Plusrite PLS-30W Installation guide

P: F: [email protected] 03 9708 2552 • 03 9708 2553 • www.plusrite.com.au
LED SOLAR STREET LIGHT RANGE
PRODUCT DETAILS
PLS-30W PLS-90W PLS-150W
Q20
MODEL
NUMBER Materials LED CHIPS LUMENS CCT Panel
Charging CRI DIMMABLE
30W SMD5730 3000lm 4K 5K 6K ＞80
LED Q’ty
(pcs)
60 6V 7W
Wattage
ABS
Battery
Yes
Warranty
3 years
12000mAh
PLS-30W
Time
Discharging
Time
Solar
6-8 Hours 10-12 Hours
90W SMD5730 9000lm 4K 5K 6K ＞80
180 6V 11.5W
ABS Yes 3 years
24000mAh
PLS-90W
6-8 Hours 10-12 Hours
150W SMD5730 15000lm 4K 5K 6K ＞80
300 6V 22W
ABS Yes 3 years
36000mAh
PLS-150W
6-8 Hours 12-14 Hours
This bracket will come with
the solar street light.
A
B
This bracket can be installed
on the wall or any pole with
45mm one is for 30W,90W,150W
the diameter 45mm to 100mm.
End A connect to the light.
End B connect to the wall or
the pole and End C connect
MOTION SENSOR INSTRUCTION
C
to the back of the pole.
Mode button:
Mode 1: Motion sensor mode, starts with 100% lumen output then
standby 30% lumen output if no motion after dusk.
Mode 2: Constant 100% brightness after dusk.
4H & 6H button: Hours lasting for Mode 1 or Mode 2, then turns off.
ON button: The light is on with mode 1.
OFF button: The light turns off.
PLS-RC
PLS-RC Remote controller for LED solar street light, batten light and Flood light.
1. Press the ON/OFF button once. The light flashes once and works
at motion sensor mode, standby 30% light output if no motion after dusk.
2. Press the ON/OFF button again. The light flashes twice and
works at constant 100% brightness mode after dusk.
3. Hold down the ON/OFF button to turn off the light.
REMOTE CONTROLLER INSTRUCTION
LED Solar Street light
Polycrystalline Solar panel
Lithium baery
No AC power cables, no electrical charges
Moon sensor, dim down to 30% lumen output
when there is no movement detected.
Build-in dusk to dawn sensor
Product:
Net Weight: 1.50 / 2.60 / 4.20 / 5.30kg
Outer ctn size: 490*375*255mm
Q’ty per ctn: 10 / 5 / 4 / 3 pcs
G.W per ctn: 16.50 / 15.00 / 19.00 /19.00 kg
PACKING DETAILS:
PLS-30W
PLS-90W
PLS-150W
665*375*275mm
860*305*275mm
PLS-240W
PLS-240W
1270*325*275mm
Unit: MM
240W SMD5730 24000lm 4K 5K 6K ＞80
432 10V 39W
Aluminum Yes 3 years
42000mAh
PLS-240W
6-8 Hours 12-14 Hours
60mm one is for 240W
The length of the bracket is about 500mm

P: F: [email protected] 03 9708 2552 • 03 9708 2553 • www.plusrite.com.au
PRODUCT DETAILS
Galvanised Pole with Cage for Solar Street lights and Solar Post Top lights
Unit:MM
240*240*8
240*240*8
PLS-3M-G
PLS-4M-G
LED SOLAR STREET LIGHT RANGE
Pole Sealed Top Cage Cage Size: 200mm x 200mm x500mm
