Pluribus Networks F9532L-C User manual

– 1 –
1. Unpack the Switch and Check Contents
F9532L-C or
F9532-C
Rack Mounting Kit—2 front-post brackets, 2 rear-post
brackets, 20 screws, and 2 ear-locking screws
Power Cord (included with AC PSUs only)
Ground Wire (included with DC PSUs only)
Console Cable—RJ-45 to DB-9
DC Power Cable (included with 48 VDC PSU only)
Documentation—Quick Start Guide (this document)
and Safety and Regulatory Information
Note: The switch has the Open Network Install
Environment (ONIE) software installer pre-loaded on the
switch, but no switch software image. Information about
compatible switch software can be found at
www.edge-core.com.
Caution: The switch includes plug-in power supply (PSU)
and fan tray modules that are installed into its chassis. All
installed modules must have a matching airflow direction.
That is, if the installed power modules have a front-to-back
(F2B) airflow direction, all the installed fan tray modules
must also have a F2B airflow direction.
Note: The switch drawings in this document are for
illustration only and may not match your particular switch
model.
2. Attach the Brackets
Attach each of the front- and rear-post brackets to the
switch using four of the included bracket screws.
Use an additional two screws to secure each of the rear-post
brackets at the mid-point on the sides of the switch.
3
1
1
2
1
2
Use the screws and cage nuts supplied with the rack to
secure the switch in the rack.
Caution: Installing the switch in a rack requires two
people. One person should position the switch in the rack,
while the other secures it using the rack screws.
装置の吸排気に必要な領域をマニュアル上に規定して
いる。
3. Adjust Rear-Post Bracket Ears
Lock the position of the rear-post bracket ears using the
included position-locking screws.
You can also adjust the rear-post bracket ears to fit different
rack depths from 56 cm to 75 cm.
4. Ground the Switch
Ensure the rack is properly grounded and in compliance
with ETSI ETS 300 253. Verify that there is a good electrical
connection to the grounding point on the rack (no paint or
isolating surface treatment).
Attach the grounding wire #14 AWG to the grounding point
on the switch rear panel. Then connect the other end of the
wire to rack ground.
For details on grounding the switch with a 12 VDC PSU in an
Open Rack, refer to the Edgecore ORSA-1U Open Rack Tray
Set Installation Guide.
Caution: The earth connection must not be removed
unless all supply connections have been disconnected.
3
1
1
1
2
1
2
19-0031
www.pluribusnetworks.com
32-Port 100G Fiber Ethernet Switch
Quick Start Guide
F9532L-C | F9532-C

– 2 –
5. Connect Power
Install one or two AC or DC power modules in the switch.
The switch supports up to two PSUs that must have the
same matching airflow direction as the installed fan tray.
Connect an external AC or DC power source to the modules.
Connect the Open Rack tray connector to the 12 VDC PSU
when the switch is installed in an Open Rack.
Caution: Use a UL/IEC/EN 60950-1 certified power supply
to connect to a DC converter, and a #14 AWG (for -36 VDC to
-72 VDC PSU) or #8 AWG (for 12 VDC PSU) wire to connect to
a DC PSU.
Positronic PLA03F7000/
AA connector -36 – -72 VDC (red wire)
DC Return (black wire) Ground (yellow-green
wire)
6. Verify Switch Operation
Verify basic switch operation by checking the system LEDs.
When operating normally, the PSU1/PSU2, Diag, and Fan
LEDs should all be on green.
2
1
3
1
2
3
4
3
2
1
1 3
2 4
1
1
7. Perform Initial System Boot
If the network operating system (NOS) installer is located on
a network server, first connect the RJ-45 Management
(Mgmt) port to the network using 100-ohm Category 5, 5e
or better twisted-pair cable. (Not required if the NOS
installer is located on attached storage.)
Note: The RJ-45 Mgmt port of F9532-C only supports 1000
Mbps mode.
Boot the switch. Wait for the ONIE software to locate and
execute the NOS installer, and then wait for the installer to
load the NOS software image.
Subsequent switch boots will bypass ONIE and directly run
the NOS software.
Note: Refer to the network operating system (NOS) installer
and NOS documentation for details on software options and
set up for ONIE.
