PL Systems Washroom DV2100 User manual

Please read these instructions carefully and store in a
safe place for future reference.
DV2100
As part of the P+L Systems®Washroom brand of
washroom hygiene products, DV2100 is a robust hand
dryer, available in plastic, white metal or brushed
stainless steel.
Contents of package
- 1 x DV2100 hand dryer
- 1 x M4 Hex key
- 4 x Wall mounting screws and wall plugs
- 1 x Mounting template
WARNING
- DV2100 should only be installed by qualified
electricians.
- This appliance must be correctly earthed. (Class 1)
- DV2100 is not designed for domestic use.
- Do not install this hand dryer above sources of water
such as sinks or taps.
- The mains cable must be a ‘Type Y’ cable, and if
damaged it must be replaced by a specialist mains
cable available from your supplier.
POSITIONING
DV2100 should be mounted at the appropriate height
for the application as shown in the recommended
mounting height table.
Where two or more dryers are being installed, ensure
there is at least 600mm between each dryer.
CLEANING
CLEANING SHOULD BE CARRIED OUT BY SERVICE
PERSONNEL ONLY, AFTER ENSURING THAT THE UNIT IS
DISCONNECTED FROM THE MAINS SUPPLY.
It is recommended that cleaning is carried out regularly
every month. Remove the front guard by releasing the
two fixing screws. Carefully remove any build up of dust
from within the dryer mechanism. Then replace the
guard and wipe down the exterior of the dryer with a
damp cloth, removing any build up of dirt. Never use
abrasive cleaning liquids to clean the dryer. Ensure the
unit is completely dry before reconnecting the power
supply.
GUARANTEE
DV2100 has a two year guarantee and if maintained as
recommended in these instructions should continue to
work for many years.*
*Does not cover breakdown due to misuse, incorrect operation or use in an incorrect
application.
DISPOSAL
DV2100 falls under the scope of the ‘WEEE Directive’
(2002/96/EC) and should be appropriately disposed of
at the end of the products life.
RECOMMENDED MOUNTING HEIGHTS
USER HEIGHT
Men 109cm
Women 104cm
Children, ages 11 - 17 99cm
Children, ages 3 - 10 84cm
Wheelchair users 89cm
DV2100
Robust Hand Dryer
DV2100
minimum 600mm
recommended
mounting
height
WIRING OPTIONS
Discreet wiring Simple wiring

SPECIFICATION
Unit DV2100P
Voltage 230V ~ 50Hz
Dimensions(mm) 252 x 273 x 207
Weight 2.5 Kg
Power Draw 2,100 w
Motor Speed 5,000 RPM
Drying Time 25 seconds
Noise Level 75 db
Unit DV2100W
Voltage 230V ~ 50Hz
Dimensions(mm) 252 x 273 x 207
Weight 3.2 Kg
Power Draw 2,100 w
Motor Speed 5,000 RPM
Drying Time 25 seconds
Noise Level 75 db
Unit DV2100S
Voltage 230V ~ 50Hz
Dimensions(mm) 252 x 273 x 207
Weight 2.9 Kg
Power Draw 2,100 w
Motor Speed 5,000 RPM
Drying Time 25 seconds
Noise Level 75 db
INSTALLATION
INSTALLATION SHOULD BE CARRIED OUT BY SERVICE PERSONNEL ONLY, IN LINE WITH
LOCAL WIRING REGULATIONS. ENSURE POWER IS ISOLATED FROM THE
CONNECTION POINT BEFORE STARTING THE INSTALLATION PROCESS.
The mains cable can either enter from behind the dryer for discreet installation
(Requires a sunken mains cable) or from below for simple installation (Does not
require a sunken mains cable.)
To install DV2100...
1. Remove the dyer front guard by first unscrewing the three retaining screws
holding the guard in position, using the supplied hex key.
2. Offer the hand dyer backplate up to the mounting surface and mark the four
fixing points through the holes in the backplate.
3. Drill the four marked fixing holes and insert the supplied wall plugs.
4. Offer the dryer backplate up to the wall, and insert the four fixing screws through
the backplate into the wall plugs.
5. Connect the three wires coming from the mains supply to the terminal block,
ensuring the correct locations are used for each wire as described below.
5. Replace the front guard and loosely insert the three retaining screws, before
tightening them all to fix the guard in position.
6. Use an appropriate silicone sealant and culkling gun to apply a silicone seal
around the entire dryer, between the front guard and mounting surface. This will
both further secure the front guard in place and protect from water ingress.
USING DV2100
DV2100 incorporates no touch sensor activation for hygienic use. Before inserting
hands under the dryer, shake off excess water. The dryer will stop activation when
hands are removed.
Installation
WIRING MARKINGS
Terminal Block Marking Standard wire colour
L (Live) Brown
N (Neutral) Blue
(Earth) Green & yellow
2
1
R3 07/14
C2014
P+L Systems Ltd
Information provided on these instructions is modified and
updated from time to time. This is due to the constant
redevelopment of our products. As such, it is not intended that
you should rely on it or that it should form part of any contract.
Sterling House
Grimbald Crag Close
Knaresborough
North Yorkshire
HG5 8PJ UK
T [phone]
F [phone]
W www.pandlsystems.com
E [email protected]
WEEE Compliance No. WEE/GF0661QR
