttons
Change according to the funtion or setting
that has been selected.
3CD EJECT button
Press to eject a CD from your built-in CD
player.
4MD EJECT button
Press to eject a MD from your built-in MD
player.
5RESET button
Press to reset the microprocessor.
6NEXT button
Press to switch through the functions of
multi-function buttons.
7BACK button
Press to return to the previously mode.
8SOURCE selector
his unit is turned on by selecting a source.
When you press SOURCE, it extends out-
ward so that it becomes easier to turn. o re-
tract SOURCE, press it again. Rotate to
cycle through all of the available sources.
9a/b/c/dbuttons
Press to do manual seek tuning, fast for-
ward, reverse and track search controls.
Also used for controlling functions.
aVOLUME
When you press VOLUME, it extends out-
ward so that it becomes easier to turn. o re-
tract VOLUME, press it again. Rotate to
increase or decrease the volume.
bBAND button
Press to select among three FM and one
AM bands and cancel the control mode of
functions.
2
1
a
78b
4
5
3
6
9
Whats What
En 13
English
Section
02

Remote control
Operation is the same as when using the but-
ton on the head unit.
cATT button
Press to quickly lower the volume level, by
about 90%. Press once more to return to the
original volume level.
dVOLUME button
Press to increase or decrease the volume.
eFUNCTION button
Press to select functions.
fAUDIO button
Press to select various sound quality con-
trols.
gSOURCE button
his unit is turned on by selecting a source.
Press to cycle through all of the available
sources.
Note
If you press FUNCTION on the remote control
while pressing BAND on it, the remote control
will not function properly. o cancel this setting,
press AUDIO on the remote control while press-
ing BAND on it to return to the previous
setting.
d
c
f
e
g
9
b
Whats What
En
14
Section
02

Turning the unit on
%Rotate SOURCE on the head unit to
turn the unit on.
When you select a source the unit is turned
on.
#When using the remote control, press
SOURCE to turn the unit on.
Selecting a source
You can select a source you want to listen to.
o switch to the built-in CD player, load a CD
in this unit (refer to page 19). o switch to the
built-in MD player, load an MD in this unit
(refer to page 28).
%Rotate SOURCE on the head unit to se-
lect a source.
Rotate SOURCE repeatedly to switch between
the following sources:
TunerTelevisionDVD player/Multi-DVD
playerBuilt-in CD playerMulti-CD
playerBuilt-in MD playerExternal unit
1External unit AUXSources off
#When using the remote control, press
SOURCE repeatedly.
Notes
!In the following cases, the sound source will
not change:
When a unit corresponding to each source
is not connected to this unit.
When no disc is set in this unit.
When no disc is set in the DVD player.
When no magazine is set in the multi-CD
player.
When no magazine is set in the multi-DVD
player.
When the AUX (auxiliary input) is set to off
(refer to page 57).
!External unit refers to a Pioneer product (such
as one available in the future) that, although
incompatible as a source, enables control of
basic functions by this unit. wo external units
can be controlled by this unit. When two exter-
nal units are connected, the allocation of
them to external unit 1 or external unit 2 is
automatically set by this unit.
!When this units blue lead is connected to the
cars auto-antenna relay control terminal, the
cars antenna extends when this units se-
lected source is the tuner. o retract the anten-
na, switch to a source other than tuner.
Turning the unit off
%Rotate SOURCE on the head unit until
the unit turns off.
When using the remote control, press
SOURCE and hold until the unit turns off.
Power ON/OFF
En 15
English
Section
03

Listening to the radio
1234
5
FORM1
hese are the basic steps necessary to operate
the radio. More advanced tuner operation is
explained starting on this page.
Important
If you are using this unit in North, Central or
South America, reset the AM tuning step (see
Setting the AM tuning step on page 58).
1Band indicator
Shows which band the radio is tuned to, AM
or FM.
2LOC indicator
Shows when local seek tuning is on.
3Preset number indicator
Shows what preset has been selected.
4Stereo (5) indicator
Shows that the frequency selected is being
broadcast in stereo.
5Frequency indicator
Shows to which frequency the tuner is
tuned.
1 Rotate SOURCE to select the tuner.
Rotate SOURCE until you see Tuner displayed.
Use VOLUME to adjust the sound level.
Rotate to increase or decrease the volume.
3 Press BAND to select a band.
Press BAND until the desired band is dis-
played, FM-1,FM- ,FM-3 for FM or AM.
4 To perform manual tuning, press cor
dwith quick presses.
he frequencies move up or down step by
step.
5 To perform seek tuning, press and hold
cor dfor about one second and release.
he tuner will scan the frequencies until a
broadcast strong enough for good reception is
found.
#You can cancel seek tuning by pressing either
cor dwith a quick press.
#If you press and hold cor dyou can skip
broadcasting stations. Seek tuning starts as soon
as you release the buttons.
Introduction of advanced
tuner operation
he tuner function menu has the following
functions:
BSM (best stations memory)chLIST (chan-
nel list)LOC (local seek tuning)
Note
If you do not operate the function within about 30
seconds, the display is automatically returned.
Tuner
En
16
Section
04

