Pioneer AVH-Z9200DAB User manual

English
AVH-Z9200DAB
DVD RDS AV RECEIVER
Operation Manual

English
- 2 -
Important
■Precaution ......................... 5
Important safety information .................................. 6
To ensure safe driving................................................. 7
When using a display connected to V OUT ........ 7
To avoid battery exhaustion..................................... 8
Rear view camera ......................................................... 8
Handling the SD card slot ......................................... 8
Handling the USB connector ................................... 8
Visit our website ........................................................... 9
Protecting the LCD panel and screen ................... 9
Notes on internal memory........................................ 9
About this manual ....................................................... 9
■Parts and controls ........... 10
Main unit ....................................................................... 10
Protecting your product against theft................ 11
■Basic operation ............... 14
Notes on using the LCD panel ............................... 14
Adjusting the LCD panel angle ............................. 14
Resetting the microprocessor ............................... 14
Remote control ........................................................... 15
Starting up the unit................................................... 15
Using the touch panel .............................................. 16
Top menu screen ........................................................ 19
■Bluetooth ......................... 21
Bluetooth connection .............................................. 21
Bluetooth settings..................................................... 21
Hands-free phoning.................................................. 22
Bluetooth audio ......................................................... 27
■Wi-Fi.................................. 29
Wi-Fi connection ........................................................ 29
Wi-Fi settings ............................................................... 29
Wi-Fi audio ................................................................... 30
■AV source ......................... 31
Supported AV source................................................ 31
Displaying the AV operation screen.................... 31
Selecting a source ..................................................... 32
Changing the display order of source ................ 32
Adjusting the range of favourite source icons
area .......................................................................... 33
■Setup for iPod/iPhone or
smartphone ..................... 34
iPod/iPhone ................................................................. 34
Smartphone (Android™ device) ........................... 35
■Digital Radio.................... 36
Digital Radio tuner operations.............................. 36
Starting procedure.................................................... 36
Basic operation ........................................................... 37
DAB settings ................................................................ 38
■Radio ................................ 40
Starting procedure.................................................... 40
Basic operation ........................................................... 40
Storing the strongest broadcast frequencies
(BSM) ....................................................................... 41
Radio settings ............................................................. 41
■Disc ................................... 43
Inserting and ejecting a disc ................................. 43
Basic operation ........................................................... 43
■Compressed files ............. 48
Inserting and ejecting media ................................ 48
Contents
Thank you for buying this Pioneer
product.
Please read through these instructions
so you will know how to operate your
model properly. After you have finished
reading the instructions, keep this
document in a safe place for future
reference.
The screen shown in the examples may
differ from actual screens, which may be
changed without notice for
performance and function
improvements.

English
- 3 -
Starting procedure .................................................... 50
Basic operation ........................................................... 50
■iPod .................................. 56
Connecting your iPod............................................... 56
Basic operation ........................................................... 56
■WebLink™ ........................ 60
Using WebLink ............................................................ 60
Starting procedure .................................................... 60
Using the audio mix function ................................ 62
■Apple CarPlay.................. 63
Using Apple CarPlay.................................................. 63
Setting the driving position ................................... 63
Starting procedure .................................................... 64
Adjusting the volume............................................... 65
■Android Auto™ ................ 66
Using Android Auto................................................... 66
Setting the driving position ................................... 66
Starting procedure .................................................... 67
Adjusting the volume............................................... 68
Setting the auto-launch function......................... 68
■HDMI ................................ 70
Starting procedure .................................................... 70
Basic operation ........................................................... 70
■AUX .................................. 71
Starting procedure .................................................... 71
Basic operation ........................................................... 72
■AV input ........................... 73
Starting procedure .................................................... 73
Basic operation ........................................................... 74
■Wireless Mirroring .......... 75
Starting procedure .................................................... 75
Basic operation ........................................................... 76
■Vehicle equipment
information ..................... 77
Using the Vehicle Bus adapter............................... 77
Displaying obstacle detection information ...... 78
Displaying the operating status of the climate
control panel......................................................... 78
■Settings ............................ 79
Displaying the setting screen................................ 79
System settings .......................................................... 79
Theme settings ........................................................... 88
Audio settings............................................................. 91
Video settings ............................................................. 97
■Favourite menu ............. 101
Creating a shortcut ................................................. 101
Selecting a shortcut................................................ 101
Removing a shortcut .............................................. 101
■Other functions ............. 102
Setting the time and date..................................... 102
Changing the wide screen mode....................... 102
Selecting the video for the rear display........... 103
Setting the anti-theft function............................ 104
Restoring this product to the default
settings ................................................................. 105
■Appendix ....................... 106
Troubleshooting....................................................... 106
Error messages.......................................................... 108
Handling and care of discs ................................... 112
Playable discs ............................................................ 112
Detailed information for playable media........ 113
Bluetooth.................................................................... 118
Wi-Fi.............................................................................. 118
SDXC............................................................................. 118
WMA/WMV................................................................. 119
FLAC.............................................................................. 119
DivX .............................................................................. 119
AAC ............................................................................... 119
WebLink ...................................................................... 120
Waze ............................................................................. 120
Google™, Google Play, Android .......................... 120
Android Auto............................................................. 120
Detailed information regarding connected iPod
devices .................................................................. 120
Using app-based connected content............... 121
HDMI ............................................................................ 122
Notice regarding video viewing......................... 122
Notice regarding DVD-Video viewing.............. 122
Notice regarding MP3 file usage ........................ 122
Notice regarding open source licenses ........... 122
Using the LCD screen correctly........................... 122

