CONTENTS LIST
PAGE CONTENTS
1
2 NOTE OF DISCS
3 ACCESSORY INCLUDED
4 INSTALLATION
6 DETACHABLE CONTROL PANEL
7 WIRING DIAGRAM
8 CONTROL PANEL FUNCTION
9 BASIC OPERATIONS
10 MENU OPERATION
12 AUDIO OPERATION
13 TUNER OPERATION
14 RDS OPERATION
15 CD /MP3/WMA OPERATION
19 USB OPERATION
20 MEMORY CARD OPERATION
21 RECORDING OPERATION
24 MUSIC FILES TRANSFERRING
26 MUSIC FILES ERASING
28 FILES MANAGER
29 iPod OPERATION
31 BLUETOOTH HAND FREE OPERATION
42 REMOTE FUNCTION
43 SPECIFICATIONS
44 TROUBLE SHOOTING
2
CDE VERSION
1. NOTE OF DISCS
MOISTURE CONDENSATION
NOTES ON CDs
P. 2
P. 3
P. 4
P. 1
P. 5
P. 6
P. 7
1.
2.
3.
4.
5.
NOTES ON DISCS
There are paste residue.
Ink is sticky (P.5).
Stickers that are beginning
to peel away, leaving a
sticky residue (P.6).
Labels are attached (P.7).
On a rainy day or in a very damp area, moisture may condense on the lenses inside the unit.
Should this occur, the unit will not operate properly. In such a case, remove the disc and wait for
about an hour until the moisture has evaporated.
A dirty or defective disc may cause sound
dropouts while playing. To enjoy optimum
sound, handle the disc as follows.
Handle the disc by its edge. To keep the disc
clean, do not touch the surface (P.1).
If you use the discs explained below, the
sticky residue can cause the CD to stop
spinning and may cause malfunction or ruin
your discs.
Do not use second-hand or rental CDs that
have a sticky residue on the surface (for
example, from peeled-off stickers or from
ink, or glue leaking from under the stickers).
Do not stick paper or tape on the disc (P.2).
Before playing, clean the discs with an
optional cleaning cloth. Wipe each disc from
the centre out (P.4).
Do not use solvents such as benzene,
thinner,commercially available cleaners, or
antistatic spray intended for analog discs.
Do not expose the discs to direct sunlight or
heat sources such as hot air-ducts, or leave
them in a car parked in direct sunlight where
there can be a considerable rise in
temperature inside the car (P.3).
Do not use rental CDs with old labels that
are beginning to peel off.
Do not use your CDs with labels or stickers
attached.
**************
*******
*******
*******
*******
*******
*******
*******
*******
****
*******
******* *******
*******
Do Not Use Special Shape CDs
Be sure to use round shape CDs only for
this unit and do not use any special shape
CDs. Use of special shape CDs may cause
the unit to malfunction.(P.8).
Be sure to use CDs with disc mark
Only for this unit.
RECORDABLE
REWRITABLE
P. 8
CD-Rs and CD-RWs which have not
undergone finalization processing cannot
be played. (For more information on
finalization processing, refer to the manual
for your CD-R/CD-RW writing software or
CD-R/CD-RW recorder.) Additionally,
depending on the recording status, it may
prove impossible to play certain CDs
record on CD-R or CD-RW.
TEXT
2. ACCESSORY INCLUDED
3
When first unpacking your new full detachable DVD head unit, please check first that the package
contains all of the items below. If something is missing, contact the store where you purchased
the player.
Remote control
Lithium Battery
3V
+
2
2
0
R
5
C
Half Sheeve
Insert Key
1. Dashboard
2. Nut (5mm)
3. Spring washer
4. Screw (4X12mm)
5. Screw
6. Support Strap
7. Plain washer
1
7
4
2
3
5
6
Owner’s
manual
Owner’s Manual
Warranty
Card
Warranty Card
4
3. INSTALLATION
Before finally installing the unit, connect the wiring temporarily and make sure it is all
connected up properly and the unit and system work properly.
Use only the parts included with the unit to ensure proper installation. The use of
unauthorized parts can cause malfunctions.
Consult with your nearest dealer if installation requires the drilling of holes or other
modifications of the vehicle.
Install the unit where it does not get in the driver's way and cannot injure the passenger if
there is a sudden stop, like an emergency stop.
If installation angle exceeds 30 from horizontal, the unit might not give its optimum
performance.
Avoid installing the unit where it would be subject to high temperature, such as from direct
sunlight, or from hot air, from heater, or where it would be subject to dust dirt or excessive
vibration.
Be sure to remove the front panel before installing the unit.
DIN FRONT/REAR-MOUNT
This unit can be property installed either from “Front” (conventional DIN Front-mount) or “Rear”(DIN
Rear-mount installation, utilizing threaded screw holes at the sides of the unit chassis). For details,
refer to the following illustrated installation methods A and B.
