Pioneer DV-300-S User manual

ORDER NO.
PIONEER CORPORATION 4-1, Meguro 1-chome, Meguro-ku, Tokyo 153-8654, Japan
PIONEER ELECTRONICS (USA) INC. P.O. Box 1760, Long Beach, CA 90801-1760, U.S.A.
PIONEER EUROPE NV Haven 1087, Keetberglaan 1, 9120 Melsele, Belgium
PIONEER ELECTRONICS ASIACENTRE PTE. LTD. 253 Alexandra Road, #04-01, Singapore 159936
PIONEER CORPORATION 2007
TOP MENU MENU
RETURN
ENTER
HOME
MENU
OPEN/CLOSE
STANDBY/
ON
DV-300-S
RRV3561
DVD PLAYER
DV-300-S
DV-300-K
THIS MANUAL IS APPLICABLE TO THE FOLLOWING MODEL(S) AND TYPE(S).
Model Type Power Requirement Region No. Remarks
DV-300-S WYXZT5 AC220-240V 2
DV-300-S WYXZT/UR5 AC220-240V 5
DV-300-K WYXZT5 AC220-240V 2
DV-300-K WYXZT/UR5 AC220-240V 5
For details, refer to "Important Check Points for Good Servicing" .
T-ZZV FEB. 2007 printed in Japan

DV-300-S
2
1234
1234
C
D
F
A
B
E
SAFETY INFORMATION
This service manual is intended for qualified service technicians ; it is not meant for the casual do-
it-yourselfer. Qualified technicians have the necessary test equipment and tools, and have been
trainedto properly and safely repair complex products such as those covered by this manual.
Improperly performed repairs can adversely affect the safety and reliability of the product and
may void the warranty. If you are not qualified to perform the repair of this product properly and
safely, you should not risk trying to do so and refer the repair to a qualified service technician.
WARNING !
THE AEL (ACCESSIBLE EMISSION LEVEL) OF THE LASER POWER OUTPUT IS LESS THAN CLASS 1
BUT THE LASER COMPONENT IS CAPABLE OF EMITTING RADIATION EXCEEDING THE LIMIT FOR
CLASS 1.
A SPECIALLY INSTRUCTED PERSON SHOULD DO SERVICING OPERATION OF THE APPARATUS.
LASER DIODE CHARACTERISTICS
FOR DVD : MAXIMUM OUTPUT POWER : 5 mW
WAVELENGTH : 650 nm
FOR CD : MAXIMUM OUTPUT POWER : 5 mW
WAVELENGTH : 780 nm
Additional Laser Caution
∗: See page 16.
1.
• Laser diode is driving with Q2303,Q2305(650nm LD) and Q2302,
Q2304(780nm LD)on the DVD MT PCB Assy.
Therefore, when short-circuit between the emitter and collector of these
transistors or the base voltage is supplied for transistors turn on, the
laser oscillates. (failure mode)
• In the test mode ∗, there is the mode that the laser oscillates except
for the disc judgment and playback. LD ON mode in the test mode
oscillates with the laser forcibly.
2. When the cover is open, close viewing through the objective lens with
the naked eye will cause exposure to the laser beam.
LABEL CHECK
(Printed on the Rear Panel)
Location: inside of the unit
TOPMENUMENU
RETURN
ENTER
HOME
MENU
OPEN/CLOSE
STANDBY/
ON

