PLD MOBO-SX50 User manual

Motorized Flat Screen TV Stand / Cabinet Mount
PLD STUDIOS LLC Tel/Fax: [phone] [email protected] www.pldstudios.com

Please make sure you have all parts before beginning installation. If any parts are missing or damaged, contact your
retailer and DO NOT ATTEMPT INSTALLATION. Use only parts provided by the manufacturer or damage may result.
The following tools are necessary for proper installation. If you don't own them already, you could borrow them from
your neighbor. But if your neighbor is like ours, it's better to just go buy them
stud-finder
pencil 3/16”
drill bit
13/32”
masonry
drill bit
power drill hammer socket
wrench
Phillips
screw driver
①③
Plastic anchor sleeves
2 pcs
②
M6 x 50mm
Self-tapping screw
2 pcs
Washer
4 pcs
④
M6 x 25mm
TV Screw
4 pcs
⑤
M5 x 25mm
TV Screw
4 pcs
⑥
Spacer
4 pcs
⑦
Power adapter
1 pcs
⑧
M6 x 15mm
Bracket Screw
4 pcs

The television and bracket are heavy and must be attached securely to a wall or cabinet that is strong enough
to support them both. Attaching the wall support to directly to drywall without proper anchoring is not advised.
If you are not familiar with how to properly attach this product to your cabinet or wall, you should seek the advice
of an expert. The manufacturer and retailer DO NOT assume any liability for improper installations or misuse. So
if your television falls over, it is entirely your own problem.
DANGER!
This motorized bracket is an electrical device. This unit is designed for indoor use only. You should only use
it in a dry and clean environment, and plugged into a properly grounded electrical outlet. If you die of electrocution,
you will not be able to enjoy your television.
To reduce the risk of electrical shock you should take some basic precautions, including:
1. Always unplug the unit when installing, removing, mounting, adjusting, or cleaning the unit.
2. Never operate the unit outside of the limits, specifications or parameters described in this booklet.
3. Do not attach anything else to the bracket other than a television of the specified size/weight.
4. Do not attach any other accessories or devices, and do not let anyone touch the unit while in operation.
5. Never operate the system if it has become wet; if it shows any signs of damage; if it has become clogged
with dust, lint or hair; shows signs of excessive wear and tear; or, if the power cords have become
damaged or frayed.
6. Keep the unit and power cords away from heat sources such as vents, heaters, fireplaces, or radiators.
7. Use only a dry cloth to clean the unit; do not use any chemicals, sprays or liquids of any kind.
8. Periodically check to make sure all screws and fastening devices are properly tightened and secure.
To avoid damage to the screw threads be sure not to over-tighten.
This unit is designed for PROFESSIONAL INSTALLATION.
If you attempt installation yourself, you assume all risks
and consequences, so please be sure that you know what
you’re doing. If your spouse says, “Don’t worry, I know what
I’m doing,” you should probably still worry. Incorrect installation
can result in personal injury, and damage to your television
or other property.
The manufacturer and retailer are NOT responsible for improper
installations.
The limited warranty only covers defects in the design or
manufacture of the bracket, and doesn’t cover issues arising
from improper installation or misuse. If you are uncertain about
how to safely install this unit, please seek help from a professional
installer. These instructions are based upon a typical installation
scenario; your particular circumstances may require special
arrangements that are outside the scope of these instructions and
should be undertaken only by a trained professional.
WARNING!!!

We strongly recommend that this unit be installed
in consultation with a professional installer.
Safe installation will require at least two people.
Step 2. (A) Free Standing Installation
Step 1. Choose the installation type:
Attach the Base:
Attach the base (purchased separately) using the
screws provided along with the base unit.
Wall Support:
For Drywall:
Place the unit in the desired location. Use a pencil to lightly mark the location of
the holes. Pre-drill and install drywall anchors and screws. Attach the screws as
indicated.
For Masonry Wall:
Place the unit in the desired location. Use a pencil to lightly mark the location of
the holes. Use a 13/32” masonry bit on a percussion drill to pre-drill holes 2” deep.
Insert the masonry anchors into the holes, and install the screws as indicated.
Attach the Wall Support Bracket:
Remove the screws and reinstall them
along with the bracket, as indicated.
This unit is designed for either
“Standing” use or for use along with
a custom cabinetry solution.
Before you begin, you must
make sure your chosen installation
location can support the weight of both
the bracket and the television.
If you aren’t sure your desired location
can support the weight, consult an expert.
DO NOT attempt to use it
without proper Wall Support.
4 5 6 7

A. Secure the Wall Support Bracket
Align the wall bracket and use a pencil to mark the
proper location on the rear wall. Pre-drill starter holes if
necessary and use wood screws or bolts as necessary
based upon the specfics of your cabinet construction.
B. Secure the Base
Mark and drill holes as necessary based upon the specifics
of your cabinet construction and firmly screw/bolt the base
to the floor of the cabinet.
Step 2. (B) Cabinet Installation
The lift mount must be secured directly to the back wall and bottom of the
cabinet (or other equivalent structural elements). The cabinet must be
able to support the combined weight of the TV and the lift unit. If in doubt
get professional advice.
Attach Wall Support Bracket and Lid Arm:
Remove the 4 screws on the stand and attach the wall support bracket
and lid arm, as indicated.
Mount within Cabinet:
Place the unit in the desired location inside the cabinet. The unit must be secured at the base and at the top. Do not
attempt to use the unit without the wall support and base screws securely installed.
B
A
Step 3. Attach Bracket Rail Assembly
The bracket rails are installed in the factory but
may need to be adjusted to ensure the rails are
centered by loosening the locking screws. Install
the entire bracket assembly to the top of the
lift using four bracket screws (④).
4 5 6 7

