Point Mobile PM3 User manual

CONTENTS
BLUETOOTH SCANNER
PM3
PM3
User Manual

PM3 User Manual
2
Table of Contents
Introduction....................................................................................................4
1.1 About PM3 Bluetooth Scanner.........................................................................................4
1.2 Symbols in this manual ....................................................................................................4
1.3 Accessories......................................................................................................................5
Getting Started...............................................................................................6
2.1 Charge the Device............................................................................................................6
2.2 Turn Your Device On & Off ..............................................................................................6
Get to Know Your Device ..............................................................................7
3.1 Front Panel Layout...........................................................................................................7
3.2 Back Panel Layout...........................................................................................................7
3.3 Left Side Panel Layout.....................................................................................................8
3.4 Top Panel Layout.............................................................................................................8
3.5 Bottom Panel Layout........................................................................................................8
3.6 LED Indicator ...................................................................................................................9
3.7 USB Cable .......................................................................................................................9
3.8 Battery Power...................................................................................................................9
3.9 Sleep Mode......................................................................................................................9
3.10 PM3 Technical Specifications.......................................................................................10
Using the Buttons.........................................................................................11
Using the Image Engine...............................................................................12
5.1 Overview........................................................................................................................12
5.2 Available Image Engines................................................................................................13
5.3 Depth of Field.................................................................................................................13
5.4 Supported Bar Code Symbologies.................................................................................13
5.5 To Decode a Barcode ....................................................................................................13
Using the Laser/CCD Engine.......................................................................14
6.1 Overview........................................................................................................................14
6.2 Available Laser Engines.................................................................................................14
6.3 Depth of Field.................................................................................................................14
6.4 Supported Bar Code Symbologies.................................................................................15
6.5 Decoding a Barcode.......................................................................................................15

PM3 User Manual
3
6.6 Scanning Positions.........................................................................................................16
Bluetooth......................................................................................................17
7.1 Enabling the Bluetooth...................................................................................................17
7.2 Pairing Bluetooth Devices..............................................................................................17
7.3 ReconnectingHID..........................................................................................................17
User Menus...................................................................................................18
AdminMenus ...............................................................................................19
Initializing the Memory ...............................................................................24
Using the USB Memory in Connection with PC........................................24
Troubleshooting and Note.........................................................................25
12.1 Firmware Update..........................................................................................................25
12.2 Factory Reset...............................................................................................................27
Safety Regulations.....................................................................................28
13.1 Battery Safety...............................................................................................................28
13.2 General Safety Rules...................................................................................................29
13.3 Power Supply...............................................................................................................29
13.4 Laser Safety.................................................................................................................30
13.5 LED Safety...................................................................................................................31
13.6 CB Scheme..................................................................................................................31
13.7 Radio Compliance........................................................................................................31
13.8 WEEE Compliance.......................................................................................................31
13.9 Canadian Compliance..................................................................................................32

PM3 User Manual
4
Introduction
This manual generally provides you with the safety information and basic features and operations
of the PM3 device. Please read all safety precautions and this manual carefully before using your
device and peripherals to ensure safe and proper use.
1.1 About PM3 Bluetooth Scanner
The new PM3 is the latest generation Bluetooth scanner, combining a pocket-sized form factor.
The PM3 is designed for retail warehousing and logistics applications where maximum
performance and durability is required in compact Handheld device.
The PM3 is available in different models depending on the options.
1.2 Symbols in this manual
In this manual, some important items are described with the symbols shown below. Be sure to
read these items before using this equipment.
WARNING Indicates a potentially hazardous situation which, if not avoided, could result in
death serious injury, or serious damage, or fire in the equipment or surrounding objects.
CAUTION Indicates a potentially hazardous situation which, if not avoided, may result in
minor or moderate injury, partial damage to the equipment or surrounding objects, or loss of data.
☞NOTE Indicates information to which you should pay attention when operating the
equipment.