DV-300-S 3
5678
5678
C
D
F
A
B
E
[Important Check Points for Good Servicing]
In this manual, procedures that must be performed during repairs are marked with the below symbol.
Please be sure to confirm and follow these procedures.
1. Product safety
Please conform to product regulations (such as safety and radiation regulations), and maintain a safe servicing environment by
following the safety instructions described in this manual.
1Use specified parts for repair.
Use genuine parts. Be sure to use important parts for safety.
2Do not perform modifications without proper instructions.
Please follow the specified safety methods when modification(addition/change of parts) is required due to interferences such as
radio/TV interference and foreign noise.
3Make sure the soldering of repaired locations is properly performed.
When you solder while repairing, please be sure that there are no cold solder and other debris.
Soldering should be finished with the proper quantity. (Refer to the example)
4Make sure the screws are tightly fastened.
Please be sure that all screws are fastened, and that there are no loose screws.
5Make sure each connectors are correctly inserted.
Please be sure that all connectors are inserted, and that there are no imperfect insertion.
6Make sure the wiring cables are set to their original state.
Please replace the wiring and cables to the original state after repairs.
In addition, be sure that there are no pinched wires, etc.
7Make sure screws and soldering scraps do not remain inside the product.
Please check that neither solder debris nor screws remain inside the product.
8There should be no semi-broken wires, scratches, melting, etc. on the coating of the power cord.
Damaged power cords may lead to fire accidents, so please be sure that there are no damages.
If you find a damaged power cord, please exchange it with a suitable one.
9There should be no spark traces or similar marks on the power plug.
When spark traces or similar marks are found on the power supply plug, please check the connection and advise on secure
connections and suitable usage. Please exchange the power cord if necessary.
0Safe environment should be secured during servicing.
When you perform repairs, please pay attention to static electricity, furniture, household articles, etc. in order to prevent injuries.
Please pay attention to your surroundings and repair safely.
2. Adjustments
To keep the original performance of the products, optimum adjustments and confirmation of characteristics within specification.
Adjustments should be performed in accordance with the procedures/instructions described in this manual.
4. Cleaning
For parts that require cleaning, such as optical pickups, tape deck heads, lenses and mirrors used in projection monitors, proper
cleaning should be performed to restore their performances.
3. Lubricants, Glues, and Replacement parts
Use grease and adhesives that are equal to the specified substance.
Make sure the proper amount is applied.
5. Shipping mode and Shipping screws
To protect products from damages or failures during transit, the shipping mode should be set or the shipping screws should be
installed before shipment. Please be sure to follow this method especially if it is specified in this manual.

DV-300-S
4
1234
1234
C
D
F
A
B
E
NOTES ON USE
WHEN REPLACING DVD DECK
NOTES ON SOLDERING
• For environmental protection, lead-free solder is used on the printed circuit boards mounted in this unit.
Be sure to use lead-free solder and a soldering iron that can meet specifications for use with lead-free solders for repairs
accompanied by reworking of soldering.
• Compared with conventional eutectic solders, lead-free solders have higher melting points, by approximately 40 ºC.
Therefore, for lead-free soldering, the tip temperature of a soldering iron must be set to around 373 ºC in general, although
the temperature depends on the heat capacity of the PC board on which reworking is required and the weight of the tip of
the soldering iron.
Compared with eutectic solders, lead-free solders have higher bond strengths but slower wetting times and higher melting
temperatures (hard to melt/easy to harden).
The following lead-free solders are available as service parts:
• Parts numbers of lead-free solder:
GYP1006 1.0 in dia.
GYP1007 0.6 in dia.
GYP1008 0.3 in dia.
NOTES ON SOLDERING
• For environmental protection, lead-free solder is used on the printed circuit boards mounted in this unit.
Be sure to use lead-free solder and a soldering iron that can meet specifications for use with lead-free solders for repairs
accompanied by reworking of soldering.
• Compared with conventional eutectic solders, lead-free solders have higher melting points, by approximately 40 ºC.
Therefore, for lead-free soldering, the tip temperature of a soldering iron must be set to around 373 ºC in general, although
the temperature depends on the heat capacity of the PC board on which reworking is required and the weight of the tip of
the soldering iron.
Compared with eutectic solders, lead-free solders have higher bond strengths but slower wetting times and higher melting
temperatures (hard to melt/easy to harden).
The following lead-free solders are available as service parts:
• Parts numbers of lead-free solder:
GYP1006 1.0 in dia.
GYP1007 0.6 in dia.
GYP1008 0.3 in dia.
Before removing Pick Up PCB and DVD PCB connector, short circuit the position shown in Fig. 1 using
a soldering iron. If you remove the DVD Deck with no soldering, the Laser may be damaged.
WHEN REPLACING DVD DECK
[ Removing the DVD Deck ]
[ Installing the DVD Deck ]
Remove all the soldering on the short circuit position after the connection of Pick Up PCB and DVD
PCB connector.
NOTE
Fig. 1
Before your operation, please read “PREPARATION OF SERVICING” .
Use the Lead Free solder.
Manual soldering conditions
• Soldering temperature: 320 ±20˚C
• Soldering time: Within 3 seconds
• Soldering combination: Sn-3.0Ag-0.5Cu
When Soldering/Removing of solder, use the draw in equipment over the Pick Up Unit to prevent the
Flux smoke from it.
•
•
•
•
Short circuit using a
soldering iron.
Pick Up PCB

