1.Introduction
1.1.Product Description
VG1001 UWB Gateway is designed to collect data from UWB Tags when UWB tags
are within 3m and stay for at least 1 second. The collecting process might affect
the alarm and recording function of UWB Tag. The collected data will be uploaded
to the designated server, and will be only held by the owner of UWB Gateway and
server.
1.2.Typical Applications
In typical cases, UWB Gateway is mounted near main entrance, and connected to
a designated local server. When a person carries a UWB Tag through the main
entrance, if the distance between the UWB Tag and the UWB Gateway is within
3m and stay for more than 1 second, the recorded alarm data in the UWB Tag will
be collected by the UWB Gateway, and finally be uploaded to the server.
Server Room
Server
Ethernet Cable
UWB Gateway
2.Panels
2.1.Front panel of the UWB Gateway
Three LED indicators are on the front panel of VG1001 UWB Gateway to indicate
its working status.
Description
1Network
Link Indicator
LED is On: No network link
LED is Flashing: Network link is normal.
This indicator is reserved for further use.
LED is On: No link with the tag
LED is Flashing: Tag link is normal.
Wireless Indicator
(reserved)
UWB Link Indicator
2
3
21

2.Panels
2.2.Rear panel of the UWB Gateway
The rear panel of VG1001 UWB Gateway includes network connector, power
supply connector, reset button and label.
3.Installation and power supply
3.1.Installation of UWB Gateway
The VG1001 UWB Gateway is generally installed near the entrance, and the
installation height is generally 2m. The installation method is as follows:
UWB gateway can only effectively cover a range of 3m radius. It should be installed
with care to function normally. You need to pay attention to the following:
The UWB Gateway should be installed in the correct posture, face down.
The UWB Gateway should not be installed vertically or at an angle.
The UWB Gateway should not be blocked by objects. Keep away from
obstructions such as weak current bridges, fire pipes, air conditioning pipes and
other shelters.
Avoid installing the UWB Gateway on top of the ceiling (no matter the material
of the ceiling is metallic, like aluminum gussets, or non-metallic, like gypsum
boards and glass plates).
Keep away from objects that easily cause signal reflection, including large-area
metals and large screens.
Description
1 RJ45 Network Port PoE power input & network transmission
multiplexing port.
When power is on, use a needle to press
this button and hold for 15 seconds and
then release. The UWB Gateway will
restore the factory settings and restart.
DC power input interface, connect
to 24VDC/1A adapter.
UWB Gateway information.
Reset Button
DC24V Power
Adaptor Port
Label Zone
2
3
4
Ceiling installation Suspension installation
CEILING CEILING
43

3.2.Power supply
UWB Gateway has two power supply methods: PoE and DC.
Power over Ethernet Use Cat 5+ network cable to connect PoE switch (which meets
the 802.3af standards) and UWB Gateway. Note that the distance between PoE
switch and UWB Gateway should not exceed 80 meters. This method uses a single
cable to achieve both power and network connection.
DC Power UWB Gateway uses 24VDC/1A adapter for power supply. Please use the
original adapter or selected adapter that meets the above specifications. At the
same time, use Cat 5+ network cable to connect an ordinary network switch and
the UWB Gateway to achieve network connection.
4. Internet connection of UWB Gateway
4.1.Wired network
There are two main connection methods between the UWB Gateway and the
computer, as shown in Figures 4.1 and 4.2:
Network Cable Power Cable
4.1 Direct connection via network cable
UWB Gateway Server
Network Cable
4.2 Connection via network switch
Server
Network Cable
Network Cable
UWB Gateway
56

