Planet WNRT-617G User manual

User’s Manual
www.PLANET.com.tw
150Mbps 802.11n
Wireless 3G Router
WNRT-617G

Copyright
Copyright 2013 by PLANET Technology Corp. All rights reserved. No part of this publication may be
reproduced, transmitted, transcribed, stored in a retrieval system, or translated into any language or computer
language, in any form or by any means, electronic, mechanical, magnetic, optical, chemical, manual or
otherwise, without the prior written permission of PLANET.
PLANET makes no representations or warranties, either expressed or implied, with respect to the contents
hereof and specifically disclaims any warranties, merchantability or fitness for any particular purpose. Any
software described in this manual is sold or licensed "as is". Should the programs prove defective following
their purchase, the buyer (and not this company, its distributor, or its dealer) assumes the entire cost of all
necessary servicing, repair, and any incidental or consequential damages resulting from any defect in the
software. Further, this company reserves the right to revise this publication and to make changes from time to
time in the contents hereof without obligation to notify any person of such revision or changes.
All brand and product names mentioned in this manual are trademarks and/or registered trademarks of their
respective holders.
Federal Communication Commission Interference Statement
This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to
Part 15 of FCC Rules. These limits are designed to provide reasonable protection against harmful
interference in a residential installation. This equipment generates, uses, and can radiate radio
frequency energy and, if not installed and used in accordance with the instructions, may cause
harmful interference to radio communications. However, there is no guarantee that interference will not occur in
a particular installation. If this equipment does cause harmful interference to radio or television reception, which
can be determined by turning the equipment off and on, the user is encouraged to try to correct the interference
by one or more of the following measures:
1. Reorient or relocate the receiving antenna.
2. Increase the separation between the equipment and receiver.
3. Connect the equipment into an outlet on a circuit different from that to which the receiver is
connected.
4. Consult the dealer or an experienced radio technician for help.
FCC Caution:
To assure continued compliance, (example-use only shielded interface cables when connecting to computer or
peripheral devices) any changes or modifications not expressly approved by the party responsible for
compliance could void the user’s authority to operate the equipment.
This device complies with Part 15 of the FCC Rules. Operation is subject to the Following two conditions:
(1) This device may not cause harmful interference
(2) This Device must accept any interference received, including interference that may cause undesired
operation.
Any changes or modifications not expressly approved by the party responsible for compliance could void the
user’s authority to operate the equipment.
I

Federal Communication Commission (FCC) Radiation Exposure Statement
This equipment complies with FCC radiation exposure set forth for an uncontrolled environment. In order to
avoid the possibility of exceeding the FCC radio frequency exposure limits, human proximity to the antenna
shall not be less than 20 cm (8 inches) during normal operation.
R&TTE Compliance Statement
This equipment complies with all the requirements of DIRECTIVE 1999/5/CE OF THE EUROPEAN
PARLIAMENT AND THE COUNCIL OF 9 March 1999 on radio equipment and telecommunication terminal
Equipment and the mutual recognition of their conformity (R&TTE).
The R&TTE Directive repeals and replaces in the directive 98/13/EEC (Telecommunications Terminal
Equipment and Satellite Earth Station Equipment) As of April 8, 2000.
Safety
This equipment is designed with the utmost care for the safety of those who install and use it. However, special
attention must be paid to the dangers of electric shock and static electricity when working with electrical
equipment. All guidelines of this and of the computer manufacture must therefore be allowed at all times to
ensure the safe use of the equipment.
National Restrictions
This device is intended for home and office use in all EU countries (and other countries following the EU
directive 1999/5/EC) without any limitation except for the countries mentioned below:
Country Restriction Reason/remark
Bulgaria None General authorization required for outdoor use and
public service
France
Outdoor use limited to 10
mW e.i.r.p. within the band
2454-2483.5 MHz
Military Radiolocation use. Refarming of the 2.4 GHz
band has been ongoing in recent years to allow current
relaxed regulation. Full implementation planned 2012
Italy None If used outside of own premises, general authorization is
required
Luxembourg None General authorization required for network and service
supply(not for spectrum)
Norway Implemented This subsection does not apply for the geographical area
within a radius of 20 km from the centre of Ny-Ålesund
Russian
Federation
None Only for indoor applications
Note: Please don’t use the product outdoors in France
WEEE regulation
To avoid the potential effects on the environment and human health as a result of the presence of
hazardous substances in electrical and electronic equipment, end users of electrical and electronic
equipment should understand the meaning of the crossed-out wheeled bin symbol. Do not dispose of
WEEE as unsorted municipal waste; they have to be collected separately.
II

Revision
User’s Manual for PLANET 802.11n Wireless 3G Router
Model: WNRT-617G
Rev: 2.0 (MAY. 2013)
Part No: EM-WNRT-617Gv2_v2.0 (2081-E50210-002)
III

