Planet Networking & Communication GUP-805A-60W User manual

100/1000BASE-X SFP to 10/100/1000BASE-T
802.3bt PoE++ Media Converter
GUP-805A-60W/GUP-805A-95W
User’s Manual

Table of Contents
1. Package Contents................................................................................. 3
2. Product Features .................................................................................. 5
3. Product Outlook ................................................................................... 6
3.1 Front View .................................................................................... 6
3.2 LED Indication ............................................................................... 6
3.3 Rear View ..................................................................................... 8
3.4 Power Information ......................................................................... 8
4. Installing The Converter........................................................................ 9
5. Duplex Mode Support ......................................................................... 12
6. Cable Connection Parameter................................................................ 13
7. ProductSpecications ......................................................................... 14
8. Customer Support .............................................................................. 16

3
1. Package Contents
Thank you for purchasing PLANET GUP-805A 100/1000BASE-X SFP to
10/100/1000BASE-T 802.3bt PoE++ Media Converter series. In the following
sections, the term “GUP-805A series” means the GUP-805A-60W or
GUP-805A-95W.
Model PoE Standard PoE
Budget LAN Port Speed SFP Slot Speed
GUP-805A-60W IEEE 802.3af/
at/bt 60 watts 10/100/ 1000Mbps
100/
1000BASE-X
GUP-805A-95W IEEE 802.3af/
at/bt 95 watts 10/100/ 1000Mbps
100/
1000BASE-X
Please unpack the box of the GUP-805A series carefully, and the box should
contain the following items:
GUP-805A Series Media Converter x 1 QR Code Sheet x 1
Let’s get started with your PLANET product
GUP-805A-60W
EN Please scan the QR code to browse our online User’s Manual or Quick
Installation Guide and follow the instructions to complete the setup.
User's Manual
DE
Bitte scannen Sie den QR- Code sie werden per Browser zur
Bedienungsanleitung oder Schnellanleitung weiter geleitet. Folgen Sie den
Anweisungen um die Installation abzuschließen.
FR
Veuillez scanner le code QR pour obtenir notre Notice d’Utilisation en
ligne ou notre Guide d’Installation Rapide et suivez les instructions pour
compléter la conguration
ES
Escanee el código QR para encontrar el Manual del Usuario en línea o
la Guía de Instalación Rápida y siga las instrucciones para completar la
conguración.
IT Scansiona il codice QR per consultare online il Manuale utente o la Guida di
installazione rapida e segui le istruzioni per completare la congurazione.
PT Por favor, escaneie o QR code para navegarno Manual do Usuário ou Guia
de Instalação Rápida. Siga as instruções para completar a conguração.
PL
Zeskanuj kod QR, aby otworzyć naszą internetową instrukcję obsługi
lub instrukcję szybkiej instalacji. Postępuj zgodnie z instrukcjami, aby
zakończyć poprawną kongurację.
RU
One word modify: Отсканируйте QR-код, чтобы просмотреть наше
онлайн-руководство пользователя или руководство по быстрой
настройке, и следуйте инструкциям для завершения настройки
RO Te rugam sa scanezi codul QR, pentru a descarca User’s Manual sau Quick
Installation Guide si a urmari instructiunile necesare in nalizarea instalarii
AR
Need more help?
PLANET online FAQs:
http://www.planet.com.tw/en/support/faq
Technical Support: [email protected]
Copyright © PLANET Technology Corp. 2023.
Contents are subject to revision without prior notice.
PLANET is a registered trademark of PLANET Technology Corp.
All other trademarks belong to their respective owners.
Part No. 2361-AM1090-000
AC-DC Adapter (Output: 52V~55V DC) x 1 AC Power Cord x1

4
If any item is missing or damaged, please consult the dealer from whom
you purchased your GUP-805A series Gigabit Ethernet 802.3bt PoE++ Media
Converter.
The GUP-805A-60W and GUP-805A-95W comes with one vacant
SFP module slot. The mini GBIC SFP module is not included in
the package.

