Pioneer VSX-530-K User manual

ORDER NO.
PIONEER ELECTRONICS (USA) INC. P.O. Box 1760, Long Beach, CA 90801-1760, U.S.A.
PIONEER EUROPE NV Haven 1087, Keetberglaan 1, 9120 Melsele, Belgium
PIONEER ELECTRONICS ASIACENTRE PTE. LTD. 253 Alexandra Road, #04-01, Singapore 159936
2015
1-1, Shin-ogura, Saiwai-ku, Kawasaki-shi, Kanagawa 212-0031, Japan
2015 Printed in Japan
VSX-530-K
RRV4598
AV Receiver
VSX-530-K
VSX-430-K
THIS MANUAL IS APPLICABLE TO THE FOLLOWING MODEL(S) AND TYPE(S).
This service manual should be used together with the following manual(s).
For SPECIFICATIONS and PANEL FACILITIES, refer to the operating instructions.
Model Type Power Requirement Remarks
VSX-530-K CUXEVSM AC 120 V
VSX-430-K SYXEV8AC 220 V to 230 V
Model No. Order No. Remarks
VSX-523-K RRV4418VSX-523-K/CUXESM
K-ZZZ JULY

2VSX-530-K
12 3 4
A
B
C
D
E
F
12 3 4
1. EXPLODED VIEWS AND PARTS LIST
1.1 PACKING SECTION
NOTES:
-
Parts marked by “NSP” are generally unavailable because they are not in our Master Spare Parts List.
-
The >mark found on some component parts indicates the importance of the safety factor of the part.
Therefore, when replacing, be sure to use parts of identical designation.
-
Screws adjacent to bmark on product are used for disassembly.
-
For the applying amount of lubricants or glue, follow the instructions in this manual.
(In the case of no amount instructions, apply as you think it appropriate.)
Poly bagpackingstyle
Cord AC
Tape (clear)
Dry cell batteries
(AAA size IEC R03)
PE sheet
SPEAKER CAUTIONSheet
VSX-430-K/SYXEV8
only
Safety Brochure
1/2
2/2

3
VSX-530-K
56 7 8
56 7 8
A
B
C
D
E
F
(1) PACKING SECTION PARTS LIST
(2) CONTRAST TABLE
VSX-530-K/CUXEVSM and VSX-430-K/SYXEV8are constructed the same except for the following:
Mark No. Description Part No.
1 Remote control AXD7741
2 AM Loop Antenna E601019000010S
3 FM Wire Antenna E605010140010S
>4Power Cord See Contrast table (2)
5Quick Start Guide See Contrast table (2)
6
Operating Instructions (CD-ROM) See Contrast table (2)
7 Box, Gift See Contrast table (2)
8Cushion Snow423 6230213384100S
9 • • • • •
NSP 10 Warranty Card ARY7172
Mark No. Symbol and Description VSX-530-K
/CUXEVSM
VSX-430-K
/SYXEV8
>4Power Cord Not used L068250160070S
5Quick Start Guide 5707000010050S 5707000010060S
6 Operating Instructions (CD-ROM) 6517000002180S 6517000002190S
7 Box, Gift 60072125800F0S 60072125800G0S

4VSX-530-K
12 3 4
A B C D E F
12 3 4
1.2 EXTERIOR SECTION
CONTACT SIDE
NON-CONTACT
SIDE
I
L
A
G
F
B
E
K
J
D
H
Silicon grease
(GEM1057)
Silicon adhesive
(GYA1011)
C
MF
NF
Nut
Nut
HP plate
Clamp
Binder
Binder
×23
VSX-430-K/SYXEV8
only
VSX-530-K/CUXEVSM
only

5
VSX-530-K
56 7 8
56 7 8
A
B
C
D
E
F
(1) EXTERIOR SECTION PARTS LIST
(2) CONTRAST TABLE
VSX-530-K/CUXEVSM and VSX-430-K/SYXEV8are constructed the same except for the following:
Mark No. Description Part No.
1 MAIN Assy See Contrast table (2)
2 D-MAIN Assy 7028077971010
3 OPTCO Assy 7028077923010
4 FUSB Assy 7028077963010
5 CONCT Assy 7028077965010
6 CPU Assy See Contrast table (2)
7 AMP5 Assy 70280745410R0
8INSEL Assy 7028077964010
9 FRONT Assy See Contrast table (2)
10 HP Assy 7028077962010
>11 SMPS Assy See Contrast table (2)
12 REG Assy See Contrast table (2)
13 WG Assy 70280745420R0
14 G-L Assy 7028077925010
15 G-R Assy 7028077926010
16 NTC Assy 7028077924010
17 BT Assy 7028077941010
18Semi, TR/GE PNP 2SB J5011560Y0000S
19 Semi, TR/GE NPN 2SC J502396400010S
20 Semi, TR/GE NPN 2SD J5032390Y0000S
21 Cable, Flat Card 1.0 mm N711250822480S
22 Pioneer Badge B (PLS) XAM3006
23 Cabinet VSX-523 3008212076000V
24 Panel See Contrast table (2)
25 Back Chassis 530CU 3207215246000S
26 Spring 3720210556000S
27 Foot (PLS) 4000210391010S
28HS Bracket 4010056906010S
29 SMPS Bracket 401021488600DS
30 Cushion 4050211605000SV
31 SP ScrewCushion 4050211745100SV
32 PCB Support (ABS) 4070001601020S
33 Stopper See Contrast table (2)
34 Plate 4470212736000S
35 Window50772131130T0S
36 Knob5080212431000S
37 Standby Button 5090213741100S
385 Key Button 5090214561200S
39 10 Key Button 5090214571200S
40 Sheet 1210210235000SV
41 Screw1500001206020SV
42 ScrewBBT30P100FTB
43 Screw1500040083B10SV
44 ScrewBBZ30P080FTB
45 ScrewBBZ30P080FTC
46 ScrewBBZ30P180FTC
47 ScrewBSZ30P040FTB
48ScrewB018230141H11SV
49 ScrewB020230063B10-IL
50 ScrewB028940101B11-IL
51 Screw1500001206010SV
52 Screw1500001456010SV
53 ScrewSee Contrast table (2)
54 • • • • •
55 • • • • •
>56 Power Trans See Contrast table (2)
>57 Power Cord See Contrast table (2)
>58AC Inlet See Contrast table (2)
59 Sheet 1210210772100SV
60 Chassis See Contrast table (2)
61 Heatsink 2120212168010S
62 BT Cover 4310216061100S
Mark No. Description Part No.
Mark No. Symbol and Description VSX-530-K
/CUXEVSM
VSX-430-K
/SYXEV8
1 MAIN Assy 7028077921010 7028077921020
6 CPU Assy 7028077931010 7028077931020
9 FRONT Assy 7028077961010 7028077961020
>11 SMPS Assy 70280733610W0 70280733610Y0
12 REG Assy 7028077922010 7028077922020
24 Panel 3067215861010S 3067215861140S
33 Stopper 4380040162010S Not used
53 ScrewNot used CBZ30P080FTB
>56 Power Trans 8200960611680S 8200960611690S
>57 Power Cord L068125101710S Not used
>58AC Inlet Not used G430040807010S
60 Chassis 3200214556211S 3207215246100S

