Planet FPS-1010M User manual

USB2.0 MFP Print Server
FPS-1010M
User’s Manual
Version: 1.0
(February, 2006)

Copyright
Copyright©2006 by PLANET Technology Corp. All rights reserved. No part of this
publication may be reproduced, transmitted, transcribed, stored in a retrieval system, or
translated into any language or computer language, in any form or by any means,
electronic, mechanical, magnetic, optical, chemical, manual or otherwise, without the prior
written permission of PLANET.
PLANET makes no representations or warranties, either expressed or implied, with respect
to the contents hereof and specifically disclaims any warranties, merchantability or fitness
for any particular purpose. Any software described in this manual is sold or licensed "as
is". Should the programs prove defective following their purchase, the buyer (and not this
company, its distributor, or its dealer) assumes the entire cost of all necessary servicing,
repair, and any incidental or consequential damages resulting from any defect in the
software. Further, this company reserves the right to revise this publication and to make
changes from time to time in the contents hereof without obligation to notify any person of
such revision or changes.
All brand and product names mentioned in this manual are trademarks and/or registered
trademarks of their respective holders.
Federal Communication Commission Interference Statement
This equipment has been tested and found to comply with the limits for a Class B digital
device, pursuant to Part 15 of FCC Rules. These limits are designed to provide
reasonable protection against harmful interference in a residential installation. This
equipment generates, uses, and can radiate radio frequency energy and, if not installed
and used in accordance with the instructions, may cause harmful interference to radio
communications. However, there is no guarantee that interference will not occur in a
particular installation. If this equipment does cause harmful interference to radio or
television reception, which can be determined by turning the equipment off and on, the
user is encouraged to try to correct the interference by one or more of the following
measures:
1. Reorient or relocate the receiving antenna.
2. Increase the separation between the equipment and receiver.
3. Connect the equipment into an outlet on a circuit different from that to which the
receiver is connected.
4. Consult the dealer or an experienced radio technician for help.
FCC Caution:
To assure continued compliance.(example-use only shielded interface cables when
connecting to computer or peripheral devices). Any changes or modifications not expressly
approved by the party responsible for compliance could void the user’s authority to operate
the equipment.
This device complies with Part 15 of the FCC Rules. Operation is subject to the Following
two conditions: (1) This device may not cause harmful interference, and (2) this Device
must accept any interference received, including interference that may cause undesired
operation.
Federal Communication Commission (FCC) Radiation Exposure Statement
This equipment complies with FCC radiation exposure set forth for an uncontrolled
environment. In order to avoid the possibility of exceeding the FCC radio frequency
exposure limits, human proximity to the antenna shall not be less than 20 cm(8 inches)
during normal operation.
R&TTE Compliance Statement
This equipment complies with all the requirements of DIRECTIVE 1999/5/CE OF THE
EUROPEAN PARLIAMENTAND THE COUNCIL OF 9 March 1999 on radio equipment and
telecommunication terminal Equipment and the mutual recognition of their conformity
(R&TTE)
The R&TTE Directive repeals and replaces in the directive 98/13/EEC (Telecommunications

Terminal Equipment and Satellite Earth Station Equipment) As of April 8,2000.
Safety
This equipment is designed with the utmost care for the safety of those who install and use
it. However, special attention must be paid to the dangers of electric shock and static
electricity when working with electrical equipment.All guidelines of this and of the computer
manufacture must therefore be allowed at all times to ensure the safe use of the equipment.
WEEE regulation
To avoid the potential effects on the environment and human health as a result of
the presence of hazardous substances in electrical and electronic equipment, end
users of electrical and electronic equipment should understand the meaning of the
crossed-out wheeled bin symbol. Do not dispose of WEEE as unsorted municipal
waste and have to collect such WEEE separately.
Revision
User’s Manual for PLANET USB2.0 MFP Print Server
Model: FPS-1010M
Rev: 1.0 (February, 2006)
Part No. EM-FPS1010M

Contents
1. Introduction....................................................................................................1
2. Product Package ...........................................................................................1
3. MFP Server Installation in Windows 2000/XP................................................2
3.1 Hardware Installation.......................................................................2
3.2 Software Installation Procedure.......................................................2
3.3 MFP Server Utilities.........................................................................8
3.4 Install the MFP Drivers/Utilities........................................................8
4. Using the MFP.............................................................................................13
4.1 Share Printer and Fax ...................................................................13
4.2 Share Scanner...............................................................................14
4.3 Share Card Reader .......................................................................15
5. MFP Server Control Manager......................................................................16
5.1 MFP Server List.............................................................................16
5.2 My Favorite....................................................................................17
5.3 Auto Connect List..........................................................................18
5.4 Quick Setup...................................................................................21
5.5 Option Settings..............................................................................22
5.5.1 General Setting ......................................................................22
5.5.2 Installed MFP List...................................................................23
5.5.3 Search for MFP Server...........................................................24
6. Server Configuration....................................................................................25
6.1 Introduction....................................................................................25
6.2 Status ............................................................................................26
6.3 Setup.............................................................................................27
6.3.1 General Configuration............................................................28
6.3.2 TCP/IP Configuration..............................................................29
6.3.3 System Configuration.............................................................30
6.3.4 MFP Server Management ......................................................31
6.4 Report............................................................................................32
7. Web Management .......................................................................................33
7.1 Introduction....................................................................................33
7.2 Login..............................................................................................33