DV-300-S 5
5678
5678
C
D
F
A
B
E
DISC REMOVAL METHOD
The laser diode used for a pickup head may be destroyed with external static electricity.
Moreover, even if it is operating normally after repair, when static electricity discharge is
received at the time of repair, the life of the product may be shortened.
Please perform the following measure against static electricity, be careful of destruction of a
laser diode at the time of repair.
• Place the unit on a workstation equipped to protect against static electricity, such as
conductive mat.
• Soldering iron with ground wire or ceramic type is used.
• A worker needs to use a ground conductive wrist strap for body.
PREPARATION OF SERVICING
If the stored 4 digit password in the Rating Level menu needs to be cancelled, please follow the steps
below.
Set the DVD to the Stand-by Mode.
Press and hold the 'STOP' key on the front panel.
Simultaneously press and hold the POWER key on the front panel.
The 4 digit password has now been cleared.
1.
2.
3.
4.
PARENTAL CONTROL - RATING LEVEL
4 DIGIT PASSWORD CANCELLATION
NOTE: The above procedure will reset ALL of the player's settings to the default factory state.
Slide the Rack Loading (White) toward the arrow direction by using a minus driver to release the lock.
(Refer to Fig. 1)
Manually open the Tray.
Please strongly pushing Rack Loading (White) to release the lock because the tray doesn't go out
easily.
1.
2.
Fig. 1
Rack Loading (White)
DVD Player (Bottom Side)
NOTE:
DISC REMOVAL METHOD AT NO POWER SUPPLY

DV-300-S
6
1234
1234
C
D
F
A
B
E
CONTENTS
SAFETY INFORMATION..................................................................................................................................... 2
NOTES ON USE.................................................................................................................................................. 4
WHEN REPLACING DVD DECK......................................................................................................................... 4
DISC REMOVAL METHOD ................................................................................................................................. 5
JIGS LIST ............................................................................................................................................................ 7
ACCESSORIES................................................................................................................................................... 7
1. BLOCK DIAGRAM ............................................................................................................................................ 8
1.1 OVERALL BLOCK DIAGRAM.................................................................................................................... 8
1.2 DVD LOADER BLOCK DIAGRAM ............................................................................................................. 9
1.3 POWER BLOCK DIAGRAM..................................................................................................................... 10
2. DIAGNOSIS .................................................................................................................................................... 11
2.1 TROUBLE SHOOTING ............................................................................................................................ 11
2.2 METHOD FOR DIAGNOSING DEGRADATION OF THE LDS ON THE PICKUP ASSY......................... 15
3. TEST MODE ................................................................................................................................................... 16
3.1 TEST MODE PROCEDURE .................................................................................................................... 16
3.2 TEST MODE IN........................................................................................................................................ 17
3.3 DISPLAY SPECIFICATION OF THE TEST MODE .................................................................................. 18
3.4 FUNCTIONAL SPECIFICATION OF THE SHORTCUT KEY................................................................... 19
3.5 FUNCTIONAL SPECIFICATION OF THE SERVICE MODE.................................................................... 20
4. DISASSEMBLY ............................................................................................................................................... 21
4.1 EXTERIOR SECTION.............................................................................................................................. 21
4.2 DVD DECK SECTION.............................................................................................................................. 22
5. EACH SETTING AND ADJUSTMENT ........................................................................................................... 26
5.1 PROCEDURES FOR UPDATING THE FIRMWARE................................................................................ 26
5.2 ADJUSTMENT......................................................................................................................................... 27
6. EXPLODED VIEWS AND PARTS LIST .......................................................................................................... 28
6.1 PACKING SECTION ................................................................................................................................ 28
6.2 EXTERIOR SECTION.............................................................................................................................. 30
6.3 06 DVD MECHA SECTION...................................................................................................................... 32
7. SPECIFICATIONS .......................................................................................................................................... 34
7.1 DISC/CONTENT FORMAT PLAYBACK COMPATIBILITY ....................................................................... 34
7.2 MAIN SPECIFICATIONS.......................................................................................................................... 36
7.3 FRONT PANEL SECTION ....................................................................................................................... 37
7.4 REMOTE CONTROL ............................................................................................................................... 38
8. SCHEMATIC DIAGRAM ................................................................................................................................. 40
8.1 OVERALL WIRING CONNECTION DIAGRAM........................................................................................ 40
8.2 DVD MT PCB ASSY (1/6) ........................................................................................................................ 42
8.3 DVD MT PCB ASSY(2/6) ......................................................................................................................... 44
8.4 DVD MT PCB ASSY(3/6) ......................................................................................................................... 46
8.5 DVD MT PCB ASSY(4/6) ......................................................................................................................... 48
8.6 DVD MT PCB ASSY(5/6) ......................................................................................................................... 50
8.7 DVD MT PCB ASSY(6/6) ......................................................................................................................... 52
8.8 OPERATION 1 and OPERATION 2 PCB ASSYS (WYXZT5 types)......................................................... 54
8.9 OPERATION 1 and OPERATION 2 PCB ASSYS (WYXZT/UR5 types) .................................................. 56
8.10 POWER PCB ASSY (1/2) ...................................................................................................................... 58
8.11 POWER PCB ASSY (2/2) ...................................................................................................................... 60
8.12 WAVE FORMS ....................................................................................................................................... 62
9. PCB CONNECTION DIAGRAM ..................................................................................................................... 64
9.1 DVD MT PCB ASSY................................................................................................................................. 65
9.2 OPERATION 1 PCB and OPERATION 2 PCB ASSYS (WYXZT5 types) ................................................ 67
9.3 OPERATION 1 PCB and OPERATION 2 PCB ASSYS (WYXZT/UR5 types) .......................................... 68
9.4 POWER PCB ASSY................................................................................................................................. 69
10. PCB PARTS LIST ......................................................................................................................................... 71
11. IC .................................................................................................................................................................. 72

