User’s Guide
1000Base-SX PCI Bus Gigabit Ethernet Adapter
ENW-9600SX

FCC Information
The Federal Communication Commission Radio Frequency Interference
Statement includes the following paragraph:
This equipment has been tested and found to comply with the limits for a
Class B Digital Device, pursuant to Part 15 of the FCC Rules. These limits
are designed to provide reasonable protection against harmful interference in
a residential installation. This equipment generates, uses and can radiate
radio frequency energy and, if not installed and used in accordance with the
instructions, may cause harmful interference to radio communication.
However, there is no guarantee that interference will not occur in a particular
installation. If this equipment does cause harmful interference to radio or
television reception, which can be determined by turning the equipment off
and on, the user is encouraged to try to correct the interference by one or more
of the following measures:
♦Reorient or relocate the receiving antenna.
♦Increase the separation between the equipment and receiver.
♦Connect the equipment into an outlet on a circuit different from that to
which the receiver is connected.
♦Consult the dealer or an experienced radio / TV technician for help.
The user should not modify or change this equipment without written
approval from company name. Modification could void authority to use
this equipment.
For the safety reason, people should not work in a situation which RF
Exposure limits are exceeded. To prevent the situation happening, people
who work with the antenna should be aware of the following rules:
1. Install the antenna in a location where a distance of 6.5 cm from the
antenna may be maintained.
2. While installing the antenna in the location, please do not turn on the
power of wireless card.
3. While the device is working, please do not contact the antenna.

Copyright
Copyright © 1999 Planet Technology Corp., all rights reserved. No part
of this publication may be reproduced, adapted, stored in a retrieval
system, translated into any language, or transmitted in any form or by
any means without the written permission of Planet Technology Corp.
Trademarks
Planet is trademark of Planet Technology Corp., all other trademarks
throughout this manual are the property of their respective companies.
Limited Warranty
In no event will Planet be liable for any damage, including loss of data
or profits, cost of cover, or other incidental, consequential or indirect
damages arising from the installation, maintenance, use, performance,
failure or interruption of Planet’s products, whatever caused and on
any theory of liability. This limitation will apply even if Planet has
been advised of the possibility of such damage.
CE Mark Warning
This is a Class A product. In a domestic environment, this product
may cause radio interference, in which case the user may be required
to take adequate measures.
About This Manual
1000Base-SX PCI Bus Gigabit Ethernet Adapter User’s Guide
is published by Planet Technology Corp. in 1999. This Revision is
issued in Nov. 1999.
Revision
1000Base-SX PCI Bus Gigabit Ethernet Adapter User’s Guide
ENW-9600SX
Part No.: EM-9600SX

CONTENTS
INTRODUCTION ...........................................................................1
PACKAGE CONTENTS.................................................................2
HOW TO USE THIS GIGABIT ETHERNET ADAPTER............2
SPECIFICATION..........................................................................10

1
INTRODUCTION
Thanks for your purchase of this Gigabit Ethernet LAN adapter. It is fully
compliant with the IEEE802.3 standard. With the features like 1000Mbps
Gigabit Ethernet, full/half duplex mode transmission, it offers users a high
performance network.
Features
•IEEE802.3z and IEEE802.3x Standard Compliant
•1000Mbps Gigabit data rate and full/half duplex transmission mode.
•32-bit PCI local bus specification 2.1 Compliant
•Comprehensive software driver support for popular networking system.
•Provides on-board screening of VLAN tagged Ethernet frames.
•Duplex SC fiber connector.
Network Drivers Support
•Novell NetWare Server 3.12, 3.2 , 4.1x, 5.0 or later
•Microsoft Windows 95/98
•Microsoft Windows NT3.51, NT4.0, NT5.0
•Microsoft Windows 2000 Beta or later
•Linux 2.0, 2.2
System Requirements
This Gigabit Ethernet adapter has the following system requirements:
•At least 32MB of system memory.
•The latest BIOS.
•Microsoft Windows 95/98
•Microsoft Windows NT3.51, NT4.0, NT5.0
•Microsoft Windows 2000 Beta or later
•Novell NetWare 3.12, 3.2, 4.1x, 5.0 or later
•Linux 2.0, 2.2
•62.5/125µm or 50/125µm multi-mode fiber optic cable

2
PACKAGE CONTENTS
PCI 1000Mbps Gigabit Ethernet Adapter
USERS MANUAL
MANUAL
DRIVER DISKETTE
Adapter Driver
HOW TO USE THIS GIGABIT ETHERNET
ADAPTER
Follow the instructions in this section for installing the Gigabit Ethernet
adapter in your system.
1. Make sure your system meets the system requirements.
2. Shut down and power off your system.
3. Plug this Gigabit Ethernet adapter into your system’s PCI slot
4. Connecting the network cables.
Multi-mode Fiber 62.5/125 µm50/125 µm
Operating Distance 2 to 260 meters 2 to 550 meters
Connect one end of the cable to the Gigabit Ethernet adapter, as shown in
below.