8. Connect Network Cables
For the RJ-45 Management port, connect 100-ohm Category
5, 5e or better twisted-pair cable.
Connect DAC cables directly to the QSFP28 slots. Or first
install QSFP28 transceivers in the slots and then connect
fiber optic cabling to the transceiver ports.
As connections are made, check the port status LEDs to be
sure the links are valid. Each QSFP28 port has four LEDs that
indicate valid links in the following modes:
1 LED Blue — 100 Gbps mode
1-2 LEDs Purple — 50 Gbps breakout mode (two lanes)
1 LED Orange — 40 Gbps mode
1-4 LEDs White — 25 Gbps breakout mode (four lanes)
1-4 LEDs Green — 10 Gbps breakout mode (four lanes)
Note: As connections are made, check the port status LEDs
to be sure the links are valid.
1
2
2
1
3
1
2
3
Quick Start Guide

– 3 –
Hardware Specifications
Switch Chassis
Size (WxDxH) 438.4 x 515 x 43.5 mm (17.26 x 20.28 x 1.71 inch)
Weight 10.87 kg (23.96 lb), with two installed PSUs
Temperature Operating (F2B): 0° C to 45° C (32° F to 113° F)
Operating (B2F): 0° C to 40° C (32° F to 104° F)
Storage: -40° C to 70° C (-40° F to 158° F)
Humidity Operating: 5% to 95% (non-condensing)
Power
Consumption 550 Watts maximum
AC PSU
Power Rating 100–240 VAC, 50-60 Hz, 650 Watts
AC Input 100–240 VAC, 50-60 Hz, 6 A max.
DC Output 5 VDC @ 4-3 A, 12 VDC @ 54-52.9 A
48 VDC PSU
