PITBULL X24-36 User manual

Pitbull Compact
Loaders
Operator’s manual

3
© Copyright 2019
All rights reserved. No part of this publication may be reproduced, stored in or introduced into a
retrieval system, or transmitted, in any form or by any means, electronic, mechanical, by
photocopying, recording or otherwise, without the prior written permission of Peeters
Landbouwmachines B.V. This also applies to the accompanying drawings and schedules.
Peeters Landbouwmachines B.V. reserves the right to change parts at any time, without prior or
direct notification to the buyer.
The contents of this operator's manual may also be changed without prior notification. Please
contact your supplier's technical service department for any information about settings,
maintenance work or repairs which are not provided for in this operator's manual.
Although this operator's manual has been drawn up with all due care, Peeters Landbouwmachines
B.V. does not assume any liability for any errors in this operator's manual or any consequences
thereof.

4
Contents
1. Introduction......................................................................................................................................... 6
1.1 Preface........................................................................................................................................... 6
1.2 Warranty and liability.................................................................................................................... 7
1.3 EC declaration of conformity......................................................................................................... 8
1.4 Safety instructions......................................................................................................................... 9
1.5 Type designation ........................................................................................................................... 9
2. Applications of the machine.............................................................................................................. 10
3. Safety instructions............................................................................................................................. 12
4. Function of the machine ................................................................................................................... 17
4.1 Main elements............................................................................................................................. 17
4.2 Technical specifications............................................................................................................... 18
4.3 Loading Diagrams ........................................................................................................................ 19
5. Operation of the machine ................................................................................................................. 20
6. Making the machine ready for use.................................................................................................... 26
7. Commissioning of the machine......................................................................................................... 29
8. Maintenance...................................................................................................................................... 32
8.1 Periodic maintenance schedule .................................................................................................. 32
8.2 Service areas................................................................................................................................ 34
8.3 Lubrication points........................................................................................................................ 34
8.4 Chassis bolt tightening torques................................................................................................... 34
8.5 Tyres ............................................................................................................................................ 35
8.6 Brake fluid.................................................................................................................................... 35
8.7 Gearbox oil .................................................................................................................................. 35
8.8 Front axle oil................................................................................................................................ 36
8.9 Rear axle oil ................................................................................................................................. 36
8.10 Motor oil.................................................................................................................................... 37
8.11 Coolant ...................................................................................................................................... 37
8.12 Cyclone filter.............................................................................................................................. 38
8.13 Motor oil filter........................................................................................................................... 38
8.14 Air filter...................................................................................................................................... 39
8.15 Fuel filter ................................................................................................................................... 39
8.16 Hydraulic oil............................................................................................................................... 40
8.17 Hydraulic oil filters..................................................................................................................... 41

5
8.18 Battery....................................................................................................................................... 42
8.19 Article numbers......................................................................................................................... 42
9. Damage and malfunctions................................................................................................................. 43
9.1 Damage repair............................................................................................................................. 43
9.2 Towing......................................................................................................................................... 43
9.3 Hoisting........................................................................................................................................ 43
9.4 Troubleshooting list..................................................................................................................... 45
10. Servicing .......................................................................................................................................... 48
11. Fluids Specification Sheets .............................................................................................................. 52
Index...................................................................................................................................................... 67
Notes ..................................................................................................................................................... 68

6
1. Introduction
1.1 Preface
We would like to start by congratulating you on purchasing your new Pitbull Compact Loader. The
Pitbull Compact Loader is a unique product with extra attention for safety, quality and power. The
Pitbull Compact Loader is compact and highly manoeuvrable.
Before you start using the Pitbull, it is important that you read this operator's manual carefully and
understand the information provided. This contributes to better control and maintenance for an
optimal machine service life.
Ensure that the user manual is always present with the Pitbull; this document is an integral part of
the machine and must always be present with the machine to provide the correct information about
the machine. The most recent version can be requested from your dealer and a digital version can be
downloaded via www.pitbull-loader.com, under 'Support'.
TIP! After use, keep the manual in the storage compartment behind the seat back, to keep
it protected from weather conditions.
DANGER! After an accident in which the Pitbull is involved, the Pitbull and/or its
surroundings may be unsafe. Do not approach the Pitbull to get the manual, but request it
from your dealer or via www.pitbull-loader.com.
If you encounter any further questions or problems that this operator's manual does not answer,
please contact your dealer or Peeters Landbouwmachines B.V.

