Point Six OneSix User manual

Users Guide
OneSix™OPC Server
Version 2.2
Copyright ©2004, Point Six, Inc.
Point Six, Inc.
2333 Alumni Parkway.
Suite 305
Lexington, KY 40517
USA
[phone]
http://www.pointsix.com

OneSix Server Help Contents xi
Contents
Overview 1
Quick Start .................................................................................................................................1
Description .................................................................................................................................2
Receivers....................................................................................................................................3
Device List .................................................................................................................................4
Polling ........................................................................................................................................4
Identification ..............................................................................................................................4
Filtering......................................................................................................................................5
What is OPC?.............................................................................................................................5
Data Logging..............................................................................................................................5
Diagnostics.................................................................................................................................6
OneSix Main Window 7
Main Window.............................................................................................................................7
Setup ..........................................................................................................................................7
Change Port..................................................................................................................7
Add/Delete IP Connection ...........................................................................................8
View IP Connection Status ..........................................................................................8
Outputs.......................................................................................................................10
Search and Add Devices ............................................................................................11
ReConfigure Net ........................................................................................................11
Device List ...............................................................................................................................11
Errors........................................................................................................................................12
Tools ........................................................................................................................................12
Traffic ........................................................................................................................12
Quit ..........................................................................................................................................12
Help..........................................................................................................................................12
OneSix Server .INI File Format 13
OneSixOPC.ini.........................................................................................................................13
SERVER ....................................................................................................................14
Logging......................................................................................................................15
IP Addesses................................................................................................................15
DIGITAL I/O.............................................................................................................15
TEMPERATURE Setup ............................................................................................16
HUMIDITY ...............................................................................................................17
DIGCOUNTER and Directional Counter ..................................................................18
CNTTEMP.................................................................................................................18
FASTCNTTEMP.......................................................................................................20
ALARMTEMP ..........................................................................................................21
Analog Input ..............................................................................................................22
Access/Control Reader...............................................................................................23

ii xContents OneSix Server Help
Repeater .................................................................................................................... 23
Dual Discrete Output................................................................................................. 24
Wireless Analog Output ............................................................................................ 25
OneSix INI Backup ................................................................................................................. 26
OneSix Server OPC Tags 27
Using OPC Tags...................................................................................................................... 27
Device Names.......................................................................................................................... 27
Device Tag Names .................................................................................................................. 29
Temperature .............................................................................................................. 29
Digital I/O: DIGITALn............................................................................................. 30
Humidity Probe: HUMIDITYn................................................................................. 31
DIGCOUNTER and Directional Counter: DIGCOUNTERnand DIRECTCNTn... 32
CNTTEMP: CNTTEMPn......................................................................................... 33
FASTCNTTEMP: FASTCNTTEMPn...................................................................... 34
ALARMTEMP: ALARMTEMPn............................................................................. 35
AnalogInput: AIn...................................................................................................... 36
Access/Control Reader: IDRn................................................................................... 37
Repeater: REPEATERn............................................................................................ 39
Dual Discrete Output: OUTPUTDISCn.................................................................... 40
Wireless Analog Output: OutputAnalogn................................................................. 41
Server Item Names .................................................................................................................. 42
OneSix Server Data Logging 44
Features ................................................................................................................................... 44
File Management ..................................................................................................................... 45
File Format -Data Log ............................................................................................................ 46
File Format -Error Log ........................................................................................................... 47
TCP/IP Receivers 48
Overview of TCP/IP Receivers ............................................................................................... 48
Setting up to use TCP/IP Receivers......................................................................................... 48
Notes ....................................................................................................................................... 49
Error Messages 50
Communication Errors ............................................................................................................ 50
No Devices Attached! ............................................................................................... 50
Error In Finding/Initializing Port. ............................................................................. 50
Cannot Open Communication Port; Already In Use. ................................................ 50
Cannot Find Receiver! .............................................................................................. 50
Cannot find and load lowlevel driver!....................................................................... 50
Runtime Errors ........................................................................................................................ 51
Communication Error: CRC16 or Time Out ............................................................. 51
Cannot Find Receiver................................................................................................ 51
No Devices Attached................................................................................................. 51
OneSix Server Internal Error. ................................................................................... 51
Corrections 52
Why Use Corrections .............................................................................................................. 52
Correction IDs........................................................................................................... 52
Pre-defined Thermistor ............................................................................................. 52

OneSix Server Help Contents xiii
How to use Corrections ............................................................................................................53
Correction.INI file .....................................................................................................53
Predefined Corrections...............................................................................................53