CONTENTS
Chapter 1. Product Introduction...........................................................................................................1
1.1 Package Contents.................................................................................................................1
1.2 Product Description...............................................................................................................1
1.3 Product Features...................................................................................................................3
1.4 Product Specifications...........................................................................................................4
Chapter 2. Hardware Installation ..........................................................................................................7
2.1 Hardware Description............................................................................................................7
2.1.1 The Front Panel........................................................................................................7
2.1.2 LED Indications.........................................................................................................7
2.1.3 The Rear Panel.........................................................................................................9
Chapter 3. Connecting the Router......................................................................................................10
3.1 System Requirements.........................................................................................................10
3.2 Installing the Router ............................................................................................................10
Chapter 4. Quick Installation Guide ...................................................................................................12
4.1 Manual Network Setup - TCP/IP Configuration ..................................................................12
4.1.1 Obtain an IP Address Automatically........................................................................12
4.1.2 Configure the IP Address Manually ........................................................................15
4.2 Starting Setup in Web UI.....................................................................................................19
Chapter 5. Configuring the Router .....................................................................................................28
5.1 Login....................................................................................................................................28
5.2 Status ..................................................................................................................................28
5.3 Quick Setup.........................................................................................................................30
5.4 WPS ....................................................................................................................................30
5.5 Network ...............................................................................................................................34
5.5.1 Internet Access .......................................................................................................34
5.5.2 3G ...........................................................................................................................36
5.5.3 3G Advanced Settings ............................................................................................39
5.5.4 WAN........................................................................................................................41
5.5.5 LAN.........................................................................................................................53
5.5.6 MAC Clone .............................................................................................................54
5.6 Wireless...............................................................................................................................55
5.6.1 Wireless Settings....................................................................................................55
5.6.2 Wireless Security....................................................................................................58
5.6.3 Wireless MAC Filtering ...........................................................................................63
IV

5.6.4 Wireless Advanced .................................................................................................66
5.6.5 Wireless Statistics...................................................................................................68
5.7 DHCP ..................................................................................................................................69
5.7.1 DHCP Settings........................................................................................................69
5.7.2 DHCP Clients List ...................................................................................................70
5.7.3 Address Reservation ..............................................................................................71
5.8 Forwarding ..........................................................................................................................73
5.8.1 Virtual Servers ........................................................................................................73
5.8.2 Port Triggering ........................................................................................................76
5.8.3 DMZ ........................................................................................................................78
5.8.4 UPnP.......................................................................................................................79
5.9 Security ...............................................................................................................................80
5.9.1 Basic Security .........................................................................................................80
5.9.2 Advanced Security..................................................................................................82
5.9.3 Local Management .................................................................................................84
5.9.4 Remote Management .............................................................................................86
5.10 Parental Control ..................................................................................................................87
5.11 Access Control ....................................................................................................................91
5.11.1 Rule.........................................................................................................................91
5.11.2 Host.........................................................................................................................95
5.11.3 Target......................................................................................................................97
5.11.4 Schedule...............................................................................................................100
5.12 Advanced Routing.............................................................................................................102
5.12.1 Static Routing List.................................................................................................103
5.12.2 System Routing Table...........................................................................................104
5.13 Bandwidth Control.............................................................................................................105
5.13.1 Control Settings ....................................................................................................105
5.13.2 Rules List ..............................................................................................................106
5.14 IP & MAC Binding .............................................................................................................108
5.14.1 Binding Settings....................................................................................................108
5.14.2 ARP List................................................................................................................ 110
5.15 Dynamic DNS.................................................................................................................... 112
5.15.1 Comexe.cn DDNS ................................................................................................ 112
5.15.2 Dyndns.org DDNS ................................................................................................ 113
5.15.3 No-ip.com DDNS .................................................................................................. 114
5.15.4 Planetddns.com DDNS......................................................................................... 115
5.16 System Tools..................................................................................................................... 117
V

5.16.1 Time Settings........................................................................................................ 117
5.16.2 Diagnostic ............................................................................................................. 119
5.16.3 Firmware Upgrade................................................................................................121
5.16.4 Factory Defaults....................................................................................................122
5.16.5 Backup & Restore.................................................................................................123
5.16.6 Reboot ..................................................................................................................123
5.16.7 Password ..............................................................................................................124
5.16.8 System Log...........................................................................................................125
5.16.9 Statistics................................................................................................................128
Chapter 6. Quick Connection to a Wireless Network .....................................................................130
6.1 Windows XP (Wireless Zero Configuration)......................................................................130
6.2 Windows 7 (WLAN AutoConfig) ........................................................................................132
6.3 Mac OS X 10.x ..................................................................................................................135
6.4 iPhone / iPod Touch / iPad................................................................................................137
Appendix A: FAQ ..................................................................................................................................140
Appendix B: Configuring the PCs ......................................................................................................147
Appendix C: Specifications.................................................................................................................151
Appendix D: Glossary..........................................................................................................................154
VI