PM3 User Manual
5
1.3 Accessories
Power Supply
AC Adaptor
INPUT: AC100~240V 50/60Hz, OUTPUT: DC5V 0.7A Power Supply
Cables
Packed with the Power Supply
Others
Customized necklace String (when requested)
PM3 Bluetooth Scanner contains the following items basically:
Bluetooth scanner
5V/0.7A AC Adaptor with USB type C cable
AC Plugs
☞ NOTE:
Keep the original packaging for use when sending products to the technical assistance center. Damage
caused by improper packaging is not covered under the warranty

PM3 User Manual
6
Getting Started
2.1 Charge the Device
Battery pack is assembled inside of the PM3 Bluetooth scanner. Charge the device with the
charging cable for about 4 hours before initial use.
Attach the appropriate plug adapter to the plug of the power cable.
Insert the plug into the appropriate power source.
Plug the Bluetooth scanner power cable into the USB connector on the side end of the unit.
WARNING: UseonlyPoint Mobile-approved peripherals, power cables, andpower adapters.
Unauthorized peripherals, cables, orpower adapters may cause explosion ordamage onyour device.
DONOT attempt to charge damp/wet Bluetooth scanners or batteries. Allcomponents must be drybefore connecting to
anexternal power source.
Batteries must be charged at a temperature ranging from 0~45℃(±3℃). If you don’t follow the guide, it might
have a harmful effect on the battery life.
CAUTION: After the device has been charged, disconnect the DC Power Jack. If you stay on that plug-in use, it
is possible to break the power cord.
2.2 Turn Your Device On & Off
To turn on, press the UP button for 1 second.
To turn off, press the UP button for 5 seconds.

PM3 User Manual
7
Get to Know Your Device
3.1 Front Panel Layout
3.2 Back Panel Layout
Battery Installed Inside of the Device
For information about battery power, see Battery Power.
Speaker
The integrated speaker sounds audio signals as you scan bar code labels and enter data, the
speaker meets the following SPL levels at 10cm:
•500Hz–70dB
•1kHz–80dB
•4kHz–80dB
LED Indicators
Buttons
Wire spring
mount hole
Lanyard
mount hole

PM3 User Manual
8
3.3 Left Side Panel Layout
3.4 Top Panel Layout
Image Engine Window
The angled image engine reads and decodes most popular bar code symbolizes. For more
information, see Using the Image Engine.
3.5 Bottom Panel Layout
USB Port
This connector supports full speed USB 2.0 communication also external power from the adaptor
that is included with the terminal. When connected to the adaptor, the terminal is powered and the
main battery pack is charging.
Speaker
Image engine window (with engine)
USB Connector

PM3 User Manual
9
3.6 LED Indicator
Shows the information needed to operate your device as follows:
LED Color Meaning
Battery LED (Left)
- Red Lights when main battery is charging
- Green Lights when main battery charging has completed.
Scan LED (Middle)
- Red Lights when a scan fails
- Blue Lights when a scan pass
Bluetooth LED (Right)
- Blue Lights when Bluetooth pairing has completed
3.7 USB Cable
The USB type C cable is used when communicating between the terminal and a host computer to
transfer data via the USB interface.
3.8 Battery Power
The battery works to prevent data loss when the terminal is used over long periods of time. The
battery must be charged to full capacity before using the BLUETOOTH SCANNER AC
Adaptor for the first time!
Charge the Bluetooth scanner with AC Adaptor for about 4 hours before initial use.
3.9 Sleep Mode
Sleep Mode suspends PM3 operation. The device appears to be offwhen in Sleep Mode. The
device is programmed to go into Sleep Mode automatically when inactive for a specified period of
time. You can set this time period in the Sleep Timeout menu.