4.2.Network configuration
You need the “Social Distancing Contact Tracing Software” to configure the
Gateway. Please refer to “Software Installation and Deployment Instructions” for
detailed configuration steps. If you don’t get the software, contact your
system administrator for help. Here is the basic network knowledge of the
UWB Gateway.
The VG1001 UWB Gateway uses a fixed IP address to access the network and does
not support either the DHCP function, nor the network domain name function.
The default IP of the UWB Gateway is "192.168.1.X" and the network port number
is "48200". The X in IP varies with the ID of the UWB Gateway. You can get the
default IP from the label on the packaging box.
Before modifying the network settings of the UWB Gateway, you should first
modify the IP address of the computer. It is recommended to configure the
computer's network as:
5.Data Collection
The main purpose of VG1001UWB Gateway is to collect data from UWB Tags. It
takes about 1 second for each UWB Tag to upload its alarm records. The effective
data collection zone is a circle with a radius of 3m and centered on the
UWB Gateway. Please ensure that UWB Tags stay in the collection zone for more
than 1 second to ensure the collecting process.
During collecting, the alarm function of UWB Tags may be interfered. It will return
to normal when leaving the data collection zone.
The collected data will be uploaded to the designated server, and is only owned
and controlled by the owner of the server.
6.Important safety information for UWB Gateway
WARNING: Failure to follow these safety instructions could result in fire,
electric shock, injury, or damage to UWB Gateway or other property. Read
all the safety information below before using UWB Gateway.
Handling Handle UWB Gateway during transportation, installation and
other cases with care. UWB Gateway contains sensitive electronic
components and can be damaged if dropped, burned, punctured, or crushed.
Repairing Don’t open UWB Gateway and don’t attempt to repair
UWB Gateway yourself. Disassembling UWB Gateway may damage it, and
may cause injury to you. If UWB Gateway is damaged or malfunctions, contact
local distributor for help.
Powering UWB Gateway uses 24VDC / 1A adapter for power supply. Please use
the original adapter or selected adapter that meets the above specifications. It’s
important to keep UWB Gateway and the power adapter installed in a
well-ventilated area. Using a UWB Gateway power adaptor that’s damaged, using
a third-party selected powering solution which doesn't meet 24VDC/1A or local
IP: 192.168.1.11
Subnet Mask: 255.255.255.0
Default Gateway: 192.168.1.1
7 8

safety regulation requirements, or powering UWB Gateway when moisture is present,
can cause fire, electric shock, injury, or damage to UWB Gateway or other property.
Prolonged heat exposure UWB Gateway and the power adapter comply with
applicable surface temperature standards and limits. UWB Gateway and the
power adapter will become warm when plugged in to a power source.
Radio frequency exposure UWB Gateway uses radio signals to connect to
UWB Tags. UWB Gateway has been tested and meets applicable limits for radio
frequency (RF) exposure.
Radio frequency interference Observe signs and notices that prohibit or restrict
the use of electronic devices. Although UWB Gateway is designed, tested, and
manufactured to comply with regulations governing radio frequency emissions,
such emissions from UWB Gateway can negatively affect the operation of other
electronic equipment, causing them to malfunction. Unplug the UWB Gateway
power adaptor and the PoE cable when use is prohibited, or when asked to do
so by authorities.
Medical device interference UWB Gateway contains components and radios that
emit electromagnetic fields. These electromagnetic fields may interfere with
medical devices, such as pacemakers and defibrillators. Consult your physician
and medical device manufacturer for information specific to your medical device
and whether you need to maintain a safe distance of separation between your
medical device and UWB Gateway. Stop using UWB Gateway if you suspect they
are interfering with your medical device.
Not a medical device UWB Gateway is not a medical device and should not be
used as a substitute for professional medical judgment. It is not designed or
intended for use in the diagnosis of disease or other conditions, or in the cure,
mitigation, treatment, or prevention of any condition or disease. Please consult
your healthcare provider prior to making any decisions related to your health.
Not an absolutely reliable equipment UWB Gateway is not intended for use
where the failure of the device could lead to death, personal injury, disease
transmission or severe environmental damage.
Explosive and other atmospheric conditions Powering on UWB Gateway in any
area with a potentially explosive atmosphere, such as areas where the air
contains high levels of flammable chemicals, vapors, or particles (such as grain,
dust, or metal powders), may be hazardous. Exposing UWB Gateway to
environments having high concentrations of industrial chemicals, including near
evaporating liquified gasses such as helium, may damage or impair UWB Gateway
functionality. Obey all signs and instructions.
Choking hazard Some UWB Gateway bands may present a choking hazard to
small children. Keep these bands away from small children.
7.Important handling information for UWB Gateway
Exposure to liquid UWB Gateway is not water resistant. Always avoid exposing
UWB Gateway to liquids and moisture.
Cleaning and care Keep UWB Gateway clean and dry, but avoid damaging
UWB Gateway. Observe the following:
Don’t clean UWB Gateway while it’s powering.
Don’t dry UWB Gateway using any external heat source (for example, a hair dryer).
Don’t use cleaning products, ultrasonic cleaners, or compressed air when
cleaning your UWB Gateway.
Using buttons, connectors, and ports Never apply excessive pressure to a button
on UWB Gateway, or force a powering connector into a port, because this may
cause damage that is not covered under the warranty. If the connector and port
don’t join with reasonable ease, they probably don’t match. Check for
obstructions and make sure that the connector matches the port and that you
have positioned the connector correctly in relation to the port.
Operating temperature UWB Gateway is designed to work best in ambient
temperatures between -4°F and 158° F (-20° and 70° C) and be stored in
temperatures between -40°F and 185° F (-40° and 85° C). UWB Gateway
can be damaged if stored or operated outside of these temperature ranges.
Avoid exposing UWB Gateway to dramatic changes in temperature or humidity.
Indoor Use UWB Gateway is designed for indoor use only.
9 10

