Planet Audio PABC50D User manual

UNIVERSAL BLUETOOTH®
CLASS D MICRO AMP
SOURCE UNIT
PABC50D
USER MANUAL
QUICK INSTALLATION GUIDE
PABC50D
USER MANUAL
QUICK INSTALLATION GUIDE
UNIVERSAL BLUETOOTH®CLASS D MICRO AMP
SOURCE UNIT
PRINTED IN CHINA
VER:1.0 EN
iPod / iPhone are trademarks of Apple Inc. registered in the U.S. and other countries.
PLANET AUDIO is not a󰀩liated with Apple Inc.
Specications subject to change without prior notice.
1016
Flat Subwoofer
PX12
2012
www.planetaudiousa.com/technical-support
1.888.990.1236 Toll-free
1.805.988.0215 Local Main
Flat Subwoofer
PX12
2012
PABC50D-UMv1.0.indd 1 9/18/2016 5:06:45 PM

EN EN
Congratulations
on your new purchase of the
PABC50D
Please read through these instructions carefully so you will
know how to operate your model properly. After you have
nished reading the instructions, keep this document in a
safe place for future reference.
INTRODUCTION .........................................................................1
WHAT’S IN THE BOX .................................................................2
IMPORTANT SAFETY PRECAUTIONS .......................................3
INSTALLATION PRECAUTIONS .................................................4
WIRING .........................................................................................5
MOUNTING METHODS ..............................................................6
GETTING TO KNOW YOUR PABC50D .......................................7
BLUETOOTH OPERATION ........................................................8
BLUETOOTH RECONNECTION ...............................................10
BLUETOOTH STREAMING CONTROL ...................................11
AUX-IN .......................................................................................12
TROUBLE SHOOTING ..............................................................13
SPECIFICATIONS ......................................................................13
All rights reserved. No part of this publication may be reproduced,
distributed, or transmitted in any form or by any means, including
photocopying, recording, or other electronic or mechanical methods,
without the prior written permission of PLANET AUDIO.
Copyright © 2016 PLANET AUDIO
All trademarks are the property of their respective owners.
PLANET AUDIO has no a󰀩liation with these companies.
TABLE OF CONTENTS
The PABC50D is a universal
Bluetooth®audio source unit controller
with integrated 2CH Class D amplier. Designed for
Android / iOS / Windows Smart devices.
The PABC50D conveniently expands your existing
sound system from one small package. Rear RCA
outputs connect direct to your larger ampliers for
extending your system. You can easily control your
favorite music streaming APP all whilst keeping
your device safely stored away.
Other conveniences include a front 3.5mm AUX
INPUT port and USB charging port for keeping your
Smart Devices battery topped o󰀨.
(USB and AUX cables not included)
PABC50D-UMv1.0.indd 3 9/18/2016 5:06:46 PM

INSERTINSERT
EN EN
2
WHAT’S IN THE BOX
PABC50D
BAR MULTI-MOUNT
QUICK START GUIDE
USER MANUAL
QUICK START GUIDE
0.75” ~ 1”
1.5” ~ 2.00”
HANDLEBAR & CAGE BUSHINGS
SURFACE MOUNT BEZEL
4mm Allen Head
INTRODUCTION
FCC COMPLIANCE STATEMENT
This device complies with part 15 of the FCC Rules. Operation is subject to the
following two conditions:
(1) this device may not cause interference, and
(2) this device must accept any interference, including interference that may cause
undesired operation of this device.
This transmitter must not be co-located or operated in conjunction with any other
antenna or transmitter. The Bluetooth antenna cannot be removed (or replaced) by
user. This equipment complies with FCC/ IC radiation exposure limits set forth for an
uncontrolled environment and meets the FCC radio frequency (RF) Exposure Guidelines
and RSS-102 of the IC radio frequency (RF) Exposure rules. This equipment has very low
levels of RF energy that it deemed to comply without maximum permissive exposure
(MPE) evaluation. But it is desirable that it should be installed and operated keeping the
radiator at least 20 cm or more away from person’s body (excluding extremities: hands,
wrists, feet and ankles). Alteration or modications carried out without appropriate
authorization may invalidate the user’s right to operate the equipment.
NOTE: This equipment has been tested and found to comply with the limits for a Class B
digital device, pursuant to Part 15 of the FCC Rules. These limits are designed to provide
reasonable protection against harmful interference in a residential installation. This
equipment generates, uses and can radiate radio frequency energy and, if not installed
and used in accordance with the instructions, may cause harmful interference to radio
communications. However, there is no guarantee that interference will not occur in
a particular installation. If this equipment does cause harmful interference to radio or
television reception, which can be determined by turning the equipment o󰀨 and on, the
user is encouraged to try to correct the interference by one or more of the following
measures:
■ Relocate or reorient the receiving antenna.
■ Increase the separation between the equipment and receiver.
■ Connect the equipment into an outlet on a circuit di󰀨erent from that to which the
receiver is connected.
■ Consult the dealer or an experienced radio/TV technician for help.
The Bluetooth® word mark and logos are registered trademarks
owned by Bluetooth SIG, Inc. and any use of such marks is
under license. Other trademarks and trade names are those of
their respective owners.
CAUTION!!
ADJUSTMENT OR ALTERATIONS OF THIS DEVICE MAY RESULT
IN HAZARDOUS RADIATION EXPOSURE.
PABC50D-UMv1.0.indd 4 9/18/2016 5:06:49 PM