Storing and recalling
broadcast frequencies
If you press any of the preset tuning buttons
16you can easily store up to six broadcast
frequencies for later recall with the touch of a
button.
1 Press NEXT to display 16.
Press NEXT until 16appears in the display.
When you find a frequency that you
want to store in memory press a preset
tuning button 16 and hold until the preset
number stops flashing.
he number you have pressed will flash in the
preset number indicator and then remain lit.
he selected radio station frequency has been
stored in memory.
he next time you press the same preset tun-
ing button 16the radio station frequency is
recalled from memory.
Notes
!Up to 18 FM stations, 6 for each of the three
FM bands, and 6 AM stations can be stored in
memory.
!You can also use aand bto recall radio sta-
tion frequencies assigned to preset tuning
buttons 16.
Tuning in strong signals
Local seek tuning lets you tune in only those
radio stations with sufficiently strong signals
for good reception.
1 Press FUNC and then press LOC to select
the local mode.
Press LOC to set the local seek sensitiv-
ity.
Press LOC repeatedly to switch between the
following settings:
FM: Local OFFLevel 1Level Level 3
Level 4
AM: Local OFFLevel 1Level
he Level 4 setting allows reception of only
the strongest stations, while lower settings let
you receive progressively weaker stations.
Storing the strongest
broadcast frequencies
BSM (best stations memory) lets you automa-
tically store the six strongest broadcast fre-
quencies under preset tuning buttons 16and
once stored there you can tune in to those fre-
quencies with the touch of a button.
1 Press FUNC to select BSM mode.
Press BSM to turn BSM on.
Searching appears. he six strongest broad-
cast frequencies will be stored under preset
tuning buttons 16in order of their signal
strength.
When finished, Searching disappears and the
display switches to the preset channel list
mode.
#o cancel the storage process, press BSM
again.
Note
Storing broadcast frequencies with BSM may re-
place broadcast frequencies you have saved
using 16.
Tuner
En 17
English
Section
04

Selecting stations from the
preset channel list
he preset channel list lets you see the list of
preset stations and select one of them to re-
ceive.
1 Press FUNC and then press chLIST to se-
lect the preset channel list mode.
Press any of the buttons 16 to recall
the desired station frequency.
Note
You can also use c,dand ato select and recall
the desired station.
Tuner
En
18
Section
04

Playing a CD
12
FORM1
hese are the basic steps necessary to play a
CD with your built-in CD player. More ad-
vanced CD operation is explained starting on
the next page.
WARNING
Do not use with the front panel left open, after
ejecting a CD. If you do leave it open, it may result
in injury in the event of an accident.
1Play time indicator
Shows the elapsed playing time of the cur-
rent track.
2Track number indicator
Shows the track currently playing.
1 Press CD EJECT.
CD loading slot appears.
#After a CD has been inserted, rotate SOURCE
to select the built-in CD player.
Insert a CD into the CD loading slot.
Front panel is closed automatically, and play-
back will start.
CD loading slot
#You can eject a CD by pressing CD EJECT.
3 Use VOLUME to adjust the sound level.
Rotate to increase or decrease the volume.
4 To perform fast forward or reverse,
press and hold cor d.
#If you select the search method to
Rough search, pressing and holding cor den-
ables you to search every ten track in the current
disc. (Refer to Selecting the search method on
page 21.)
5 To skip back or forward to another
track, press cor d.
Pressing dskips to the start of the next track.
Pressing conce skips to the start of the cur-
rent track. Pressing again will skip to the pre-
vious track.
Notes
!he built-in CD player plays one, standard, 12-
cm or 8-cm (single) CD at a time. Do not use
an adapter when playing 8-cm CDs.
!Do not insert anything other than a CD into
the CD loading slot.
!A CD left partially inserted after ejection may
incur damage or fall out.
!If you cannot insert a disc completely or if
after you insert a disc the disc does not play,
check that the label side of the disc is up.
Press CD EJECT to eject the disc, and check
the disc for damage before inserting the disc
again.
!If the built-in CD player does not operate prop-
erly, an error message such as ERROR-11
may be displayed. Refer to nderstanding
built-in CD player error messages on page 65.
!When a CD EX disc is inserted, the disc and
track titles begin to scroll to the left auto-
matically.
Built-in CD Player
En 19
English
Section
05

Introduction of advanced
built-in CD player operation
he built-in CD player function menu has the
following functions:
RPT (repeat play)RDM (random play)
SCAN (scan play)T.LIST (track title list)
PAUSE (pause)TTLin (disc title input)
R.SRCH (search method)T.READ (tag dis-
play)
Notes
!If you do not operate the function within about
30 seconds, the display is automatically re-
turned.
(When you select the disc title input mode
(TTLin), the display is not returned automati-
cally.)
!T.LIST is displayed only when playing a CD
EX disc.
Repeating play
Repeat play lets you hear the same track over
again.
1 Press FUNC to select the repeat mode.
Press RPT to turn the repeat play on.
he light illuminates. he track currently play-
ing will play and then repeat.
#o turn repeat play off, press RPT again.
Notes
!If you perform track search or fast forward/re-
verse, repeat play is automatically cancelled.
!When the repeat mode is exited while repeat
play is on, T.RPT appears on the basic dis-
play.
Playing tracks in a random
order
Random play lets you play back tracks on the
CD in a random order.
1 Press FUNC and then press RDM to se-
lect the random mode.
Press RDM to turn random play on.
he light illuminates. racks will play in a ran-
dom order.
#o turn random play off, press RDM again.
Note
When the random mode is exited while random
play is on, RDM appears on the basic display.
Scanning tracks of a CD
Scan play lets you hear the first 10 seconds of
each track on the CD.
1 Press FUNC and then press SCAN to se-
lect the scan mode.
Press SCAN to turn scan play on.
he light illuminates. he first 10 seconds of
each track is played.
3 When you find the desired track press
SCAN to turn scan play off.
he light goes off. he track will continue to
play.
#If the scan mode is automatically canceled,
select the scan mode again.
Notes
!After scanning of a CD is finished, normal
playback of the tracks will begin again.
!When the scan mode is exited while scan play
is on, SCAN appears on the basic display.
Built-in CD Player
En
20
Section
05