6VSX-530-K
12 3 4
A
B
C
D
E
F
12 3 4
2. CONTRAST OF MISCELLANEOUS PARTS
CONTRAST TABLE
VSX-523-K/CUXESM, VSX-530-K/CUXEVSM and VSX-430-K/SYXEV8are constructed the same except for the following:
Notes :For PCB ASSEMBLIES, Refer to "CONTRAST OF PCB ASSEMBLIES".
5 6 2 1
1 R 0
R 5 0
5 6 1
4 7 3
NOTES:
-
Parts marked by “NSP” are generally unavailable because they are not in our Master Spare Parts List.
-
The >mark found on some component parts indicates the importance of the safety factor of the part.
Therefore, when replacing, be sure to use parts of identical designation.
-
When ordering resistors, first convert resistance values into code form as shown in the following examples.
Ex.1 When there are 2 effective digits (any digit apart from 0), such as 560 ohm and 47 k ohm (tolerance is shown by J = 5%,
and K = 10%).
560 Ω→56 × 101→561 ...................................................................RD1/4PU J
47 kΩ→47 × 103→473 ...................................................................RD1/4PU J
0.5 Ω→R50 .................................................................................................RN2H K
1 Ω→1R0 .................................................................................................RS1P K
Ex.2 When there are 3 effective digits (such as in high precision metal film resistors).
5.62 kΩ→562 × 101→5621 .................................................................RN1/4PC F
Mark No. Symbol and Description VSX-523-K
/CUXESM
VSX-530-K
/CUXEVSM
VSX-430-K
/SYXEV8 Remarks
PCB ASSEMBLIES
NSP 1..PCB TTL ASSY MAIN 7025HK1211010-IL 7025HK1408010 7025HK1408020
No.1 2..MAIN ASSY 7028073311010-IL 7028077921010 7028077921020
No.12 2..REG ASSY 7028073312010-IL 7028077922010 7028077922020
No.3 2..OPTCO ASSY 7028073313010-IL 7028077923010 7028077923010
No.16 2..NTC ASSY Not used 7028077924010 7028077924010
No.13 2..WG ASSY 7028073315010-IL Not used Not used
No.14 2..G-L ASSY 7028073316010-IL 7028077925010 7028077925010
No.15 2..G-R ASSY 7028073317010-IL 7028077926010 7028077926010
NSP 1..PCB TTL ASSY FRONT 7025HK1211011-IL 7025HK1408011 7025HK1408021
No.9 2..FRONT ASSY 7028073321010-IL 7028077961010 7028077961020
No.10 2..HP ASSY Not used 7028077962010 7028077962010
No.10 2..HPMIC ASSY 7028073322010-IL Not used Not used
No.4 2..FUSB ASSY 7028073323010-IL 7028077963010 7028077963010
No.82..INSEL ASSY 7028073324010-IL 7028077964010 7028077964010
No.5 2..CONCT ASSY 7028073325010-IL 7028077965010 7028077965010
NSP 1..PCB TTL ASSY DMAIN 7025HK1211012-IL 7025HK1408012 7025HK1408022
No.2 2..D-MAIN ASSY 7028073351010-IL 7028077971010 7028077971010
NSP 1..PCB TTL ASSY CPU 7025HK1211013-IL 7025HK1408013 7025HK1408023
No.6 2..CPU ASSY 7028073331010-IL 7028077931010 7028077931020
NSP 1..PCB TTL ASSY AMP5 7025HK1211014-IL 7025HK1408014 7025HK1408024
No.7 2..AMP5 ASSY 7028073341010-IL 70280745410R0 70280745410R0
No.13 2..WG ASSY Not used 70280745420R0 70280745420R0
NSP 1..PCB TTL ASSY SMPS 7025HK1211015-IL 7025HK1408015 7025HK1408025
>No.11 2..SMPS ASSY 7028073361010-IL 70280733610W0 70280733610Y0
NSP 1..PCB TTL ASSY BT Not used 7025HK1408016 7025HK1408026
No.17 2..BT ASSY Not used 7028077941010 7028077941010
CONTRAST OF PCB ASSEMBLIES
C
F
OPTCO ASSY
Although 7028073313010-IL and 7028077923010 are different and are NOT COMPATIBLE! Some components on these
assy's are different. Since these different components are not available as service part, they are not listed.
D
F
FUSB ASSY
Although 7028073323010-IL and 7028077963010 are different and are NOT COMPATIBLE! Some components on these
assy's are different. Since these different components are not available as service part, they are not listed.

