PlayAlive SoundSystem One User manual

Installation manual v1
SoundSystem One
®

Content
1
1. Content
2. Component overview
2.1 Electronics
2.2 Steel components
2.3 Other
3. Inside components & sign mounting
3.1 Sound console components
4. Sound console
4.1 Installation
5. Power supply
5.1 230V power supply for sound console
6. Start up
6.1 Start up the sound console
6.2 Connect the sound console to a mobile device
6.3 Adjust volume

Component overview
2
1 x Splitter Sensor
P00250
3 x Dual adhesive tape
or male/female velcro
(for Sign)
1 x Termination Plug
(preinstalled in console)
P00252
1 x SoundSystem control box
IPSU
(preinstalled in console)
P00251
Installation manual
(this copy)
2.1 Electronics
2.2 Steel components
2.3 Other
1 x Power Cable
10 m (standard)
1 x Sign
for console
(either sourced locally or
ordered by PlayAlive)
1 x Bit TX 25 x 25 MB 4 x M5 Countersunk
16 mm A2
1 x Sound console
(stainless steel)
1 x Speaker
90 W
(preinstalled in console)

Inside components & sign mounting
3
LOGO
infowww
Conduit pipe
with cable to
power supply
Sign
Sensor
Dual adhersive tape
Top cover
Holes for
fastening
the sensor
SoundSystem control box
(230V AC / 24V DC)
Speaker 90W
3.1 Overview of individual console components

Installation
4
4.1 Installing the sound console
Seperate the console from its casting legs by remov-
ing the 4 screws at the bottom of the console. (The top
cover is reinstalled after casting and cable pulling.)
Use pull wire in the conduit pipe to draw power cable.
In order to avoid moisture from the ground, please seal
o the consoles connection to the ground.
Reinstall the top cover of the console, and fasten it at
the bottom with the 4 screws.
1.
2.
3.
4.
Sound console
Casting legs
Conduit pipe
with power
cable to standard
power outlet
Seal o the
connection to
the ground
- 0,30 m
0,00 m
- 0,60 m
- 0,70 m

Power supply
5
Optional: A timer controlling the electricity (power on/o)
can be added to the cabinet. Please see illustration of standard
timer that can be installed in a 110V/230V power outlet.
The timer need to be sourced locally. When applying a timer
the power can be switched o for examble at night time.
The optional timer
could look like this.
50 cm under ground
(recommended)
Power outlet
(230V)
Sound Console
Power cable in conduit pipe
Connect the power cable
to a power outlet
in nearby building.
5.1 230V power supply for sound console
230V
The system runs on 230V AC. A 24V DC power supply is installed in the
SoundSystem control box.
230V AC

Start up
6
6.1 Start up the sound console
Once the installation has been completed and the power has been
switched on, the sensor unit will light up in blue. When the sensor
is touched a voice command will follow: “Connect to the PlayAlive
SoundSystem by Bluetooth”.
6.2 Connect the sound console to a mobile device
Connect the sound console to a mobile device by opening Bluetooth
settings on the mobile device and nd “PlayAlive Sound System”.
The sound console have a default acces code “0000”. When the
sound console are connected to a mobile device a voice command
will follow: “Connection complete - enjoy 15 minutes of music”.
The user are now connected to the sound console and can listen to
music.
After 1 minute of inactivity the user will be disconnected from the
system and can reconnect again by following the above mentioned
guide.
6.3 Adjusting volume
Volume can be adjusted by simply holding on the sensor unit and
wait until all of the red lights are switched on.
One tap on the sensor unit adds a higher sound level.
When the desired sound level has been found the user hold on to
the sensor unit again until all lights on the sensor have turned on.
The system has to be switched o again if one wants to readjust
the sensor sound level.
Important!
The volume can only
be adjusted the rst 30
seconds after power have
been switch o.