DV-300-S 7
5678
5678
C
D
F
A
B
E
JIGS LIST
ACCESSORIES
Service Remote Control Unit GGF1381 diagnosis
Name Jig No. Remarks
DVD Test Disc (DVD- Video,NTSC)
GGV1025 Operation Check
DVD Test Disc (DVD-Video,PAL)
CD Test Disc
GGV-1101
STD-905
Operation Check
Operation Check
7Jigs list
Lubricants and Glues list
Cleaning
Daifree GEM1036 (ZLX-ME413A) Refer to "6.3 06 DVD MECHA SECTION"
Grease GYA1001 (ZLB-PN397B) Refer to "6.3 06 DVD MECHA SECTION"
Grease GEM1018 Refer to "6.3 06 DVD MECHA SECTION"
Name Lubricants and Glues No. RemarkName Lubricants and Glues No. Remark
• Before shipping out the product, be sure to clean the following positions by using the prescribed cleaning tools:
Pickup leneses Cleaning liquid : GEM1004
Cleaning paper : GED-008
Position to be cleaned Cleaning tools RemarkPosition to be cleaned Cleaning tools Remark
Accessories
• Remote control ×1
(07650KY070)
• Power cable ×1
(1206158802)
• Audio / Video cable(1.2m) ×1
(red/white/yellow)
(06CPBA2006)
• Dry cell batteries ×2
(AA/R6P) • Warranty Card
• Operating Instructions

DV-300-S
8
1234
1234
C
D
F
A
B
E
1. BLOCK DIAGRAM
1.1 OVERALL BLOCK DIAGRAM
P. CON+12V
AC220~240V
FLDC+/-
27MHz X4001
-28V AT+12V for mute AT+3.3V P. CON+6V P. CON+5V
POWER
SUPPLY
DVD
LOADER
(DM4)
MOTOR DRIVER
IC2301
AM5766
FIP DRIVER IC
IC651
PT6315
8K EEPROM
IC4002
S-24CS08AFJ-
TB-1GE
AUDIO AMP IC
IC8003
RC4580IDR
FIP
HNV-08SS44T
KEY
SERVO
RF
SERVO
IR
FP,STB
ASPDIF
RESET
AUDIO_L, AUDIO_R
AMP_AUDIO_L/R
LD_DVD, LD_CD
IR 108MHz
TV Encoder
MPEG-1/2/
JPEG
VIDEO
DECORDER
R
COAXIAL
RF
CO
L
OVERALL BLOCK DIAGRAM
IR RECEIVER
(OS651)
ROM-V340TAO
16Mbit FLASH
IC4004
ES29LV160EB-70TG
64Mbit(4Mx16) 143MHz
SDRAM
IC4005
HY57V641620ETP-7-C
SDA, SCL
AMUTE
MPEG/MICON BLOCK
IC4001
MT1389FE/E-L AUDIO CODEC/
INTERNAL DAC
+1.8V
A0~A20, AD0~AD7
MA0~MA11, DQ0~DQ15
RESET IC
IC4003
R3112N291A-
TR-FA
VIDEO DRIVER 6CH IC
IC7301
LA73054-TLM-E
4CH VIDEO DAC
V
CVBS
U
Y
4CH BUS SW IC
IC7302
SN74CBT3257PWR
21PIN
RGB OUT