7
VSX-530-K
56 7 8
56 7 8
A
B
C
D
E
F
K
F
SMPS ASSY
Mark Symbol and Description 7028073361010-IL 70280733610W0 70280733610Y0
C112 Not used D041330088050S D041330088050S
R106 Not used C060012466050-IL C060012466050-IL
CN9100 CN, Wafer 7.92 mm L108396030010-IL L108396030010-IL Not used
7028073361010-IL, 70280733610W0 and 70280733610Y0 are constructed the same with the exception of some components,
including the following:
The mounting positions of the additional parts are described in the circuit diagram and PCB diagram of the parent manual.
Note: This list is not complete. Only components that are available as service part are listed!
L
F
REG ASSY
Although 7028073312010-IL, 7028077922010 and 7028077922020 are different and are NOT COMPATIBLE! Some
components on these assy's are different. Since these different components are not available as service part, they are not listed.
G-L, G-R and WG ASSEMBLIES
There is no service parts.
E
F
CONCT ASSY
H
F
INSEL ASSY
Although 7028073324010-IL and 7028077964010 are different and are NOT COMPATIBLE! Some components on these
assy's are different. Since these different components are not available as service part, they are not listed.
Mark Symbol and Description 7028073325010-IL 7028077965010
CN109 CN, Wafer L109012511520-IL L109012511540S
7028073325010-IL and 7028077965010 are constructed the same with the exception of some components, including the
following:
>
I
F
FRONT ASSY
Mark Symbol and Description 7028073321010-IL 7028077961010 7028077961020
D701, D702 K500052009011-IL Not used Not used
IC701 J127163150020-IL J127197044010-IL J127197044010-IL
S9701 SW, Encoder G121122400230-IL G121122400231S G121122400231S
R779, R780 C060001063050-IL C060001063050-IL C0602R2063050-IL
7028073321010-IL, 7028077961010 and 7028077961020 are constructed the same with the exception of some components,
including the following:
Note: This list is not complete. Only components that are available as service part are listed!
G
F
AMP5 ASSY
Mark Symbol and Description 7028073341010-IL 70280745410R0
Q452 J5000992FA050-IL J5001024Y0050-IL
Q1 J5001024Y0050-IL J5000992FA050-IL
7028073341010-IL and 70280745410R0 are constructed the same with the exception of some components, including the
following:
Note: This list is not complete. Only components that are available as service part are listed!
Note: This list is not complete. Only components that are available as service part are listed!
J
F
HPMIC ASSY / HP ASSY
Mark Symbol and Description 7028073322010-IL 7028077962010
JA702 Jack, D3.5 G40132340000Y-IL Not used
IC902 J121458001010-IL Not used
7028073322010-IL (HPMIC Assy) and 7028077962010 (HP Assy) are constructed the same with the exception of some
components, including the following:
Note: This list is not complete. Only components that are available as service part are listed!

8VSX-530-K
12 3 4
A
B
C
D
E
F
12 3 4
PCB PARTS LIST
• CONTRAST OF PCB ASSEMBLIES for VSX-530-K/CUXEVSM and VSX-430-K/SYXEV8
• PCB PARTS LIST
BT ASSY (7028077941010)
N
F
There is no service parts.
MAIN ASSY (7028077921010)
A
F
IC 401-403 J121458000050-IL
IC 1009 BD3473KS2-K
IC 1200 J127410500010-IL
Q 14,15 J522305200050-IL
Q 16 J520015301210-IL
>Q 17 J5000916Y0050-IL
Q 19,20 J522305200050-IL
>D 7 K047100600220-IL
>D 9400 K06606R84P430-IL
>D 9401 K06606R84P430-IL
A
F
MAIN ASSY
Mark Symbol and Description 7028077921010 7028077921020
601 Tuner, FM/AM E903004100781S E903104100781S
7028077921010 and 7028077921020 are constructed the same with the exception of some components, including the following:
Note: This list is not complete. Only components that are available as service part are listed!
F
F
CPU ASSY
Although 7028077931010 and 7028077931020 are different and are NOT COMPATIBLE! Some components on these assy's
are different. Since these different components are not available as service part, they are not listed.
Mark No. Description Part No.
SEMICONDUCTORS
D-MAIN ASSY (7028077971010)
B
F
>IC 2 J122214300010S
IC 1605,1606 J046205101010S
IC 1808 TC7WHU04FK-TRB
IC 1812 TC7SH08FUS1-TLB
IC 2004 NJM2831F33-TLB
IC 2005,2006
S-1170B50UC-OUJ-TRB
IC 2008 MM3529A32P-TRB
IC 2011 J080458800010-IL
IC 2014 J040742570040-IL
IC 2018 J001986466020S
IC 2022 J040741570110-IL
Q 2026,2040 J543608000010-IL
Mark No. Description Part No.
SEMICONDUCTORS
JA 1601,9601-9604 HDMI JACK AKP7286- -K
X 2002 CRYSTAL (24.576 MHz) E80024R576890S
X 2003 CRYSTAL (4 MHz) E80004R000990S
MISCELLANEOUS
CN 201 CN,WAFER L109012513340S
CN 203 CN,WAFER L109012511140S
CN 210 CN,WAFER L109012511340S
X 201 CRYSTAL (16 MHz) E80016R000890S
MISCELLANEOUS
CPU ASSY (7028077931010)
F
F
IC 204 J000241600170-IL
>IC 301 J126111733630S
SEMICONDUCTORS
NTC ASSY (7028077924010)
M
F
TH 80,81 THERMISTOR F340160801030S
MISCELLANEOUS
C 3042 D040102081060-IL
CAPACITORS
JA 101 TER,BOARD SCREW 4P G612405E0200Y-IL
JA 102 TER,BOARD PUSH 6P G596601SA010Y-IL
JA 401 TER,RCA 6PIN G603610A0001Y-IL
JA 402 TER,RCA 3PIN G606305AW140Y-IL
JA 403 TER,RCA 1PIN G600107A0000Y-IL
RY 2 RELAY G680060103010-IL
RY 3 RELAY G680060103010-IL
RY 4 RELAY G680060103010-IL
RY 5 RELAY G680240202080S
CN 9013,9016,9110 CN,WAFER L109012511540S
CN 9015 CN,WAFER L109012511340S
601 TUNER,FM/AM E903004100781S
MISCELLANEOUS
R 5,7,9,11,13,25 C060010065050-IL
R 6,8,10,12,14 C060010066050-IL
R 15,16 C060033166050-IL
R 64 C060022063050-IL
R 66 C0604R7065050-IL
R 588,589 C060010165060-IL
RESISTORS
C 55,58 D040682088010-IL
CAPACITORS

