Pipishell PIECK1 User manual

V4.0
8-inch Digital Clock Instruction Manual
Model: PIECK1(Black)
PIECK2W(White)
Thank you for choosing this product! We strive to provide you with the
best quality products and services in the industry. Please share your
experience of our product with others at https://pipishellav.com/pag-
es/reviews if you are satisfied. Should you have any issues, please
don't hesitate to contact us.
Technical Support:
1-800-556-9829 Mon-Fri 10am - 5pm (PST) (USA) (CAN)
Other Info:
[email protected] (US/CA)

HOW TO USE:
15/16 in.(24mm)
OK
25/64 in.(10mm)
OPERATION INSTRUCTION:
Remove the clock and AC adaptor from the package.
Plug the input connector of the AC Adaptor into the DC 5V
1.5A hole on the side of the device, then plug the other end
of the AC Adaptor into the power supply.
Press and hold the ON/OFF button for a few seconds. In 5
seconds the clock will display the day of the week/day
cycle/exact time/calendar.
1.
2.
3.
UP
Model: PIECK1(Black)
PIECK2W(White)
NOTE:
The Digital Clock is preset to Eastern Time. If you receive the clock in
another time zone (e.g. Pacific, Mountain or Central), you will have to
adjust the time by following these instructions.
USB port for factory software upgrading only!
01

1. SET TIME
Press the [MENU] button to access the settings page.
Press the [UP/DOWN] button to access the 1st line titled
“Set Time”.
Please note: The function you are in will turn yellow as shown
in the image above. When the fonts of the selected line turn
into yellow, press the [OK] button and the HOUR you select-
ed will turn into red as shown in the image in the page 03,
then press the [UP/DOWN] button to adjust the hour.
A.
B.
C.
02
Press the [MENU] button to access the settngs page.
Please Note: The function you are in will turn yellow as shown
in the image above.
Press [OK] to save and [MENU] to exit.
Caution

E.
F.
A. Press the [MENU] button to access the settings page.
B. Press the [DOWN] button to access the 2nd line titled
“Set Date”.
C. Please note: The function you are in will turn yellow as
shown in the image in the next page. When the fonts of the
selected line turn into yellow, press the [OK] button and the
DAY you selected will turn into red font as shown in the
image in the next page.
2. SET DATE
After finishing the hour adjustment, press [RIGHT] button to
select the MINUTE to be changed and the MINUTE you
selected will turn into red, then press the [UP/DOWN] button
to adjust the minute.
After the changes are completed, press the [OK] button to
save the settings.
Press the [MENU] button to go back to the main display or
press the [UP/DOWN] button to access other settings.
10
D.
03

2. SET DATE
A. Press the [MENU] button to access the settings page.
B. Press the [DOWN] button to access the 2nd line titled
“Set Date”.
C. Please note: The function you are in will turn yellow as
shown in the image in the next page. When the fonts of the
selected line turn into yellow, press the [OK] button and the
DAY you selected will turn into red font as shown in the
image in the next page.
3. SET TIME MODE
A. Press the [MENU] button to access the settings page.
B. Press the [DOWN] button to access the 3rd line titled“Time
Mode”.
C. Please note: The function you are in will turn yellow as shown
in the image below. When the fonts of the selected line turn into
yellow, press the [OK] button and the TIME MODE you selected
will be framed in red box as shown in the image below, then
press the [RIGHT/LEFT] button to switch between: 12 Hours
(A.M./P.M.) or 24 Hours (Military Time)
D. After the changes are completed, press the [OK] button to
save the settings.
E. Press the [MENU] button to go back to the main display or
press the [UP/DOWN] button to access other settings.
D. After finishing the day adjustment, press [RIGHT] button to
select the MONTH to be changed and the MONTH you selected
will turn into red, then press the [UP/DOWN] button to adjust
the month. Press the [OK] button to save the settings.
E. After finishing the month adjustment, press [RIGHT] button to
select the YEAR to be changed and the year you selected will
turn into red, then press the [UP/DOWN] button to adjust the
year. Press the [OK] button to save the settings.
F. After the changes are completed, press the [OK] button to
save the settings.
G. Press the [MENU] button to go back to the main display or
press the [UP/DOWN] button to access other settings.
04
Time Mode 12 Hours
Set Date 23-04-2019
Set Date 23-04-2019
Set Date 23-04-2019
DAY
MONTH
YEAY

