INSTRUCTION MANUAL
3L DEEP FRYER
INDOOR HOUSEHOLD USE ONLY
Please save and read this instruction manual carefully before use.
Article no. Model no. / Item no. EAN
10516696 DF7702-GS (SR 7483008) 6001224294033
10532066 DF7702-GS (SR 7740844) 6001224343472
10532067 DF7702-GS (SR 7740899) 6001224343489

1
ENGLISH
INTRODUCTION
Thank you for purchasing our “Platinum” Deep Fryer. Each unit has been manufactured to ensure
safety, reliability, and easy of use. Before use, please read these instructions carefully and save them
for future reference.
IMPORTANT SAFEGUARDS
When using your “Platinum” Deep Fryer, basic precautions should always be followed, including the
following:

This appliance is not intended for use by persons (including children) with reduced physical, sensory
or mental capabilities, or lack of experience and knowledge concerning the use of this product,
unless they are supervised or have been given instruction concerning use of the appliance by a
person responsible for their safety.
Children should be supervised to ensure that they do not play with the appliance.
Always ensure that the voltage on the rating label corresponds to the voltage in your home.
Check the power cord and plug regularly for any damage. If the cord or the plug is damaged, it
must be replaced by the manufacturer or a qualified person in order to avoid an electrical hazard.
This appliance is intended for household use only. Industrial or commercial use will void the
warranty, and the supplier can not be held responsible for injury or damage caused when using the
appliance for any other purpose than that intended.
Incorrect operation and improper use can damage the appliance and cause injury to the user.
Do not use the appliance if it has been dropped or damaged in any way. In case of damage, take
the unit in for examination and/or repair by an authorized service agent.
To reduce the risk of electric shock, do not immerse or expose the motor assembly, plug or the
power cord to water or any other liquid.
Never immerse the unit in water or any other liquid for cleaning purposes.
Remove the plug from the socket by gripping the plug. Do not pull on the cord to disconnect the
appliance. Always unplug the unit when not in use, before cleaning or when adding or removing
parts.
The use of accessory attachments that are not recommended or supplied by the manufacturer may
result in injuries, fire or electric shock.
Do not let the cord hang over the edge of a table or counter. Ensure that the cord is not in a
position where it can be pulled on inadvertently.
Do not allow the cord to touch hot surfaces and do not place on or near a hot gas or electric burner
or in a heated oven.
Never use this unit near bathtubs, showers, basins or other vessels containing water.
Use of an extension cord with this appliance is not recommended. However, if it is necessary to
use an extension lead, ensure that the lead is suited to the power consumption of the appliance to
avoid overheating of the extension cord, appliance or plug point. Do not place the extension cord
in a position where it can be pulled on by children or animals or tripped over.
If the supply cord is damaged, it must be replaced by the manufacturer, its service agent or similarly
qualified persons in order to avoid hazard.


2
This appliance is not suitable for outdoor use. Do not use this appliance for anything other than its
intended use.
Do not carry the appliance by the power cord.
Do not touch hot surfaces directly. Use handles or knobs.
Do not leave this appliance unattended during use. Always unplug the unit when not in use. Allow
it to cool before putting on or taking off parts, and before cleaning the appliance.
Always operate the appliance on a smooth, even and stable surface. Do not place the unit on a hot
surface.
The manufacturer does not accept responsibility for any damage or injury caused by the improper or
incorrect use of the appliance, or by repairs carried out by unauthorized personnel.
In case of technical problems, switch off the machine and do not attempt to repair it yourself.
Return the appliance to an authorized service facility for examination, adjustment or repair. Always
insist on the use of original spare parts. Failure to comply with the above mentioned precautions
and instructions, could affect the safe operation of this machine.
This appliance is intended to be used in household and similar applications such as:
- Staff kitchen areas in shops, offices and other working environments;
- Farm houses;
- By clients in hotels, motels and other residential type environments;
- Bed and breakfast type environments.
ENGLISH

3
KNOW YOUR DEEP FRYER
1. Lid
2. Frying basket handle
3. Frying basket
4. Oil reservoir
5. Fryer housing
6. Housing handle
7. Guide edges
8. Reset button
9. Temperature control
SPECIFICATIONS
Capacity: 3 Liters
Voltage: AC 230V / 50Hz
Wattage: 2000W
USING YOUR DEEP FRYER
You must read all instructions before using.
1. Remove all packaging and any labels.
2. This type of Deep Fryer may only be used with oil or liquid fat, and is not suitable for use with solid fat. Solid
fat may contain water, which can cause hot fat to be sprayed out when heated.
TO USE YOUR DEEP FRYER
1. Remove the lid from the deep fryer and take out the accessories.
2. Fill the Deep Fryer with the desired amount of oil or fat. Make sure that it is filled not less than
minimum level and not higher than the maximum level as indicated on the inside of the appliance. For
best results, we recommend that you do not mix different kinds of oil together.
3. Plug the appliance into the mains.
4. Choose the temperature, which is suitable for what you are frying. Consult the temperature table.
5. Prepare the food to be fried and place it in the basket, making sure that it does not rise above 2/3 of
its capacity.
ENGLISH
Plug Article no. Model no. / Item no. EAN
3R 16A South Africa Plug 10516696 DF7702-GS (SR 7483008) 6001224294033
3 Flat Pin 10532066 DF7702-GS (SR 7740844) 6001224343472
Schuko 10532067 DF7702-GS (SR 7740899) 6001224343489