9
VSX-530-K
56 7 8
56 7 8
A
B
C
D
E
F
3. DIAGNOSIS
3.1 TROUBLESHOOTING
No Power
Other trouble.
Check D41, D103, T101, IC102 on
SMPS Assy or replace SMPS Assy.
AMP DC Protention works.
Disconnect speaker cables if you connect speakers.
(Prevention of Speaker destruction.)
Is Stand by?
(or ON→Stand by)
Is the error indicated?
(HDMI LED flashing?)
Does DC Protection work
when power ONagain?
Ye s
This is just for general reference and does not including every single case.
Ye s
Ye s
No
No
Replace SMPS Assy.
No
Check +5.6Vline on D-MAINAssy
or replace D-MAINAssy.
Cancel the DC detection. Refer to "6. [3] 3.4 How to
cancel the status after detection of the DC error".
Connect speakers, and check that sound output does
not have any problem.
No
Check IC301 on CPU Assy or
replace CPU Assy.
Replace CPU Assy.
No
Check cable connection between CX101 on SMPS Assy
and CN101 on D-MAINAssy. If it is OK, replace that cable.
No
Check connection betwwern CN201 on D-MAINAssy
and CN201 on CPU Assy.
No
No
Is the fuse (F100) open?
Is the voltage +5.6 V?
(SMPS Assy CX101
pins 5, 6, 7)(C129 +side)
Is the voltage +5.6 V?
(D-MAINAssy
CN101 pins 1, 2, 3)
Ye s
Ye s
Is the voltage +5.6 V?
(D-MAINAssy
CN201 pins 3, 4)
Ye s
Is the voltage +5.6 V?
(CPU Assy
CN201 pins 30, 31)
Is the voltage +3.3 V?
(CPU Assy
IC301 pin 2)
Ye s
Ye s
Refer to "5.3 [1] Overload and DC Protection Circuit",
Diagnosis AMP5 Assy and MAINAssy.
Ye s
No
No Power

10 VSX-530-K
12 3 4
A
B
C
D
E
F
12 3 4
No FL DISPLAY
Are the voltage 2.3 Vac to 2.5 Vac?
(FRONT Assy CP703 pins 1, 3)
This is just for general reference and does not including every single case.
Ye s
No
No
No
NoNoNo
NoReplace Power transformer.
Replace FLT701 or
replace FRONT Assy.
Check Q17, R64, R65, R66, D23,
ZD24, ZD25 on MAINAssy
or replace MAINAssy.
Check FLT701, R779, R780 or
replace FRONT Assy.
Ye s
Check L701, IC701 or
replace FRONT Assy.
No
No
Check Q702, Q703, R777, R778 or
replace FRONT Assy.
Replace CP16.
No
Is the voltage -30 V?
(FRONT Assy C728 - side)
Is the voltage 3.3 V?
(FRONT Assy C730 + side)
Are the voltage 2.28 Vac?
(FRONT Assy FLT701
pins 1, 2, 38, 39)
Are the voltage -30 V?
(FRONT Assy CN704A
pins 3, 4)
Are the voltage -30 V?
(CPU Assy CN704B
pins 3, 4)
Are the voltage -30 V?
(CPU Assy CN209A
pins 21, 22)
Are the voltage -30 V?
(MAINAssy CP16
pins 21, 22)
Is the voltage 2.27 Vac
to 2.28 Vac?
(Transformer orange wire)
Ye s
Replace FFC.
Replace FRONT Assy.
Replace FLT701.
Ye s
Ye s
Is damage in FLT701?
Ye s
Ye s
Replace CN209A or
replace CPU Assy.
Ye s
Ye s
No
No FL DISPLAY