4. SET DATE MODE
A. Press the [MENU] button to access the settings page.
B. Press the [DOWN] button to access the 3rd line titled “Date
Mode”.
Please note: The function you are in will turn yellow as shown
in the image below. When the fonts of the selected line turn
into yellow, press the [OK] button and the DATE MODE you
selected will be framed in red box as shown in the image
below, then press the [LEFT/RIGHT] button to switch be-
tween:
Day-Month-Year (Standard European Mode).
Month-Day-Year (Standard U.S. Mode).
C. After the changes are completed, press the [OK] button to
save the settings.
D. Press the [MENU] button to go back to the main display or
press the [UP/DOWN] button to access other settings.
5. SET LANGUAGE
A. Press the [MENU] button to access the settings page.
B. Press the [DOWN] button to access the 5th line titled “Lan-
guage”.
C. Please note: The function you are in will turn yellow as
shown in the image below. When the fonts of the selected line
turn into yellow, press the [OK] button and the LANGUAGE you
selected will be framed in red box as shown in the image
below, then press [LEFT/RIGHT] button to select a language (8
languages available including English, French, German, Italian,
Polish, Spanish, Dutch, Welsh ).
D. After the changes are completed, press the [OK] button to
save the settings.
E. Press the [MENU] button to go back to the main display or
press the [UP/DOWN] button to access other settings.
05
Date Mode Day-Month-Year
Langeuage < English >

6. AUTOMATIC BRIGHTNESS
A. Press the [MENU] button to access the settings page.
B. Press the [DOWN] button to access the 6th line titled“Auto-
matic brightness”.
C. Please note: The function you are in will turn yellow as
shown in the image below. When the fonts of the selected line
turn into yellow, press the [OK] button and the field you select-
ed will be framed in red box as shown in the image below, then
press the [LEFT/RIGHT] button to select between: Auto，Level
1, Level 2, Level 3, Level 4, Level 5.
Please note: Auto means the brightness automatically dims at
night and brightens during the day.
Level 1 means the dimmest level and level 5 is the brightness
level.
D. After the changes are completed, press the [OK] button to
save the settings.
E. Press the [MENU] button to go back to the main display or
press the [UP/DOWN] button to access other settings.
7. SET ALARM STATUS
A. Press the [MENU] button to access the settings page.
B. Press the [UP/DOWN] button to access the 8th line titled
“Alarm Status”. The function you are in will turn yellow as
shown in the image below.
06
Automatic brightness < Auto >
Alarn Status

07
C. When the fonts of the selected line turn into yellow, press the
[OK] button to access the timer page as shown in the image
below, then press [UP/DOWN] button to select between timer 1,
timer 2, timer 3, timer 4 and add timer shown in the image
below.
Timer 1 Off
Timer 2 Off
Timer 3 Off
Add Timer
D. When you select the 1st line titled “Timer 1”, the front will
turn into yellow as shown in the image below, then press [OK]
button to access the setting page, please refer to procedures 2
and 3 to set the time and date. After the changes are completed,
press the [OK] button to save the settings.
Set Time < Unset >
Set Date 23-4-2019
E. Press the [UP] button to select the 3rd line titled “Set
Repeat”. When the fronts turns into yellow as shown in the
image below, press [OK] button to access the setting page,
then press the [UP/DOWN] button to switch between: Sunday,
Tuesday, Friday, Wednesday, Thursday, Friday, Saturday and
Monday. After the changes are completed, press the [OK]
button to save the settings.
Set Repeat Sunday/Monday