OneSix Server Help Overview x1
Overview
Quick Start
When OneSix is run for the first time it displays this help screen. You may view this
help screen again by selecting "Help" from OneSix's main window.
OneSix is designed to gather data from sensors. OneSix makes available the data it
receives from each sensor through OPC tags.
The Main OneSix™ Server window will show the total number of devices in the
startup list and how many of those that are online. The offline devices will be shown
in the list box at the bottom of the window.
OneSix™ can be a stand-alone data logger. When data logging is enabled, OneSix™
will store collected data in an ASCII file at a programmable interval. See section
"OneSix Server Data Logging".
This Help and all other Help topics may be accessed from the main window by
selecting Help or pressing F1.
Setup
xPlug the reciever into your serial port
xStart OneSix.
xIf necessary, tell OneSix what kind of Receiver you are using.
xWhen the "Add Wireless Device" screen appears, press the service
mode button on your transmitter to transmit a packet that OneSix can
see.
xWhen a device appears in the window, you may click to select it and
then press the 'Edit' button to change its label name and transmit time.
xPress OK to add these sensors to the OneSix list
xOneSixOPC will create OPC tag objects for each device and start
polling and gathering data from each device.

2xOverview OneSix Server Help
If there is not an OneSixOPC.ini file or if [Server]NumberDevices 0 and when
OneSix™starts, it will automatically prompt for devices on the network and add them
to its list of devices to process.
Description
OneSix™is a data acquisition OLE for Process Control (OPC) server that acquires
data from devices and passes this data using OPC to a client application. OneSix
waits for the device to transmit and then processes the transmission.
Any Windows® application that can use OPC can obtain this data from the
OneSix™Server. Examples of such applications include Wonderware® Intouch,
National Instruments® LookOut, and general development applications like
Microsoft® Visual Basic and Borland® Delphi.
OneSix™can be a stand-alone data logger. When data logging is enabled,
OneSix™will also store collected data in an ASCII file at a programmable interval.
Another program such as a spreadsheet or a database manager can import the data.
See section "OneSix Server Data Logging".
OneSix Server can receive transmissions from wireless devices such as the wireless
temperature transmitter. Other devices include the wireless humidity sensor and
wireless analog input. OneSix uses a wireless receiver such as the Point Repeater,
the Point Host or the PointView Receiver to receive transmissions from wireless
sensors. OneSix can also use multiple TCP/IP Receivers (Point Managers in Pass-
Thru mode) to receive data through TCP/IP connection.
When setting up a wireless network, OneSix passively waits for transmissions instead
of actively polling for devices. This can make the acquisition of sensors take a
longer time than for a wired network as OneSix must wait for the device to transmit.
You can speed up this process by pressing the service button on the device so that it
transmits while you are in the “Add Sensors” screen.
Each device has an entry in the device's INI file section. Each device has a
"repeateraddress" attribute. When running OneSix with a Point Repeater, the
Repeater ID is stored in the "repeateraddress" entry. The value in the
"repeateraddress" indicates which Point Repeater sent the sensor information With
all other wireless receivers, the "repeateraddress" is set to 0. Finally, the INI entry
and OPC tag "Polltime" for each device has a different meaning when working with
wireless transmitters. OneSix cannot poll the wireless sensors. It must wait for a
transmission. Therefore, OneSix uses polltime to estimate how frequently a
transmission should come from a device. It also uses a multipler of this time to
determine if a device is offline. This multipler is configurable by the user.
Setup Described
OneSix will display the “Add Sensors” screen when it starts for the first time. The
setup screen is the method by which OneSix acquires wireless devices. The default
on the setup screen is to accept only packets that are sent in service mode from the
device (the packet is sent by pressing the service button on the device.) To change
this default, uncheck the "Service Mode Only" checkbox. OneSix will then display
all the packets it receives. When OneSix receives a packet from a device new to it, it
names the device following the naming conventions detailed below, and it displays
the device's name and serial number in the window.
You have several options after the device has been displayed. The "Clear New"
button will clear all the devices that have just been received. The "Delete" button

OneSix Server Help Overview x3
will delete a single device. Click on a device to select it and click on "Delete" to
delete it. To edit a device click on the device to select it and click on "Edit" to edit
the device. There is also a "Stop" button. If you click that button, OneSix will stop
listing devices in the window. When you click on the "Stop" button it becomes a
"Receive" button. If you click on that, OneSix will start receiving packets and listing
devices again.
When you are ready, hit "OK", or "Cancel" to exit.
Edit Device
The Edit screen for a new wireless device shows the device's serial number, which
the user cannot change, the device's current Label, which can be changed by the
user, and the Transmit Rate for the device. The Label cannot be the same as the label
used by any current device. The Transmit Rate is in seconds. The default value is
60. OneSix uses the Transmit Rate to determine if a device has gone offline.
Receivers
The following is a list of the receivers that OneSix can use:
xPoint View Receiver
xPoint Host Receiver
xPoint Integrator Logger –select "Point Host Receiver" from the "Select
Communication Port" screen
xPoint Repeater and Repeater III –select "Point Host Receiver" and set
the TZR baud rate to 19,2000.
xTCP/IP Receiver (Point Manager in “Pass-Thru” mode)