7
1.2 Warranty and liability
To rule out any misunderstandings, we ask you to please read the entire operator's manual with due
care and attention. We have tried to guarantee the machine's functionality and your safety. For this
reason, we would like to inform you of a number of points regarding the warranty and liability
offered by Peeters Landbouwmachines BV.
Before the product left the factory, great efforts were made to safeguard you against any and all
defects in materials and workmanship. If they should occur nonetheless, Peeters Landbouwmachines
BV will make all parts that are defective available free of charge for a period of twelve months or 750
working hours, whichever is reached first, after delivery, with the exception of wear parts.
This warranty shall become void if:
Deviations from the operating and maintenance instructions in this manual are made
without the manufacturer's written consent.
Maintenance is not carried out in accordance with the maintenance schedule indicated in
this manual. These maintenance services must be documented in chapter 10. Servicing.
Non-original parts are used for maintenance and repairs. The original parts that must be
used are included in the parts list. The parts book can be downloaded via www.pitbull-
loader.com under 'Support'.
The user statement below has not been fully completed, signed, scanned and sent to Peeters
Landbouwmachines BV by the buyer of the machine.
Unauthorised changes are made to the machine.
The damage was caused by attachments.
The machine is resold.
The warranty is limited in all cases to the free delivery of replacement parts, which means that
Peeters Landbouwmachines BV cannot be held liable for:
Loss of revenue caused by malfunctioning of the machine.
Transport costs incurred to and from a workplace.
Costs incurred for the required tools.
Personnel costs incurred for a mechanic.
To make a warranty claim, please contact your dealer. The costs of the parts may first be charged,
and will only be reimbursed after inspection by an authorised dealer or by Peeters
Landbouwmachines BV.
User statement
Write down the following information about your machine to help you report problems and order
spare parts.
1. Model: Pitbull _______________________ 2. Delivery date:__________________________
3. Serial number of the machine: ______________________________________________
By signing this user statement, the undersigned confirms that they have fully read this user manual
and understand all the information:
Name:______________________________ Signature:

8
1.3 EC declaration of conformity
Peeters Landbouwmachines B.V.
Munnikenheiweg 47
4879 NE Etten-Leur
The Netherlands
EC declaration of conformity
Technical documentation available at the abovementioned manufacturer's site.
The undersigned hereby declares that the machine:
Brand: Pitbull
Models: X24-36, X24-45, X27-36, X27-45
Category: Compact wheel loader / articulated loader / shovel / earth-moving
machine
Complies with the following guidelines:
2006/42/EC (Machinery Directive)
(EU) 2016/1628 (Emissions Directive)
Place: Etten-Leur
Date: September 13, 2019
_________________
D.P.M. Peeters
Managing Director

9
1.4 Safety instructions
Incorrect or careless operation of the compact wheel loader can cause an accident. To ensure safe
operation and maintenance of the Pitbull, it is important that all instructions contained in this user
manual are followed. All persons who use the machine must familiarise themselves with the
instructions. Various marking conventions are used in this manual to further clarify safety risks.
Symbol
Meaning
WARNING!
WARNING AGAINST DANGER / FATAL HAZARD
You may be seriously injured if you do not carry out the
procedures carefully.
Fatal hazard: there is a direct risk of your getting killed.
CAREFUL!
CAREFUL
The machine may be damaged if you do not carry out the
procedures carefully.
NOTE!
NOTE
A remark with additional information; alerts you to possible
problems.
TIP!
TIP
Offers suggestions and advice to help you carry out certain
work more easily or more handily.
1.5 Type designation
1
Contact details of manufacturer
7
Reserved for extra details
2
Serial number of the machine
8
Maximum total machine weight
3
Year of manufacture of the machine
9
Weight of the machine
4
Model name of the machine
10
Maximum working weight of the machine
5
Machine version
11
Maximum front axle load
6
Engine power of the machine
12
Maximum rear axle load