5
2. Product Features
Physical Port
zMedia conversion between 10/100/1000BASE-T and 100BASE-
FX/1000BASE-SX/LX
zCopper RJ45 interface with Data + Power output
zCopper port supports 10/100/1000BASE-T auto-negotiation and auto-
MDI/MDI-X.
zFiber media allows
-Multi-modeberusingLCconnector
-Single-modeberusingLCconnector
Power over Ethernet
zCompatible with IEEE 802.3bt Power over Ethernet plus plus end-span +
mid-span PSE
zBackward Compatible with IEEE 802.3at Power over Ethernet plus end-
span/mid-span PSE
zProvides DC 52V~55V power over RJ45 Ethernet cable to devices with
Ethernet port
zRJ45 PoE++ port with built-in 802.3bt type-4 PoE 60W or 95W injector
function
zAuto detects powered device (PD)
zCircuit protection prevents power interference between ports
zRemote power feeding up to 100m
zIEEE 802.3bt/IEEE 802.3at splitter devices compatibility
Layer 2 Features
zStore-and-Forward mechanism
zNon-blocking full wire-speed forwarding rate
zIEEE 802.1Q Tag VLAN transparent, multicast pass through
z9K jumbo frame
zIEEE 802.3x full-duplex and half-duplex back-pressure ow control to
eliminate the loss of packets
Mechanical
zMetal case
zLED indicators for easy network diagnostics
zDIP switch for PoE power feeding options (BT/UPOE/Legacy) selection
zDC 52V~55V power input socket
zWall mounting or DIN-rail installation (optional)
zCompact in size, easy installation

6
3. Product Outlook
3.1 Front View
There are one RJ45 twisted-pair jack (auto-MDI/MDI-X), one 100/1000X ber-
optic SFP slot and four LED indicators, and one DIP switch for BT/UPOE/Legacy
PoE power feeding options.
TP
LNK/
ACT
Fiber
LNK/
ACT
PWR
PoE-
in-Use
100/1000X
SFP
10/100/1000T
PoE++
BT
Legacy
UPOE
Figure 1: Front Panel of the GUP-805A Series
3.2 LED Indication
 System
LED Color Function
PWR Green Lit To indicate that the GUP-805A series has power.
O To indicate that the power is not detected.
 10/100/1000BASE-T 802.3bt PoE++ Port
LED Color Function
PoE-in-Use Amber
Lit To indicate the RJ45 port is providing PoE
in-line power.
O To indicate the RJ45 port is not providing PoE
in-line power.
LNK/ACT Green
Lit To indicate the link through TP port is
successfully established.
Blink To indicate the port is actively sending or
receiving data.
O To indicate that the copper port is linked down.

7
 100/1000BASE-X SFP Slot
LED Color Function
Fiber
LNK/ACT Green
Lit Toindicatethelinkthroughberportis
successfully established.
Blink Toindicatetheberportisactivelysendingor
receiving data.
O Toindicatethattheberopticportislinked
down.
 DIP Switch
PoE Mode Function
BT
(Default)
This mode makes the GUP-805A series fully support IEEE
802.3af/at/bt standards.
UPOE This mode makes the GUP-805A series fully support Cisco UPoE
or PoH standards
Legacy
The legacy detection is to identify the valid current signature of
the PDs that do not fully follow the IEEE 802.3af/at/bt standard.
This protects against damage to the PDs as the right PoE mode
is applied.
Please power on the device after changing the DIP switch mode.