FIGURE
FIGURE 2-1 WNRT-617G FRONT PANEL..................................................................................................7
FIGURE 2-2 WNRT-617G FRONT PANEL..................................................................................................8
FIGURE 3-1 ADJUST THE DIRECTION OF THE ANTENNA ............................................................................. 11
FIGURE 3-2 HARDWARE INSTALLATION OF THE WNRT-617G WIRELESS ROUTER..................................... 11
FIGURE 4-1 CHANGE ADAPTER SETTINGS................................................................................................13
FIGURE 4-2 NETWORK CONNECTION PROPERTIES ..................................................................................13
FIGURE 4-3 TCP/IP SETTING.................................................................................................................14
FIGURE 4-4 OBTAIN AN IP ADDRESS AUTOMATICALLY ...............................................................................15
FIGURE 4-5 USE STATIC IP ADDRESS......................................................................................................16
FIGURE 4-6 WINDOWS 7-SEARCH BOX..................................................................................................17
FIGURE 4-7 SUCCESSFUL RESULT OF PING COMMAND .............................................................................17
FIGURE 4-8 FAILED RESULT OF PING COMMAND ......................................................................................18
FIGURE 4-9 LOGIN THE ROUTER.............................................................................................................19
FIGURE 4-10 LOGIN WINDOW ................................................................................................................19
FIGURE 4-11 WNRT-617G WEB UI SCREENSHOT..................................................................................20
FIGURE 4-12 QUICK SETUP ...................................................................................................................20
FIGURE 4-13 QUICK SETUP –INTERNET ACCESS ....................................................................................21
FIGURE 4-14 QUICK SETUP –3G...........................................................................................................22
FIGURE 4-15 QUICK SETUP –WAN CONNECTION TYPE ..........................................................................23
FIGURE 4-16 QUICK SETUP –PPPOE....................................................................................................23
FIGURE 4-17 QUICK SETUP –STATIC IP .................................................................................................24
FIGURE 4-18 QUICK SETUP –MAC CLONE ............................................................................................24
FIGURE 4-19 QUICK SETUP –WIRELESS ................................................................................................25
FIGURE 4-20 QUICK SETUP –FINISH (NO WIRELESS PARAMETER CHANGED) ............................................27
FIGURE 4-21 QUICK SETUP –FINISH (REBOOT IS REQUIRED) ..................................................................27
FIGURE 5-1 MAIN MENU ........................................................................................................................28
FIGURE 5-2 ROUTER STATUS .................................................................................................................29
FIGURE 5-3 WPS..................................................................................................................................30
FIGURE 5-4 HARDWARE WPS/RESET BUTTON .......................................................................................31
FIGURE 5-5 SOFTWARE WPS/RESET BUTTON ........................................................................................31
FIGURE 5-6 ADD A NEW DEVICE ..............................................................................................................32
FIGURE 5-7 NEW DEVICE CONNECTED SUCCESSFULLY ............................................................................33
FIGURE 5-8 THE NETWORK MENU ..........................................................................................................34
FIGURE 5-9 INTERNET ACCESS MODE ....................................................................................................34
FIGURE 5-10 3G ...................................................................................................................................36
FIGURE 5-11 3G USB MODEM SETTINGS ...............................................................................................38
FIGURE 5-12 ADD OR MODIFY A 3G USB MODEM ENTRY........................................................................39
FIGURE 5-13 3G ADVANCED SETTINGS ..................................................................................................40
VII