1. Dashboard
2. Holder
After inserting the half sleeve into the
dashboard, select the appropriate tab
according to the thickness of the
dashboard material and bend them
inwards to secure the holder in place.
3. Screw
1
7
4
23
5
61. Dashboard
2. Nut (5mm)
3. Spring washer
4. Screw (4x12mm)
5. Screw
6. Support Strap
Be sure to use the support strap to secure
the back of the unit in place. The strap can
be bent by hand to the desired angle.
7. Plain washer
182
53
12
3
DIN FRONT-MOUNT (Method A)
Installation the unit
5
DIN REAR-MOUNT (METHOD B)
Installation using the screw holes on the sides of the unit.
Fastening the unit to the factory radio mounting bracket.
1. Select a position where the screw
holes of the bracket and the screw
holes of the main unit become
aligned (are fitted) and tighten the
screws at 2 places on each side.
2. Screw
3. Factory radio mounting bracket.
4. Dashboard or Console
5. Hook (Remove this part)
Note: the mounting box, outer trim ring,
and half-sleeve are not used for method
B installation.
5
2
4
3
25
a. Frame
b. Insert fingers into the groove in the
front of frame and pull out to remove
the frame. (When re-attaching the
frame, point the side with a groove
down wards and attach it.)
c. Insert the levers supplied with the
unit into the grooves at both sides of
the unit as shown in figure until they
click. Pulling the levers makes it
possible to remove the unit from the
dashboard.
Trim Plate Installation:
Push the trim plate against the chassis until it is fitted.
You must do this before you install the front panel, otherwise it can't be attached.
Removing the unit
a
b
c
6
4. DETACHABLE CONTROL PANEL (D.C.P.)
Removing The Detachable Control Panel (D.C.P.).
1. Turn the power off
2. Press the D.C.P. release button
3. Remove the D.C.P.
PANEL RELEASE
BUTTON
B
A
2
Attaching the DCP
CAUTION
1. Attach the panel at the right side first, with
point B on the main unit touching point A on
the D.C.P. (As shown on the diagram).
2. Then press the left side of D.C.P. onto the main
unit until a “click” sound is heard.
DO NOT insert the D.C.P from the left side. Doing so may damage it.
The D.C.P can easily be damaged by shocks. After removing it, place it in a protective case and be careful not
to drop it or subject it to strong shocks.
When the release button is pressed and the D.C.P is unlocked, the car's vibrations may cause it to fall. To
prevent damage to the D.C.P, always store it in a protective case after detaching it.
The rear connector that connects the main unit and the D.C.P is an extremely important part. Be careful not to
damage it by pressing on it with fingernails, pens, screwdrivers, etc.
Note:
If the D.C.P is dirty, wipe off the dirt with soft,
dry cloth only. And use a cotton swab soaked
in isopropyl alcohol to clean the socket on the
back of the D.C.P.
RESETTING THE UNIT:
After releasing the front panel, use a pencil or any non-metalic object to press & hold the
reset button for five seconds to reset the unit.
Socket
7
FUSE
L-CH
(See Figure 2)
R-CH
L-CH
R-CH
ISO
CONNECTOR
5. WIRING DIAGRAM (20 PIN + ISO PLUG)
20-PIN
AUDIO/POWER
HARNESS
(See Figure 1)
PIN(B8) GREEN/BLACK
PIN(B1) VIOLET
PIN(B4) GREY/BLACK
PIN(B2) VIOLET/BLACK
PIN(B3) GREY
PIN(A4) YELLOW
PIN(A7) RED
PIN(A5) BLUE
PIN(A8) BLACK
PIN(B7) GREEN
PIN(B6) WHITE/BLACK
PIN(B5) WHITE
ISO CONNECTOR 4PIN+8PIN
FEMALE WITH MALE TERMINAL
1122
3344
77
5566
8877
55
33
11
88
66
44
22
Figure 2
CONNECTOR B
CONNECTOR A
FUNCTION/LABEL
LEFT REAR SPEAKER (+)
LEFT REAR SPEAKER (-)
RIGHT REAR SPEAKER (+)
RIGHT REAR SPEAKER (-)
RIGHT FRONT SPEAKER (+)
LEFT FRONT SPEAKER (+)
LEFT FRONT SPEAKER (-)
RIGHT REAR PRE-AMP LINE OUT