English
- 4 -
Specifications............................................................ 123

English
- 5 -
Private households in the member states of the EU, in Switzerland and Norway may return their used
electronic products free of charge to designated collection facilities or to a retailer (if you purchase a
similar new one).
For countries not mentioned above, please contact your local authorities for the correct method of
disposal.
By doing so you will ensure that your disposed product undergoes the necessary treatment, recovery
and recycling and thus prevent potential negative effects on the environment and human health.
Precaution
Certain country and government laws may prohibit or restrict the placement and use of this product
in your vehicle. Please comply with all applicable laws and regulations regarding the use, installation
and operation of this product.
If you want to dispose this product, do not mix it with general household waste. There is a separate
collection system for used electronic products in accordance with legislation that requires proper
treatment, recovery and recycling.
CAUTION
This product is a Class 1 laser product classified under the safety standard, IEC 60825-1:2014, and
contains a class 1M laser module. To ensure continued safety, do not remove any covers or attempt
to gain access to the inside of the product. Refer all servicing to qualified personnel.
MOVING PARTS.
KEEP BODY PARTS AWAY FROM MOVING PARTS.
CLASS 1 LASER PRODUCT
CAUTION—CLASS 1M VISIBLE AND INVISIBLE
LASER RADIATION WHEN OPEN, DO NOT VIEW
DIRECTLY WITH OPTICAL INSTRUMENTS.

- 6 -
English
WARNING
Slots and openings in the cabinet are provided for ventilation to ensure reliable operation of the
product, and to protect it from overheating. To prevent fire hazard, the openings should never be
blocked or covered with items (such as papers, floor mat, cloths).
CAUTION
This product is evaluated in moderate and tropical climate condition under the Audio, video and
similar electronic apparatus - Safety requirements, IEC 60065.
WARNING
•Do not attempt to install or service this product by yourself. Installation or servicing of this product by
persons without training and experience in electronic equipment and automotive accessories may
be dangerous and could expose you to the risk of electric shock, injury or other hazards.
•Do not allow this product to come into contact with liquids. Electrical shock could result. Also,
damage to the product, smoke, and overheating could result from contact with liquids.
•If liquid or foreign matter should get inside this product, park your vehicle in a safe place, turn the
ignition switch off (ACC OFF) immediately and consult your dealer or the nearest authorised Pioneer
Service Station. Do not use this product in this condition because doing so may result in a fire, electric
shock, or other failure.
•If you notice smoke, a strange noise or odour from this product, or any other abnormal signs on the
LCD screen, turn off the power immediately and consult your dealer or the nearest authorised Pioneer
Service Station. Using this product in this condition may result in permanent damage to the system.
•Do not disassemble or modify this product, as there are high-voltage components inside which may
cause an electric shock. Be sure to consult your dealer or the nearest authorised Pioneer Service
Station for internal inspection, adjustments or repairs.
Before using this product, be sure to read and fully understand the following safety
information:
•Do not operate this product, any applications, or the rear view camera option (if
purchased) if doing so will divert your attention in any way from the safe operation of
your vehicle. Always observe safe driving rules and follow all existing traffic
regulations. If you experience difficulty in operating this product, pull over, park your
vehicle in a safe location and apply the handbrake before making the necessary
adjustments.
•Never set the volume of this product so high that you cannot hear outside traffic and
emergency vehicles.
•To promote safety, certain functions are disabled unless the vehicle is stopped and the
handbrake is applied.
•Keep this manual handy as a reference for operating procedures and safety
information.
•Do not install this product where it may (i) obstruct the driver’s vision, (ii) impair the
performance of any of the vehicle’s operating systems or safety features, including air
Important safety information

