Pixelfly NEX-MC10 User manual

USER MANUAL
NEX-MC10
IP Control Box

1
Important Safety Information
1. Read, follow, and keep these instructions.
2. Heed all warnings.
3. Do not use this product near water. Keep away from wet places, such as: spas, pools,
sinks, laundries, wet basements, etc.
4. When cleaning, unplug the unit and wipe with a dry cloth. Do not use damp cloths,
cleaning fluids, or aerosols which may result in electric shock, fire, or unit damage.
5. Operate this product using only the included power supply and/or power cable. Use of an
unapproved power implement may impair performance, damage the product, or cause
fires.
6. Do not block any ventilation openings. Install in accordance with the manufacturer’s
instructions.
7. Do not install or place this product near any heat sources such as radiators, heat
registers, stoves, or other apparatus (including amplifiers) that produce heat.
8. Protect the power cord from being walked on or pinched particularly at plugs,
convenience receptacles, and the point where they exit from the product.
9. Only use attachments/accessories specified by Pixelfly to avoid fire, shock, or other
hazards.
10. To reduce the risk of electric shock and/or damage to this product, never handle or touch
this unit or power cord if your hands are wet or damp. Do not expose this product to rain
or moisture.
11. Unplug this product during lightning storms or when unused for long periods of time.
12. Never open, remove unit panels, or make any adjustments not described in this manual.
Attempting to do so could result in electric shock, damage to the unit, or other hazards.
CAUTION
The exclamation point within an equilateral triangle is
intended to alert the user to the presence of important
operating and maintenance (servicing) instructions in
the literature accompanying the appliance.
The lightning flash with arrowhead symbol, within an
equilateral triangle, is intended to alert the user to the
presence of uninsulated dangerous voltage within the
product’s enclosure that may be of sufficient magnitude
to constitute a risk of electric shock to persons.
TO REDUCT THE RISK OF ELECTRIC SHOCK
DO NOT OPEN ENCLOSURE OR EXPOSE
TO RAIN OR MOISTURE.
NO USER-SERVICEABLE PARTS
INSIDE REFER SERVICING TO
QUALIFIED SERVICE PERSONNEL.

2
Contents
Important Safety Information............................................................................ 1
Introduction...................................................................................................... 3
Features ................................................................................................... 3
Package Contents .................................................................................... 3
Panel Description............................................................................................. 4
Front Panel ............................................................................................... 4
Rear Panel................................................................................................ 5
Specifications................................................................................................... 7
Installation........................................................................................................ 8

3
Introduction
NEX-MC10 is an IP control box that is used as an A/V control device for
controlling, configuring and managing encoders and decoders on the local
area network. It integrates two Ethernet ports and two RS232 ports, offering
integration-friendly control features -- LAN (Web GUI & Telnet). It also can be
used with a third-party controller to provideasimple, flexible control and
management options. It can automatically search and display encoders and
decoders. It is designed to be compatible with the configuration file from PC
configurator (PF-IP Console) and use the imported configuration file to
perform operations on encoders and decoders such as matrix and video wall.
Features
IP control via LAN (Web GUI & Telnet) and a third-party controller
Features two Ethernet ports and two RS232 ports
Discover encoders and decoders automatically
Supports matrix switching between encoders and decoders
Compatible with the configuration file from PC configurator to quickly
perform operations on encoders and decoders, such as matrix and video
wall
Web configuration page
Package Contents
1 x IP Control Box
1 x DC 12V Power Adapter (with US, UK, EU, AU pins)
1 x Phoenix Male Connector (3.5 mm, 6 Pins)
2 x Mounting Brackets (with Screws)
5 x Label Cards (49 mm x 15 mm)
1 x Quick Start Guide

4
Panel Description
Front Panel
43
2
1
No.
Name
Description
1 Label Card
Location
Inserts a supplied label card intended for writing short
notes such as an IP address.
2 STATUS
LED
Blue: When NEX-MC10 is working properly.

Off: When NEX-MC10 is powered off or is booting.
3 POWER
LED
Red: When NEX-MC10 is powered on.

