Super Boom Skid Steer Specifications
L150 L160 L170 L175 L180 L185 L190
Pag 1 of 1
MODEL L150 L160 L170 L175 L180 L185 L190
ENGINE
Make and model, New Holland N843H N844 N844T NH844LT 334/M2 334T/M2 445/M2
Type of fuel...............................................................................................................................................Diesel..........................................................................................................
Gross power @ R M, hp (kW) 38 (28) @ 3200 46 (34) @ 2900 52 (39) @ 2900 60 (45) @ 2900 63 (47) @ 2300 78 (58) @ 2300 80 (60) @ 2300
Net power @ R M, hp (kW) 36 (27) @ 3200 44 (33) @ 2900 50 (37) @ 2900 56 (42) @ 2900 59 (44) @ 2300 72 (54) @ 2300 74 (55) @ 2300
eak torque, lb.-ft. (N-m) @ R M 73 (99) @ 1700 101 (137) @ 1700 113 (153) @ 1700 128 (174) @ 1700 179 (243) @ 1400 228 (309) @ 1400 236 (320) @
1400
Number of cylinders 344 4334
Displacement, cu. in. (l) 91 (1.5) 121.7 (2.0) 121.7 (2.0) 135.3 (2.2) 204 (3.4) 204 (3.4) 274 (4.5)
DRIVE TRAIN
Max travel speed, fwd, mph (kph) 7.3 (11.8) 7.3 (11.8) 7.3 (11.8) 5.9 (9.5) 6.9 (11.1) 6.9 (11.1) 7 (11.3)
-with 2 speed transmission,
mph (kph) NA NA NA 10 (16.1) 11.3 (18.2) 11.3 (18.2) 11.4 (18.3)
Drive chain size 50/80 HD 80 HD 80 HD 80 HD 100 HD 100 HD 100 HD
Tire size 10.00x16.5 10.00x16.5 10.00x16.5 12.00x16.5 12.00x16.5 12.00x16.5 14.00x17.5
HYDRAULICS
Total flow, gpm (l/min) 11.6 (43.9) 15.1 (57.2) 17.2 (65.1) 17.2 (65.1) 19.3 (73.1) 19.3 (73.1) 21.9 (82.9)
Main relief pressure, psi (k a) 2500 (172) 2500 (172) 2500 (172) 2550 (176) 3050 (210) 3050 (210) 3050 (210)
Optional high flow, gpm (l/min) NA NA 30.3 (114.7) 30.3 (114.7) 34.7 (131.3) 34.7 (131.3) 37.3 (141.2)
PERFORMANCE / LOADER ARMS
Linkage geometry.................................................................................................................................Vertical lift ......................................................................................................
Rated operating load, lbs. (kg) 1,350 (612) 1,600 (726) 1,765 (801) 2,000 (907) 2,200 (998) 2,500 (1134) 2,800 (1270)
Bucket breakout force,, lbf (kN) 3,500 (1591) 3,712 (1687) 3,712 (1687) 4,312 (1956) 6,034 (2737) 7,670 (3479) 7,670 (3479)
Boom break out force, lbs. (kg) 2,400 (1089) 2,828 (1285) 2,828 (1285) 3,003 (1362) 4,194 (1902) 4,836 (2194) 6,229 (2825)
Max. dump angle at full height, degrees 45 45 45 43 45 45 45.3
Dump clearance at full height
discharge, in. (mm) 87.9 (2230) 92.1 (2340) 92.1 (2340) 95.4 (2420) 100 (2540) 100 (2540) 102 (2590)
Dump reach at full height
discharge, in. (mm) 25 (640) 29 (740) 29 (740) 29 (740) 32.5 (830) 32.5 (830) 32.3 (820)
Max. hinge pin height, in. (mm) 114.3 (2900) 115.5 (2930) 115.5 (2930) 119.7 (3040) 124.6 (3160) 124.6 (3160) 125.6 (3190)
Bucket rollback at carry position, degrees 36 37 37 37 37 37 37
DIMENSIONS
Length with bucket down, in. (mm) 120 (3050) 125 (3180) 125 (3180) 129.5 (3290) 139 (3530) 139 (3530) 145.7 (3700)
Width with bucket, in. (mm) 60 (1520) 60 (1520) 66 (1680) 72 (1830) 72 (1830) 72 (1830) 78 (1980)
Width over tires, in. (mm) 60 (1520) 65.6 (1670) 65.6 (1670) 70.8 (1800) 71.25 (1810) 71.25 (1810) 76.4 (1940)
Height to top of RO S, in. (mm) 73.4 (1860) 74.8 (1900) 74.8 (1900) 76 (1930) 77 (1960) 77 (1960) 79.6 (2020)
Wheelbase, in. (mm) 37.5 (950) 42.5 (1080) 42.5 (1080) 42.5 (1080) 48 (1220) 48 (1220) 51.5 (1310)
Ground clearance, in. (mm) 8.25 (210) 7.4 (190) 7.4 (190) 8.4 (210) 8 (200) 8 (200) 10.1 (260)
OTHER FEATURES
Standard RO S Tilt forward Tilt forward Tilt forward Tilt back Tilt forward Tilt forward Tilt forward
Self leveling bucket....................................................................................................................................Std. ..........................................................................................................
OPERATING WEIGHT, lbs. (kg) 4,500 (2042) 5,534 (2510) 5,540 (2513) 6,230 (2826) 7,095 (3218) 7,100 (3220) 7,755 (3518)
SERVICE CAPACITIES
Fuel tank, gal. (l) 8.75 (33) 14.4 (55) 14.4 (55) 14.4 (55) 18 (68) 18 (68) 21.5 (81)
Cooling system, gal. (l) 2.45 (9.3) 2.7 (10.2) 2.7 (10.2) 4.5 (17) 4.5 (17) 4.5 (17) 4.5 (17)
Hydraulic system total, gal. (l) 5 (18.9) 8.6 (32.6) 8.6 (32.6) 8.6 (32.6) 15 (57) 15 (56.8) 15 (56.8)
L150 - Equipped with 60" 11.5 cu. ft. dirt and foundry bucket and 10.00 x 16.5 tires L180 - Equipped with 72" 17.1 cu. ft. low profile bucket and 12.00 x 16.5 tires
L160 - Equipped with 60" 11.5 cu. ft. low profile bucket and 10.00 x 16.5 tires L185 - Equipped with 72" 16.7 cu. ft. dirt and foundry bucket and 12.00 x 16.5 tires
L170 - Equipped with 66" 15.2 cu. ft. dirt and foundry bucket and 10.00 x 16.5 tires L190 - Equipped with 78" 25.8 cu. ft. dirt and foundry bucket and 14.00 x 17.5 tires
L175 - Equipped with 72" 17.1 cu. ft. low profile bucket and 12.00 x 16.5 tires
Safety begins with a th r ugh understanding f
the equipment. Always make sure y u and
y ur perat rs read the Operat r’s Manual
bef re using the equipment. Pay cl se
attenti n t all safety and perating
decals and never perate machiner y
with ut all shields, pr tective devices
and structures in place.
Design, materials and/ r specificati ns are subject t
change with ut n tice and with ut liability theref r.
Specificati ns are applicable t units s ld in Canada, the
United States, its territ ries and p ssessi ns, and may
var y utside these areas.