10
2. Applications of the machine
The Pitbull is suitable for the following operations, among others:
Lifting and moving loaded pallets with pallet forks or a lifting mast; the mass of the load must
not exceed the recommended load in the loading diagrams.
Lifting loads with a hook arm, jip or hoisting mast.
Moving and shifting soil and debris with an implement, volume bucket, rubble bucket, multi-
purpose bucket and bucket grab.
Loading soil, debris or feed into another machine with a high-tipping bucket.
Moving bales with a silage grab, bale fork or bale grab.
Moving manure with a manure grab, manure fork or manure shovel.
Moving and distributing feed with a feed dispenser or feed blade.
Moving tiles with a tile rake or tile grab.
Removing weeds with a weed brush.
Sweeping the surface with a sweeper or sweeping broom.
Mowing grass with a mower.
Picking up waste with a suction unit.
Work the substrate with a drill, splitter or cutter.
Moving trees with a log grab, tree grab or soil grab.
Trimming hedges with a hedge trimmer.
Digging with a digging arm.
Shovelling snow with a snow shovel.
Towing a load in a trailer.
It is not permitted to use the Pitbull for the following operations:
Transporting animals.
Carrying persons other than the driver.
Transport of (hazardous) substances and products containing (hazardous) substances that
are included in the ADR, which has been implemented in the Transport of Dangerous
Substances Act and the Regulation on the Land Transport of Dangerous Substances.
Lifting materials that are heavier than indicated in the loading diagram.
Operations that are not permitted by law.
Attachments
The Pitbull is suitable for performing various tasks thanks to the wide variety of attachments that can
be used. An implement is supplied as standard. Use only undamaged and CE-approved attachments.
Your Pitbull may have the option for a different insertion than the standard insertion, so use only
attachments that are suitable for your chosen insertion. If your Pitbull has the optional third or third
and fourth front hydraulic function, in which case the attachment can be additionally power-assisted.
Always read the attachment manual carefully before use and learn to work safely with the
attachment.
NOTE! During the operation of the machine, loading diagrams are displayed that apply to
the optionally supplied pallet forks. When other attachments are used, the maximum load
differs.

11
Surface
The surface on which the vehicle is being driven affects the stability of the machine. Drive as much as
possible on a paved and level surface. Adjust your speed, curve radius and the amount of load to the
surface on which you drive. Keep the lifting height about 20 centimetres above the ground while
driving.
Legislation
The machine may only travel on public roads if it is equipped with the option package for road
admission. In this case, the driver must hold a tractor driving licence (driving licence T). Please pay
attention to the following points:
The maximum speed is 25km/h.
Load must be covered while driving.
Protruding parts must be shielded.
The attachment must not cause any obstruction of sight or danger to other drivers.
Local traffic rules must be observed.
Ensure that the machine meets specific national requirements.
Be aware of other road users who cannot properly estimate the road handling and risks of
the machine.
The machine must be insured by the owner for civil liability according to the Motor Vehicle Liability
Insurance Act when it is used on public roads, on private property that is accessible to the public and
on private property that is only accessible to a number of authorised persons. This, therefore, applies
to the Pitbull both with and without the option package for road admission.
According to the Working Conditions Act, the machine is considered lifting and hoisting equipment,
which means that it may only be operated by persons who have specific expertise for this purpose.
Insurers may require a certificate of training as a condition of an insurance policy.
NOTE! Always adhere to laws and regulations, which have been drawn up for the safety of
the driver, and bystanders and other road users.
Recommended operating and ambient temperature
The recommended operating and ambient temperature is between -25°C and +40°C. If the operating
and ambient temperature are outside this range, take into account possible system failures.
Using the system at lower temperatures will lead to accelerated wear to hydraulic gaskets and it will
increase the risk of hydraulic hoses being damaged and brittle fractures in the steel structure. If you
work at temperatures lower than the recommended temperature, the maximum load is less than
what is normally allowed.
Before starting to work at a low temperature, have the oil circulate through the system for some
minutes. Slowly repeat all actions several times so that the gaskets will become flexible before being
exposed to full pressure.
If working in extremely high temperatures, remember that the hydraulic oil will heat up extremely. If
the oil temperature exceeds +80°C, the oil will evaporate and the gaskets will be damaged The
electronics may work more slowly because the processor of the controller protects against
overheating due to the extreme heat.

12
3. Safety instructions
To contribute to safety, a number of stickers have been placed on the Pitbull with safety and warning
signs. They draw your attention to the risks that are present in and around the machine. Check that
all warning indicators are present. If this is not the case, contact the dealer and ensure that the
warning signs are renewed where necessary. The stickers consist of an image that depicts the danger
in a warning triangle and an image that makes clear how to prevent the danger.
NOTE! To enable all (new) users to work safely, the stickers must always be clean and
clearly legible; always replace any stickers that are damaged. They are available from your
dealer.
1
2
3.1
Crushing hazard near the
mixing compartment. Keep
your distance from the space
between the wheel and the
wheel arch.
Keep your distance from the
exhaust, it may be hot and may
cause burns.
Read the user manual before
using the machine.
3.2
3.3
3.4
Operating instructions for the
joystick.
Place the boom in the lowest
position, activate the parking
brake, switch the machine to
neutral and remove the key
from the ignition when parking
the machine.
Read the user manual for
maintenance intervals, use the
step, keep your distance from
objects, wear the belt, pay
attention to power cables and
wear eye protection.