11
VSX-530-K
56 7 8
56 7 8
A
B
C
D
E
F
A B C
No Sound
Phones
When connected phones,
is CN206 pin 4 (HP_DET)
low?
Is the voltage 0 to 12 V?
(MAINAssy R32)
Does the sound of speaker
front ch output?
Set "STEREO" mode with STANDARD
SURROUND key and speaker ON/OFF
with SPEAKERS key.
Is pin 18 voltage changing
from 3.3 Vto 2.23 V?
(FRONT Assy CP704A pin 18)
Change analog input signal to
another analog input (e.g VIDEO)
and select it.
Are the signal on AMP5 Assy
CP401 pin 1, 9?
Does HP OUTPUT signal
output?
(CPU Assy CN206 pin 1 or 3)
When connected phones,
does the relay change to phones?
(CPU Assy IC203 pin 24 0 →3.3 V)
This is just for general reference and does not including every single case.
Speaker front ch sound
Relay Control Check flow
No
No
NoReplace HP Assy.
Replace HP Assy.
No Problem / No Damage
Replace HP Assy.
Replacce Q12, Q5 on MAINAssy
or replace MAINAssy.
Check IC203 on CPU Assy
or replace CPU Assy.
No
No
NoNo
Replacce Q2, Q9 on MAINAssy
or replace MAINAssy.
Check and repair FL or FR AMP
circuit or replace AMP5 Assy.
No
Replace CPU Assy.
No
NoNoNo
Check connectors between FRONT
Assy CN106 and HP Assy CP104.
Replace CPU Assy.
No Problem / No Damage
Check connecters between CPU Assy
CN206 and FRONT Assy CN106.
Ye s
Ye s
Ye s
Ye s
Ye s
Ye s
Check the problem analog signal
line between input connector and
IC1009 (Input selector IC)
or replace MAINAssy.
Ye s
Ye s
Ye s
Ye s Ye s
No Sound
Is the voltage changing
3.3 Vto 2.23 V?
(CPU Assy CN704B pin 18)
Is the voltage 0 to 3.2 V?
(CPU Assy CN208 pin 6)
Is the voltage 0 to 12 V?
(MAINAssy R20)
Analog in (e.g. CD)
Pure Direct →
Speaker out sound
Are the signal on AMP5
Assy CP401 pin 1, 9?

12 VSX-530-K
12 3 4
A
B
C
D
E
F
12 3 4
D E
A B C
Check the voltage.
(MAINAssy CN8 pin 4: +12 V)
(MAINAssy CN8 pin 1: -12 V)
Check the voltage.
(MAINAssy CN8 pin 4: +12 V)
(MAINAssy CN8 pin 1: -12 V)
Are the signal on CONCT
Assy CN110 pin 9, 11?
Are the signal on CONCT
Assy CN109 pin 5, 7?
Are the signals on CONCT
Assy CN109 pin 1, 3?
Are the signals on MAIN
Assy CP110 pin 13, 15?
Is Digital signal from OPT
(or COAX) input OK?
INPUT?
No
Auto Surround
Check between MAINAssy CP110
and CONCT Assy CN110.
NoCheck the data signals at the following locations.
VOL_CLK pin 8, VOL_DATA pin 9, CN208 (CPU Assy) - CP15 (MAINAssy)
Check CP15 pin 8 (VOL_CLK),
pin 9 (VOL_DATA).
Repair IC1009 and its peripheral
circuit or replace MAINAssy.
Check and repair analog audio lines
between IC401 pin 31, 32 and CP110
pin13, 15 or replace MAINAssy.
NoNo
No
No
No
No
Is the digital signal
on D-MAINAssy
CP2008 pin 1?
No
No
No
No
No
Analog
input
Digital
input
Replace MAINAssy.
Replace CONCT Assy.
Replace CONCT Assy.
Replace OPTCO Assy.
No Problem / No Damage
Ye s
Ye s
Repair IC402, IC403 and its peripheral
circuit or replace MAINAssy.
Repair IC2011 (AK4588) and its
peripheral circuit or replace D-MAINAssy.
Check selection of speaker system
by [SPEAKERS] key on front panel
is correct.
Check signals of problem channel
on AMP5 Assy CP401 pin 3 (SL),
5(C), 7(SR).
Check signals of problem channel
on CONCT Assy CN110 pin 7 (SR),
5 (SL), 3 (C), 1 (SW).
NoNo
Check signals of problem channel
on CONCT Assy CN109 pin 9 (SR),
11 (SL),13 (C),15 (SW).
Check and repair AMP circuit of problem
channels or replace AMP5 Assy.
Check relay operating. (Refer to Relay
Control Check flow for Front ch.)
Ye s
Check signal line between
CN109 and CN110.
Ye s
Ye s
Ye s Ye s
Ye s
Repair IC2011 (AK4588) and its
peripheral circuit or replace D-MAINAssy.
Change speaker system to correct
setting.
Select surround mode to EX.STEREO
in Advanced Surround .
Check CPU Assy CN208 pin 4
(C_RLY) pin 5 (S_RLY).
No sound from Speaker System
is "SP: OFF" is selected,
Ye s
Ye s
Ye s
Ye s
Replace MAINAssy
or their peripheral circuit.
Ye s
Check the signal CN109 - CN110
or replace CONCT Assy.
Ye s
Check +/- 12 Vline on MAINAssy
or replace MAINAssy.
Ye s
Speaker C (SB etc) ch (Front LR is OK)

13
VSX-530-K
56 7 8
56 7 8
A
B
C
D
E
F
D E
Is Front L, R speaker output
sound OK?
Input PCM to COAX in or
OPT in, set Auto Surround
No
Repair IC2011 (AK4588) and its
peripheral circuit or replace D-MAINAssy.
No
Replace IC2021, IC1606 on D-MAIN
Assy or replace FUSB Assy.
No
Repair IC2011 (AK4588) and its
peripheral circuit or replace D-MAINAssy.
Check IC1200 on MAINAssy or
replace MAINAssy.
Repair IC2011 (AK4588) and its
peripheral circuit or replace D-MAINAssy.
Replace D-MAINAssy.
Replace PACK601 (Tuner Pack)
on MAINAssy.
Ye s
Ye s
Repaier or Replace D-MAINAssy.
Ye s
Tuner →(Other Analog OK)
USB in →
HDMI in on rear →
Composite in →No Composite out
Replace D-MAINAssy.
Rear HDMI in →No HDMI out
Is the voltage 5 V?
(D-MAINAssy CP2006 pin 1,
pin 3, 4 digital signal)
A sound not coming out only
in HDMI IN1 to IN4?
No Picture
This is just for general reference and does not including every single case.
No Picture