REAR PRE-AMP LINE OUT COMMON
RIGHT FRONT SPEAKER (-)
LEFT REAR PRE-AMP LINE OUT
FRONT PRE-AMP LINE OUT COMMON
RIGHT FRONT PRE-AMP LINE OUT
LEFT FRONT PRE-AMP LINE OUT
18 RED
17 WHITE
16 BLACK
15 YELLOW
20 WHITE
19 BLACK
14 BLUE
CHASSIS GROUND
CONTANT 12 VOLTS (+)
POWER ANTENNA
1 GREY/BLACK
7 GREEN/BLACK
4 VIOLET/BLACK
12 WHITE/BLACK
8 RED
6 GREEN
2 GREY
3 VIOLET
11 WHITE
10 RED
9 BLACK
5
13
IGNITION(ACC)
WIRE COLOR
PIN
RIGHT REAR SPEAKER (-)
B2 VIOLET/BLACK
GREEN/BLACK
GREY/BLACK
WHITE/BLACK
GREEN
GREY
WHITE
B3
B4
B5
B6
B7
B8 LEFT REAR SPEAKER (-)
RIGHT FRONT SPEAKER (-)
LEFT FRONT SPEAKER (-)
LEFT REAR SPEAKER (+)
LEFT FRONT SPEAKER (+)
RIGHT FRONT SPEAKER (+)
ISO CONNECTOR WIRING CHART
WIRE COLOR
RED
YELLOW
BLACK
VIOLET
PIN
A4
A5
A7
A8
B1
FUNCTION/LABEL
POWER ANTENNA
RIGHT REAR SPEAKER (+)
IGNITION(ACC)
CONTANT 12 VOLTS (+)
GROUND
BLUE
R-CH
L-CH
RED
WHITE
YELLOW AUX LINE IN
ANTENNA
JACK
ANTENNA
EXTENDER
CABLE
SUB WOOFER
RCA-TO-RCA CABLES
(not supplied)
WHITE
BLUE
SUB
WOOFER
AMP
RCA-TO-RCA CABLES
(not supplied)
GREY
REAR LINE OUT
BLACK
FRONT LINE OUT
WHITE
RED
WHITE
RED
iPod
iPod ready cable
WHITE
8
6. CONTROL PANEL FUNCTION(RDS+BLUETOOTH+iPOD)
12 13 14 15 16 17 10
9
3
7
1
4
6
58
219
20
21 18 11
22 23
OPERATIONS:
Power
Eject
Panel release button
Audio
Menu Enter
Source
Encod er Volume
Band Fi le/Folde r
Search
Sub- W AF
TA
PTY
Recor d
Copy
ix-Ba ss
PS AS ID3
iPod
informati on
iPod
Search
M1
M2
M3
M4
M5
M6
Memory 1
Memory 2
Memory 3
Memory 4
Memory 5
Memory 6
Pause
/Play
Pause
/Play
Intro Folder
Intro
Repeat Folder
Repeat
Repeat Album
Repeat
Random
Fol der
Rando m
Shuffle
Album
Shuffle
Folder
Down
Folder
Up
Display
Seek Up
Track/File
Up
Fast
Forward
Tune Up
Seek
Down
Tune
Down
Track/File
Down
Fast
Backwa rd
USB Cover / Socket
File
Erase
iPod
KEY
SYSTEM TUNER CD/MP3/W MA BLUETOOTH
1
2
4
5
6
7
8
9
10
11
12
13
14
15
16
17
18
19
20
21
3
Short
Press
Long
Press
Short
Press
Long
Press
Short
Press
Long
Press
Short
Press
Long
Press
Short
Press
Long
Press
Phone
Answer Dial
Call
Trans fer
Clear
File Up Fast
Forward
Fast
Backwa rd
File Down
22
Mute
Dial
23
Menu
LO/DX
Enter
9
5) MODE BUTTON (MODE)
Press this button to remove the control panel.
7. BASIC OPERATIONS
3) PANEL RELEASE BUTTON (REL)
1) POWER ON/OFF BUTTON ( )
Press POWER button or any other button on the front of the radio to turn the unit on. Press
PO WER bu t to n ag a in to t ur n th e un it o ff .
22) MUTE BUTTON (MUTE)
Press the mute button momentarily to mute the audio volume, and "Mute" will flash in the
display. Press the mute button again to restore volume to the previous setting.
8) SUB-WOOFER (SUB-W)
Long press the SUB-W button to activate the Subwoofer function On, and “Subwoofer” will
appear on the LCD display for 3 seconds. press the SUB-W button again to turn off the
Subwoofer function.
10) iX-BASS BUTTON (iX-Bass )
Long press the iX-Bass button to turn on the function, and “iX-Bass” will appear in
the LCD display for 3 seconds. Press the iX-Bass button again to turn off the function
iX-Bass
iX-Bass
Press MODE button to select a different mode of operation as indicated on the display
panel. Available modes include Tuner, CDP, USB Host, SD/MMC, iPod and Aux Line In .
6) ENCODER VOLUME BUTTON
To increase the volume, rotate the volume control decrease the volume, rotate
the volume control counter clockwise.When volume is adjusted, the volume level will be
shown on the display panel as a number ranging from 0 (lowest) to 46 (highest).
clockwise. To
AUX INPUT
Connect the external signal to the RCA line in jack located at the rear of the press
Mode button to select Aux mode. Press Mode Button again to cancel Aux Mode and return
to previous mode.
unit, then