Power Rating -48 VDC, 650 Watts
DC Input -36 – -72 VDC, 16 A maximum
DC Output 5 VDC @ 4 A, 12 VDC @ 52.9 A
12 VDC PSU (PSU-12V-750)
DC Input 12 VDC (from Open Rack busbar)
Regulatory Compliances
Emissions EN 55032:2012+AC:2013, Class A
EN 61000-3-2:2014, Class A
EN 61000-3-3:2013
FCC Class A
VCCI Class A
CCC GB 9254-2008, Class A
BSMI Class A, CNS 13438 (AS7712-32X only)
CE Mark
Immunity EN 55024:2010 (AS7712-32X/AS7716-32X only)
EN 55024:2010+A1+2015 (AS7512-32X only)
IEC 61000-4-2/3/4/5/6/8/11
Safety UL (CSA 22.2 No 60950-1 & UL60950-1)
CB (IEC/EN60950-1)
CCC GB 4943.1-2011
BSMI, CNS 14336-1
Taiwan RoHS CNS 15663 (AS7712-32X only)
Quick Start Guide

– 4 –
1. 打开交换机的包装并检查内装物
F9532L-C 或
F9532-C
前柱支架 x2, 带可调节吊耳的后柱支架 x2, 支架螺丝
x20, 后支架吊耳位置 - 锁定螺丝 x2
电源线 ( 仅随 AC PSU 附带 )
接地线 ( 仅随 DC PSU 附带 )
控制台线 — RJ-45 转DB-9
DC 电源线 ( 仅随 48 VDC PSU 附带 )
文档 — 快速入门指南 (本文档）以及安全和管制信
息
注意： 此交换机预装了 Open Network Installer
Environment (ONIE) 软件，但没有预装交换机软件映像。
有关其他交换机相容软件，请参考
www.edge-core.com 网站说明。
警告 : 本交换机的机箱中安装有插入式电源 (PSU) 和风扇
架模块。所有后部安装模块都必须具有匹配的气流方
向。即，如果安装的电源模块有从前到后 (F2B) 的气流通
过，则所有安装的风扇架模块也必须有 F2B 气流通过。
注意： 本文档中的交换机图片仅用于举例说明 , 不一定
与您的交换机实际外观完全一致。
2. 安装交换机
使用四个随附的支架螺丝将各个前柱和后柱支架安装到
交换机。
使用另外两个螺丝将每个后柱支架固定到交换机侧面上
的中间点。
3
1
1
2
1
2
使用机架随附的螺丝和卡式螺母将交换机固定到支架
上。
警告 ：将此交换机安装在机架中时需要两个人。一个人
将交换机放置在机架中，同时另一个人用机架螺丝将其
固定。
装置の吸排気に必要な領域をマニュアル上に規定して
いる。
3. 调整后柱支架吊耳