DV-300-S 9
5678
5678
C
D
F
A
B
E
1.2 DVD LOADER BLOCK DIAGRAM
DVD LOADER/MPEG BLOCK DIAGRAM
DVD
Loader (DM-4)
MPEG/MICON IC
IC4001
MT1389FE/E-L
X4001
27MHz
IOA, V20
C
RF, A, B, C, D, E, F, MDI1
LD_DVD, LD_CD Q2302~2305
LD DRIVE
LDO1, LDO2
MOTOR DRIVER IC
IC2301
AM5766
DMSO, FMSO,
TROPEN, TRCLOSE,
TRSO, FOSO,
STBY, V1P4
T+/-, F+/-,
LOAD+/-,
MOT_SLED+/-,
MOT_SPDL+/-
OPU
SPINDLE/
STEPING/
SLED
MOTOR
LIMIT, TRIN, TROUT,
OPO, OP+/-
16Mbit FLASH
IC4004
ES29LV160EB-70TG
MA0~MA11, DQ0~DQ15, DQM0, DQM1, DBA0, DBA1, SDCLK, SDCKE, DWE#, DRAS#, DCAS#, DCS#
AUDIO AMP IC
IC8003
RC4580IDR
A
D
A0~A20, AD0~AD7,
PRD#, PCE#, PWR#
IC4005
HY57V641620ETP-7-C
A
3 2R
L
AUDIO JACK J8003
AUDIO R
AUDIO L
AUDIO L, R
F
A
A.......AT+3.3V B.......+1.8V C.......P.CON+5V D.......P.CON+6V E.......AT+12V F.......P.CON+12V G.......-28V H.......V+5H
EEPROM IC
IC4002
S-24CS08AFJ-TB-
1GE
SCL
A
SDA
RESET IC
IC4003
R3112N291A-
TR-FA
A
RESET
ASPDIF 2
COAXIAL JACK J8001
VIDEO DRIVER 6CH IC
IC7301
LA73054-TLM-E
LETTER, I/XP,
R/CR, B/CB, G/Y, C/V C
IR
IR RECEIVER (OS651)
ROM-V340TAO
IR A
A, B
GR1~GR8, P1~P16
FP_DI, FP_DO, FP_SCK, STB FIP DRIVER IC
IC651
PT6315
A
3 5Y
U
CVBS/Y/U/V J7302
2V
FIP (V651)
HNV-08SS44T
G
19 CVBS
21PIN CONNECTOR
J8101
11
15 R OUT
G OUT
16
7B OUT 3L
4CH BUS SW IC
IC7302
SN74CBT3257PWR
D
SQUEEZE, VSEL1
VSEL1
6CVBS
CR OUT
Y OUT
CB OUT
CR OUT
1R 8
VSEL1
SQUEEZE
21 PIN CTL
BLANKING_OUT
Q8101, Q8102
21 PIN CTL
Q8104, Q8105
DVD_RGB_H_OUT
64Mbit(4Mx16) 143MHz
SDRAM

DV-300-S
10
1234
1234
C
D
F
A
B
E
1.3 POWER BLOCK DIAGRAM
SWITCHING
TRANS
T501
P.CON SW
POWER BLOCK DIAGRAM
Q505
AC IN
P.CON+5V
AT+3.3V
FL DC -
-28V
AT+12V for mute
P.CON+6V
P.CON+12V
P.ON-H
FL DC +
Q515
P.CON +5V SW
Q510
P.CON +12V SW
Q504
FL+ P.CON SW
Q502
-28V P.CON SW
VOLTAGE CTL
IC501
KIA431A-AT
PHOTO COUPLER
IC504
PS2561AL1-1-V (W)
POWER CTL
IC502
STR-A6151M
(DVD MOTOR)
6V REG
IC503
PQ070XF01SZH
REG+1.8V
IC4006
LM1117S-ADJ +1.8V