G. Press the [UP] button to select the 5th line titled “Start Timer”,
When the fronts turns into yellow as shown in the image below,
then press [OK] button and the selected field is framed in red as
shown in the image below, then press the [RIGHT/LEFT] button to
switch between: Off and On. After the changes are completed,
press the [OK] button to save the settings.
08
Del Timer
F. Press the [UP] button to select the 4th line titled “Tag”. When
the fronts turns into yellow as shown in the image below, press
[OK] button to access the setting page, then press the
[UP/DOWN] button to switch between: Off, Meal, Medicine,Clinic,
Shower, Gardening Cleaning Appointment, Walk Dog. After the
changes are completed, press the [OK] button to save the set-
tings.
Off
Meal
Medicine
Clinic
Start Timer < Off >
H. Press the [UP] button to select the 6th line titled “Del Timer”.
When the fronts turns into yellow as shown in the image below,
then press [OK] button to delete timer.
I. After the changes are completed, press the [OK] button to save
the settings. Press the [MENU] button to go back to the main
display or press the [UP/DOWN] button to access other settings.

09
PLEASE NOTE:
Please refer to the procedures in setting timer 1 to set timer 2,
timer 3 and so on.
The alarm will ring for 60 seconds and then go off on its own, or
you can manually stop it by pressing any button on the back of
the clock.
Advanced Mode < Off >
8. SET ADVANCED MODE
Please Note: Advance mode turn on and off the time of day
for morning, afternoon, evening and night.
A. Press the [MENU] button to access the settings page.
B. Press the [DOWN] button to access the 9th line titled“Ad-
vanced Mode”.
C. Please note: The function you are in will turn yellow as shown
in the image below. When the fonts of the selected line turn into
yellow, press the [OK] button and the field you selected will be
framed in red box as shown in the image below, then press the
[UP/DOWN] button to switch between: Off and On
D. After the changes are completed, press the [OK] button to
save the settings.
E. Press the [MENU] button to go back to the main display or
press the [UP/DOWN] button to access other settings.
9. SET VOLUME
A. Press the [MENU] button to access the settings page.
B. Press the [DOWN] button to access the 8th line titled“Vol-
ume”.

SPECIFICATIONS:
• Name: 8 inches high definition digital clock
• Digital Display: week, day cycle, exact time, calendar
• 2 Time Mode: 12-hours and 24-hours
• 2 Date Mode: dd/mm/yy and mm/dd/yy
• Color: white, black
• 8 Languages Available: English, French, German, Italian,
Polish, Spanish, Dutch, Welsh
• Volume Range: 0 to 5 (5 is the highest volume and 0 is mute)
• Power Supply: Plug in
• Specification of Power Adapter: AC 110V—240V/DC 5V 1.5A
• Placement Method: wall mount/table stand
WARNING
To reduce the risk of fire or electric shock, do not expose this
appliance to rain or moisture condition. To prevent fire or
shock hazard, do not install this product in a confined space.
Volumn < 0 >
D. After the changes are completed, press the [OK] button to
save the settings.
E. Press the [MENU] button to go back to the main display or
press the [UP/DOWN] button to access other settings.
C. Please note: The function you are in will turn yellow as shown
in the image below. When the fonts of the selected line turn into
yellow, press the [OK] button and the field you selected will be
framed in red box as shown in the image below, then press the
[LEFT/RIGHT] button to select the volume ranging from 0 to 5, 5
is the highest volume and 0 is mute.
10

IMPORTANT & WARRANTY
The Digital Clock is packaged with a thin anti-scratch
screen protector. Please feel free to peel it off using the
pull-up tab. Please be sure not to apply pressure to the high
quality non-reflective LED screen.
The Digital Clock is preset to Eastern Time. If you receive
the clock in another time zone (e.g. Pacific, Mountain or
Central), you will have to adjust the time by using these
instructions.
The Digital Clock does not change the time automatically
for daylight savings time, and needs to be adjusted manual-
ly.
The Digital Clock has a 12-month warranty provided by the
manufacturer.
Non-artificial damage or defect of the device or AC adapter
can be replaced during the warranty period.
1.
2.
3.
4.
5.
CAUTION
To reduce the risk of electric shock, do not remove the cover
(or back). No user-serviceable parts inside
11