使用随附的定位螺丝固定后柱支架吊耳的位置。
此外，还可以调整后柱支架吊耳以适合不同的机架深
度，范围是 56 cm 到75 cm。
4. 对交换机实施接地
请确保对机架正确实施接地，并确保符合 ETSI ETS 300
253。请确认机架上的接地点的电气导通状态良好 （确
保没有油漆或绝缘表面处理）。
将14 号的 AWG 接地线连接至交换机背面面板上的接地
点上。然后将接地线的另一端连接至机架的接地。
关于如何连接 12 VDC PSUs 至开放式机架连接器，请参阅
Edgecore ORSA-1U Open Rack Tray Set 安装手册。
警告 : 在断开所有电源连接前，切勿断开接地。
3
1
1
1
2
1
2
32端口100G 以太网交换机
快速入门指南
F9532L-C | F9532-C

– 5 –
5. 连接电源
在交换机上安装 1 个或 2 个 AC 或 DC 电源模块。 本交换
机可使用最多 2 个 PSU，且 PSU 的气流方向必须与安装
的风扇框相同。
将外部 AC 或 DC 电源连接至模块。
交换机安装在开放型机架中时，将机架的托架接口连接
到 12 VDC PSU。
警告 ：使用 UL/IEC/EN60950-1 认证的电源连接 DC
converter。使用 #14 AWG ( 用于 -36 VDC 到 -72 VDC PSU)
或 #8 AWG ( 用于 12 VDC PSU) 线连接到 DC PSU。
Positronic PLA03F7000/
AA 接口 -36 – -72 VDC ( 红线 )
DC 返回 (黑线 )接地 (黄绿线 )
6. 确认交换机的运转情况
透过检查系统 LED，确认交换机的基本运转情况。 如运
转正常， PSU1/PSU2、Diag 和风扇 LED 会亮起绿灯。
2
1
3
1
2
3
4
3
2
1
1 3
2 4
1
1
7. 执行初次系统启动
如果网络操作系统 (NOS) 安装程序位于网络服务器中，
应首先使用 5、5e 类或以上双绞线将 RJ-45 管理 (Mgmt)
端口连接到网络。 (NOS 安装程序位于相连的存储装置中
时不需要。 )
注意： F9532-C， RJ-45 Mgmt 管理仅支持 1000 Mbps 模
式。
启动交换机。等待 ONIE 软件找到和执行 NOS 安装程
序，然后等待安装程序加载 NOS 软件映像。
以后交换机启动时将跳过 ONIE 而直接运行 NOS 软件。
注意： 有关 ONIE 软件位置选项和设置的详细信息，请
参见 NOS 安装程序和 NOS 文档。
8. 连接网线
对于 RJ-45 管理端口，请连接 100-ohm 类别 5、5e 或以上
的双绞线。
将 DAC 缆线连接至 QSFP28 插槽，也可先安装好 QSFP28
收发器，然后将光纤连接至收发器端口上。
建立连接后，检查端口状态 LED，确保连接正常。每个
QSFP28 端口有四个 LED，在以下模式中指示正常连接：
1 LED 蓝色 — 100 Gbps 模式
1-2 LED 紫色 — 50 Gbps 突破模式 ( 兩通道 )