FIGURE 5-14 WAN -DYNAMIC IP...........................................................................................................42
FIGURE 5-15 WAN -STATIC IP ..............................................................................................................43
FIGURE 5-16 WAN –PPPOE ................................................................................................................44
FIGURE 5-17 PPPOEADVANCED SETTINGS ...........................................................................................46
FIGURE 5-18 WAN –BIGPOND CABLE ...................................................................................................47
FIGURE 5-19 WAN -L2TP SETTINGS.....................................................................................................49
FIGURE 5-20 WAN -PPTP SETTINGS....................................................................................................51
FIGURE 5-21 LAN SETTINGS .................................................................................................................53
FIGURE 5-22 MAC ADDRESS CLONE......................................................................................................54
FIGURE 5-23 WIRELESS MENU ...............................................................................................................55
FIGURE 5-24 WIRELESS SETTINGS.........................................................................................................55
FIGURE 5-25 WDS SETTINGS................................................................................................................57
FIGURE 5-26 WIRELESS SECURITY -NONE.............................................................................................59
FIGURE 5-27 WIRELESS SECURITY -WEP .............................................................................................59
FIGURE 5-28 WIRELESS SECURITY -WPA/WPA2 ENTERPRISE ...............................................................61
FIGURE 5-29 WIRELESS SECURITY -WPA/WPA2 PERSONAL..................................................................62
FIGURE 5-30 WIRELESS MAC ADDRESS FILTERING ................................................................................63
FIGURE 5-31 ADD OR MODIFY WIRELESS MAC ADDRESS FILTERING ENTRY ............................................64
FIGURE 5-32 WIRELESS MAC ADDRESS FILTERING ................................................................................65
FIGURE 5-33 WIRELESS ADVANCED .......................................................................................................66
FIGURE 5-34 THE ROUTER ATTACHED WIRELESS STATIONS......................................................................68
FIGURE 5-35 THE DHCP MENU..............................................................................................................69
FIGURE 5-36 DHCP SETTINGS ..............................................................................................................69
FIGURE 5-37 DHCP CLIENTS LIST .........................................................................................................71
FIGURE 5-38 ADDRESS RESERVATION ....................................................................................................72
FIGURE 5-39 ADD OR MODIFY AN ADDRESS RESERVATION ENTRY ...........................................................72
FIGURE 5-40 THE FORWARDING MENU ...................................................................................................73
FIGURE 5-41 VIRTUAL SERVERS ............................................................................................................74
FIGURE 5-42 ADD OR MODIFY A VIRTUAL SERVER ENTRY........................................................................75
FIGURE 5-43 PORT TRIGGERING ............................................................................................................76
FIGURE 5-44 ADD OR MODIFY A TRIGGERING ENTRY...............................................................................77
FIGURE 5-45 DMZ ................................................................................................................................78
FIGURE 5-46 UPNPSETTING.................................................................................................................79
FIGURE 5-47 THE SECURITY MENU.........................................................................................................80
FIGURE 5-48 BASIC SECURITY ...............................................................................................................81
FIGURE 5-49 ADVANCED SECURITY........................................................................................................83
FIGURE 5-50 LOCAL MANAGEMENT ........................................................................................................85
FIGURE 5-51 REMOTE MANAGEMENT .....................................................................................................86
FIGURE 5-52 PARENTAL CONTROL SETTINGS..........................................................................................87
FIGURE 5-53 ADD OR MODIFY PARENTAL CONTROL ENTRY .....................................................................89
VIII

FIGURE 5-54 PARENTAL CONTROL SETTINGS..........................................................................................90
FIGURE 5-55 ACCESS CONTROL ............................................................................................................91
FIGURE 5-56 ACCESS CONTROL RULE MANAGEMENT .............................................................................91
FIGURE 5-57 ADD OR MODIFY INTERNET ACCESS CONTROL ENTRY.........................................................93
FIGURE 5-58 ACCESS CONTROL RULE LIST ............................................................................................94
FIGURE 5-59 ACCESS CONTROL HOST SETTINGS....................................................................................95
FIGURE 5-60 ADD OR MODIFY A HOST ENTRY –IP MODE........................................................................96
FIGURE 5-61 ADD OR MODIFY A HOST ENTRY –MAC ADDRESS MODE ....................................................96
FIGURE 5-62 HOST SETTINGS LIST ........................................................................................................97
FIGURE 5-63 TARGET SETTINGS ............................................................................................................97
FIGURE 5-64 ADD OR MODIFY AN ACCESS TARGET ENTRY ......................................................................99
FIGURE 5-65 ADD OR MODIFY AN ACCESS TARGET ENTRY ......................................................................99
FIGURE 5-66 TARGET SETTINGS LIST...................................................................................................100
FIGURE 5-67 SCHEDULE SETTINGS ......................................................................................................100
FIGURE 5-68 ADVANCED SCHEDULE SETTINGS.....................................................................................101
FIGURE 5-69 SCHEDULE SETTINGS LIST...............................................................................................102
FIGURE 5-70 ADVANCED ROUTING .......................................................................................................103
FIGURE 5-71 STATIC ROUTING .............................................................................................................103
FIGURE 5-72 ADD OR MODIFY A STATIC ROUTE ENTRY..........................................................................103
FIGURE 5-73 SYSTEM ROUTING TABLE .................................................................................................105
FIGURE 5-74 BANDWIDTH CONTROL.....................................................................................................105
FIGURE 5-75 BANDWIDTH CONTROL SETTINGS.....................................................................................106
FIGURE 5-76 BANDWIDTH CONTROL RULES LIST ..................................................................................106
FIGURE 5-77 BANDWIDTH CONTROL RULE SETTINGS............................................................................107
FIGURE 5-78 THE IP &MAC BINDING MENU .........................................................................................108
FIGURE 5-79 BINDING SETTING............................................................................................................108
FIGURE 5-80 IP &MAC BINDING SETTING (ADD &MODIFY)..................................................................109
FIGURE 5-81 FIND IP &MAC BINDING ENTRY ...................................................................................... 110
FIGURE 5-82 ARP LIST ....................................................................................................................... 110
FIGURE 5-83 COMEXE.CN DDNS SETTINGS ......................................................................................... 112
FIGURE 5-84 DYNDNS.ORG DDNS SETTINGS....................................................................................... 113
FIGURE 5-85 NO-IP.COM DDNS SETTINGS ........................................................................................... 114
FIGURE 5-86 WAN SETTINGS .............................................................................................................. 115
FIGURE 5-87 PLANETDDNS.COM DDNS SETTINGS ............................................................................... 116
FIGURE 5-88 MY DEVICES ................................................................................................................... 116
FIGURE 5-89 THE SYSTEM TOOLS MENU .............................................................................................. 117
FIGURE 5-90 TIME SETTINGS ............................................................................................................... 117
FIGURE 5-91 DIAGNOSTIC TOOLS......................................................................................................... 119
FIGURE 5-92 DIAGNOSTIC RESULTS .....................................................................................................120
FIGURE 5-93 FIRMWARE UPGRADE ......................................................................................................121
IX