4xOverview OneSix Server Help
Device List
OneSix™ Server interfaces to a large number of devices. New devices are
continually being created for the Wireless network. Check with your distributor for
the latest.
The following is a list of devices supported by OneSix™ Server:
Point Sensor Temperat ure
Point Sensor Temp/Humidity
Point Sensor Analog 5V
Point Sensor Analog 10V
Point Sensor Analog 20mA
Point Probe
Point Sensor Pressure
Point Sensor DSCI
Point Sensor IR Counter
Point Sensor Thermistor
Point Sensor Counter Temperature
Point Sensor Fast Counter Temperature
Point Sensor Alarm Temperature
Point Access/Control Reader
Point Directional Counter
Point Dual Discrete Output
Point Analog Output
Polling
The polltime has a slightly different meaning for wireless sensors. OneSix does not
actively poll wireless devices. Rather, it waits to receive a packet from the devices.
Therefore, the polltime is how often OneSix expects to receive a packet from the
wireless devices.
The polltime for a wireless device is configurable during device setup. OneSix will
use this time to determine when to mark a device offline. OneSix has a INI file
parameter called "Tries" that sets how long a device has to transmit before it is
considered offline. For example, if the device has a polltime of 1 minute, and
OneSix has "tries" set to 3, then OneSix will consider the device offline if it does not
receive a packet from that device in 3 minutes ("tries" times "polltime").
Identification
OneSix™identifies each device with a unique label name. A client application uses
this label (an OPC topic) to obtain data from the server.

OneSix Server Help Overview x5
Filtering
For both analog and temperature devices, OneSix™allows the user to define a
deadband to control the amount of change that must occur before the server updates a
Client with new data. Deadband is useful to control the amount of information that is
passed through OPC to the client application. For analog devices, the deadband is
entered as the percentage of full scale of Engineering units. For temperature devices,
the deadband is entered in degrees C.
Also for both analog and temperature devices, One Six™ provides the means to filter
the data with either an Average, Median or combination Median Average filter
before either logging data or delivering data through OPC. In the One Six INI file,
you specify the filter type and the number of samples to filter.
What is OPC?
OLE for Process Control (OPC) is a specific specification of Microsoft’s Object
Linking and Embeddeding (OLE) and Component Object Model (COM) that is
administered by the OPC Foundation (150 member companies including Microsoft
Corporation). OPC provides a common interface for devices and applications to
communicate. Devices that gather or originate data become OPC servers, providing
data to OPC client applications in a consistent fashion. At the heart of OPC is the
client/server model in which the OPC server provides and interface to the OPC
object, allowing client applications to control devices and manage device data in a
generic fashion. OPC servers can be accessed through most HMI software and
through a variety of languages, including C++, Visual Basic, and Delphi. The OPC
server collects data from physical devices for distribution to OPC client applications
and also has the responsibility for updating device data when an OPC client issues a
write.
An OPC client connects to and communicates with an OPC server through one of two
interfaces defined in the OPC specification. The OLE automation interface allows
users to access data through the use of a common, easily understood scripting
language. The COM interface is more complex, but provides finer levels of control
and flexibility for developers and users proficient in languages such as C or C++.
OPC client applications can access OPC servers locally within a computer or from a
networked server.
Data Logging
OneSix™ Server can log data to an ASCII file at a programmable interval. The
default name of the file is ONESIX.LOG.
A client application can control logging through OPC variables. The client can
start/stop logging or just log a single record.
For diagnostic purposes, OneSix™ can log errors that have occurred while waiting
or process device data.
For more information see the section OneSix Server Data Logging.

6xOverview OneSix Server Help
Diagnostics
With OneSix™, you can monitor the health of your wireless and the devices attached.
OneSix™reports through OPC errors that it encounters while polling devices. These
errors can be noted in an event error log. See the section called "Server Item Names"
for more information.