1 LED 橙色 — 40 Gbps 模式
1-4 LED 白色 — 25 Gbps 突破模式 ( 四通道 )
1-4 LED 绿色 — 10 Gbps 突破模式 ( 四通道 )
注意 : 完成连接后，请检查端口状态 LED，以确保已正常
连接。
1
2
2
1
3
1
2
3
快速入门指南

– 6 –
硬件规格
交换机机箱
尺寸
(宽 x 深 x 高)
438.4 x 515 x 43.5 mm
(17.26 x 20.28 x 1.71 英寸 )
重量 10.87 kg (23.96 磅)，含附带的两个 PSU
温度 运转时 (F2B): 0°C 至 45°C (32° F 至113° F)
运转时 (B2F): 0°C 至 40°C (32° F 至104° F)
储存时 : -40°C 至 70°C (-40° F 至158° F)
湿度 运转时 : 5% 至 95% ( 非冷凝 )
功率消耗 最大 550 瓦
AC PSU
额定功率 100–240 VAC, 50-60 Hz, 650 瓦
AC 输入 100–240 VAC, 50-60 Hz, 最大 6 A
DC 输出 5 VDC @ 4-3 A, 12 VDC @ 54-52.9 A
48 VDC PSU
额定功率 -48 VDC，650 瓦
DC 输入 -36–-72 VDC，最大 16 A
DC 输出 5 VDC @ 4 A, 12 VDC @ 52.9 A
12 VDC PSU (PSU-12V-750)
DC 输入 12 VDC ( 从开放式机架后方的母线取电 )
法规符合性
排放 EN 55032:2012+AC:2013, Class A
EN 61000-3-2:2014, Class A
EN 61000-3-3:2013
FCC Class A
VCCI Class A
CCC GB 9254-2008, Class A
BSMI Class A, CNS 13438 ( 仅限 AS7712-32X)
CE Mark
抗扰性 EN 55024:2010 ( 仅限 AS7712-32X/AS7716-32X)
EN 55024:2010+A1:2015 ( 仅限 AS7512-32X)
IEC 61000-4-2/3/4/5/6/8/11
安全 UL (CSA 22.2 No 60950-1 & UL60950-1)
CB (IEC/EN60950-1)
CCC GB 4943.1-2011
BSMI, CNS 14336-1
台湾 RoHS CNS 15663 ( 仅限 AS7712-32X/)

– 7 –
1. 󲉎󵔓󰸬󲍣󱗰󱊍󴡥󰶮󲨪󲝭󱃯󱭁󳇱
F9532L-C 󲆞
F9532-C
󱇕󲝹󲇠󲜾 x2󱼔󲝹󲇠󲜾󵗌󱍷󴩇󱚂󱬢󳇏 x2󲇠󲜾󴝂
󳳺 x20󱼔󲇠󲜾󱚂󱬢󳇏󰻕󳻶󱬢󰻕󴝂󳳺 x2
󵚃󲸘󳵢 󱁍󵘰󵗌󲕄 AC PSU
󲌭󱚸󳵢 󱁍󵘰󵗌󲕄 DC PSU
󲌯󱆾󵚃󳸤 RJ45 󴻑DB-9
DC 󵚃󲸘󳵢 󱁍󵘰󵗌󲕄 48 VDC PSU
󲔏󰹾
󱽳󴾧󱃭󵔈󲊏󱋟 󲚴󲔏󰹾󱍒 󱬑󱃰󱾯󴆏󲱝󴤗󴱏
󴦒
󴨲󲖖 󰸬󲍣󱗰󲚑󵞘󴺑󰷓󵔓󲓆󳴺󴵷󱬑󴡥󳦓󱺗󳐸󱠋
ONIE󴹧󵩜󰻎󲚲󵞘󴺑󰸬󲍣󱗰󴹧󵩜󲖨󱁗󲨜󲚑󵕤󱃾󰹞