EN EN
43
■ Do not operate mobile equipment while driving a motorized
vehicle – safe driving and safety consideration of others
should always be your highest priority.
■ In the event you should notice smoke, strange noises
or odor from this product, or any other abnormal signs,
immediately turn o󰀨 the power and consult your dealer or the
nearest authorized PLANET AUDIO Service Center. Using this
product in this condition may result in permanent damage to
the system.
■ Refer any repairs to a qualied PLANET AUDIO Service
Center.
■ Set your volume control at a low setting, then slowly
increase the sound until you can hear it comfortably without
distortion, or ear discomfort.
BE SURE TO OBSERVE THE FOLLOWING GUIDELINES:
■ Do not turn up the volume so high that you can’t hear what’s
around you.
■ Use caution or temporarily discontinue use in potentially
hazardous situations.
■ Abide all Federal, State, and Local laws.
To avoid potential shorts in the
electrical system, be sure to
disconnect the (–) battery cable
before installation. Use this unit
with a 12-volt battery and negative
grounding system only. Failure
to do so may result in a re or
malfunction.
WARNING - Always consult a professional installer
■ Do not attempt to install or service this product by yourself.
Installation or servicing of this product by persons without
professional training and experience in electronic equipment
and motorized vehicle accessories may be dangerous and
could expose you to the risk of electric shock, injury or other
hazards.
■Ensure the PABC50D is not attached to, or behind metal.
■ Never install this product in a heated location, or under water.
■Do not install the PABC50D next to the vehicles electronics.
■ The PABC50D should be hard wired directly to an accessory
switch or to the battery through an optional switched relay.
■ Always use the included fuse and fuse holder, always replace
with a 3 Amp fuse.
■ The PABC50D has a weather resistant design, it should not
be under any circumstances submerged in, or under water.
■ Use only the supplied installation parts provided with the
PABC50D.
■ Wash with a mild detergent and lukewarm water using a clean
sponge or a soft cloth.
■ Rinse well with clean water.
“DO NOT’S” - Very Important
■ DON’T clean in hot sun or on very hot days.
■ DON’T use abrasive or highly alkaline cleaners on the main
body.
■ DON’T scrape the main body with razor blades, or other sharp
instruments.
■ DON’T ever use, gasoline, acetone or carbon tetrachloride.
■ DON’T ever use a pressure washer.
IMPORTANT SAFETY PRECAUTIONS INSTALLATION PRECAUTIONS
PABC50D-UMv1.0.indd 5 9/18/2016 5:06:49 PM

QUICK START GUIDE
QUICK START GUIDE
EN EN
65
WIRING
RED --------------------------------------------- ACC SWITCHED (+12VDC)
BLACK --------------------------------------------------------------- GROUND
BLUE ------------------------------- AMP REMOTE OUTPUT (+12VDC )
RED RCA ------------------------------------------ RIGHT AUDIO OUTPUT
WHITE RCA ------------------------------------ LEFT AUDIO OUTPUT
GRAY ----------------------------------------- RIGHT SPEAKER OUTPUT
WHITE -------------------------------------------- LEFT SPEAKER OUTPUT
TECH SUPPORT: 1-888-990-1236 US Toll-free
BLUETOOTH
SOURCE CONTROLLER
YOUR
SPEAKERS
3
3
+ WHITE
- WHITE/BLK
+ GRAY
- GRAY/BLK
4 or 8 OHM LOAD ONLY
BLUE
RED
MOUNTING METHODS
TOOLS NEEDED:
- 4mm Allen Wrench
- Wire Crimpers
- HANDLEBAR
- SURFACE MOUNT
Unlock tab
HANDLEBAR / CAGE MOUNT
0.75~1.00” 1.50~2.00”
SURFACE MOUNT
Tips:
EN
Nyne Cruiser
USBCHARGE
5V1A
Tips:
EN
Nyne Cruiser
USBCHARGE
5V1A
1) Check mounting depth before drilling
2) Use the surface mount bezel as template
3) Drill or cut wire hole exactly
4) Insert PABC50D
PABC50D can rotate 90ofor
the best mounting position
Tips:
EN
Nyne Cruiser
USB CHARGE
5V 1A
4mm Allen Head
OPTIONAL TOOLS NEEDED:
- Hand saw or Jigsaw
■ The ground cable length should not exceed 18 inches.
Unlock tab
PABC50D-UMv1.0.indd 6 9/18/2016 5:06:53 PM