X
FIGURE 5-94 RESTORE FACTORY DEFAULT...........................................................................................122
FIGURE 5-95 BACKUP &RESTORE CONFIGURATION..............................................................................123
FIGURE 5-96 REBOOT THE ROUTER .....................................................................................................123
FIGURE 5-97 PASSWORD .....................................................................................................................124
FIGURE 5-98 SYSTEM LOG ..................................................................................................................125
FIGURE 5-99 MAIL ACCOUNT SETTINGS................................................................................................126
FIGURE 5-100 MAIL ACCOUNT SETTINGS -AUTHENTICATION .................................................................127
FIGURE 5-101 STATISTICS ...................................................................................................................128
FIGURE 6-1 WIRELESS ZERO CONFIGURATION......................................................................................130
FIGURE 6-2 CHOOSE A WIRELESS NETWORK .........................................................................................130
FIGURE 6-3 ENTER THE ENCRYPTION KEY .............................................................................................131
FIGURE 6-4 WIRELESS NETWORK CONNECTED.....................................................................................131
FIGURE 6-5 WLAN AUTOCONFIG.........................................................................................................132
FIGURE 6-6 WLAN AUTOCONFIG WINDOW ...........................................................................................132
FIGURE 6-7 WLAN AUTOCONFIG –TYPE THE NETWORK SECURITY KEY .................................................133
FIGURE 6-8 WLAN AUTOCONFIG –CONNECTING..................................................................................133
FIGURE 6-9 WLAN AUTOCONFIG –CONNECTED ..................................................................................134
FIGURE 6-10 THE AIRPORT NETWORK CONNECTION ICON ....................................................................135
FIGURE 6-11 THE AIRPORT NETWORK CONNECTION MENU ...................................................................135
FIGURE 6-12 THE AIRPORT NETWORK CONNECTION –ENTER PASSWORD..............................................136
FIGURE 6-13 THE AIRPORT NETWORK CONNECTION –CONNECTED.......................................................136
FIGURE 6-14 THE WI-FI SETTINGS IN IPHONE/IPOD TOUCH/IPAD...........................................................137
FIGURE 6-15 GENERAL SETTINGS ........................................................................................................137
FIGURE 6-16 GENERAL SETTINGS –NOT CONNECTED ..........................................................................138
FIGURE 6-17 GENERAL SETTINGS –WI-FI ON......................................................................................138
FIGURE 6-18 GENERAL SETTINGS –ENTER PASSWORD.........................................................................139
FIGURE 6-19 GENERAL SETTINGS –WI-FI NETWORK CONNECTED ........................................................139
FIGURE A-1 PPPOECONNECTION TYPE ..............................................................................................140
FIGURE A-2 MAC CLONE ....................................................................................................................141
FIGURE A-3 VIRTUAL SERVERS ............................................................................................................142
FIGURE A-4 ADD OR MODIFY A VIRTUAL SERVER ENTRY .......................................................................142
FIGURE A-5 DMZ................................................................................................................................143
FIGURE A-6 BASIC SECURITY ..............................................................................................................144
FIGURE A-7 REMOTE MANAGEMENT ....................................................................................................145
FIGURE A-8 VIRTUAL SERVERS ............................................................................................................145
FIGURE A-9 ADD OR MODIFY A VIRTUAL SERVER ENTRY .......................................................................146
FIGURE B-1 NETWORK CONNECTION PROPERTIES ...............................................................................147
FIGURE B-2 TCP/IP SETTINGS ............................................................................................................148
FIGURE B-3 TCP/IP –OBTAIN AN IP ADDRESS AUTOMATICALLY .............................................................149
FIGURE B-4 TCP/IP SETTINGS –STATIC IP..........................................................................................150