DV-300-S 11
5678
5678
C
D
F
A
B
E
2. DIAGNOSIS
2.1 TROUBLE SHOOTING
POWER DOES NOT TURN ON
Is the voltage at
pin 8 and pin 9 of CP502 about 3.3V
and at pin 5 of CP502
about 5V?
No
Yes
No
Is there waveform at
X4001 about 3.0Vp-p ?
Check X4001, IC4001 and
peripheral circuit.
Yes
Write DVD FIRMWARE DATA.
Check AT+3.3V line of POWER BLOCK.
Check Q515 and peripheral circuit.
No
Yes
No
DECK DOES NOT ACCEPT
OPEN/CLOSE
Check P.CON 6V line of
POWER BLOCK.
Yes
Is the lose connection
at CD2302 to DECK ?
Check CD2302
connection to DECK.
Change DVD LOADER.
Is the voltage at
pin 8 and 19 of IC2301
about DC6V ?

DV-300-S
12
1234
1234
C
D
F
A
B
E
DOES NOT LIGHT ON DISPLAY
Yes
Is the voltage at
pin 13 and pin 43 of IC651
about 3V ?
Check AT+3.3V line of
POWER BLOCK.
No
Replace V651 or IC651.
NO PLAYBACK PICTURE OF AV
JACK
Is there
video signal at pin 33
of IC7301 ?
Change IC7301.
No
Yes
No
Yes
Check J7302 and peripheral
circuit.
Is there
a signal at pin 164 of
IC4001 ?
Check IC4001 and
peripheral circuit.

DV-300-S 13
5678
5678
C
D
F
A
B
E
NO DIGITAL AUDIO ON
PLAYBACK OF COAXIAL JACK
Is there
waveform at pin 2 of J8001
about 0.3Vp-p?
Check connection at RCA
Cable.
Yes
Yes
No
No
Change IC4001.
Is there
waveform at pin 159 of IC4001
about 0.3Vp-p ?
Check Q8005 and
peripheral circuit.
NO ANALOG AUDIO ON
PLAYBACK
Is there
AUDIO signal at pins 1 and 7
of IC8003 ?
Yes
Is there
AUDIO signal at C8051
and C8053 ?
No
Check J8003 and peripheral
circuit.
Yes
No
Check AT pins 184 and
186 of IC4001.
Change IC8003.

DV-300-S
14
1234
1234
C
D
F
A
B
E
Symptoms That May Occur When Any Of The Following ICs Is In Failure
IC Symptoms
EEPROM
(DVD MT PCB Assy : IC4002)
User's data cannot be stored in memory.
The ID number is lost.
16M Flash ROM
(DVD MT PCB Assy : IC4004)
The power cannot be turned on.
Downloading of the firmware cannot be performed.
DVD IC
(DVD MT PCB Assy : IC4001)
Any kind of symptoms (no power, a failure in any of the servo, video and audio systems, etc.) may be
generated, because the DVD processing is performed by a single chip.
64M SDRAM
(DVD MT PCB Assy : IC4005)
No power.
Block noise is generated during playback.

DV-300-S 15
5678
5678
C
D
F
A
B
E
2.2
METHOD FOR DIAGNOSING DEGRADATION OF THE LDS ON THE PICKUP ASSY
C2317_1
W820
Q2307
Q2306
R2316
W805
W806
C2307
C2312 C2311
R2310
W802
R2313 R2312
R2304
R2327 R2318
R2317
R2311
C2306
IC2301
C4116
C
4
006
C4096
C4095
C4094
R4013
R4015
C4089 C4090
C2301
CP2301
CP2303
C
P2302
C2321
C2320
R2309
R4009
R2306
R4006
R2307
R4007
R2323
R2321
R2320
R2322
R4010
R2338
R2331
R2319
R2329
Q2303
Q2304
Q2301
Q2305
Q2302
Case when this diagnosis is required :
When playback of any disc, including a test disc (DVD: GGV1025, CD: STD-905), cannot be performed
How to diagnose
In the case mentioned above, degradation of the laser diodes (LDs) mounted on the PICKUP Assy is suspected.
Measure the voltage between the two ends of one of the resistors mentioned below.
Measure the voltage between the two ends of R2321 or R2323 on the DVDM
Assy. If the voltage is 0.4 V or higher, the 650-nm LD is degraded.
No playback of a DVD :
Measure the voltage between the two ends of R2320 or R2322 on the DVDM
Assy. If the voltage is 0.4 V or higher, the 780-nm LD is degraded.
No playback of a CD :
If the measurements show degradation
of an LD, replace the PICKUP Assy.
SIDE A
Front side
DVD MT PCB ASSY