English
- 7 -
bags or hazard lamp buttons or (iii) impair the driver’s ability to safely operate the
vehicle.
•Please remember to fasten your seat belt at all times while operating your vehicle. If
you are ever in an accident, your injuries can be considerably more severe if your seat
belt is not properly buckled.
•Never use headphones while driving.
Certain functions (such as viewing of video image and certain touch panel key
operations) offered by this product could be dangerous (possibly resulting in serious
injury or death) and/or unlawful if used while driving. To prevent such functions from
being used while the vehicle is in motion, there is an interlock system that senses when
the handbrake is set and when the vehicle is moving. If you attempt to use the functions
described above while driving, they will become disabled until you stop the vehicle in a
safe place.
WARNING
• LIGHT GREEN LEAD AT POWER CONNECTOR IS DESIGNED TO DETECT PARKED STATUS AND
MUST BE CONNECTED TO THE POWER SUPPLY SIDE OF THE HANDBRAKE SWITCH. IMPROPER
CONNECTION OR USE OF THIS LEAD MAY VIOLATE APPLICABLE LAW AND MAY RESULT IN
SERIOUS INJURY OR DAMAGE.
• Do not take any steps to tamper with or disable the handbrake interlock system which is in
place for your protection. Tampering with or disabling the handbrake interlock system could
result in serious injury or death.
• To avoid the risk of damage and injury and the potential violation of applicable laws, this
product is not for use with a video image that is visible to the driver.
•In some countries the viewing of video image on a display inside a vehicle even by persons other
than the driver may be illegal. Where such regulations apply, they must be obeyed.
If you attempt to watch video image while driving, the warning “Viewing of front seat
video source while driving is strictly prohibited.” will appear on the screen. To watch
video image on this display, stop the vehicle in a safe place and apply the handbrake.
Please keep the brake pedal pushed down before releasing the handbrake.
The video output terminal (V OUT) is for connection of a display to enable passengers in
the rear seats to watch video images.
WARNING
NEVER install the rear display in a location that enables the driver to watch video images while driving.
To ensure safe driving
When using a display connected to V OUT

- 8 -
English
Be sure to run the vehicle engine while using this product. Using this product without
running the engine can drain the battery.
WARNING
Do not install this product in a vehicle that does not have an ACC wire or circuitry available.
With an optional rear view camera, you are able to use this product as an aid to keep an
eye on trailers, or backing into a tight parking spot.
WARNING
•SCREEN IMAGE MAY APPEAR REVERSED.
•USE INPUT ONLY FOR REVERSE OR MIRROR IMAGE REAR VIEW CAMERA. OTHER USE MAY RESULT IN
INJURY OR DAMAGE.
CAUTION
•For safety reasons, the rear view camera function is not available until this product boots up
completely.
•The rear view mode is to use this product as an aid to keep an eye on the trailers, or while backing up.
Do not use this function for entertainment purposes.
CAUTION
•Keep the SD memory card out of the reach of small children to prevent them from accidentally
swallowing it.
•To prevent data loss and damage to the storage device, never remove it from this product while data
is being transferred.
•If data loss or corruption occurs on the storage device for any reason, it is usually not possible to
recover the data. Pioneer accepts no liability for damages, costs or expenses arising from data loss or
corruption.
•Never insert or eject an SD memory card while driving.
CAUTION
•To prevent data loss and damage to the storage device, never remove it from this product while data
is being transferred.
•Pioneer cannot guarantee compatibility with all USB mass storage devices and assumes no
responsibility for any loss of data on media players, iPhone, smartphone, or other devices while using
this product.
To avoid battery exhaustion
Rear view camera
Handling the SD card slot
Handling the USB connector