User’s Manual of WNRT-617G
-1-
Chapter 1.Product Introduction
1.1 Package Contents
The following items should be included in the package:
WNRT-617G Wireless 3G Router
5dBi Antenna
Power Adapter
Ethernet Cable
Quick Installation Guide
CD-ROM (User’s Manual included)
If there is any item missing or damaged, please contact the seller immediately.
1.2 Product Description
3G Broadband Sharing
PLANET Wireless 3G Router, WNRT-617G, provides home and SOHO users with a reliable and cost
effective wireless solution by featuring 3G/WAN backup Internet access and high speed IEEE 802.11n
wireless transmission. The WNRT-617G is equipped with one USB port for connection to mobile
network of UMTS / HSPA / EVDO via 3G/3.5G USB modem and one WAN port for wired cable and
DSL service connection. The 3G/3.5G USB capability of the WNRT-617G features activating internet
connection anytime and the redundant WAN interface to ensure the most reliable connection. The
WNRT-617G provides more flexible and easier way for users to create an instant wireless network
sharing service via 3G modem wherever at Home, Hotspot or in public places like transportation,
outdoor event, etc.
High Speed 802.11n Wireless
The WNRT-617G features the latest IEEE 802.11n radio with 1T1R antenna technology to provide
improved wireless speed and coverage with up to 150Mbps upload and download data rate. The
incredible wireless speed makes it ideal for handling multiple video stream, on-line music, VoIP and
data streams at the same time stably and smoothly. It is also backward compliant with 802.11g and
802.11b standards; thus it does not need to change the existing network for maintaining connectivity.
Just connect to the WNRT-617G and you can immediately enjoy the high-speed wireless sharing.
Wireless Coverage Plus !
With one 5dBi high-gain antenna attached, the WNRT-617G provides stronger signal quality and more

User’s Manual of WNRT-617G
-2-
excellent performance than normal wireless routers especially when in the long range or poor
environment condition for further wireless coverage range. With the detachable RP-SMA connector
design, the WNRT-617G allows users to manually exchange higher gain antenna for greater wireless
distances and coverage range across home and building. Besides essential wireless sharing for Wi-Fi
clients, the WNRT-617G provides WDS (Wireless Distribution System) bridge mode to facilitate
wireless network deployments and range expansion. It provides more flexibility for users while establishing
wireless network.
Wide Range of Wireless Security Support
To secure the wireless communication, the WNRT-617G supports not only 64/128/152-Bit WEP, but
also up-to-date encryptions including WPA-PSK/WPA2-PSK with TKIP/AES, wireless MAC filtering
and SSID broadcast control to consolidate the wireless network security and prevent unauthorized
wireless connection.
Easy, Secure Wireless Connection
In order to simplify security settings for home and SOHO network, the WNRT-617G supports Wi-Fi
Protected Setup (WPS) with configuration in PBC and PIN type. Just push the WPS button or key in
the PIN code and the secure connection between the WNRT-617G and wireless clients will be built
immediately. It offers a convenient and fast method for users.
Advanced Firewall Security
To protect user’s network from external attacks, the WNRT-617G provides dual firewall mechanisms –
NAT and SPI. The NAT function allows multiple users to access to Internet via a single legal IP, and the
SPI (Stateful Packet Inspection) firewall protects intranet PCs from unauthorized access and prevents possible
DoS attacks from the Internet. In the aspect of firewall, the WNRT-617G supplies flexible IP-Based
Access Control, schedulable MAC access control andURL block toprevent possible hackers attack.
Full Functioned Router
As a robust broadband router, the WNRT-617G supports various Internet connection protocols and
auto detect function to establish Internet service when the ISPs use different connection type. It also
provides Virtual Server and DMZ functions for LAN PC to act as an application server and offer certain
service to the clients in the LAN. The WNRT-617G allows users to set up trigger ports of special
WPS
STEP.1
CLICK
STEP.2
WLAN LANSYSPWR
1 32 4
WAN WPS
WPS/Reset
3G
PUSH
STEP.3
Connection
WPS (Wi-Fi Protected Setup)
Quick & Easy Wireless connection

