Planet Networking & Communication GPN-100 User manual

– 1 – – 2 –
1. Package Contents
Thank you for choosing PLANET GPON ONT. Before installing the
range extender, please verify the contents inside the package box.
GPN-100 User’s manual Power adapter
(12V, 0.5A)
Note
If there is any item missing or damaged, please contact
the seller immediately.
2. Physical Introduction
Top View and LEDs
PON LAN
POWER LOS
LED Indicators
LED Color Function
PWR Blue Lights Indicates the ONT has power.
OFF The ONT doesn’t receive power.
LOS Red Blinks Optical Power is too low.
OFF Optical Power is normal.
PON Blue
Blinks Indicates the port is not getting normal
Optical Signal.
Lights Indicates the port is getting normal
Optical Signal.
LNK/ACT Blue
OFF No link
Blinks Indicates the link through that port is
actively sending and receiving data.
Lights Indicates the link through that port is
successfully established.
Rear View
Power
Button
10/100/1000BASE-T
RJ45 LAN Port
GPON Port
SC/UPC
Power
Socket
Reset
Button
Bottom View
3. Hardware Installation
Safety Requirements
zNever look directly into the ends of ber or PON modules. The
emitted light could cause damage to the eye.
zMake sure the GPON service is enabled.
zEnsure that the optical ber is long enough to achieve the
desired installation place.
zPut the ONT on a sturdy table.
zDon't open the device when the ONT is operating.
zContact your local agent for permission if you want to remove
the chassis.
zAllow about 10cm of clearance around the ONT chassis for heat
dissipation.
Step 1: Connecting the RJ45 network cable.
a. Plug in the RJ45 cable to 10/100/1000 GE port.
b. Plug in the other side to your host or devices.
Step 2: Connecting the ber cable.
a. Remove the protective cap of the optical ber.
b. Remove the protective cap of the ONT optical interface
(PON interface). Insert the ber into the PON interface.
Warning
Don’t connect the ONT/HGU directly to GPON SFP
module (GPL-GSFP-C+ or GPL-GSFP-C++). Doing
so will damage the ONT/HGU optics. Use a PON
splitter to add attenuation as needed.
Note
1. Keep the optical connector and the optical fiber
clean.
2. Make sure the bending diameter of the fiber is more
than 6cm. Otherwise, the optical signal loss may be
increased.
3. Cover a protective cap to guard against dust and
water when the fiber is not used
Step 3: Connecting Power Adapter.
a. Connect the power adapter to the power socket on the
ONT.
b. Insert the other end into a power outlet.
OLT/
Splitter
Fiber
Power
Power
Adapter
PC
Router PCSwitch


– 3 – – 4 –
Verifying the Installation
zAfter powering on the ONT, the Power LED will be lit and ONT
system will start to check the Optical signal.
zIf the ONT system receives the optical signal, the PON LED will
be lit and ONT system will start to register.
zIf OLT and ONT register successfully, the Link LED will be lit
which means that the connection is establishing.
Note
PLANET GPON ONT was designed with PLANET OLT
GPL-8000 system. If your connection device is a
third-party OLT system, the PON connection might be
unstable and malfunctioned, due to the configurations
of ONT which must depend on the OLT settings
Note
If the ONT can’t work properly with OLT of other
brands, contact the third-party OLT vendor for technical
support.
4.Specications
Product GPN-100
Hardware Specications
Transmission Speed Downstream: 2.5 Gbps
Upstream: 1.25 Gbps
Port
PON Port 1 x PON Port, SC/UPC
Ethernet
Port 1 x RJ45 (10/100/1000BASE-T)
Fiber Maximum
Distance 20km
Optic Wavelength TX: 1310mm
RX: 1490mm
Optical Receive
Sensitivity -28 dBm
Optical TX Power 0.5~5 dBm
Reset Button < 5 sec: System reboot
> 20 sec: Factory default
LED Indicators
1 Power LED
1 PON LED
1 LAN Link LED
1 LOS LED
Environment Specications
Dimensions
(W x D x H) 80 x 75 x 24 mm
Weight 100g
Power Input 12V DC, 0.5A
Temperature Operating temperature: 0 ~ 50 degrees C
Storage temperature: -40 ~ 85 degrees C
Humidity
Operating Humidity: 10 ~ 85%
non-condensing
Storage Humidity: 5 ~ 95%
non-condensing
Standards Conformance
Standards
Compliance
IEEE 802.3 10BASE-T
IEEE 802.3u 100BASE-TX
IEEE 802.3ab 1000BASE-T
IEEE 802.3x ow control and back pressure
ITU-T G.984/G.988
ITU-T Y.1291
Safety CE
Customer Support
Thank you for purchasing PLANET product. You can browse our
online FAQ resource on PLANET website rst to check if it could
solve your issue. If you need more support information, please
contact PLANET support team
PLANET online FAQs:
https://www.planet.com.tw/en/support/faq
Support team mail address:
[email protected]
Energy Saving Note of the Device
This power required device does not support Standby mode operation. For energy savings, please remove the
DC plug or slide the hardware-based Power Switch to the OFF position to disconnect the device from the power
circuit. Without removing the DC plug from or switching off the device, the device will still consume power from
the power source. In view of Saving the Energy and reducing the unnecessary power consumption, it is strongly
suggested to power off or to remove the DC plug from the device if this device is not intended to be active.
