COLOR LCD DISPLAY

Service

Manual

AVD-W6000/UC

AVD-W6000 UC

AVD-W6000 EW

CONTENTS

1. SAFETY INFORMATION ............................................2

2. EXPLODED VIEWS AND PARTS LIST.......................2

3. BLOCK DIAGRAM AND SCHEMATIC DIAGRAM.....8

4. PCB CONNECTION DIAGRAM ................................30

5. ELECTRICAL PARTS LIST........................................39

6. ADJUSTMENT..........................................................48

7. GENERAL INFORMATION.......................................57

7.1 DIAGNOSIS ........................................................57

7.1.1 TEST MODE..............................................57

7.1.2 DISASSEMBLY .........................................59

7.1.3 CONNECTOR FUNCTION DESCRIPTION61

7.2 IC ........................................................................62

7.3 OPERATIONAL FLOW CHART...........................71

8. OPERATIONS AND SPECIFICATIONS....................73

-This product has the unit part numbers as below.

Unit Part No. (AVD-W6000/UC) Unit Part No. (AVD-W6000/EW) Description

CPN1733 CPN1754 Monitor Assy

CPN1734 CPN1755 Power Supply Assy

*) The unit part numbers listed above are not for the service components.