4
6. Allow the food to drain before placing it in the basket.
7. Slowly place the basket into the oil reservoir avoid overflowing and splashing. Closed the lid whilst
cooking.
8. Once the food is cooked, turn the thermostat control to minimum position (MIN) and open the lid.
Carefully lift the basket and position it in the support in order to drain the oil from the food.
9. To remove excess oil, the food can be placed into a bowl or container lined with grease absorbing
paper or kitchen paper towels.
10. Unplug the fryer after use and allow it to cool.
FILLING THE FRYING BASKET & FRYING
WARNING: When frying frozen foods, remove the frying basket from the deep fryer before filling
because oil will spatter and cause burns.
CAUTION: When frying frozen foods such as French Fries, you should not exceed the 2/3 depth of the
fryer basket. Clean off any ice from frozen food prior to frying. Failure to do so may cause fryer to
overflow when food is placed in oil.
CAUTION: Never plug in the control panel when it is not assembled to the fryer body. Do not immerse
the control panel, power cord or plug in water or any other liquid.
1. Do not fill the frying basket when it is immersed in the hot oil.
2. Place the food in the frying basket. Do not drop the food into the hot cooking oil. Do not overfill it and
never exceed the 2/3 depth of the frying basket. For optimum results and shorter frying time, fry
smaller quantities.
3. Immerse the frying basket into the oil reservoir carefully so that you do not splash the oil.
4. Replace the lid on the deep fryer while it is frying.
5. When the cooking period is over, carefully remove the deep fryer lid, lifting it up away from you to allow
the steam to escape before removing the lid completely. Keep your face away from the top of the
appliance to avoid burns caused by escaping steam.
6. Turn the temperature control to the “MIN” position and remove the plug from the electrical wall outlet.
7. Lift up the frying basket by the handle and place it on the hook to allow the oil to drain.
8. Once the oil has drained from the frying basket, the basket may be lifted off and the food served or
placed in a dish.
WARNING: Always let the deep fryer cool completely (approximately 2 hours) before cleaning or storing.
Never carry or move the appliance with hot oil inside.
CAUTION: The metal surfaces of the deep fryer become hot during use. Do not touch the sides of the
appliance while it is use.
\
ENGLISH

5
FRYING TIPS
Always use the frying basket to fry food.
Always close the lid during frying.
When the oil is pre-heated, the ready indicator light will on, indicating that the desired temperature is
reached.
Slowly lower the frying basket into the hot oil. Lowering the frying basket too quickly can result in the
oil overflowing and splashing.
Replace the lid carefully.
It is normal for steam to escape through the sides of the lid while frying.
Avoid standing too close to the deep fryer while it is working.
Do not mix different oils or new and old oil together.
Replace oil regularly. In general, oil will be tainted fast when frying food containing a lot of protein,
(such as poultry, meat and fish). When oil is used mainly to fry potatoes and is filtered after each use,
it can be used up to 8 to 10 times, but do not use the same oil for more than 6 months.
Always replace all oil as soon as it starts foaming when heated or when color becomes dark or when
it has a rancid smell or taste or becomes syrupy.
Make sure that the food to be fried is dry.
Remove loose ice from frozen food before frying.
To cook evenly, pieces should be the same size and thickness.
Thicker pieces will take longer to cook.
Note: The following cooking times reflect only the approximate time needed to fry one basket. The exact
time may be different depending on actual quantity, personal cooking preferences, size and thickness of
pieces, etc.
TEMPERATURE SETTINGS
In general, use lower settings for delicate foods (vegetables, fish) and higher settings for frozen foods,
French Fries and chicken.
ENGLISH
FOOD
COOKING TIME
TEMPERATURE
French fries
8-10 minutes
190OC
Fish fillets
3-5 minutes
150OC
Chicken legs
13-20 minutes
170OC
Fried zucchini
3 minutes
150OC
Fried mushrooms
3 minutes
150OC
Onion rings
3 minutes
150OC
Donuts
3-5 minutes
170OC
Apple beignets
4 minutes
170OC
Shrimp
4-6 minutes
150OC