8
3.3 Rear View
There is also one DC 52V ~ 55V power socket for the GUP-805A series Gigabit
Ethernet 802.3bt PoE++ Media Converter.
52-55V
Figure 2: Rear Panel of the GUP-805A Series
3.4 Power Information
The power jack of the Gigabit Ethernet 802.3at PoE+ Media Converter
measures 2.1mm in diameter, and comes with DC 52V~55V power input. It
conforms to the bundled AC-DC adapter. Should you have the issue of making
the power connection, please contact your local sales representative.
2.1mm
DC Receptacle 2.1mm, DC 52~55V
DC receptacle is 2.1mm wide that conforms to the Ethernet Extender
2.1mm DC jack’s central post. Do not install any improper unit.

9
4. Installing The Converter
To install the GUP-805A series, simply complete the following steps:
Ethernet Installation
Step 1: Turn o the power of the device/station in a network to which the
GUP-805A series will be attached.
Step 2: Ensure that there is no activity in the network.
Step 3: AttachbercablefromtheGUP-805Aseriestothebernetwork.
Step 4: Attach a Cat.5/5e/6 UTP cable from the 10/100/1000BASE-T network
to the RJ45 port on the GUP-805A series.
Step 5: Connect the 52V~55V DC power adapter to the GUP-805A series and
verify that the Power LED lights up.
Step 6: Turn on the power of the device/station; the TP Link and SFP Fiber
Link LEDs should light up when all cables are attached.
100/1000BASE-X
SFP Transceiver
100/1000BASE-X
LC Fiber
10/100/1000BASE-T UTP
Figure 3: GUP-805A Series Installation

10
1. It is recommended to use PLANET MFB/MGB series
100/1000BASE-FX/SX/LX SFP on the GUP-805A series. If you
insert an SFP transceiver that is not supported, the GUP-805A
series will not recognize it.
2. Please check the link of your SFP transceivers and its physical
wiring distance. In some installation, an in-line optical attenu-
ator may be required to protect your transceivers.
3. RJ45/STP, UTP Cat5/5e/6, or straight/crossover cable is
accepted; refer to section 8 for more about the wiring
distance of your TP and optic-fiber networks.
PoE++ Function
The installation of the GUP-805A Series and the IEEE 802.3bt/802.3at
Injector/Splitter.
Before your installation, it is recommended to check your network
environment. If there is any IEEE 802.3bt/802.3at devices that need to be
powered on, the GUP-805A series can provide you with a way to supply power
for this Ethernet device conveniently and easily.
The GUP-805A series equips an AC-DC adapter with DC 52V~55V input and it
injects the DC power into the pin of the twisted-pair cable (Pins 1, 2, 3 6 and
Pins 4, 5, 7, 8).
PoE+
Speed Dome
Fiber Switch
1000 PoE
GUP-805A-60W(95W)
1000BASE-SX/LX Fiber Optic
1000
PoE
1000BASE-T UTP with PoE
Power
DataData
Power DC
52V~55V
550m~120km 100m
AC-to-DC Adapter

11
For the places hard to nd the power inlet, the GUP-805A series provides the
easiest way to power your powered device such as laptops, Thin Client, POS
System, PTZ (pan, tilt & zoom) network cameras, PTZ speed dome, color
touch-screen IP phones, multi-channel wireless LAN access points via PLANET
IEEE 802.3bt/802.3at Power over Ethernet Splitter (POE-173S/162S/161S)
over a long distance if necessary.
Fiber Switch
1000 PoE
GUP-805A-60W(95W)
1000BASE-SX/LX Fiber Optic
1000
PoE
1000BASE-T UTP with PoE
Power
DataData
550m~120km 100m
802.3bt
PoE++ Splitter
Thin
Client
DC
Power DC
52V~55V
AC-to-DC Adapter
DC
Power Line (DC)

12
5. Duplex Mode Support
The GUP-805A series TP port supports triple speed -- 10/100/1000BASE-T
auto-negotiation. It will auto detect the link speed and the duplex mode by
default with its link partner. The ber port (100/1000BASE-FX/SX/LX) allows
100/1000Mbps full duplex by auto-negotiation. Please also check the
setting of the link partner as well.