󳚀󱭁󰸬󲍣󱗰󴹧󵩜󴩓󱍋󵔹 www.edge-core.com 󳴺󳩡󴨲
󲖖
󲱰󲂗 󰸬󲍣󱗰󱊍󱎳󲍚󱃭󱺗󵚃󲸘󰼣󲅑󱗰󰹭󱍒󵠰󲇏󲇠󳙬󲦩
󳳌󲇈󲚑󱼔󵁰󱬑󴡥󰷓󲦩󳳌󲮫󲳉󲕁󱎙󱽍󵞐󰶈󴅼󲂗󱋻
󱤊󲜤󱬑󴡥󳘌󵚃󲸘󰼣󲅑󱗰󲚑󱼦󱇕󴅻󱼔󳘌󲮫󲳉󲕁󱎙
F2B󱇏󲇈󲚑󱬑󴡥󳘌󵠰󲇏󲇠󳙬󲦩󳳌󰷧󱽍󵞐󳁂󱇕󴅻󱼔󳘌
󲮫󲳉󲕁󱎙 F2B
󴨲󲖖 󲚴󲔏󰹾󰼇󳒰󳘌󰸬󲍣󱗰󱚞󳇏󱁍󰼣󴆑󰼓󴨲󲖖󰶕󰶈󱬢
󴆏󲀰󳘌󰸬󲍣󱗰󱢞󴥈󱬔󱃰󰶈󴅼
2. 󱬑󴡥󰸬󲍣󱗰
󱆱󳒰󱙣󰾓󲇈󵗌󰷓󲇠󲜾󴝂󳳺󱮏󱇕󲝹󱐔󱼔󲝹󲇠󲜾󱬑󴡥󱚰󰸬
󲍣󱗰󰶒
󵟕󱢞󰼇󳒰󱃱󰾓󴝂󳳺󱮏󱼔󲝹󲇠󲜾󱎌󱆭󱚂󱬢󱚰󰸬󲍣󱗰󰿼󵀒
󰶵󵔛󴗝
3
1
1
2
1
2
󰼇󳒰󵘰󲧧󲩋󲍘󰼣󳘌󴝂󳳺󱍒󳯨󳻱󴝂󱷅󱮏󰸬󲍣󱗰󱚂󱬢󱚰󲧧
󲩋󰶒
󲱰󲂗 󵚈󴤉󱃱󰾓󰹂󱮏󰸬󲍣󱗰󴡥󱆸󲧧󲩋󰶒󰶈󰹂󴰨󴰴󱚂
󱬢󰸬󲍣󱗰󱚰󲧧󲩋󰶒󰷓󰻕󳻶󱍮󰶈󰹂󴰨󴰴󳒰󲧧󲩋󴝂󳳺󱚂
󱬢
装置の吸排気に必要な領域をマニュアル上に規定して
いる。
3. 󴩇󲓼󱼔󲝹󲇠󲜾󱚂󱬢󳇏
󱆱󳒰󲇈󵗌󳘌󱬢󰻕󴝂󳳺󵌞󳵒󱼔󲝹󲇠󲜾󱚂󱬢󳇏󰻕󳻶
󰸮󱍷󴩇󲓼󱼔󲝹󲇠󲜾󱚂󱬢󳇏󰹭󱬑󴡥󱚰󲵹󱸮󳁂 56 cm 󴅻
75 cm 󰶕󳫑󰷓󲧧󲩋󰶒
4. 󱮕󰸬󲍣󱗰󱭮󲕅󲌭󱚸
󴩓󳡂󰽥󱮕󲧧󲜾󲫫󳡂󱭮󲕅󲌭󱚸󰶮󳡂󰽥󳪮󱎐 ETSI ETS 300
253󴩓󳡂󴨕󲧧󲜾󰶒󳘌󲌭󱚸󵹦󳘌󵚃󲮫󱮖󴾢󳉈󲃓󴇷󱤅 󳡂
󰽥󲰚󲚑󲱁󲺎󲆞󳳝󳵫󴟰󵛪󴗝󳎎
󱮏14 󴗧 AWG 󲌭󱚸󳵢󴾫󲌭󴅻󰸬󲍣󱗰󴁔󵛪󵛪󲜇󰶒󳘌󲌭󱚸󵹦
󰶒󳂾󱼔󱮏󲌭󱚸󳵢󳘌󱍮󰶈󳩷󴾫󲌭󴅻󲧧󲜾󳘌󲌭󱚸
󵕤󲕄󱤊󰻝󴾫󲌭 12 VDC PSUs 󴅻󵔓󲓆󱺗󲧧󲜾󴾫󲌭󱗰󴩓󱍋
󵔹 Edgecore ORSA-1U Open Rack Tray Set 󱬑󴡥󲇓󱄒
󲱰󲂗 󱚰󲔿󵔓󲇈󲚑󵚃󲸘󴾫󲌭󱇕󱆏󱊇󲔿󵔓󲌭󱚸
3
1
1
1
2
1
2
32埠100G 乙太網路交換器
快速入門指南
F9532L-C | F9532-C

– 8 –
5. 󴾫󲌭󵚃󲸘
󱚰󰸬󲍣󱗰󰶒󱬑󴡥 1 󰾓󲆞 2 󰾓 AC 󲆞 DC 󵚃󲸘󲦩󳳌 󲚴󰸬󲍣
󱗰󱍷󰼇󳒰󲚈󱢢 2 󰾓 PSU󰶜 PSU 󳘌󲮫󲳉󲕁󱎙󱽍󵞐󴆏󱬑󴡥
󳘌󵠰󲇏󲟎󳚀󱎔
󱮏󱢞󵁰 AC 󲆞 DC 󵚃󲸘󴾫󲌭󴅻󲦩󳳌
󱮏󰸬󲍣󱗰󴡥󱃭󵔓󲓆󱺗󲧧󲩋󱼔󱮏󵔓󲓆󱺗󲧧󲩋󲇠󳙬󲌭󵞵󴾫
󲌭󴅻 12 VDC PSU
󲱰󲂗 󱚰 DC Converter 󳘌󱇕󳩷󱽍󵞐󰼇󳒰 UL/IEC/EN
60950-1 󴨕󴫑󳘌󵚃󲸘󰼣󲅑󱗰 󴾫󲌭 DC PSU 󰼇󳒰 #14
AWG 󳵢 󴿱󳒰󲕄 -36 VDC 󴅻-72 VDC PSU󲆞 #8
AWG 󳵢 󴿱󳒰󲕄 12 VDC PSU󴾫󲌭󴅻 DC PSU
Positronic
PLA03F7000/ AA 󲌭󵞵 -36 – -72 VDC 󳲍󳵢
DC 󱙦󲳉 󵹙󳵢 󲌭󱚸 󵹋󳴨󳵢
6. 󳡂󴨕󰸬󲍣󱗰󲑕󰻤
󴾗󴿖󲨪󲝭󳲃󳳹 LED󳡂󴨕󰸬󲍣󱗰󳘌󱞂󲚴󴿓󴻑󲁍󲱉 󱤊󴿓
󴻑󲫫󱷀PSU1/PSU2Diag 󱐔󵠰󲇏 LED 󲚋󰸶󴳿󳴨󳅐
2
1
3
1
2
3
4
3
2
1
1 3
2 4
1
1
7. 󱝿󴟔󱆥󲪩󳲃󳳹󱓧󱉝
󴉭󳴺󴵷󰻤󲣵󳲃󳳹 NOS󱬑󴡥󳦓󱺗󰻕󲕄󳴺󴵷󰻂󲚕󱗰󱃐
󰼇󳒰 5-ohm 󳪴5󵟦5e 󵟦󲆞󲙼󱂲󰷓󵙡󳳦󳵢󵚃󳸤󴾫󲌭
RJ-45 󳬩󳎎 Mgmt󱝨󴅻󳴺󴵷󴉭 NOS 󱬑󴡥󳦓󱺗󰻕
󲕄󲇈󵗌󱂺󱫠󴦵󱀡󰶵󱇏󰶕󵚈󴤉
󴨲󲖖 F9532-CRJ-45 Mgmt 󴾫󲌭󱝨󱁍󲒷󲍼 1000
Mbps 󲦩󱺗
󱓧󱉝󰸬󲍣󱗰󳫑󱼍 ONIE 󴹧󵩜󲈆󱮓󰶮󱝿󴟔 NOS 󱬑󴡥󳦓
󱺗󰶮󳫑󱼍󱬑󴡥󳦓󱺗󴺑󱃭 NOS 󴹧󵩜󲖨󱁗󲨜
