PLASTIC VACUUM FORMING The Blynd Bow User manual

© 2016 PLASTIC VACUUM FORMING, INC.
4’x8’ BOW BLYND
ASSEMBLY INSTRUCTIONS
NOTE: Door comes
installed. Shown off for
clarity of other assemblies.
NOTE: Door panel may be
moved to any side when
utilized as a ground blynd.
NOTE: Window
is pre-bent to
insure stability
in window
track.
NOTE: When
securing walls,
start with the
top screw and
work downward.
Be sure not to
over torque
screws and
clips.
PANELS
SCREWS
CORNER
BRACKET
❿

© 2016 PLASTIC VACUUM FORMING, INC.
HELPFUL HINT:
It is recommended that you have an assistant help you with the assembly of the Bow Blynd.
NOTE:
Anchoring system is owner’s responsibility.
Plastic Vacuum Forming, Inc. assumes no liability for injury or damage to persons or property resulting from the use of its
products or services. The products that we sell must be assembled, installed, anchored and used with care, caution,
and common sense.
Please read all instructions before starting assembly.
RECOMMENDED TOOLS:
Cordless drill
Phillips Head Bit
BOXED:
Item List:
(1) Door panel with full size door
(1) Package screws & clips
(5) Side walls
(2) Aluminum T-bars (w/ L Bracket supports at bottom)
(1) 4’ x 8’ roof
(1) Roof support brace (connects to top of T-bars)
(1) 4’ x 8’ plywood floor
(6) Wall support corner brackets
(1) Door window
ASSEMBLY INSTRUCTIONS:
❶
Join back panels and front panels together with T-bar sandwiched between. Use seven screws and clips
per panel assembly. See detail.
❷
Place back panel between helper or a stable object. Overlap corner panels as shown and secure each side
panel to back panel with seven screws and clips.
❸
Slide plywood into bottom of back and side panel slots. NOTE: Plywood must be positioned with side
marked “UP” as shown. Extend the life of the floor with an exterior oil-based paint or water seal product.
❹
Slide front panel into position and secure to sides.
❺
Connect roof support brace.
❻
Position the roof over the wall flanges. From inside, push upper panel against roof flange and secure each
side with screws and clips.
❼
Turn the Bow Blynd on its side and secure plastic flanges to plywood. See illustration 3.
❽
Line up door stop and secure to floor flange as shown with flange turned outward.
❾
Install window with the bent side facing out.
❿
Install wall support corner brackets with existing holes in back corners.
NOTE: Floor handle only comes with a Tower Kit. To assemble use holes provided in floor to locate and install handle.
Use two 1/4"-20x1-1/4" Hex Capscrews, 5/16" fender washers, and 1/4"-20 Hex Nuts to secure.
DOWNLOAD AT WWW.BLYND.COM
Plastic Vacuum Forming, Inc. assumes no liability for injury or damage to persons or property resulting from
the use of its products or services. The products that we sell must be assembled, installed, anchored and
used with care, caution, and common sense.
Please read all instructions before starting assembly.