PM3 User Manual
10
3.10 PM3 Technical Specifications
Model
PM3
Operating System
Firmware
Processor
ATMEL SAM4S16C, 32-bit ARM® Cortex® -M4 RISC processor 120Mhz
Memory
1MB(PGM), 4MB Storage Flash, 128KB RAM
Display
Bright OLED/ 0.96 inch (21.74mm x 11.18mm Active Area)
128x64 Dot Passive Matrix/Monochrome (Blue)
Scan Engine
1D engine: SE-965HP
2D engine: SE4710
CCD: SE655
Buttons
3 buttons [ 1 scan button, 2 menu buttons (Up & Down) ]
Audio
Built-in speaker
I/O
Full Speed USB v2.0(12Mbps) Client.
support USB Disk Mode & USB to Serial mode
Battery
3.7V, 900mAh Lithium Polymer battery
Expected Charge
Time
< 4 hours (from Low-Battery Shutdown level)
Charging
Peripherals
USB Cable
Operating
Temperature
-10°C to 50°C
Charging
Temperature
0~45℃(±3℃))
Storage
Temperature
-20°C to 60°C
Humidity
95% humidity, non-condensing
Construction
High impact resistant PC housings
Drop
1.5m multiple drops to concrete, MIL-STD-810G
ESD
Air: ± 15kV Direct: ± 8kV
Environmental
Independently certified to meet IP54 standards for moisture and particle
resistance (IEC 60529)
Dimensions
78.5mm x 39.0mm x 19.4mm
Weight
SE655: 61g
SE965: 65g
SE4710: 65g
Bluetooth
Bluetooth Class 2, v4.2
Notification
Vibration Motor
Yes

PM3 User Manual
11
Using the Buttons
Scan Button
Located at the center for easy access with either hand.
Scanning Barcodes or choosing options in menu.
Up / Down Button
Located at the bottom left / right.
Moving up / down in the menu
☞ NOTE: Press the UP and DOWN buttons at the same time to move to the main menu
On Idle Screen
On Menu Screen
SCAN
Button
Scans
Starts/Stops Auto Scan
Selects Menus
Selects settings
UP Button
Turns off when pressing for 5
seconds
Turns on when pressing for 1
second on power OFF
Display enters to the menu screen
when pressing with DOWN button at
the same time
Moves up to the menu above
Keeps it moving up when
pressing for 3 seconds
DOWN
Button
Disconnects BT when pressing for 3
seconds if BT is connected
Tries to reconnect when pressing for
1 second if disconnected on BT HID
mode
Display enters to the menu screen
when pressing with UP button at the
same time
Moves down to themenu below
Keeps it moving up when
pressing for 3 seconds
Scan button
Up button
Down button

PM3 User Manual
12
Using the Image Engine
5.1 Overview
The BLUETOOTH SCANNER contains an SE4710 2D image engine that instantly reads all
popular 1D and 2D bar codes and supports omni-directional aiming and decoding or a SE965HP,
SE655 1D laser engine that reads all popular 1D bar codes. The image engine can also capture
digital images, such as signatures and pictures.
☞ NOTE: It may not read the barcode due to specular reflection if scanning from directly above. Try again
after changing angle.
☞ NOTE: It may not read the barcode, if this Bluetooth scanner is too close to or too far from the barcode
even if the barcode is within the aiming range. Move the Bluetooth scanner toward or away from the barcode
slowly and try again. The aiming range is for reference only.
☞ NOTE: It may not read the barcode if the barcode surface is curved. Scan the barcode at the center of the
aiming range.
☞
NOTE: It may not read the barcode if the barcode surface is dirty. Try again after cleaning the barcode.
☞ NOTE: It may not read the barcode if the image engine window is dirty. Try again after wiping the window
with a cotton swab or similar soft object gently.
☞ NOTE: It may not read the barcode according to the direct sunlight or the brightness of the surrounding.
Try again away from the direct sunlight. Try again after adjusting the brightness of the surrounding if indoors.
☞ NOTE: It may not read the barcode if it is blue on white background. Try again after changing angle or
adjusting the brightness of the surrounding.
☞ NOTE: It may not read the barcode if it is black on silver background. Try again after changing angle or
adjusting the brightness of the surrounding.
☞ NOTE: Bar codes printed on glossy or laminated paper are best read at angles greater than 5°in relation
to the Laser Engine. This prevents bright illumination reflections from being returned to the Laser Engine.
☞ NOTE: Performance may be impacted by bar code quality and environmental conditions
☞ NOTE: Misreading may occur, if the bar code isn’t positioned correctly. Recommended scanner beam
positions are as follows