QUICK START GUIDE
QUICK START GUIDE
EN EN
87
GETTING TO KNOW YOUR PABC50D
PABC50D MFC - MULTIFUNCTION CONTROLLER
POWER ON - Press and hold for 3 seconds
PLAY/PAUSE
NEXT TRACK - Press and hold for Fast Forward
PREVIOUS TRACK - Press and hold for Fast Rewind
BLUETOOTH PAIRING - LED BLUE COLOR
VOL DOWN
VOL UP
AUX-INPUT
CABLE NOT INCLUDED
USB 1A CHARGING
NOT FOR AUDIO PLAYBACK OPEN
ALWAYS CLOSE WHEN NOT IN USE
NEVER USE USB or AUX WHILE IN
MUD or WATER
Tips:
EN
Nyne Cruiser
USBCHARGE
5V1A
A
1
2
3
4
5
6
7
2
1
A
73
4
RESET
LONG PRESS
10 SECONDS
BLUETOOTH OPERATION
PAIRING & DISCOVERING A NEW BLUETOOTH CONNECTION
1) Power on the PABC50D by long pressing 1POWER button
for 3 seconds
2) Long press the BLUETOOTH 5button, the BLUE LED will
start to rapidly ash, signalling that the PABC50D is now ready
for BLUETOOTH pairing
NOTE: You have 2 minutes before you must restart this
procedure over again.
3) Now that the PABC50D is in pairing mode:
ANDROID users:
a. Go into the Settings Menu of your ANDROID device
b. Enter the BLUETOOTH Menu
c. Turn ON BLUETOOTH and press SCAN
d. “BOSS PABC50D” will now be displayed under
AVAILABLE DEVICES
Tips:
EN
Nyne Cruiser
USBCHARGE
5V1A
Tips:
EN
Nyne Cruiser
USBCHARGE
5V1A
1
5
Tips:
EN
Nyne Cruiser
USB CHARGE
5V 1A
5
6
PABC50D-UMv1.0.indd 7 9/18/2016 5:06:55 PM

QUICK START GUIDE
QUICK START GUIDE
EN EN
109
BLUETOOTH OPERATION (C0N’T)
iOS users:
a. Go into the Settings Menu of your iOS device
b. Enter the BLUETOOTH Menu
c. Turn ON BLUETOOTH
d. Tap on “BOSS PABC50D”
e. If prompted, enter passcode: “0000”
4) If BOSS AUDIO PABC50D is not seen, repeat the above
steps to refresh the “Device List”
5) An audible conrmation TONE will be heard and the
BLUETOOTH LED will illuminate solid when the connection
is successful, you are now ready to stream music from your
favorite media player APP to the PABC50D
To avoid battery exhaustion, be sure to
occasionally run the vehicles engine while using
this product.
Tips:
EN
Nyne Cruiser
USB CHARGE
5V 1A
Tips:
EN
Nyne Cruiser
USBCHARGE
5V1A
Tips:
EN
Nyne Cruiser
USBCHARGE
5V1A
BLUETOOTH RECONNECTION
ONCE THE DEVICE IS BACK IN RANGE, IT SHOULD ATTEMPT
TO AUTOMATICALLY RECONNECT
1) Power on the PABC50D and your devices BLUETOOTH
2) The BLUETOOTH LED will ash slowly as it is looking for
your previously paired device
3) The PABC50D should now try to automatically reconnect to
your last paired device
4) If your device was previously paired with the PABC50D, but
it wasn’t the last paired device:
See page 8 for PAIRING & DISCOVERING A NEW BLUETOOTH
CONNECTION
Tips:
EN
Nyne Cruiser
USB CHARGE
5V 1A
Tips:
EN
Nyne Cruiser
USB CHARGE
5V 1A
NOTE: If the device is out of range from the PABC50D, it will
disconnect automatically.
Tips:
EN
Nyne Cruiser
USBCHARGE
5V1A
Tips:
EN
Nyne Cruiser
USBCHARGE
5V1A
PABC50D-UMv1.0.indd 8 9/18/2016 5:06:57 PM

