Pittsburgh Automotive 67338 Assembly instructions

Visit our website at: http://www.harborfreight.com
Email our technical support at: [email protected]
Owner’s Manual & Safety Instructions
Save This Manual Keep this manual for the safety warnings and precautions, assembly,
operating, inspection, maintenance and cleaning procedures. Write the product’s serial number in the
back of the manual near the assembly diagram (or month and year of purchase if product has no number).
Keep this manual and the receipt in a safe and dry place for future reference. 21d
When unpacking, make sure that the product is intact
and undamaged. If any parts are missing or broken,
please call 1-888-866-5797 as soon as possible.
Copyright© 2021 by Harbor Freight Tools®. All rights reserved.
No portion of this manual or any artwork contained herein may be reproduced in
any shape or form without the express written consent of Harbor Freight Tools.
Diagrams within this manual may not be drawn proportionally. Due to continuing
improvements, actual product may differ slightly from the product described herein.
To ol s r eq ui r ed f o r as s em bl y a nd se rvice m ay not be in cluded.
Read this material before using this product.
Failure to do so can result in serious injury.
SAVE THIS MANUAL.

Page 2 For technical questions, please call 1-888-866-5797. Item 67338
Specifications
Rated Capacity 1500 lb. per dolly
Casters
(per dolly)
Two swivel casters
Two swivel casters with brakes
Important Safety Information
1. Study, understand, and follow all
instructions before operating this device.
2. Do not exceed rated capacity.
3. Use only on hard level surface.
4. Before moving a load, assure that
the load is centered and secured
with a load restraint device.
5. No alterations shall be
made to this product.
6. Wear ANSI-approved safety goggles
and heavy-duty work gloves during use.
7. Keep clear of load’s path while
placing on and removing from
dollies, and while moving.
8. Use as intended only. Do not use for
aircraft purposes. Use only in pairs.
9. Inspect before every use; do not
use if parts loose or damaged.
10. Be aware of dynamic loading! Sudden
load movement may briefly create
excess load causing product failure.
11. Use two Vehicle Dollies to support
the front or rear end of the vehicle.
Use four Dollies (two pairs) to
support entire vehicle.
12. Read vehicle owner’s manual
and instruction manual for
Jack (not included) for proper
jacking positions before use.
13. Position carrying handles to outer
side of car; do not work under
vehicle while on Dollies.
14. If used for extended storage
under vehicle tires, periodically
lift vehicle to rotate tires.
15. Keep lifting area free of spectators
and do not allow anyone into
vehicle while on Dollies.
16. Use wheel chocks when raising front
of vehicle for placement onto Dollies.
17. Assemble only according to instructions.
Improper assembly can create hazards.
18. This product is not a toy. Do not allow
children to play with or near this item.
19. Maintain product labels and nameplates.
These carry important safety
information. If unreadable or
missing, contact Harbor Freight Tools
for a replacement.

Page 3For technical questions, please call 1-888-866-5797.Item 67338
Instructions
Read the ENTIRE IMPORTANT SAFETY INFORMATION section at the
beginning of this document including all text under subheadings therein
before set up or use of this product.
Assembly
1. Insert Brake Casters (2) and Casters (3)
through holes in Frame (1), making
sure Brake Casters are on same
outer side. Fasten using Washers (6),
Lock Washers (5) and Nuts (4).
2. Once Dollies are assembled, roll Dollies
along surface to verify all connections
are secure and Dollies roll freely.
Operation
1. Chock opposite end wheels
to keep vehicle from rolling.
Chocks sold separately.
2. Place Dolly in position under raised
front or rear wheels and lower
vehicle slowly onto Dollies.
3. To move a vehicle supported by
four Dollies: remove wheel chocks,
unlock Casters, and use Handles
to guide vehicle to location.
4. Lock casters once vehicle is in location.
Parts List and Diagram
Part Description Qty.
1 Frame with Handle 2
2 Caster With Brake 4
3 Caster 4
4 Nut 8
5 Lock Washer 8
6 Washer 8
Record Serial Number Here:
Note: If product has no serial number,
record month and year of purchase instead.
Note: Some parts are listed and
shown for illustration purposes only,
and are not available individually
as replacement parts. Specify UPC
792363673389 when ordering parts.
Handle

PLEASE READ THE FOLLOWING CAREFULLY
THE MANUFACTURER AND/OR DISTRIBUTOR HAS PROVIDED THE PARTS LIST AND ASSEMBLY
DIAGRAM IN THIS DOCUMENT AS A REFERENCE TOOL ONLY. NEITHER THE MANUFACTURER
OR DISTRIBUTOR MAKES ANY REPRESENTATION OR WARRANTY OF ANY KIND TO THE
BUYER THAT HE OR SHE IS QUALIFIED TO MAKE ANY REPAIRS TO THE PRODUCT, OR
THAT HE OR SHE IS QUALIFIED TO REPLACE ANY PARTS OF THE PRODUCT. IN FACT, THE
MANUFACTURER AND/OR DISTRIBUTOR EXPRESSLY STATES THAT ALL REPAIRS AND PARTS
REPLACEMENTS SHOULD BE UNDERTAKEN BY CERTIFIED AND LICENSED TECHNICIANS,
AND NOT BY THE BUYER. THE BUYER ASSUMES ALL RISK AND LIABILITY ARISING OUT OF
HIS OR HER REPAIRS TO THE ORIGINAL PRODUCT OR REPLACEMENT PARTS THERETO,
OR ARISING OUT OF HIS OR HER INSTALLATION OF REPLACEMENT PARTS THERETO.
Limited 90 Day Warranty
Harbor Freight Tools Co. makes every effort to assure that its products meet high quality
and durability standards, and warrants to the original purchaser that this product is free from
defects in materials and workmanship for the period of 90 days from the date of purchase.
This warranty does not apply to damage due directly or indirectly, to misuse, abuse, negligence
or accidents, repairs or alterations outside our facilities, criminal activity, improper installation,
normal wear and tear, or to lack of maintenance. We shall in no event be liable for death,
injuries to persons or property, or for incidental, contingent, special or consequential damages
arising from the use of our product. Some states do not allow the exclusion or limitation of
incidental or consequential damages, so the above limitation of exclusion may not apply to you.
THIS WARRANTY IS EXPRESSLY IN LIEU OF ALL OTHER WARRANTIES, EXPRESS OR
IMPLIED, INCLUDING THE WARRANTIES OF MERCHANTABILITY AND FITNESS.
To take advantage of this warranty, the product or part must be returned to us with transportation
charges prepaid. Proof of purchase date and an explanation of the complaint must accompany
the merchandise. If our inspection verifies the defect, we will either repair or replace
the product at our election or we may elect to refund the purchase price if we cannot readily
and quickly provide you with a replacement. We will return repaired products at our expense,
but if we determine there is no defect, or that the defect resulted from causes not within
the scope of our warranty, then you must bear the cost of returning the product.
This warranty gives you specific legal rights and you may also
have other rights which vary from state to state.
26541 Agoura Road • Calabasas, CA 91302 • 1-888-866-5797