PM3 User Manual
13
5.2 Available Image Engines
The BLUETOOTH SCANNER is equipped with an SE4710.
5.3 Depth of Field
Depth of Field for SE4710
5.4 Supported Bar Code Symbologies
Symbology Type
Symbology Name
SE4710
Symbologies
UPC A, UPC E, UPC E1, EAN 8, EAN 13, BOOKLAND EAN,
CODE 128, GS1 128, ISBT 128, CODE 39, TRIOPTIC CODE 39,
CODE 93, CODE 11, INTERLEAVED 2 OF 5, DISCRETE 2 OF 5,
CODABAR, MSI, GS1 DATABAR, GS1 DATABAR LIMITED, GS1
DATABAR EXPANDED, UCC COUPON, CHINESE 2 OF 5,
MATRIX 2 OF 5, KOREAN 3 OF 5, US POSTNET, US PLANET,
UK POSTAL, JAPAN POSTAL, AUSTRALIA POST,
NETHERLANDS KIX CODE, USPS 4CB/ONE
CODE/INTELLIGENT MAIL, UPU FICS POSTAL, COMPOSITE
CC-C, COMPOSITE CC-A/B, COMPOSITE TLC-39, PDF417,
MICROPDF417, DATA MATRIX, MAXICODE, QR CODE, MICRO
QR, AZTEC, HAN XIN
5.5 To Decode a Barcode
Position the Bluetooth scanner over the barcode.
A range of 4–10 inches (10–25 cm) from the bar code is recommended.
Project the aiming brackets by pressing and holding the Scan button. The Scan LED lights
red.
Center the aimer crosshair over the bar code. The aiming beam should be oriented in line
with the barcode to achieve optimal decoding.
When the bar code is successfully decoded, the scan LED lights blue and the terminal
beeps.

PM3 User Manual
14
Using the Laser/CCD Engine
6.1 Overview
The BLUETOOTH SCANNER (SE965HP laser version, SE655 CCD version) contains a laser
diode that emits a beam toward an oscillating mirror that scans through the code and the reflected
light is bounced off of two mirrors back to the collector. The laser version reads all popular 1D bar
codes.
☞ NOTE: Performance may be impacted by bar code quality and environmental conditions.
6.2 Available Laser Engines
The BLUETOOTH SCANNER can be equipped with an SE965HP or SE655 laser/CCD engine
(depending on the configuration purchased).
6.3 Depth of Field
Depth of Field for SE965HP

PM3 User Manual
15
Depth of Field for SE655
6.4 Supported Bar Code Symbologies
Symbology Type
Symbology Name
SE965HP
Symbologies
UPC A, UPC E, UPC E1, EAN 8, EAN 13, BOOKLAND EAN,
CODE 128, GS1 128(EAN 128), ISBT 128, CODE 39, TRIOPTIC
CODE 39, CODE 93, CODE 11, INTERLEAVED 2 OF 5,
DISCRETE 2 OF 5, CODABAR, MSI, GS1 DATABAR 14, GS1
DATABAR LIMITED, GS1 DATABAR EXPANDED, UCC
COUPON, CHINESE 2 OF 5, MATRIX 2 OF 5, KOREAN 3 OF 5
SE655
Symbologies
UPC A, UPC E, UPC E1, EAN 8, EAN 13, BOOKLAND EAN,
CODE 128, GS1 128(EAN 128), ISBT 128, CODE 39, TRIOPTIC
CODE 39, CODE 93, CODE 11, INTERLEAVED 2 OF 5,
DISCRETE 2 OF 5, CODABAR, MSI, GS1 DATABAR 14, GS1
DATABAR LIMITED, GS1 DATABAR EXPANDED, UCC
COUPON, CHINESE 2 OF 5, MATRIX 2 OF 5
6.5 Decoding a Barcode
Position the Bluetooth scanner over the barcode.
A range of 4-10 inches (10-25 cm) from the bar code is recommended.
Project the aiming beam by pressing and holding the Scan button. The Scan LED lights red.
Center the aimer beam horizontally over the bar code and highlight all of the vertical bars of
the bar code. The aiming pattern is smaller when the terminal is held closer to the code and
larger when the terminal is held farther from the code. Symbologies with smaller bars or
elements (mil size) should be read closer to the unit whereas larger bars or elements (mil size)

PM3 User Manual
16
should be read farther from the unit.
When the bar code is successfully decoded, the scan LED lights blue and the terminal
beeps.
6.6 Scanning Positions
The aiming beam must be aimed across the entire bar code to provide you with the best scanning
performance. The aiming pattern is smaller when the terminal is held closer to the code and larger
when the terminal is held farther from the code. Symbologies with smaller bars or elements (mil
size) should be read closer to the unit whereas larger bars or elements (mil size) should be read
farther from the unit.