14 VSX-530-K
12 3 4
A B C D E F
12 3 4
3.2 PROTECTION CIRCUIT
[1] Overload and DC Protection Circuit
REG ASSY
L
F
AMP5 ASSY
G
F
MAIN ASSY
A
F
MAIN ASSY
A
F
CPU ASSY
F
F

15
VSX-530-K
56 7 8
56 7 8
A B C
D
E
F
[2] TEMP Protection Circuit
CPU ASSY
F
F
AMP5 ASSY
G
F
AMP5 ASSY
G
F
NTC ASSY
M
F
MAIN ASSY
A
F
97
71
34
GND5
MET37
R81
R80
D18
D9
Q20
Q19
TRANS_TEMP_DET
TRANS_TEMP_DET

16 VSX-530-K
12 3 4
A
B
C
D
E
F
12 3 4
3.3 PAIRING WITH THE UNIT (INITIAL REGISTRATION)
In order for the unit to playback music stored on a Bluetooth capable device, pairing must first be performed. Pairing should be
performed when first using the unit with the Bluetooth capable device, or when the pairing data on the device has been erased
for any reason.
Pairing is a step required to allow communication using Bluetooth wireless technology to be carried out.
• Pairing is only performed the first time that you use the unit and the Bluetooth capable device together.
• In order to allow communication using Bluetooth wireless technology to take place, pairing must be performed on both the
unit and the Bluetooth capable device.
• After pressing the BT and switching to BT Audio function, perform the pairing procedure on the Bluetooth capable device.
If pairing has been performed correctly, you will not need to perform the pairing procedures for the unit as shown below.
Please refer to the user’s manual for your Bluetooth capable device for more details.
1 Press the uRECEIVER and turn the power to the unit on.
2 Press the BT.
3 Turn on the power to the Bluetooth capable device that you wish to pair with, and perform pairingprocedure on it.
Note
• This unit will be displayed as “Pioneer AVR” on all Bluetooth capable devices that you have.
Pairing will start.
• Place the Bluetooth capable device close to the unit.
• Please refer to the user’s manual for your Bluetooth capable device for details on when pairing can be performed and the
procedures required for pairing.
• When PINcode entry is requested, enter “0000.” (This unit does not accept any PINcode setting other than “0000.”)
4 Confirm on the Bluetooth capable device that pairinghas been completed.
If pairing with the Bluetooth capable device has been completed correctly “CONNECT“ will be displayed.

17
VSX-530-K
56 7 8
56 7 8
A
B
C
D
E
F
4. EACH SETTING AND ADJUSTMENT
4.1 UPDATING OF THE FIRMWARE (IC3: SUB MICROCOMPUTER)
Rear side
[Preparations]
1. Install the software for updating on the PC.
2. Unplug the power cord of the main unit.
Connect the FFC of the updating jig for updating to the
main unit.
(Orient the FFC so that the conductive surface of the
connector faces the triangular asymbol.)
[Procedures]
To perform updating, proceed as follows:
1. Set the values for Target MCU and Crystal Frequency,
as follows:
Target MCU: MB9AF156M/N/R 1
Crystal Frequency: 4MHz 2
3. Start the software for updating on the PC.
4. Click on "Full Operation (D+E+B+P)"7.
5. After the window shown below is displayed, turn the
main unit on.
6. Press the Reset button of the updating jig for updating.
7. Click on "OK" 8.
3. Specify the COM PORT.
Click on "Set Environment" 4to open the
Environment Setting window.
Assign the COM PORT number 5, according to the
environment.
Click on "OK" 6to close the Environment Setting
window.
2. Specify the software file to be updated.
Click on "Open" 3 to open the File Selection window.
Select Intel Hex files (*.hex) in File Type.
• The updating jig (GGF1642) in this Section is the same as that used for updating of the MAINmicrocomputer of the base
model (VSX-523-K/CUXESM).
• The software for updating to be used on a PC is "FLASH MCU Programmer for FM0+/FM3/FM4."
Please download it from Service Website.
• The updating procedure for MAINmicrocomputer is same as the base model (VSX-523-K/CUXESM).
Please refer to the Service Manual (RRV4418) for VSX-523 regarding it.
1
2
3
4
7
8
5
6

18VSX-530-K
12 3 4
A
B
C
D
E
F
12 3 4
9. Updating has been successfully completed if "Full
Operation OK!" is displayed.
Note:
If an error message like the one shown below is displayed,
after checking the connection of the updating jig for updating
and the COM PORT setting, start updating again from Step 1.
10. Turn the main unit off then disconnect the updating jig
for updating.
11. Perform Factory Reset on the main unit.
8. The indications in the window change, as indicated
below:

19
VSX-530-K
56 7 8
56 7 8
A B C
D
E
F
5. SCHEMATIC DIAGRAM 5.1 MAIN ASSY (1/2)
IN1
IN2
-
H
-
10K
R39
R76
0
IN3 -H
C1 47N(EB)-100V
100N(R)-250V
C65
C53 100/25(6.3*11)
R69 15K R58 27K
100/10C99
GND4
TO CHASSIS
C27 1N-J
C29 1N-J
R31 22K
R26 22K
C102/C103 : SIZE 3*5
SW2SW1
L(OPEN)
H
H
MUTE
/RST
SCLK
VCC_5V
TU_R
INT
LUG707A
R25
10(1)
R36
47K(1/4) 47K(1/4)
R35
C26 1N-J
C28 1N-J
C30 1N-J
R27 22K
10
R32
2K2(1)
R30
RT1P237C
Q4
10
R22
10/50
C57
DZ1
LUDZS3.6B
2K2(1)
R28
10K
R40
RT1P237C
Q3
C59
10N-K
D8
LBAS16HT1G
R45
10K
51K
R49
C102
1/50(3*5)
4R7(1)
R66
C1206
100P-J
R1260
1K
R1259
470
100N-K
C1227
ZD25
ZJ16B
68K
R1258
LBAS16HT1G
D18
R54
100K
C1223
100N-K
C1209
47/16
C108 100N-K
R1256
0
L(OPEN)
C1232
10N-K
100/16(6.3*11)
C1233
H
/SEN
SDIO
GND
TU_L
100N-K
C612
NM
C635
NM
C613
4N7-K
C611L
10N-K
C609
C611R
4N7-K
C609R
10/50
NM
R636
NM
R635
BD3580
BD601
NM
R637
100N-K
C615
SP-2507
L2
C4
47N(EB)-100V
31 2 35328-0360
CP1 SP-2507
L3
R9
10(1)
C9
47N(EB)-100V
R10 10(2)
C61 100N(EB)-100V
R5
10(1)
L4
SP-2507
10(2)
R6
C12 47N(EB)-100V
C3
10N(EB)-100V
L5
SP-2507
R13
10(1)
C17
47N(EB)-100V
R14
10(2)
C8
10N(EB)-100V
C14
10N(EB)-100V
C11
10N(EB)-100V
R24 22K
R23 22K
RT1N237C
Q11
RT1N237C
Q10 RT1N237C
Q9
R64
22(1/4)
C101
330/63(12.5*20)
R51
51K
R65 10K
C104
100P/500V
C1204
100N-K
R1203
75-F
R78 NM R70 15K R79 NM
R60 27K
1/50(3*5)
C103 C1205
100N-K
R1257
68K
R77 10K
R74 10K
2N2-KC98
R53 33K
C1254
100N-K
D417
LBAS16HT1G
R1237
-
1 2 3 4 5 6 87 9
PACK 6 01
C608
100P 100P
C611
C617
100P
R84
0-1608
LBAS16HT1G
D5
LBAS16HT1G
D4
C105
330/6.3(6.3*11)
C616
10/50
MUTE
1K
R608R
L(OPEN)
L(OPEN)
NJM41050VT LOGIC TABLE
LUG707B
100N(EB)-100V
C64
1
2
35 4
5678910 432 1
CN3
CN1 CN5
CN8
CP16
CP15
CP13
C66 100N(R)-250V
C55
6800/63(30*40)
C67
100N(R)-250V
100N(R)-250V
C68
10K
R43
R20
10
10
R21
RT1P237C
Q5
2K2(1)
R29
2SC3052
Q19
C99 : SIZE 6.3*5
R59
10K
C100
10N-K
ZD24
ZJ16B R67
0
1000N-K
C1225
C1226
47/16
R1206
75-F
R1200
-
C607 10N-K
NM
C614
100P
C618
C636
NM
R638
NM-1608
C609L 10/50
R7
10(1)
SP-2507
L1
R8
10(2)
RLY2 JZC-42F JZC-42F
RLY3 C6
10N(EB)-100V
C-CAP:SYXEV8 : 22N
CUXEV :10N
C58
6800/63(30*40)
R11
10(1) R12
10(2)
RLY4 JZC-42F
C106
330/6.3(6.3*11)
RT1N237C
Q12
D9
LBAS16HT1G
Q20
2SC3052
1N4007
D23
R52
2K2
51K
R50
R1204
75-F
C1224
100N-K
D416
LBAS16HT1G
1KR608L
100P
C610
FROM MAIN TRANS
D2
LBAS16HT1G
D3
LBAS16HT1G
Q2
RT1P237C
0-1608
R82
0-1608
R83
SPEAKER TERMINAL MAIN ASSY
(VSX-530-K/CUXEVSM: 7028077921010)
(VSX-430-K/SYXEV8: 7028077921020)
AF 1/2 AF 1/2
AF 1/2
FF
CN211
LF
CP7
MF
CP5
GF 1/2
CP402
GF 1/2
CP403
FF
CN208
FF
CN209A
AF 2/2
: Audio Signal Route (Front L ch)
(FL)
: Audio Signal Route (Surround L ch)
(SL)
: Audio Signal Route (Center ch)
(C)
: Audio Signal Route (Headphone L ch)
(HPL)
: Video Signal Route
(FL)
(FL)(FL)
(FL)
(SL)
(SL)
(SL)
(SL)
(C)
(C)
(C)
(C)
(HPL)
(HPL)
5. SCHEMATIC DIAGRAM

