Storage Canopy C3340 User manual

SHELTER
ASSEMBLY MANUAL
Model # C3340 Back wall & frame of
Container Shelter
C3340 Back wall & frame

1
SPECIFICATION
Width:33ft Length:40ft Height:15ft
IMPORTANT ----- READ MANUAL FIRST
Improper site preparation, Assembly and Maintenance may invalidate warranty and cause unnecessary and
costly mistake. If you have any questions contact your local dealer.
For User Friendly assembly we have identified each individual component with the part code as indicated in
the parts list. Please refer to the part code numbers and drawing to ensure problem free assembly.
It’s necessary to tighten the roof fabric enough to avoid “hammocks” on the roof and also re-tighten once or
twice again after a few months of use. This is important when assembly in cold weather (autumn and winter)
because the fabric is stiff then and when we got the sun and warm weather afterwards it will make the fabric
“slack” again and need to be re-tighten before next winter.
It’s the owners responsibility to take of snow immediately if not slide off by itself.
READ ALL INSTRUCTIONS BEFORE ASSEMBLY
1. Keep work area clean. Cluttered areas invite injuries. Do not set up near snow drifts, in slippery places, in
high winds, or wet location.
2. Keep children away. All children should be kept away from the work area.
3. Don’t over reach. Keep proper footing and balance at all times.
4. Do not assemble in under the influence of alcohol or drugs. Read warning labels on prescriptions to
determine if your judgment or reflexes are impaired while taking drugs. If there is any doubt, do not
assemble.
5. Be aware of possible windy conditions; fasten the bases in concrete if these conditions are likely to occur.
Remove the cover during hurricane.
6. Be careful with power and heat sources. Do not keep heat sources near the tarpaulin. Do not expose to
open flame.
7. Be aware of personal safety during assembly and use. Be carful not to pinch fingers with clips and tubes
when assembling: when using makes sure there is adequate ventilation for exhaust and other dangerous
fumes.

2
Parts List
Part Code
Description
Qty
1
Base plates for winch door
2
2
Eccentric base plates
2
3L
Standing leg at left
1
3R
Standing leg at right
1
4
Side leg on the top for front and back endwall
2
6L
Lower standing leg at left
1
6R
Lower standing leg at right
1
7
Upper standing leg for winch door
2
9
Door beam
1 Group
9A
Door boom
1
10
Horizontal tube for front door on the bottom
2
10A
Horizontal tube for front door on the top
2
11
Square tube for winch door
1
12
Mechanical wheel with wire rope
1
13
Bottom tension tube for front endwall
2
14
Door vertical tube
9 Groups
15
Clips φ60
6
15A
Welded iron plates for the side legs
2
15B
Single hole angle iron
1
16
Stake peg
8
17
Door splint
8
18
Bolts M10*30
2
19
Bolts M10*90
12
20
Bolts M10*60
4
21
Carriage Bolts M10*90
12
22
Carriage Bolts M12*100
4
23
Plastic Plug
4

3
24
Rope for pull door
1
25
Front cover
1
26
Added legs
2
27
Added door frame
2

4
SPECIFICATION
Width: 10m Length: 12m Height: 3.6m
IMPORTANT----- READ MANUAL FIRST
Improper site preparation, Assembly and Maintenance may invalidate warranty and cause
unnecessary and costly mistake. If you have any questions contact your local dealer.
For User Friendly assembly we have identified each individual component with the part code as
indicated in the parts list. Please refer to the part code numbers and drawing to ensure problem
free assembly.
It’s necessary to tighten the roof fabric enough to avoid “hammocks” on the roof and also
re-tighten once or twice again after a few months of use. This is important when assembly in cold
weather (autumn and winter) because the fabric is stiff then and when we got the sun and warm
weather afterwards it will make the fabric “slack” again and need to be re-tighten before next
winter.
It’s the owners responsibility to take of snow immediately if not slide off by itself.
READ ALL INSTRUCTIONS BEFORE ASSEMBLY
1. Keep work area clean. Cluttered areas invite injuries. Do not set up near snow drifts, in
slippery places, in high winds, or wet location.
2. Keep children away.All children should be kept away from the work area.
3.Don’t over reach. Keep proper footing and balance at all times.
4. Do not assemble in under the influence of alcohol or drugs. Read warning labels on
prescriptions to determine if your judgment or reflexes are impaired while taking drugs. If
there is any doubt, do not assemble.
5. Be aware of possible windy conditions; fasten the bases in concrete if these conditions are
likely to occur. Remove the cover during hurricane.
6. Be careful with power and heat sources. Do not keep heat sources near the tarpaulin. Do not
expose to open flame.

5
7. Be aware of personal safety during assembly and use. Be carful not to pinch fingers with clips
and tubes when assembling: when using makes sure there is adequate ventilation for exhaust and
other dangerous fumes.
EQUIPEMNT AND TOOLS FOR INSTALIATION
1. Measuring tape
2. String for alignment
3. Step ladder
4. Welder
5. Sledge hammer
6. Wrench
7. Scissors
INSTALLATION PROCESS
A—FRAME INSTALLATION
Please refer to the diagram (Figure 1) to install the base plate. UNIT: mm
Figure 1
There are four base plate comes with the back endwall. Each of them should be placed in the
right position(especially the two base plate close to the containers.)

6
Figure 2
C--INSTRUCTION FOR COVER ATTACHED
Assembly the end cover first.
NOTE: DO NOT install the cover onto the frame of your building in high wind conditions. A
slight breeze is the most advantageous for cover installation. To take advantage of the breeze,
pull the cover up over the arches with the breeze blowing in the cover like a sail filled with air.

7
Figure 3
The process is quite easy. But some tightening adjustments will be necessary to produce a flat. Please adjust
the cover timely.