User’s Manual of WNRT-617G
-3-
applications and utilize Internet services smoothly. Moreover, IP-Based ingress and egress bandwidth
control optimizes time-critical applications such as VoIP or video conference not to be interrupted or
lagged due to P2P file download by other clients in the same network environment.
Easy to Set up
Users can easily configure the wireless router by running the Smart Setup! Wizard included in the
CD-ROM provided in the package. Just click the wizard and set up step by step. You can easily get in
the wireless network and enjoy high speed Internet transmission in home or office.
1.3 Product Features
Industrial Compliant Wireless LAN & LAN
Compliant with IEEE 802.11n wireless technology capable of up to 150Mbps data rate
Backward compatible with 802.11b/g standard
Equipped with four LAN ports (10/100Mbps) and one WAN port (10/100Mbps), Auto
MDI/MDI-X supported
3G / 3.75G Mobile Internet Connection
Dual Network Interfaces: WAN port for cable / wired DSL service and 3G mobile
connection
Compatible with UMTS / HSPA / EVDO Mobile Network
Fixed-network 3G Router
Supported connection types: Dynamic IP/ Static IP / PPPoE / Telstra Big Pond / L2TP /
PPTP
Supports Static Routing, WDS, UPnP, Dynamic DNS
Secure Network Connection
Supports Wi-Fi Protected Setup (WPS)
Advanced security: 64/128/152-bit WEP, WPA/WPA2 and
WPA-PSK/WPA2-PSK(TKIP/AES encryption), 802.1x
Supports NAT firewall features, with SPI function to protect against DoS attacks.
Supports IP / Protocol-based access control and MAC Filtering
Advanced Networking function for Specific Application
Supports multiple sessions IPSec, L2TP and PPTP VPN pass-through
Supports Virtual Server, ALG, DMZ and UPnP for various networking applications
Supports DHCP Server
Easy Installation & Management
Web-based UI for and Quick setup for easy configuration

User’s Manual of WNRT-617G
-4-
Remote Management allows configuration from a remote site
System status monitoring includes DHCP Client, System Log
1.4 Product Specifications
Product WNRT-617G
150Mbps 802.11n Wireless 3G Router
Hardware Specification
WAN Port: 1 x 10/100Mbps Auto MDI/MDI-X RJ45 port
Interface LAN Port: 4 x 10/100Mbps Auto MDI/MDI-X RJ45 ports
Gain: 1 x Detachable RP-SMA Connector
1 x 5dBi antenna included in the package
Antenna
Orientation: Omni-directional
Power Button Power On/Off button at rear panel
WPS / Reset Button WPS / Reset button at front panel
Push for above 5 seconds to reset to factory default setting
LED Indicators PWR, SYS, WLAN, LAN x 4, WAN, 3G, WPS with green light
Material Plastic
Wireless Interface Specification
Standard Compliance with IEEE 802.11b/g/n
Frequency Band 2.4~2.4835GHz
Extend Frequency DSSS
Modulation Type DBPSK, DQPSK, QPSK, CCK and OFDM (BPSK/QPSK/16-QAM/ 64-QAM)
Data Transmission
Rates
11n: 135/121.5/108/81/54/40.5/27/13.5Mbps
130/117/104/78/52/39/26/13Mbps
65/58.5/52/39/26/19.5/13/6.5Mbps (Dynamic)
11g: 54/48/36/24/18/12/9/6Mbps (Dynamic)
11b: 11/5.5/2/1Mbps (Dynamic)
Transmission
Distance
Indoor up to 100m
Outdoor up to 300m (it is limited to the environment)
Channel
America/ FCC: 2.414~2.462GHz (11 Channels)
Europe/ ETSI: 2.412~2.472GHz (13 Channels)
Japan/ TELEC: 2.412~2.484GHz (14 Channels)
RF Power
High: 18 dBm (max)
Middle: 15 dBm
Low: 12 dBm
Receive Sensitivity
130M: -68dBm@10% PER
108M: -68dBm@10% PER
54M: -68dBm@10% PER
11M: -85dBm@8% PER
6M: -88dBm@10% PER