QUICK START GUIDE
QUICK START GUIDE
EN EN
1211
STREAMING MUSIC CONTROL
MULTIFUNCTION CONTROLLER BLUETOOTH OPERATION
1) Press the 2PLAY/PAUSE once to start playing music or
press the PLAY button from your devices touch screen
2) To skip songs or advance, press the 3NEXT TRACK
button
3) To select the previous song, press the 4PREVIOUS TRACK
button
VOLUME CONTROL
4) To raise the volume, press the 7VOL UP button
5) To lower the volume, press the 6VOL DOWN button
6) To MUTE the volume, press the 2PLAY/PAUSE button
Before stowing: Make sure your devices MEDIA
volume is set at 100% level.
Tips:
EN
Nyne Cruiser
USB CHARGE
5V 1A
USB 1A CHARGING
NOT FOR AUDIO PLAYBACK
64
2
73
AUX-INPUT
MULTIFUNCTION CONTROLLER AUX-IN OPERATION
1) Power on the PABC50D by pressing and holding down the
1POWER button for 3 seconds
2) Disconnect any paired Bluetooth device by turning o󰀨
BLUETOOTH in your devices SETTINGS MENU
3) Under the protective door, connect your 3.5mm AUX-IN
cable to your devices headphone jack
4) Route the AUX-IN wire back to PABC50D, secure your
device in a safe location
VOLUME CONTROL
5) To raise the volume, press the 7VOL UP button
6) To lower the volume, press the 6VOL DOWN button
7) To MUTE the volume, press the 2PLAY/PAUSE button
Before stowing: Make sure your devices HEADPHONE
volume is set at 100% level.
Tips:
EN
Nyne Cruiser
USB CHARGE
5V 1A
Tips:
EN
Nyne Cruiser
USB CHARGE
5V 1A
PABC50D can play audio from
any device that has a 3.5mm
headphone audio jack
INSERT
(Cable not included)
YOUR DEVICE 2
6
7
1
CAUTION!!
Never use USB or AUX
while in mud and/or
water
Close USB cover
when not in use
Tips:
EN
Nyne Cruiser
USB CHARGE
5V 1A
Tips:
EN
Nyne Cruiser
USB CHARGE
5V 1A
PABC50D-UMv1.0.indd 9 9/18/2016 5:07:00 PM

QUICK START GUIDE
QUICK START GUIDE
EN EN
TROUBLE SHOOTING
1413
SYMPTOM SOLUTION
No sound -------------------------------------- Unit or Device is MUTED
No sound ---------------------------------------------- Speaker is shorted
Audio is distorted ------------------------- Bluetooth is out of range
No power indicator --------------------------------------- Fuse is blown
Power source: ------------------------- 14.4VDC (10.8V ~ 16V allowable)
Grounding System: ---------------------------------------- Negative type
Power Output: ------------------------------------------------------------150W
Preamp Output: ------------------------------------------------------ 2V RMS
Preamp Impedance: --------------------------------------------------- 600Ω
Frequency Response: --------------------------------------- 20Hz-22kHz
Speaker Impedance: ----------------------------------------------- 4 or 8 Ω
Maximum current: --------------------------------------------------------- 3A
Bluetooth: ------------------------------------------------------------------ 4.1
Class:----------------------------------------------------------------------------- 2
Range: ------------------------------------------------------------------------ 33ft
Proles: --------------------------------------------------------- A2DP / GATT
USBoutput:--------------------------------------------------------5VDC@1A
Dimensions: HxDxW 3.50”x 1.55” x3.50” / 90mm x40mm x 90mm
Unit weight: -------------------------------------------- 0.25lbs / 0.114kg
Storagetemperature: ---------------------- -4°Fto160°F /-20°Cto70°C
Operation temperature: ------------------- 32°F to 110°F / 0°C to 45°C
Replace fuse with rated 3A ATM type only
SPECIFICATIONS SUBJECT TO CHANGE WITHOUT NOTICE
SPECIFICATIONS
TECH SUPPORT: 1-888-990-1236 US Toll-free
NOTES
PABC50D-UMv1.0.indd 10 9/18/2016 5:07:00 PM