English
- 9 -
Visit us at the following site:
http://www.pioneer-car.eu
•Register your product. We will keep the details of your purchase on file to help you
refer to this information in the event of an insurance claim such as loss or theft.
•We offer the latest information about PIONEER CORPORATION on our website.
•Pioneer regularly provides software updates to further improve it’s products. Please
check the support section of the Pioneer website for all available software updates.
•Do not expose the LCD screen to direct sunlight when this product is not used. This
may result in LCD screen malfunction due to the resulting high temperatures.
•When using a mobile phone, keep the aerial of the mobile phone away from the LCD
screen to prevent disruption of the video in the form of spots, coloured stripes, etc.
•To protect the LCD screen from damage, be sure to touch the touch panel keys only
with your finger and do so gently.
•If the battery is disconnected or discharged, the memory will be erased and must be
reprogrammed.
•The information will be erased by disconnecting the yellow lead from the battery (or
removing the battery itself).
•Some of the settings and recorded contents will not be reset.
This manual uses diagrams of actual screens to describe operations. However, the
screens on some units may not match those shown in this manual depending on the
model used.
Visit our website
Protecting the LCD panel and screen
Notes on internal memory
About this manual
Meanings of symbols used in this manual
This indicates to touch the appropriate soft key on the touch screen.
This indicates to touch and hold the appropriate soft key on the touch screen.

- 10 -
English
Parts and controls
Main unit
LCD screen
VOL (+/-)
Press to switch between the Application screen and the AV operation screen.
Press and hold to switch to the camera view mode.
NOTE
To activate the camera view mode with this button, set [Back Camera Input] to
[On] or [AV Input] to [Camera] (page 80).
Press to display the top menu screen.
Press and hold to power off. To power back on, press any button.
Press to display the menu bar (page 17).
Press and hold to mute or unmute.
Press to display the top menu screen or back to previous screen.
Press and hold to turn off the display.

English
- 11 -
CAUTION
•Do not attempt to detach the front panel while DISC/SD is in the eject position.
•Do not attempt to detach the front panel while data is being written to USB/SD. Doing so may cause
the data to become corrupted.
•After the front panel has been detached, the attaching plate will move back to its original position
automatically. Be careful not to let hands or other objects get caught behind the monitor as it is
moving back.
•Please make sure that the front panel is in its original position while the vehicle is in motion. It is
dangerous to drive with the front panel sticking out.
•Do not place beverages or other objects on top of the front panel while it is fully open.
Important
•Handle the front panel with care when removing or attaching it.
•Avoid subjecting the front panel to excessive shock.
•Keep the front panel out of direct sunlight and high temperatures.
•If removed, replace the front panel on the product before starting up your vehicle.
1Press .
2Touch .
3Slide the dial at the bottom of the front panel to the right, and lift up the front
panel while pushing down on the dial.
Press to activate the voice recognition mode with a connected iPhone or
smartphone.
Press and hold to display the connectable device list screen or device search
screen.
RESET Press to reset the microprocessor (page 14).
SD card slot Refer to Inserting and ejecting an SD memory card (page 48).
Auto EQ
microphone
input jack
Use to connect a microphone for acoustical measurement (sold separately).
Disc-loading
slot
Refer to Inserting and ejecting a disc (page 43).
Protecting your product against theft
Removing the front panel

- 12 -
English
4Put the front panel into the provided protective case for safe keeping.
1Slide the front panel into the top of the product and push it into place.
Slide the inserter on the front panel into the insertion slot on top of the unit and push
it into place.
2Push on the bottom of the front panel until it clicks into place.
Attaching the front panel

English
- 13 -

- 14 -
English
WARNING
•Keep hands and fingers clear of this product when opening, closing, or adjusting the LCD panel. Be
especially cautious of children’s hands and fingers.
•Do not use with the LCD panel left open. It may result in injury in the event of an accident.
CAUTION
•Do not open or close the LCD panel forcefully. It may cause a malfunction.
•Do not operate this product until the LCD panel has completely opened or closed. If this product is
operated while the LCD panel is opening or closing, the LCD panel may stop at that angle for safety.
•Do not place glass or can on the open LCD panel.
1Press .
2Touch or to adjust the angle of the LCD panel.
3Touch .
Returns to the previous screen.
CAUTION
•Pressing the RESET button resets settings and recorded contents to the factory settings.
– Do not perform this operation when a device is connected to this product.
– Some of the settings and recorded contents will not be reset.
•The microprocessor must be reset under the following conditions:
– Prior to using this product for the first time after installation.
– If this product fails to operate properly.
– If there appears to be problems with the operation of the system.
1Turn the ignition switch OFF.
2Press RESET with a pen tip or other pointed tools.
Settings and recorded contents are reset to the factory settings.
Basic operation
Notes on using the LCD panel
Adjusting the LCD panel angle
Resetting the microprocessor