󰷓󱼔󰸬󲍣󱗰󱓧󱉝󲗊󲚋󴵻󴿖 ONIE󳙼󲌭󴿓󴟔 NOS 󴹧
󵩜
󴨲󲖖 󵕤󲕄󴧻󳲸󴹧󵩜󵀀󵞍󱍒 ONIE 󴦵󱬢󴨲󲖖󴩓󱍋󵔹󳴺
󴵷󰻤󲣵󳲃󳳹 NOS󱬑󴡥󳦓󱺗󱍒 NOS 󲔏󰹾
8. 󴾫󲌭󳴺󴵷󳵢
󱮕󲕄 RJ-45 󳬩󳎎󱝨󴩓󴾫󲌭 100-ohm 󵟦󱆭 55e 󲆞󰹭󰶒
󳘌󵙡󳳦󳵢
󴾫󲌭󱃑󳸞󵚃󳸤󴅻󲒾󳘄󱗰󴾫󲌭󱝨󲆞󳙼󲌭󱮏 DAC 󳵢󴾫󲌭󴅻
QSFP28 󲍚󲦅
󴾫󲌭󱬔󲆘󱼔󴩓󲨪󲝭󴾫󲌭󱝨󳉈󲃓 LED󳡂󰽥󴾫󳳘󲚑󲓐
󲭗󰾓 QSFP28 󴾫󲌭󱝨󲚑󱙣󰾓 LED󱍷󲊏󱆂󱚰󰹭󰶓󲦩󱺗󰶵
󳘌󲚑󲓐󴾫󳳘
1 LED 󴕕 100 Gbps 󲦩󱺗
1-2 LED 󳲳—50 Gbps 󳨉󱚕󲦩󱺗 󰸔󴿛
1 LED 󲧠 40 Gbps 󲦩󱺗
1-4 LED 󳘅 25 Gbps 󳨉󱚕󲦩󱺗 󱙣󴿛
1-4 LED 󳴨 10 Gbps 󳨉󱚕󲦩󱺗 󱙣󴿛
󴨲󲖖 󱬔󲆘󴾫󲌭󱼔󴩓󲨪󲝭󱝨󳉈󲃓 LED󰹭󳡂󰽥󲫫󱷀󴾫
󲌭
1
2
2
1
3
1
2
3
󱽳󴾧󱃭󵔈󲊏󱋟

– 9 –
󳟴󵩜󴤗󲟄
󰴃󲈺󱓇󲢾󳨐
󱯂󱮀
(WxDxH)
438.4 x 515 x 43.4 mm
(17.26 x 20.28 x 1.71 󴉹󱎓
󵅕󵅗 10.87 kg (23.96 lb)󱎳󱃱󰾓󱬑󴡥󰷓 PSU
󲸳󱸮 󲑕󰻤 (F2B): 0°C 󴅻 45°C (32°F 󴅻 113°F)
󲑕󰻤 (B2F): 0°C 󴅻 40°C (32°F 󴅻 104°F)
󱂺󱫠 : -40°C 󴅻 70°C (-40°F 󴅻 158°F)
󲽝󱸮 󲑕󰻤 : 5% 󴅻 95% 󳂩󱄿󱅥
󲴐󳾟󱈧󳌏 󲚈󱢯 550 󳑮
AC PSU
󵟕󱬢󱈧󳌏 100–240 VAC50-60 Hz650 󳑮
AC 󴻀󱃭 100–240 VAC, 50-60 Hz, 󲚈󱢯 6 A
DC 󴻀󱆂 5 VDC @ 4-3 A, 12 VDC @ 54-52.9 A
48 VDC PSU
󵟕󱬢󱈧󳌏 -48 VDC650 󳑮
DC 󴻀󱃭 -36 – -72 VDC󲚈󱢯 16 A
DC 󴻀󱆂 5 VDC @ 4 A, 12 VDC @ 52.9 A
12 VDC PSU (PSU-12V-750)
DC 󴻀󱃭 12 VDC 󱼦󵔓󲓆󱺗󲧧󲜾󱼔󲕁󳘌󲭕󳵢󱍞󵚃
󲬴󴟮󳦅󱉧󱺆
󲌚󲓆 EN 55032:2012+AC:2013, Class A
EN 61000-3-2:2014, Class A
EN 61000-3-3:2013
FCC Class A
VCCI Class A
CCC GB 9254-2008, Class A
BSMI Class A, CNS 13438 ( 󱁍󵗘 AS7712-32X)
CE Mark
󵚃󳡉󳾘󱍟󱾯 EN 55024:2010 ( 󱁍󵗘 AS7712-32X/AS7716-
32X)
EN 55024:2010+A1+2015 ( 󱁍󵗘 AS7512-32X)
IEC 61000-4-2/3/4/5/6/8/11
󱬑󱃰󱾯 UL (CSA 22.2 No 60950-1 & UL60950-1)
CB (IEC/EN60950-1)
CCC GB 4943.1-2011
BSMI, CNS 14336-1
󱍸󲿫 RoHS CNS 15663 ( 󱁍󵗘 AS7712-32X)
󱽳󴾧󱃭󵔈󲊏󱋟
