Planet WDRT-750AC User manual

Note
– 1 – – 2 –
– 3 – – 4 –
1. Package Contents
2. Hardware Installation
– 7 – – 8 –
5. Wireless Network Connection
4. Enter into the Web Management
– 5 – – 6 –
Wireless AP Quick Guide CD-ROM
12V / 0.5A Power Adapter
Ethernet Cable
You have already finished the configuration of the
WDRT-750AC. Now you can use your iPhone, iPad, laptop,
and any other Wi-Fi device to connect with it wirelessly and
start surfing the Internet.
2011-E50310-000
Thank you for choosing PLANET WDRT-750AC. Before installing
the router, please verify the following items in the package box.
If there is any item missing or damaged, please
contact the seller immediately.
Step 2: Follow the figure below to connect the network
devices. It depends on your network environment
to connect the WAN port to a Cable/xDSL modem,
or the Ethernet directly in your place.
Step 1: Connect the Power Adapter provided in the package
to the WDRT-750AC. The Power LED on the front
panel will turn on accordingly.
Step 3: After you enter into the Web User Interface, please
follow the indications on the screen to quickly set
up for the Internet connection.
Default IP Address: 192.168.1.1
Default User Name: admin
Default Password: admin
Default SSID: WDRT-750AC_2.4G
WDRT-750AC_5G
Default Wireless Encryption Type: None
Step 2: Highlight the wireless network (SSID) to connect
and click [Connect] button.
Step 1: Right-click on the network icon displayed in the
system tray.
WDRT-750AC
Quick Installation Guide
750Mbps 802.11ac Wireless
Broadband Router
Step 1: The Web management allows you to access and
manage the WDRT-750AC easily. Launch the Web
browser and enter the default IP address
http://192.168.1.1
Step 2: When you enter into the Web User Interface, please
enter the User Name and Password in the login
window. The default User Name and Password are
both “admin”. Then click “Login” button to
continue.
Step 3: Enter the encryption key of the WDRT-750AC if
necessary.
The above steps introduce simple installations and
configurations for the WDRT-750AC. For further configurations
of Wireless Dual Band, WAN, LAN, Firewall, Virtual Server,
DMZ, and DDNS, please refer to the user manual in the
CD-ROM. If you have further questions, please contact the
local dealer or distributor where you purchased this product.
Power Adapter
Power
RJ-45
RJ-11
RJ-45
Power Adapter
Power
Cable/xDSL
Modem
PC/Laptop
001101010
Phone Jack
3. Network Configuration (Windows 7)
1. Click “Start” button located in the lower-left corner of the
screen.
2. Click “Control Panel”.
3. Double-click “Network and Sharing Center” icon.
4. Click “Change Adapter Settings”.
5. Double-click “Local Area Connection” icon.
6. Select “Internal Protocol Version 4 (TCP/IPv4)” and
click “Properties” button.
7. Select “Obtain an IP address automatically” and
“Obtain DNS server address automatically”, and
then click “OK” button twice to save the configuration.
A computer with a wired Ethernet connection is required for the
first-time configuration of the Wireless Router.
Steps : Set your computer to get an IP address from the
Wireless Router:
Further Information