User’s Manual of WNRT-617G
-5-
1M: -90dBm@8% PER
Wireless Management Features
Wireless Operation
Mode AP, WDS (AP+Bridge)
WEP (64/128/152-bit) encryption security
Encryption Security WPA-PSK / WPA2-PSK (TKIP/AES)
WPA / WPA2 (TKIP/AES)
WPA / WPA2 enterprise mode (802.1x authentication)
Provides wireless LAN ACL (Access Control List) filtering
Wireless MAC address filtering
Supports WPS(WIFI Protected Setup )
Wireless Security
Enable/Disable SSID Broadcast
Supports 802.11e WMM (Wi-Fi Multimedia)
Supports Wireless Roaming
Wireless Advanced
Provides Wireless Statistics
Router Features
Internet Connection
Type
Shares data and Internet access for users, supporting the following internet accesses:
PPPoE / Russia PPPoE
Dynamic IP
Static IP
Telstra Big Pond
PPTP / Russia PPTP
L2TP / Russia L2TP
NAT firewall with SPI (Stateful Packet Inspection)
NAT with ALG (Application Layer Gateway)
Built-in NAT server supporting Virtual Server, and DMZ
Built-in firewall with IP address filtering, Domain Name filtering, and MAC address filtering
Firewall
Supports ICMP-FLOOD, UDP-FLOOD, TCP-SYN-FLOOD filter, DoS protection
Routing Protocol Static Routing
VPN Pass-through PPTP, L2TP, IPSec
Built-in DHCP server supporting static IP address distributing
Supports UPnP, Dynamic DNS
Supports Flow Statistics
IP & MAC Binding
IP / Protocol-based Bandwidth Control
LAN
Session Number: Max 5210
Web-based (HTTP) management interface
Remote management
System Management
SNTP time synchronize

User’s Manual of WNRT-617G
-6-
Easy firmware upgrade
System Log supports auto mail and saves to local host
OS Compatibility
Windows 7(32-bit/64-bit)
Windows Vista (32-bit/64-bit)
Windows XP
Mac OS X 10.4 and higher
Standards Conformance
IEEE Standards
IEEE 802.11n (1T1R, up to 150Mbps)
IEEE 802.11g
IEEE 802.11b
IEEE 802.11i
IEEE 802.3 10Base-T
IEEE 802.3u 100Base-TX
IEEE 802.3x Flow Control
Other Protocols and
Standards
CSMA/CA, CSMA/CD, TCP/IP, DHCP, ICMP, NAT, PPPoE, SNTP

User’s Manual of WNRT-617G
-7-
Chapter 2.Hardware Installation
Please follow the instructions below to build the wireless network connection between WNRT-617G and your
computers.
2.1 Hardware Description
2.1.1 The Front Panel
The front panel provides a simple interface monitoring the router. Figure 2-1 shows the front panel of
the WNRT-617G.
Front Panel
Figure 2-1WNRT-617G Front Panel
WPS/Reset Button
ACTIVE TIME
WPS Press and hold the button for less than 5 seconds for WPS configuration
Reset Press and hold the button for more than 8 seconds for the factory default
setting
2.1.2 LED Indications
The front panel LEDs indicates instant status of port links, wireless data activity and system power,
and helps monitor and troubleshoot when needed. Figure 2-2 shows the LED indications of the
Wireless Router.
Power LED
System LED
Wireless LED
WPS Function LED
3G Connection LED
WPS/Reset Button
WAN Port Status LED
LAN1~LAN4 LED

User’s Manual of WNRT-617G
-8-
LED Definition
Figure 2-2WNRT-617G Front Panel
LED Status Function
On Power is on.
PWR Off Power is off.
On The Router is initializing.
Flashing The Router is working properly.
SYS
Off The Router has a system error.
Flashing The Wireless function is enabled.
WLAN Off The Wireless function is disabled.
On A device is linked to the corresponding port but there is no activity.
Flashing An active device is linked to the corresponding port.
LAN1-4
Off No device is linked to the corresponding port.
On A device is linked to the corresponding port but there is no activity.
Flashing An active device is linked to the corresponding port.
WAN
Off No device is linked to the WAN port.
On The USB 3G dongle is connected.
Flashing Data is received or sent through the 3G dongle.
3G
Off No device is linked to the USB port.
Slow Flashing A wireless device is connecting to the network by WPS function. This
process will last for about 2 minutes.
On A wireless device has been successfully added to the network by WPS
function. The LED will keep on for about 5 minutes.
WPS
Quick
Flashing
A wireless device has failed to be added to the network by WPS
function.
1. When a device has been successfully added to the network by WPS function, the
WPS LED will keep on for about 5 minutes and then turn off.
2. When pressing and holding the WPS/Reset Button for more than 5 seconds, you
will reset the router.

User’s Manual of WNRT-617G
-9-
2.1.3 The Rear Panel
Figure 2-3 Rear Panel
Interface Function
POWER The Power socket is where you will connect the power adapter.
Please use the power adapter provided with WNRT-617G.
ON/OFF The button of the power.
WAN Connect to the DSL/cable Modem, or Ethernet
1,2,3,4 (LAN)Connect to the user’s PC or network devices
USB Connect to the USB 3G modem
POWER ON/OFF
4 x 10/100Mbps LAN Ports
Connect to user’s PC or network devices
Power ON/OFF Button
Power Connector
WAN Port
(Connect to DSL/Cable Modem)
5dBi Antenna
USB port
(Connect to 3G Modem)
WAN 4 3 2 1
USB