6
FILTERING & CHANGING THE OIL
Make sure the Deep Fryer is unplugged from the electrical socket and the oil has cooled (approximately
2 hours) before changing the oil, or cleaning and storing the Deep Fryer.
Note: The oil does not need to be changed after each use. In general, the oil will be tainted rather quickly
when frying food containing a lot of protein (such as poultry, meat or fish). When oil is mainly used to fry
potatoes and is filtered after each use, it can be used 8 to 10 times. However, do not use the same oil for
longer than 6 months.
To Filter the Oil:
1. Make sure the oil has cooled (approximately 2 hours) and then empty the oil from the oil reservoir into
another container or bottle.
2. Wash and dry the oil reservoir and frying basket.
3. Refill the oil reservoir with the oil by pouring the oil through a wire strainer or paper filter.
CARE AND CLEANING
Clean the Deep Fryer on both the inside and outside regularly.
Clean the outside of the Deep Fryer with a damp cloth and dry with a soft, clean cloth.
Never use abrasive cleaners or sponges.
Clean the control panel with a damp cloth only.
The basket and the handle can be cleaned in warm, soapy water. Dry well before using again.
When replacing the oil you can also clean the inside of the Deep Fryer. Empty the Deep Fryer and
first clean the inside with a paper towel and then with a cloth dipped in soap water. Then wipe with a
damp cloth and allow drying thoroughly.
All components, with the exception of the electrical parts, may be cleaned in warm soapy water. Dry
thoroughly before use.
Dishwasher cleaning is not recommended.
THE RESET FEATURE
Your deep fryer is equipped with a reset feature. If for some reason the deep fryer stops heating, the
reason may be that the reset switch has tripped.
To reset the deep fryer:
1. Unplug the appliance from the electrical wall outlet.
2. Let the appliance and the oil in the oil reservoir cool completely.
3. After the appliance has cooled completely, lift the control panel and
using the tip of a ball point pen or pencil, push the thermostat reset
button that is located on the inside of the control panel (Fig. 1)
4. Re-assemble the control panel to the housing of the deep fryer and then
you may resume frying.
ENGLISH
Fig. 1
RESET
BUTTON

7
TROUBLE SHOOTING:
Problem Possible Cause
The fryer is not
operating
1. The control assembly is not installed correctly.
2. The plug is not connected to the electrical
wall outlet.
3. The electrical outlet is notenergized.
4. The reset switch has tripped.
1. Re-attach the control panel assembly.
2. Insert the plug into the electrical wall outlet.
3. Reset circuit breaker or replace fuse.
4. Turn the appliance off and let it cool completely.
Then remove the control panel and press the
thermostat reset button.
Oil is spilling
out of the deep
fryer
1. Too much oil in the oil reservoir.
2. The foodbasket if overfilled.
3. Oil hasbeen used too often and is foaming.
1. Turn the deep fryer off.Let the oil cool
completely and remove some of the excess oil.
2. Remove some of the food from the basket.
3. Turn the deep fryer off.Let the oil cool
completely and refill the oil reservoir with new oil.
Food is tasting
soggy or
greasy
1. Oil is nothotenough.
2. The foodbasket is overfilled.
1. Adjust the temperature control dial to appropriate
temperature for foodbeing fried.
2. Remove some of the food from the basket.
Foodnot
cooked
completely
1. Food pieces too large.
2. Cooking time too short.
3. Oil temperature too hot.
1. Cut the food into smaller pieces.
2. Continue frying and check the process
continually.
3. Lower the temperature of the oil to allow the food
to cook completely.
The cooking oil
is foaming or
emitting smoke
The oil hasbeen used too often. Let the oil cool completely and replace with new oil.
ENGLISH

8
WARRANTY
Model number
(Lot number: )
Product name
Date of purchase
Place of purchase
1. The party selling the product (“the seller”) to the original purchaser of this product (“the customer”)
hereby warrants that this product will be of good quality and, in good working order and, free of defects
and suitable for its intended purpose under normal household use, for a period of 1(one) year from the
date of purchase (“warranty period”) of this product.
2. In the event that the warranty period has not lapsed and the product is not of a good quality, or in
good working order or, it defective or is not suitable for its intended purpose under normal household
use, the customer may, subject to paragraph 3 below, return the product to the seller and have the
following options available:
2.1 Within the first 6 (six) months of the warranty: to receive a refund of the actual price paid or to
exchange the product for the same or similar product of the same purchased value;
2.2 Within the second 6 (six) months of the warranty: to have the product exchanged for the same or
similar product of the same purchased value.
3. The seller will not replace the product or refund the customer in terms of this warranty if the product:
3.1 has been altered contrary to the instructions provided in the product manual;
3.2 has been misused, abused or tampered with;
3.3 is defective or not in working order due to ordinary wear and tear;
3.4 is damaged resulting from the customer’s gross negligence, recklessness, malicious
behavior or criminal conduct;
3.5 has been utilized for commercial use.
4. This warranty applies only to the product that has been purchased from the seller and not to any
expendables attached to or installed on the product by the customer.
5. Any claim in terms of the warranty must be supported by the original proof of purchase.
ENGLISH
PLEASE AFFIX YOUR RECEIPT/PROOF OF PURCHASE HERE.
IN THE EVENT OF A CLAIM UNDER THIS WARRANTY THE AFORESAID
RECEIPT/PROOF OF PURCHASE MUST BE PRODUCED TOGETHER WITH THIS WARRANTY.
6. Note that the exchange item will only carry the balance of the warranty period as from the original date
of purchase.