English
- 15 -
The remote control CD-R33 is sold separately. For details concerning operations, see the
remote control manual.
1Start the engine to boot up the system.
The [Select Program Language] screen appears.
NOTES
•From the second time on, the screen shown will differ depending on the previous conditions.
•From the second time on, enter the password for the anti-theft function if the password entry
screen appears.
2Touch the language.
3Touch .
The [Speaker Mode Settings] screen appears.
4Touch the speaker modes.
[Standard Mode]
4-speaker system with front and rear speakers, or a 6-speaker system with front and
rear speakers and subwoofers.
[Network Mode]
3-way system with a high range speaker, middle range speaker and subwoofer (low
range speaker) for reproduction of high, middle and low frequencies (bands).
WARNING
Do not use the unit in Standard Mode when a speaker system for 3-way Network Mode is
connected to the unit. This may cause damage to the speakers.
5Touch .
The [DAB ANTENNA POWER SETTING] screen appears.
6Touch [Yes] then [OK] to use the DAB aerial power (page 39).
Initial Legal Disclaimer screen appears.
7Touch [OK].
The top menu screen appears.
NOTE
Once the speaker mode is set, the setting cannot be changed unless this product is restored to the
default settings. Restore the default settings to change the speaker mode setting (page 105).
Remote control
Starting up the unit

- 16 -
English
To change the speaker mode, you need to restore this product to the default settings.
1Restore the default setting (page 105).
You can operate this product by touching the keys on the screen directly with your
fingers.
NOTE
To protect the LCD screen from damage, be sure to touch the screen only with your finger gently.
: Returns to the previous screen.
: Close the screen.
Switching the speaker mode
Using the touch panel
Common touch panel keys
Operating list screens
Touching an item on the list allows you to narrow down the options and
proceed to the next operation.
Appears when all characters are not displayed on the display area.
If you touch the key, the rests are scrolled for display.
NOTE
This function is available only when you stop your vehicle in a safe place and apply
the handbrake.
Appears when items cannot be displayed on a single page.
Drag the side bar, the initial search bar or the list to view any hidden items.

English
- 17 -
1Press .
The menu bar pops up on the screen.
NOTE
The menu bar availability may vary depending on the activating source.
1Touch .
Operating the time bar
You can change the playback point by dragging the key.
The playback time corresponding to the position of the key is displayed while
dragging the key.
Operating the menu bar
Switches the dimmer duration by day or night.
Switches between playback and pause.
Skips files forwards or backwards.
Performs fast reverse or fast forwards.
Displays setting menu screen (page 79).
Closes the menu bar.
Switching the operation panel

- 18 -
English
The hidden function keys appear.
NOTE
This key does not appear for some AV sources.
Operating the on-screen keyboard
Displays the characters that are entered.
Moves the cursor to the right or left for a number of characters equivalent to the
number of touches.
Enters the characters in the text box.
Deletes the input text to the left of the cursor one letter at a time.
Touching and holding the key deletes the letters to the left of the cursor in rapid
succession.
Confirms the entry and proceeds to the next step.
Enters a space.
Switches between alphabet and numbers/symbols.
Switches between capital and lower case letters.

English
- 19 -
Top menu screen
Favourite source icons
TIPS
•When you connect the external navigation system to this unit, the navigation
mode key is displayed at the middle of the right side of the display.
•If you select [Power OFF], you can turn off almost all functions. The [Power OFF]
mode is released in the following cases.
– An incoming call is received (only for hands-free phoning via Bluetooth).
– A rear view camera image is input when the vehicle is in reverse.
– A button on this unit is pressed.
– The ignition switch is turned off (ACC OFF), then turned on (ACC ON).
AV/Device source operation key.
Displays the current source.
TIP
When the last source is displayed behind the key, you can switch the source by
touching the key.
Setting the time and date (page 102)
Settings (page 79) and Favourite menu (page 101)

- 20 -
English
Connected device key
Displays connected device.
Switches the source or application with connected devices such as WebLink,
external navigation system, Apple CarPlay, Android Auto.
TIPS
•When a device with a compatible application is connected, the favourite
application key appears. Once the key appears, you can adjust the range of the
favourite application key area with the following steps.
1Touch and hold .
appears at the top right of the favourite application key.
2Drag to the desired position.
To finish the adjusting, touch any place of the display except for the
favourite application key.
•You can also switch the mobile device to be connected with the following steps.
1Touch .
2Touch .
3Select desired device then follow the instruction.
Touch for the first wireless connection with the device.
NOTE
This function is available only when you stop your vehicle in a safe place and apply
the handbrake or the vehicle is completely stopped.
AV source (page 31)
Hands-free phoning (page 22)