8.FCC compliance statement
Please take attention that changes or modification not expressly approved by the
party responsible for compliance could void the user's authority to operate
the equipment.
This device complies with part 15 of the FCC Rules. Operation is subject to the
following two conditions:
(1) This device may not cause harmful interference, and
(2) this device must accept any interference received, including interference that
may cause undesired operation.
This equipment complies with FCC radiation exposure limits set forth for an
uncontrolled environment. This equipment should be installed and operated with
minimum distance 20cm between the radiator & your body.
This equipment may only be operated indoors. Operation outdoors is in violation
of 47 U.S.C. 301 and could subject the operator to serious legal penalties.
UWB devices may not be employed for the operation of toys. Operation onboard
an aircraft, a ship or a satellite is prohibited.
FCC ID: 2AIK7VG1001
9.Disposal and recycling information for UWB Gateway
UWB Gateway disposal and recycling
Your UWB Gateway should not be disposed of with household waste. Dispose of
your UWB Gateway in accordance with local environmental laws and guidelines.
European Union—Disposal Information
The symbol above means that according to local laws and regulations your
product and/or its battery shall be disposed of separately from household waste.
When this product reaches its end of life, take it to a collection point designated
by local authorities. The separate collection and recycling of your product and/or
its battery at the time of disposal will help conserve natural resources and ensure
that it is recycled in a manner that protects human health and the environment.
11 12

10.Responsibility statement
The product is an auxiliary tool, which cannot replace any safety management
system, measure and rescue solution for hazardous operation or supervision
system and measure for operation management. Please do not reduce safety
awareness while using the product, and timely charge the product and check its
operation state when the power is low.
Measurement data and results of this product are for reference only, shall not
be served as the basis for diagnosis and treatment. Products described in the
Manual (including hardware and software) are all provided in the "current
situation" within the maximum range allowed by laws, and there may exist
defects, errors or faults. The Company does not provide express or implied
guarantee in any form, or compensate for any special, incidental, accidental or
indirect damages caused by using the Manual or products of the Company.
The Company does not undertake any responsibility for any damage to personal
or property interests of one's own or third party caused by failing to use the
product according to the Manual and warning statement.
The Company does not undertake any responsibility for any product operation
abnormality, information disclosure or other problems caused by network attack,
hacker virus infection or other unknown risks due to Internet access during
product use.
The product promoting pictures and advertisements are used only for
instruction and promotion. Physical products prevail in all cases.
The data in the Manual are all theoretical values obtained by the internal lab in
specific testing environments. However, there may exist differences due to
individual product differences, software version, using conditions and different
environmental factors, and actual using conditions shall prevail in all cases.
The Company will not send special notice in the case of being necessary to
modify and adjust the above.
For more information, please contact [email protected]
Disclaimer:The UWB Gateway isnot intended to be used asatreatmentfor
COVID-19 and also not as a protectivedeviceagainstcontractingCOVID-19.
The UWB Tagisasocialdistancing device, can only be used in the context of
social distancing and contact tracing among persons, any usage not related to
social distancing are strictly prohibited.Dependingonthedesign of usage
location / environment and the way how it is used, therecouldbefalsepositives
duetotissue, walls, structures orotherfactorsandfalsenegativesduetobodily
interference,electromagneticinterference, orotherfactors.We warranties
thatthe UWB GatewayperformstotherequirementslistedontheUWB Gateway
specsheet.Allsalesarefinal.
1413

11 .Appendix
VG1001 UWB Gateway
Frequency
Transmit power density
Collect Distance
Interface Type
Interface Speed
Interface Protocol
Interface Connect Distance
Transmission medium
Dimensions
Weight
Power Supply Interface
Voltage
6.1GHz~6.9GHz
< -41.3dBm/Mhz
3~5m(LOS)
Ethernet RJ45
100Mbps
TCP/IP
100m
CAT5+
200mmx200mmx40mm
400g
POE DC
48V 24V
Current
Working temperature
Storage temperature
Working humidity
Storage humidity
0.5A
-20-70℃
-40-85℃
10% - 90% non condensing
5% - 95% non condensing
1A
15