7.3 Device Setup.................................................................................34
7.3.1 System ...................................................................................34
7.3.2 Printer.....................................................................................34
7.3.3 TCP/IP....................................................................................35
7.4 Setup Wizard.................................................................................35
7.4.1 System ...................................................................................35
7.4.2 TCP/IP....................................................................................37
7.4.3 Save Settings.........................................................................38
7.5 System Tools.................................................................................38
7.5.1 Load Default...........................................................................38
7.5.2 Upgrade Firmware from Browser ...........................................39
8. LPR Printing.................................................................................................40
9. IPP Printing..................................................................................................47
9.1 Introduction....................................................................................47
9.2 System Setup................................................................................47
9.2.1 MFP Server Side....................................................................47
9.2.2 Client Side..............................................................................47
10. MFP Server Installation in Windows 98SE/Me/NT.......................................51
10.1 Software Installation Procedure.....................................................51
10.2 Server Utilities ...............................................................................56
10.3 Network Port Setup .......................................................................56
10.4 Add Printer ....................................................................................57
11. UNIX System Network.................................................................................61
11.1 Introduction....................................................................................61
11.2 Enable MFP Server’s TCP/IP Support...........................................61
11.3 Setup MFP Server’s IPAddress....................................................61
11.3.1 DHCP.....................................................................................62
11.3.2 BOOTP...................................................................................62
11.4 Verify MFP Server’s IPAddress.....................................................63
11.5 Configure Remote LPD Printing on the Host.................................63
12. MFP Server Installation in MAC OS.............................................................66
13. Troubleshooting...........................................................................................70
Appendix A: MFP Server Compatibility List ........................................................72
Appendix B: Specification...................................................................................74

1. Introduction
Thank you for purchasing and using our MFP print server. This FPS-1010M allows your
Multi-function printer (called for short: MFP) or printer to become a shared device on the
network. Unlike many print servers, it can communicate with MFP and printer as if it is
connected directly to your computer. Because of the features, all users can share print, scan,
fax and card reader functions through the network. Furthermore, the FPS-1010M can build
the bi-directional communication with MFPs and Printers so that it can help to monitor
important information such as ink levels and paper levels.
The FPS-1010M supports print, scan, fax and card reader sharing functions in Windows 2000
SP4 above and XP SP1 above. It also supports Windows XP scanning utility and MFP
vendors’ scanning utilities. When you want to scan in the Windows XP, you can choose one of
the utilities.
Not only be a MFP print server, this FPS-1010M can also be a traditional print server. It
supports TCP/IP network protocol and LPR and IPP printing protocols. It can share print
function in the various common network operating systems including Windows
98SE/Me/NT/2000/XP/2003, Unix, Linux and MAC OS 9.x above. And it is GDI interface
supported. So it can co-work with the GDI printer.
The FPS-1010M is the best solution for users to share MFP or printer conveniently and easily.
It offers the most flexibility and manageability for MFP or printer on your Local Area Network
at an extremely low cost and with an absolute minimum setup and maintenance required.
2. Product Package
This package contains the following components:
One FPS-1010M
One Power Adapter
One Quick Installation Guide
One CD-ROM (Including all the software utilities, drivers and User’s Manual)
1

3. MFP Server Installation in Windows 2000/XP
3.1 Hardware Installation
1. Unpack the FPS-1010M package and verify the items listed in the previous section are
provided.
2. Use USB cable to connect FPS-1010M to the MFP or printer that you want to share to
your network.
3. Use a RJ-45 cable to connect the FPS-1010M to your LAN or WAN.
4. Connect the bundled power adapter to FPS-1010M. The MFP Server will perform the
Power-On-Self-Test (POST) after power on. Please wait for 20 seconds.
Note:
1. Please use the power adapter which bundled with MFP Server. DO NOT use any other
power adapter from other sources. That may cause your FPS-1010M damage.
2. To prevent the compatibility problem between FPS-1010M and a few MFP or printer, it is
recommended that you power on the FPS-1010M before the MFP or printer.
3.2 Software Installation Procedure
Before installation begin, please check your computer’s operating system. The operation
below is the installation of Windows 2000 SP4 and Windows XP SP1 or above. For the
installation procedures in Windows 98SE/Me/NT and other operating systems, please refer to
the other sections.
Note:
Some MFP printers will ask the user connect MFP to the PC directly and install the printer
driver, before MFP Server installation. That may cause the MFP Server installation adds one
more MFP (printer/scanner/fax/card reader) to your PC. You can delete the devices which the
MFP driver installed after MFP Server installation, or you can keep those devices exist in your
PC.
1. Insert User’s Manual and utility CD into the CD-ROM drive to initiate the autorun program.
Once completed a menu screen will appear.
2. Click on “MFP Server Utility” hyper link to initiate the installation. Or you can click the
“Start” button and choose “Run”. (Suppose “E” is your CD-ROM drive). When the dialog
box appears, enter “E:\Utility\Setup.exe” and press enter key. You will see the dialog box
as below. Please click “Next” to continue.
3. The “MFP Server Utilities - InstallShiled Wizard” is displayed, click "Next".
2