13
3.5
4
Ensure that no loads are stacked on top of each
other that may shift when the boom is moved.
Wear hearing protection. The maximum sound
power level that the machine can produce (LwA)
is 109 dB, the sound pressure level measured at
the operating position (LpA) is 88 dB.
5
6
7
Hoisting point. Attach the
lifting equipment only in these
places.
Danger of head injury. Keep
sufficient distance from the
boom.
Danger of crushing at the
hinged parts of the boom. Keep
sufficient distance.
8
9
10
The combustion engine runs on
diesel (B7). Only use this fuel.
Make sure that no persons or
animals are within a 4-metre
radius when the machine is
moving.
Danger of crushing when
approaching machine. Stay
away from the pivot point of
the steering.

14
11
12
Lubrication point. Follow the instructions in the
user manual.
Forbidden to come under the load.
13.1
13.2
13.3
Remove the key from the
ignition before servicing.
Danger of hand injury. Avoid
contact with leaking fluids
under pressure.
Explosion and shock hazard.
Ensure adequate ventilation
when charging the battery and
do not short-circuit.
13.4
13.5
13.6
Danger of crushing. Keep
distance from the fan when it
has not yet come to a standstill.
Danger of burns. Allow the
machine to cool down before
carrying out maintenance.
Shock hazard. Keep away from
cabling. Make sure the battery
isolator is off before
maintenance is carried out.

15

16
Green indicates that the position of
the sticker is not visible on the
image, but is between the boom.
Inner sides of bonnets

17
4. Function of the machine
In order to work safely with the machine, it is important to be properly informed about the Pitbull's
operation and the machine's specifications. The main elements of the machine are mentioned first.
These terms are used more often in the manual. Due to the different options with which the Pitbull
can be equipped, the images used may differ slightly.
NOTE! The left, right, front and rear sides used in the text must be seen from the driver's
seated position.
4.1 Main elements
The following image shows the main elements of the Pitbull.
1.
Fuel cap
2.
Front frame
3.
Attachment carrier
4.
Boom
5.
Steering hinge point
6.
FOPS safety roof (in accordance with ISO 3449:1992, protection against falling objects)
7.
ROPS frame (in accordance with ISO 3471:1994, rollover protection)
8.
Engine hood
9.
Rear frame

18
4.2 Technical specifications
The values in the table below are default data, based on the options your Pitbull is equipped with,
this may vary.
X24-36
X24-45
X27-36
X27-45
Wheelbase (A)
mm
1624
1624
1624
1624
Length without implement (B)
mm
3100
3100
3150
3150
Length with implement (C)
mm
3620
3620
3670
3670
Seat height (D)
mm
1240
1240
1240
1240
Total height (E)
mm
2140
2140
2140
2140
Maximum dump height (F)
mm
2250
2250
2250
2250
Maximum height with implement (G)
mm
3270
3270
3270
3270
Height up to the lifting pin (H)
mm
2830
2830
2830
2830
Tyre diameter (I)
mm
800
800
800
800
Undercut (J)
mm
30
30
30
30
Hauling angle
°
50
50
50
50
Tipping angle (L)
°
38
38
38
38
Maximum ramp angle
°
35
35
35
35
Machine width (N)
mm
1300/1500
1300/1500
1300/1500
1300/1500
Weight
kg
2400
2400
2700
2700
Outside turning radius (without attachment)
mm
2600
2600
2600
2600

19
4.3 Loading Diagrams
WARNING! When the wheels of the machine are steered sidewards, the load capacity
decreases. Try to straighten the machine as much as possible when lifting loads, avoid
sharp turns and take bends at a moderate speed.
The loading diagrams below have been calculated with the Pitbull positioned straight ahead. The
pallet fork is used, which can be ordered optionally with the Pitbull. The spoons of this pallet fork
have a length of 1000 mm. The indicated tipping load and recommended operating capacity are
indicated for objects where the centre of gravity rests exactly on the centre of the spoons of the
pallet fork.

20
5. Operation of the machine
In order to work safely and efficiently with the machine, it is important that all users are familiar with
the operation of the machine. Due to the different options with which the Pitbull can be equipped,
the images used may differ slightly.
NOTE! Familiarise yourself with the entire machine and all controls before starting to work
with the machine! If you have to do this while working, it will be too late.
Wheelhouse with dashboard
1
Indication: alternator not
charging the battery.
7
Indication: indicator and hazard
lights.
2
Indication: low oil pressure.
8
Indication: pre-heat.
3
Indication: coolant temperature
high.
9
Indication: reverse travel direction.
4
Indication: low fuel level.
10
Indication: parking brake applied.
5
Indication: sidelight.
11
Indication: driving direction
windscreen.
6
Indication: high beam.
12
Indication: locking differential.