DV-300-S
16
1234
1234
C
D
F
A
B
E
3. TEST MODE
3.1 TEST MODE PROCEDURE
POWER ON
DSC - &&&
GGF1381
Test mode
remote control
unit
GGF1381
Test mode
remote control
unit
<TRAY OPEN> <TRAY CLOSE>
OPEN/CLOSE
(Player)
OPEN/CLOSE
Press the play key
( ) of the normal
remote control unit.
(Player)
TEST MODE: PLAY
TEST MODE: OFF
An address is displayed
OR
ESC
<PLAY>
ESC TEST
CHECK
DVD, CD
DVD disc
POWER
ON
OFF
POWER
DISC SET
Notes:
• After going into test mode, if you play back the disc, "DISC-NON" is displayed.
• The video signal and the audio signal are outputted during the test mode.
• The SKIP key and the SCAN key are effective during the test mode.

DV-300-S 17
5678
5678
C
D
F
A
B
E
3.2 TEST MODE IN
Test Mode Functional Specification
1Test mode entry
In the power ON state, press the [ESC] (A8-5F) key and [TEST / RANDOM] (A8-5E) key in order of the Test mode remote control
unit.
• Light the all FL and LEDs.
• OSD displays test mode.
Note:
* When pressing the keys of something, the FL displays "NO DISC" and the LED lighting disappears.
2Release the Test mode
• Turn off the power.
• Press the [ESC] (A8-5F) key of the remote control unit.
3LD ON
DVD : Press the [TEST] (A8-5E) and [1] (A8-01) keys in order, and turn on the laser diode (650n).
CD : Press the [TEST] (A8-5E) and [4] (A8-04) keys in order, and turn on the laser diode (780n).

DV-300-S
18
1234
1234
C
D
F
A
B
E
3.3 DISPLAY SPECIFICATION OF THE TEST MODE
Character in bold : Item name
: Information display
1
5
6
10
11
8
9
3
2
12
15
13
14
1Address indication
The address being traced is displayed in number.
(as for the DVD, indication of decimal number is possible.)
DVD : ID indication (hexadecimal number, 8 digits)
[∗ ∗ ∗ ∗ ∗ ∗ ∗ ∗]
CD : ID indication [∗ ∗ ∗ ∗ ∗ ∗ ∗ ∗]
2Code indication of remote control unit [R – ∗ ∗ ∗ ∗]
In case of double code, display a 2nd code.
3Main unit keycode indication [K – ∗ ∗]
5Tracking status [TRKG – ∗ ∗ ∗]
Tracking on : [ON]
Tracking off : [OFF]
6Spindle status [SPDL – ∗ ∗ ∗]
[OFF], [CLV]
7Mechanism (loading) position value [M – ∗ ∗]
Unknown : [01] or [41]
Open state : [04]
Close state : [08]
During opening : [12]
During closing : [22]
8Slider position [S – ∗ ∗ ∗ ∗]
In Side Switch ON : [01]
In Side Switch OFF : [00]
9Output video system [V – ∗ ∗ ∗ ∗]
NTSC system : [NTSC]
PAL system : [PAL]
Automatic setting : [AUTO]
Scart terminal output [SK – ∗ ∗]
(Display only the WY model which can do the output setting
of scart terminal.)
VIDEO : [00]
S-VIDEO : [01]
RGB : [02]
0Disc sensing [DSC – ∗ ∗ ∗]
The type of discs loaded is displayed.
[DVD], [CD ], [VCD], [ ]
-Jitter value [J – ∗ ∗ ∗ ∗] Note:Don't use it.
=Version of the FL controller [FL: ∗ ∗ ∗ ∗]
~Region setting of the player [REG: ∗]
Setting value : [1] to [6]
!Destination setting of the FL controller
[MDL: ∗ ∗ ∗ ∗ / ∗ ∗ ∗]
Four characters in the front represent code 01.
Three characters in the back represent the destination code.
J: /J, K: /KU, /KC, /KU/KC, R: /RL/RD, RAM : /RAM,
LB: /LB, WY: /WY
@Version of the flash ROM [VERSION: ∗∗∗∗∗∗∗∗]
7