TV
Step 5. Place Television on Rails
Remove the locking blocks and hand screws if they’re already in place.
Carefully place the television on the rails and make sure it is properly seated
in the bracket channels. Someone must brace the television until the locking
blocks are secure.
Step 4. Attach Bracket Arms to Television
Slide the Locking Blocks into place.
Tighten the Locking Handscrews.
Step 6. Secure Locking Blocks and Handscrews
CAUTION!
For cabinet installation, make sure the top
of the lid arm is higher than the top of the TV.
Adjust the TV mounting location using
different holes on the bracket if needed.
CAUTION!
At least two people are required
to safely lift the television!
Locate and align the TV mounting
holes with the bracket. Use the
television screws (⑤or ⑥) along
with the washers (③) and spacers
(⑦) and tighten gently.
4 5 6 7

This device contains electronics and other materials
which should only be disposed of in a proper disposal
facility designed to process electronic waste.
Please help protect our environment:
DO NOT dispose of this unit in household or office trash.
Step 7. Attach AV and power
Attach AV and power cables from your sources to the interface ports at the top of the unit. DO NOT ATTACH
source cables directly to the TV; ONLY attach the TV inputs to the interface ports at the bottom of the unit.
Make sure to use short cables to avoid snagging.
Step 8. Remote Control
Install the included battery in the remote control and test the operation of your
motorized stand/cabinet mount.
: hold down to adjust the TV to the left
: hold down to adjust the TV to the right
: hold down to tilt the TV upwards
: hold down to tilt the TV downwards
: one click to lift the TV all the way to the top
: one click to lower the TV all the way to the bottom
: one click to return TV to center position
: stops movement in current position
Connect the power and your
AV sources to the base ONLY.
Connect your TV to these
ports ONLY.
CAUTION!
Please ensure that the area around the television is free from any obstructions that
might prevent free movement of the unit, otherwise you may damage the television or motor.
Also make sure that your AV and power cabling are installed so that movement of the
television does not cause snagging or damage to your cables or connectors.
4 5 6 7

Product Dimension (inch) Carton Dimension (inch) Net Weight (lbs.) Gross Weight (lbs.)
General Specs:
Certifications:
Rated Voltage Current (no load) Current (rated load) Operation Temperature Maximum Humidity
This device complies with part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) this device may not cause harmful
interference, and (2) this device must accept any interference received, including interference that may cause undesired operation.
Electrical Specs:
Operational Specs:
ONE YEAR LIMITED WARRANTY
PLD STUDIOS LLC (hereinafter, "PLD") warrants to original end-users of PLD products that those products will be free from defects in
materials and workmanship, under normal use, for a period of one year from the date of purchase by the original end-user. At its option,
PLD will repair or replace, or refund the purchase price of, any product that fails during the term of this warranty.
Any implied warranties which may apply are limited in duration to a periodof one year from the date of purchase by the original end-user.
Notwithstanding the foregoing, PLD specifically disclaims any and all implied warranties, including, without limitation, implied warranties
of merchantability and implied warranties of fitness for a particular purpose, with respect to products used for commercial purposes.
Some states do not allow limitations on how long an implied warranty lasts, so the above limitation may not apply to you.
This warranty does not cover damage caused by (a) service or repairs by anyone other than PLD or its authorized repair personnel,
(b) the failure to utilize proper packing when returning the product, (c) improper installation or the failure to follow the instructions or
warnings provided by PLD, or (d) misuse or accident, in transit or otherwise.
In no event shall PLD be liable for incidental or consequential damages or damages arising from the use of, or the inability to use, the
product, or criminal or tortious acts by any third party. Some states do not allow the exclusion or limitation of incidental or consequential
damages, so the above limitation or exclusion may not apply to you.
This warranty is in lieu of all other warranties, expressed or implied, and is the sole remedy with respect to product defects. No dealer,
distributor, installer or other person or organization is authorized to modify or extend this Limited Warranty or impose any obligation on
PLD, its resellers or distributors, in connection with the sale of any PLD product.
This warranty gives specific legal rights, and you may also have other rights which vary from state to state.
To ask any questions or to obtain service under this warranty, please contact PLD at 415-992-6620, or contact [email protected]
to describe the nature of the warranty issue and to obtain a Return Material Authorization (RMA) number with instructions for returning
the product to PLD. Under no circumstances will PLD will accept any returned product without a previously-issued “Return Materials
Authorization” number.
Pending Approved Approved Approved
35 x 14 x 12 77 ± 1 82 ± 1
DC24V 0.7A 1.8A -20˚C to 50˚C 80% RH
TV Size Maximum
Install Pattern
Minimum
Install Pattern
Maximum
Bearing Weight Maximum Lift Height
32” - 65” 860 x 460 (mm) 185 x 135 (mm) 132 lbs.
Traveling Time
35 secs.