Off
: When NEX-MC10 is powered off.
4 RESET
When NEX-MC10 is powered on, use a pointed stylus
to hold down RESET button for five or more seconds,
and then release it. It will reboot and restore to its
default settings.
Note: When the default settings are restored, your
custom data is lost. Therefore, exercise caution when
using the RESET button.

5
Rear Panel
3
12
No.
Name
Description
1 LAN 1-2
1xLAN1 (AV/POE):
Connects to a switch for communication with encoders
and decoders on the same network.
Default Protocol
IP Address
169.254.1.1
Subnet mask 255.255.0.0
Gateway
169.254.1.254
DHCP
Off
Link speed
and duplex
Auto detected
Ethernet port indicators :
Green Link LED: this green colored LED lights
when NEX-MC10 actively communicates with a
network.
Amber Activity LED: this amber colored LED
flickers as NEX-MC10 is connected to a network.
1 x LAN2 (C):
Connects to a third-party controller for controlling,
configuring and managing NEX-MC10, encoders and
decoders through LAN control (Web GUI & Telnet).
Default Protocol
IP Address
192.168.11.243
Subnet mask
255.255.0.0
Gateway
192.168.11.1
DHCP
Off
Link speed
and duplex
Auto detected

6
No.
Name
Description
Ethernet port indicators : same as above.
Note:
•Only LAN1 (AV/POE) port supports PoE. You can
connect it to a PoE switch to receive power,
eliminating the need for a nearby power outlet.
•We would recommend that you power NEX-MC10
using either a power adapter or a PoE switch
instead of using both them at the same time. For
example, if you want to use a power adapter,
ensure that PoE function of the connected LAN
port in the switch is disabled or a non-PoE switch
is used.
2 RS-232
Left (DEBUG): Pins TX, RX, G are used for device
troubleshooting only.
RS232 Parameters
Baud Rate 115 200 bps
Data Bits
8 bits
Parity
None
Stop Bits
1
Middle (Control):
Pins G, RX, TX are used for
controlling, configuring and managing NEX-MC10,
encoders and decoders through RS232 software or a
third-party controller.
RS232 Parameters
Baud Rate 9 600 bps
Data Bits
8 bits
Parity
None
Stop Bits
1
Right (Power): Pins G, 12V are used for providing a
12VDC 0.5A output.
Note: Please connect the correct pins for device debug
and control. When NEX-MC10 is powered by a power
adapter, if you connect control terminal to control port
after first connection with the debug port, you need to
reboot NEX-MC10 for device control process.
3
DC 12V
Connects to a supplied 12 VDC 1 A power adapter.

7
Specifications
Technical
Input/Output Port
1 x LAN1 (AV/POE) (10/100 Mbps)
1 x LAN2 (C) (10/100 Mbps)
2 x RS232
LED 1 x STATUS LED
1 x POWER LED
Button
1 x RESET Button
Control Method LAN (Web GUI & Telnet), RS232 and a third-party
controller
General
Operating Temperature
0°C to 45°C (32°F to 113°F)
Storage Temperature
-20°C to 70°C (-4°F to 158°F)
Humidity
10% to 90%, non-condensing
ESD Protection
Human-body Model:
±8kV (Air-gap discharge)/
±4kV (Contact discharge)
Power Supply
12 VDC 1A
Power Consumption
•4.5W Max. (without outputting 12V 0.5A using RS232
port)
•10.5W Max. (with outputting 12V 0.5A using RS232
port)
Device Dimension
(W x H x D)
93.2 mm x 26 mm x 138.7 mm/3.67'' x 1.02'' x 5.46''
Net Weight
0.38kg/0.84lbs

8
Installation
Note: Before installation, please ensure the device is disconnected from the
power source.
Steps to install the device in a suitable location:
1. Remove the four screws from the two side panels.
2. Position and install the mounting brackets on the two side panels using
the mounting screws provided in package.
3. Mount and secure the device to a surface or a suitable location with the
mounting screws (provided by others).

[e-mail] [phone]
USER MANUAL
NEX-MC10
IP Control Box