20 VSX-530-K
12 3 4
A B C D E F
12 3 4
5.2 MAIN ASSY (2/2)
SR
C
R478 470K
C488 100N C483 100N
R515 3K9
FR
R504 0 R502 0 R500 0
470
R512
10/50
C541
J502 0
C469 0
R572 10K
R568 10K
100
R472
C517 33P-J
R562 -
C503
RT1P14 1C
SL
FL
C556
-
C540
220P-J
330
R590
C539
100P-J
330
R541
C505
220P-J
C504
100P-J
R532
330
330
R530
C497
220P-J
C496
100P-J
220P-J
C494
R521
330
C493
100P-J
C457
-
Q416
INC2001AC1
R470
0
R591
470K
R594
470K
C506 10/50
C542 10/50
R538
470K
10/50
C498
C499 10/50
R528
470K
C492 10/50
R523
470K
R463
10K
C476
-
J501 0
J500 0
INC2001AC1
Q417
R465
-
JP72
-
C529
10N-K
10N-K
C514
C519
33P-J
C522 33P-J
R469 100
R566 10K
R569 10K
C520 33P-J
R544
1K
R588
100(1)
R589
100(1)
R577 -
C528
10N-K
2SK209Y
10N-K
C515
C507
10/50
C547
330P-J
-
R479
NM
C558
470K
R477
D414
LBAS16HT1G
1K5
R554
R539
4K7
R540
4K7
2K2
R564
RT1P141C
Q426
10K
R613
RT1N441C
C475
10/50
R497
1K
C482 100N C487 100N C489 2N2 R505
6K8
R506
6K8
C474 100P-J
C485
10N-K
R518
0
C480
100P-J
J402 -
J417 -
R514
10K
470
R508
470K
R501
R444
1K5
R427
1K5
1K5
R415
R435
10K
R428
10K
R420
10K
R436
47K
R429
47K
R410
47K
R421
47K
C409
82P-J
C557
-
R593
330
C502
220P-J
C544
220P-J
C543
100P-J
C501
100P-J
-
C470
R461
100
R534
470K
1K
R462
C512
3N3-K
R549
100K
R561
10K
220/16(6.3*11)
C537 C538
220/16(6.3*11)
C546
330P-J
C473
10N-K-2012
C441
10N-K-2012
D415
LBAS16HT1G
680P-J
C511
R551
100K
R513 47K C481 1N-K
R503 0 R498 0 R499 0
470R511
100P-J
C477
0.22U/25VC478
C439
10/50
R404
1K5
R433
1K5
R448
10K
R409
10K
R449
47K
8
4
5
6
3
2
1
7
NJM4580CG
IC402
470K
R610
C464,C462 : SIZE 3*5
10/16C462
R574 10K
91K
R571
C516 : SIZE 3*5
R559 10K
C509 10/50
R507 1K5
GND
GND
C548
100N-K
R592
-
R595
-
R537
-
R527
--
R522
C465
100P-J
R468
10K
C472
-
R583 470K
470K
R609
470K
R582
10/16
C464
R467
47K
470K
R565
1/50
C516
10K
R573
R557 91K
10K
R560
C508 10N-K
C486
10/50
C484
47P-J
C479 2N2
C446
10/50
C420
10/50
C406
10/50
C563
-
C562
-
82P-J
C435
C561
-
82P-J
C419
Q406
INC2001AC1
INC2001AC1
Q405
C559
-
82P-J
C407
GND
GND
GND
C549
100N-K
R533
-
1K
R466
R576
10K
10/50
C460
Q427
RT1N441C
R542
0
R548
5K6
ZD400
LUDZS6.8B
C564
NM
ZD401
LUDZS6.8B
R517
0
C401
10/50
INC2001AC1
Q410
INC2001AC1
Q402
INC2001AC1
Q407
C560
-
82P-J
C426
8
4
5
6
3
2
1
7
IC403
NJM4580CG
D419 LBAS16HT1G
5
6 8
7
1
4 3
2
NJM4580CG
IC401
D418 LBAS16HT1G
Q419
RT1P141C
123456789101112
71
72
73
74
75
76
77
78
79
80
49 50 51 52 53 54 55 56 57 58 59 60
61
62
63
64
65
66
67
68
69
7031
32
33
34
35
36
37
38
39
40
41 42 43 44 45 46 47 48
1314151617181920
21
22
23
24
25
26
27
28
29
30 BD3473KS2
IC1009
COUT
SWOUT
SLOUT
1.SBLOUT
2.SBROUT
SROUT
FLOUT
FROUT
VEE
CLOCK
DATA
DGND
VCC
TNF1
BNF1
BOUT1 BOUT2
BNF2
19.TNF2
AGND2
20.AGND1
SBLIN1
SBRIN1
CIN1
SWIN1
SLIN1
SRIN1
FLIN1
FRIN1
AGND3
ADCL
ADCR
AGND4
SUB1R
SUB1L
AGND5
INR1
INR2
INL2
41.INR3
42.INL3
INR4 INR5 INR6 INR7 INR8 INR9
INR10 INR11
INL4 INL5 INL6 INL7 INL8 INL9
INL10
AGND6
INR12/FRIN2
58.INL11 60.INL12
59.INR12
INL13/FLIN2
INR14/SRIN2
INL14/SLIN2
INR15/SWIN2
INL15/CIN2
INR16/SBRIN2
INL16/SBLIN2
AGND7
INL17/RECL1
INR17/RECR1
INR18/RECR2
INR18/RECL2
RECR3
RECL3
RECR4/SUB2R
RECL4/SUB2L
AGND8
AGND9
INL1
MAIN ASSY
(VSX-530-K/CUXEVSM: 7028077921010)
(VSX-430-K/SYXEV8: 7028077921020)
AF 2/2 AF 2/2
AF 2/2
AF 1/2
AF 1/2 AF 1/2
GF 1/2
CP401
EF
CN110
: Audio Signal Route (Front L ch)
(FL)
: Audio Signal Route (Surround L ch)
(SL)
: Audio Signal Route (Subwoofer ch)
(SW)
(SW)
(SW)
(SW)
(SW)
(SW)
(SW)
(SW)
(SW)
: Audio Signal Route (Center ch)
(C)
(FL)
(SW)(SW)
(FL)
(SL)
(SW)
(C)
(FL)
(FL)
(SL)
(C)
(FL)
(SL)
(C)
(FL)
(FL)
(SL)
(SL)
(C)
(C)
: Audio Signal Route (CD L ch)
(CD)
: Audio Signal Route (SAT L ch)
(SAT)
: Audio Signal Route (DVD L ch)
(DVD)
: Audio Signal Route (L ch)
(CD)
(SAT)
(DVD)
(CD)
(SAT)
(DVD)