13
6. Cable Connection Parameter
The wiring details are shown below:
Duplex Connection Limitation (max.)
Twisted Pair
Half/Full Node to Node
Node to Switch/Hub 100 meters
Fiber Optic Cables:
Standard
(Wavelength)
100BASE-FX
(1310nm)
1000BASE-SX
(850nm)
1000BASE-LX
(1310nm)
Fiber Type & Cable
Specications
Multi-mode 50/125μmor62.5/125μm
Single-mode 9/125μm

14
7.ProductSpecications
Model GUP-805A-60W GUP-805A-95W
Interface
Copper Port
10/100/1000BASE-T Ethernet RJ45 interface Auto-
negotiation, auto MDI/MDI-X with PoE injector
function
SFP Interface 100/1000BASE-X SFP interface
Fiber Mode May vary on SFP Module
Fiber Port Type
(connector) SFP, LC type
Fiber Maximum Distance May vary on SFP Module
Power Over Ethernet
PoE Output
IEEE 802.3af Power over Ethernet PSE
IEEE 802.3at Power over Ethernet Plus PSE
IEEE 802.3bt Power over Ethernet Plus Plus PSE
Power Output PoE 52-55V DC, 60
watts
PoE 52-55V DC, 95
watts
PoE Power Budget 60 watts 95 watts
PoE Power Supply Type End-span + Mid-span
Power Pin Assignment
802.3bt: 1/2(-), 3/6(+), 4/5(+), 7/8(-)
End-span: 1/2(-), 3/6(+)
Mid-span: 4/5(+), 7/8(-)
HardwareSpecications
Enclosure Metal case
Dimensions (W x D x H) 94 x 70 x 26 mm
Weight 144g
LED
System: PWR (Green)
Fiber 100/1000BASE-X: LNK/ACT (Green)
TP 10/100/1000BASE-T: LNK/ACT (Green)
PoE: Power-in-use (Amber)
DIP Switch PoE power feeding options (BT/UPOE/Legacy)
selection

15
Power Supply DC 52V~55V Power Socket, external AC-to-DC
adapter
Installation Wall-mount or DIN-rail installation (Optional)
Layer 2 Features
Switch Architecture Store-and-Forward
Forwarding Rate Non-blocking full wire-speed forwarding rate
Flow Control Back pressure for half duplex mode
IEEE 802.3x pause frame for full duplex mode
Maximum Frame Size 9K
Standards Conformance
Regulatory Compliance FCC Part 15 Class A, CE
Protocols and Standards
Compliance
IEEE 802.3 Ethernet
IEEE 802.3u 100BASE-TX/100BASE-FX
IEEE 802.3ab Gigabit Ethernet over TP
IEEE 802.3z Gigabit Ethernet over Fiber Optic
IEEE 802.3x Flow Control
IEEE 802.3af Power over Ethernet
IEEE 802.3at Power over Ethernet Plus
IEEE 802.3bt Power over Ethernet Plus Plus
Cables
TP: Cat 3/4/5/5e/6 UTP cable
Fiber: Multi-mode: 50/125µm or 62.5/125µm optic
ber
Single-mode:9/125µmopticber
Environment
Temperature Operating: 0 ~ 50 degrees C
Storage: -10 ~ 70 degrees C
Humidity 5% ~ 95% non-condensing
1. For connection to the Gigabit Ethernet products, please refer
to the device’s technical manual.
2. Consult your dealer for DIN-rail installation.

16
8. Customer Support
Thank you for purchasing PLANET products. You can browse our online FAQ
resource and User’s Manual on PLANET Web site rst to check if it could solve
your issue. If you need more support information, please contact PLANET
switch support team.
PLANET online FAQs:
https://www.planet.com.tw/en/support/faq
Switch support team mail address:
[email protected]
Copyright © PLANET Technology Corp. 2023.
Contents are subject to revision without prior notice.