PM3 User Manual
17
Bluetooth
Bluetooth wireless technology is a short-range communications technology to connect portable
and/or fixed devices while maintaining high levels of security.
7.1 Enabling the Bluetooth
Choose Admin Menu > Bluetooth > Power
Choose Enabled and Save
☞ NOTE: Area coverage and Bluetooth radio performance may vary, due to environmental conditions or
interference caused by other devices (microwave ovens, radio transmitters, etc.).
7.2 Pairing Bluetooth Devices
Connecting Bluetooth devices usually requires them to be paired; the same PIN must be entered
for each device.
Select Pairing from main menu.
Search the Bluetooth device from the smartphone and connect.
If you want to pair with SPP mode,
Start Bluetooth pairing from PM3 device.
Launch PMSync app from your phone and search the device by selecting the button below.
Select a device from the list and connect.
7.3 ReconnectingHID
When HID is disconnected while using PM3 device, reconnection is available by following the
options below.
Admin Menu> Bluetooth > HID Settings > HID Reconnect > Enabled
Press DOWN button for 3 second to reconnect
Bluetooth Connected is shown on the display when successfully reconnected

PM3 User Manual
18
User Menus
To use the User Menu, Select User Settings in the main menu
Auto Scan
- You can select Auto Scan and the scanning time.
- Default: Disabled & 0.5 sec
Beeper Volume
- Beeper Volume can be adjusted.
- Volume size is available among None, Low, Middle, High.
- Default: High
Vibrator
- You can select the vibrator working when scanning is succeeded or failed.
- Vibration time can be selected among None, Short, Middle, Long.
- Default: None
Connect Mode
- Bluetooth transfer mode can be selected.
- Default: SPP.

PM3 User Manual
19
Admin Menus
To use the administrator menu, select Admin Menu in the main menu.
General uses may not change the settings of the admin menu. Ask for help to an administrator
when changes are required.
Barcode/Scan
View Data
- Searching or deleting the saved barcode data
Symbologies
-
You can select use or disuse of barcode type.
- When *is shown at the left corner of the display, it means the barcode type is being
used.
Code Options
- Set the detail symbology options for each of the scanner type
Scan Options
1.4.1 Scanner Lock
- Scanner Lock Setting
1.4.2 LED On Scan
- LED alert setting when scanning is “success” and “Fail”
1.4.3 Trigger Release
- Operation mode setting for scan trigger. Default is Disabled.
- When enabling, scan button should be pressed in order to apply the trigger time.
- Scanner Trigger becomes “off”when the button is not pressed
- Trigger Time is continued if the button is not pressed when the device is disabled
1.4.4 Trigger Timeout
- Set the Scan Trigger Timeout
- Default: 3 seconds
1.4.5 Power save mode
- Set the Power save mode
- Default: Enabled

PM3 User Manual
20
1.4.6 Save Timeout (SE965, SE4710)
- Set power save timeout.
- Default: 1 second
1.4.7 Terminator
- Set the terminator text when transmitting the barcode.
- Default: None
1.4.8 Transmit Barcode ID
- Set the Barcode ID Transmission.
- Default: Disabled
1.4.9 Security Level
- Set the Security Level.
- Default: Level 1
1.4.10 Scan Angle (SE965HP)
- Set the angle of the Scanner Beam.
- Default: 47
1.4.11 Adaptive Scan (SE965HP)
- Set the focus of the Scanner Beam to Automatic change.
- Default: Disabled
1.4.12 Picklist Mode (SE4710)
- Set the scanner to scan the barcode only indicated by the aimer.
- Default: Disabled
1.4.13 Redundancy (SE4710)
- Set the Scan level to prevent from misreading.
- Default: Level 1
1.4.14 Inverse 1D (SE4710, SE655)
- Set the scanner whether the color-reversed 1D barcode should be read or not.
- Default: Regular Only
1.4.15 Prefix / Suffix
- Deleting Prefix, Suffix