3
5. Turn on your system power.
In the driver diskette in which is provided by vendor, the file name is
“install.txt”, read this file carefully, there are more detail information.
Windows NT 4.0 installation procedure
Installing the Windows NT 4.0 NDIS4 Device Driver
1. Users’system must meet the minimum system requirement, or the
driver installation may be fail.
2. Make sure your Windows NT4.0 desktop had been install Service
Packet 3 (or later) and you have Network Administrator privileges to
install the network driver.
3. Login the Windows NT4.0 OS.
4. Clicks the Network icon on the Control Panel menu.
5. Clicks “Adapter”item and select “Add…” button.

4
6. Clicks “Have Disk…” button to use the driver diskette provided by
vendor.
7. Type a correct path for the Gigabit Adapter and click “OK”.

5
8. The system will copy some of files. Users may need to prepare the
Windows NT4.0 CD. And the system will successfully install the Gigabit
adapter driver.
9. After copy the driver, the screen will show up the Gigabit adapter model
name and then click “OK”.
10. On the Adapter icon, select the Gigabit adapter and then configure the
network environment.
11. Once configuration is done, click “Close”.
12. The system will ask you to shutdown and reboot the system or not? Click
“Yes”button to shutdown and reboot the system.

6
NetWare 4.11 ODI Device Driver installation
1. After users had plugged the Gigabit adapter into the system, make sure
the system match the minim system requirement.
2. Power on system and reboot into NetWare 4.11 console prompt.At the
NetWare console prompt enter the command “load install”to start the
install utility. The Installation Options dialog box is displayed.
.
3. Select the “Driver Options”menu item and press enter. The Driver
Options dialog box is displayed.

7
4. Select the “Configure Network Drivers”menu item and press enter. The
Additional Driver Actions dialog box is displayed.
5. Insert the driver diskette that support by vendor and select a driver.
6. Select the Load an additional driver menu item option and press enter.
The “Select a driver”dialog box is displayed.
7. Press the “Ins”key to “install an unlisted driver”.

8
8. Specify the path for the drivers.
10. Press “enter”to select the JT1ODI.LAN from the Select a driver to
install dialog box. A message asking if you want to copy the driver is
displayed. Select Yes to continue. The device driver is copied.
11. .Configure the driver parameters and protocols. If you are not sure what
values are required for your network, contact your network administrator.

9
12. .Select the Save Parameters and Load Driver option and press enter to
continue.
13. .Select No when asked if you want to load additional drivers
14. .On the Additional Driver Actions dialog box, select Return to previous
menu and press Enter to continue
15. . On the Driver Options dialog box, select Return to previous menu and
press enter to continue
16. On the Install Options dialog box, select Exit to return to the NetWare
console prompt.
LED Indicators
Figure 1 shows two indicators, which indicate the presence of situation Link
and Data status.
LINK
DATA
Figure 1 LED indicators

10
LINK DATA
ON/BLINK * Link up is a
green light. *Blinking in green means data packet being transmitted or received.
OFF *Power off.
*Link down. *Power off. * No data packet being transmitted or
received.
Table 1. Status of the indicators
SPECIFICATION
ITEM DESCRIPTION
Bus Interface PCI-bus specifications Rev 2.1
Network Standard *IEEE802.3z for 1000Mbps Ethernet
*IEEE802.3x for full-duplex operation
Cable/
Connector *Duplex SC fiber connector *62.5/125-micron multi-mode fiber
*50/125-micron multi-mode fiber
Data Rate 1000Mbps
Power 6.5W
Environment *Temperature Operating: 0¢Jto 40¢J
*Storage: -20¢Jto +70¢J
*Humidity Operating: 10% to 80% RH
*Storage: 5% to 90% RH
Emissions FCC part 15Class B, CE Class B