4. Click “Next” to install the MFP Server utilities in the default folder or click “Change” to
specify the destination folder where you would like to install the MFP Server utilities.
5. The system starts installing the MFP Server Utilities.
3

6. The “MFP Server Configuration” screen is displayed. If you want to configure the MFP
Server, please select “Yes, I want to configure the MFP Server now.” and click “”Next”.
Then refer to the following steps to configure your MFP server. Or you can select “No, I
will configure the MFP Server later” and click “Next” to complete the installation.
7. The MFP Server List will auto search the MFP Servers in the network. Select the MFP
Server you wan to setup and click “Next” to continue.
4

8. Enter the “User Name” and “Password” of the MFP Server you have selected to login the
MFP Server. The default “User Name” and “Password” is “admin”. Click “OK”.
9. Set the “Alias Name” and the “MFP Server Description” to the MFP Server here. Click
“Next”.
Note:
You can define the location or other information of the MFP Server for easy to find the MFP
by filling “MFP Server Description”.
5

10. You can keep the MFP Server work with the obtain IP address or select “Assign MFP
Server IP Address” and enter the IP address to MFP Server directly. Please click “Next”.
11. The configurations are finished. Please click “Finish” to apply new settings.
6

12. Click “Finish” to complete the installation.
7

3.3 MFP Server Utilities
After the installation is completed, there will be three utilities in MFP Server’s Program folder.
MFP Server Control Manager – Allows you to manage the connection between the MFP and
your computer for sharing MFP function.
Server Configuration – Allows you to configure the MFP Server’s IP Address, network
protocols and other advanced features. It also allows you to manage the MFP Server.
Uninstall – Assistant for removing all installed MFP Server software programs.
About Version – This file has included the version list of the installed driver and utilities.
3.4 Install the MFP Drivers/Utilities
When the installation is completed, the “MFP Server Control Manager” will pop up. It will
automatically find the MFP Servers and the connected MFP and show it in the “MFP Server
List”. To start installing the MFP Drivers/Utilities, please follow the steps below.
8

1. Select the MFP which you want to install in the “MFP Sever List” and click “Install
Wizard”.
2. The following message is displayed to warn you that you have to follow the installation
instructions in the manual of the MFP. If the MFP is requiring you to connect the MFP to
your computer directly, please click “Connect”.
Note: Some MFP requires users to install the drivers/utilities before connecting the MFP to
your computer, please make sure you have followed the instructions of MFP. When the
MFP requires checking if you have connected the USB cable to MFP and your
computer, please click “Connect” to create the connection. Please refer to the below
9

illustration of “HP OfficeJet 5610” as an example.
3. If the MFP has required you to plug the USB cable between the MFP and your computer,
please click “Yes”.
4. Before creating the connection, you have to install two kinds of drivers: the drivers for
MFP Server and the drivers for MFP. Please click “Next” to start the installation.
5. When you are installing the MFP Server Drivers, the following message will be displayed
to notify you. When the MFP Server drivers are all installed, the message will be
disappeared automatically.
10

6. Select “Install the software automatically (Recommended)” to auto install the “MFP Server
Enhanced Controller” driver, then click “Next”.
7. The driver will be installed automatically. Click “Finish” to complete this driver installation.
11

8. The following message is displayed to remind you that you are now installing the MFP
Drivers. When you are sure that the MFP has been connected to MFP Server and the
MFP driver CD is insert to your CD-ROM completely, please click “Finish”.
9. Windows will start install the MFP. Please refer to your MFP manual and follow the steps
to install MFP driver and utility.
12

4. Using the MFP
After you have followed the install wizard to finish the MFP installation, the MFP is now
connected to your computer. You can start sharing print, scan, fax and card reader functions
provided on the MFP.
Note:
If you have finished using the MFP, please click “Disconnect” to release the MFP from your
PC. When there is a user using or connecting MFP, the other users can’t use the MFP until
the MFP is released. You may refer to MFP Server manual to setup the disconnect time to
make the users auto-disconnect when the MFP is no operation over the time.
4.1 Share Printer and Fax
The MFP will be added to “Printers and Faxes” in the Windows after the MFP is installed.
When you have connected to the MFP by clicking “Connect” in the “MFP Server Control
Manager”, the MFP Server will auto create the connection between the MFP and your
computer and then you can print a document just follows the same steps as usual.
13

4.2 Share Scanner
Most of the MFP provides scan utility for users. You can scan pictures or documents through
the utility. In Windows XP, user can also scan from Windows XP scanning utility.
An example: HP 5600 Series Utilities
14

Windows XP Scanning Utility
4.3 Share Card Reader
If the MFP supports card reader function, you can read the files from the plugged card reader
through the MFP Server.
15