DV-300-S 19
5678
5678
C
D
F
A
B
E
3.4 FUNCTIONAL SPECIFICATION OF THE SHORTCUT KEY
• Service mode indication (ESC + CHP/TIM keys)
ID Address
The error rate is always displayed in exponential notation, e.g., ∗.∗∗e - ∗, for both DVDs and CDs.
EDC/ID/AV 1 error history (ID Address, EDC/ID Error, last eight errors)
• Calculation of the average error rate (ESC + "5" [Test mode remote control unit] keys)
The average of the last eight error rates is calculated and indicated in exponential notation. After the calculation is completed, "OK" or "NG" is
displayed. If "NG" is displayed, the disc tray will open (for both DVDs and CDs)
For DVDs: OK with 5.0e-4 or less, for CDs: OK with 7.6e-3 or less
• Indication of model information (ESC + CHAP keys)
The items from 12 to 15 of the TEST MODE Indications are displayed. However, in the indications, S in the standard test mode is changed to
CHIP VERSION, and M is changed to FL VERSION. For details, see 7.1.3.
• Region confirmation mode (ESC + A.MON [Test mode remote control unit] + "1"-"8" [Test mode remote control unit] keys)
After you press the A.MON key while holding the ESC key pressed and then input the region number, if the number is different from that set in
the unit, an error message is displayed, and the tray opens.
Command Contents Conditions Remote Control
Key Name
Remote
Control Code
Memory clear and region / revision indication CLEAR (∗1) A8-45
Average value measurement of DVD error rate 5 (∗1) A8-05
CD error rate measurement 5 (∗1) A8-05
Scart terminal output : VIDEO
WY, models equipped with Scart terminal
AUDIO AF-BE
Scart terminal output : S-VIDEO SUBTITLE AF-36
Scart terminal output : RGB ANGLE AF-B5
Progressive OFF Only for progressive models R_SKIP A3-9D
Progressive ON F_SKIP A3-9C
ZOOM ON (X2 -> X4 -> x1) ZOOM AF-37
Service mode indication (error rate indication, etc.) CHP/TIM (∗1) A8-13
Model information indication CHAP (∗1) A8-40
Title search Input mode IN
Title No. input
Search execution
SIDE A (∗1)
Numbers (∗1)
PLAY (∗1)
A8-4D
A8-00 to A8-09
A8-17
Region confimation mode A.MON (∗1)
Numbers (∗1)
A8-1E
A8-01 to A8-08
Only during normal playback, the following shortcut keys can be assigned by pressing a required key after pressing the ESC
key of the remote control unit. To quit, press the ESC key
∗1 : Test mode remote control unit

DV-300-S
20
1234
1234
C
D
F
A
B
E
3.5 FUNCTIONAL SPECIFICATION OF THE SERVICE MODE
• Display during Service Mode
To enter Service Mode, press the CHP/TIM key while holding the ESC key pressed.
To quit, press the ESC key.
Service mode display
1ID Address
2Error rate (always displayed), in exponential notation
ERROR RATE : ∗∗ ∗ ∗ ∗ ∗ ∗
( ∗∗∗∗)
•Calculation of the average error rate
For DVDs: OK with 5.0e-4 or less, for CDs: OK with 7.6e-3 or less
3EDC/ID error history (ID Address, EDC/ID errors, last eight errors)
Note:
∗ Error of AV1 is not supported in this player.
Number of error
Indication plan contents
Character in bold : Item name
: Information display
1
2
3
ex) For DVDs
•Step 1
%%e -&
%%e -6 : OK
%%e -5 : OK
%%e -4 : Refer to Step 2
%%e -3 : NG
%%e -2 : NG
•Step 2
%%e -4
3.0e -4 : OK
4.0e -4 : OK
5.0e -4 : OK
6.0e -4 : NG
7.0e -4 : NG