OneSix Server Help OneSix Main Window x7
OneSix Main Window
Main Window
OneSix™displays the number of devices online and offline. It also lists the devices
that are currently offline displaying the name and serial number of the device. If
OneSix™ is running with TCP/IP receivers, then for each offline device it will
display the node address, name and serial number of the device.
Setup
OneSix™simplifies setup by automatically finding, identifying and beginning to poll
devices in a network. OneSix™assumes default initial values. You can easily change
these values by editing the ONESIXOPC.INI file with an ASCII text editor. (The
installation program for OneSix™Server created a short cut to the ONESIXOPC.INI
file. Double clicking will automatically start WordPad or Notepad.) See the section
"OneSix Server .INI File Format".
Change Port
The Change Port submenu allows you to switch to another wireless receiver port.
When the Change Port submenu is selected, OneSix™displays the Select
Communication Port window. Choose one of the following:
AUTO -instructs OneSix™ to search Port Numbers 1 to 4 for the
PointView Receiver.
PointView Receiver
Point Host
TZR Transceiver –(Point Transceiver) –make sure the TZR baud rate is
set to 19200.
TCP/IP Receiver –uses a receiver that uses the TCP/IP protocol to receive
sensor packet data. (Point Manager in “pass-thru” mode).
When OK is clicked, OneSix™ tries to initialize the port. For the PointView and
TCP/IP Receivers, OneSix confirms that the receiver is present. For the Point Host
and the TZR Transceiver, OneSix assumes the receiver is present. If OneSix™ fails,
OneSix™ displays the OneSix Initializing Error Window allowing you to retry, select
another port or exit OneSix™. If OneSix™succeeds, OneSix™starts listening and
processing sensor packets.

8xOneSix Main Window OneSix Server Help
Add/Delete IP Connection
(TCP/IP Receiver only)
OneSix will display the “Add/Delete IP Connection” screen. IP addresses already
setup will be displayed. The following is a list of the columns:
Node –Node number for the IP address. OneSix uses this number to
identify this IP connection. OneSix uses this number to update the OPC
tag item “nodaladdress”.
IP Address –the IP address that is used to address the receiver.
Port –the port number that is used along with the IP address to address the
receiver.
Conn –identifies who initiated the connection. Outgoing: OneSix initiated
the connection with the receiver. Incoming: the receiver initiated the
connection with OneSix.
Password –initial password used to gain access to the receiver.
Description –a general description field associated with the IP connection.
The following is list of buttons in the “Add/Delete IP Connection” screen:
Test –OneSix will try to make a connection to this IP address and report
back success or failure.
Add New –OneSix displays the “New IP Address” screen. The following
is list of the fields to enter to add a new IP connection:
IP Address –the IP address that is used to address the receiver
Port –the port number that is used along with the IP address to address
the receiver.
Description–a general description field associated with the IP
connection.
Password –initial password used to gain access to the receiver. If the
receiver does not have a password set or does not require a
password then leave this field blank.
Connection –identifies whether OneSix will initiate the connection or
whether the receiver will initiate the connection. Outgoing: OneSix
initiates the connection. Incoming: OneSix waits for the receiver to
initiate the connection.
Edit –OneSix displays the “Edit” screen showing the selected IP
connection. The “Edit” screen has the same fields as the “New IP
Address” screen.
Delete –delete the selected IP connection.
View IP Connection Status
(TCP/IP Receiver only)
OneSix will display the “IP Status” screen. OneSix shows the current state of the all
the connections. The following describes the columns:

OneSix Server Help OneSix Main Window x9
Node –Node number for the IP address. OneSix uses this number to
identify this IP connection. OneSix uses this number to update the OPC
item “nodaladdress”.
IP Address –the IP address that is used to address the receiver.
Port –the port number that is used along with the IP address to address the
receiver.
Conn –identifies who initiated the connection. Outgoing: OneSix initiated
the connection with the receiver. Incoming: the receiver initiated the
connection with OneSix.
Description –a general description field associated with the IP connection.
Status –the current status of the connection. The following is a list of the
possible status messages:
Never Connected –OneSix never attempted or received a connection to
the receiver
IP Connected –OneSix is currently connected to the receiver but has
not logged in.
Connected–OneSix is currently connected to the receiver is waiting to
receive sensor packets.
Disconnected –OneSix was connected but is now disconnected from
the receiver. If the connection was initiated by OneSix, OneSix
will continually try to reestablish the connection.
TCP/IP Error –a TCP/IP error was encounter and OneSix is not
connected to the receiver.
No IP Connection –OneSix tried to establish a connection but failed.
Wrong Password –The receiver requires a login password and the
incorrect password was used by OneSix.

10 xOneSix Main Window OneSix Server Help
Outputs
OneSix can send output packets to output devices. (Normally sensors do not receive
packets) Output devices must be setup manually. Some Outputs need to be “trained”
to the packets that it will receive for from the Server.
New and Edit
Create or edit an Output object to manage an Output sensor. The following
describe the parameters necessary to set up an Output sensor.
Type –“Dual Discrete Outputs” or “12 bit Analog Output”. Select the type
of Output sensor. Note changeable only for the Edit Output window.
Serial Number –Some Outputs sensors can “learn” a serial number. Others
have the serial number preassigned and must be entered in the field.
These sensors have the serial number labeled. For those sensors that
must learn their serial number, OneSix creates a default serial number.
Press the “Generate New Serial Number” button to generate a new
serial number.
Label –name assigned for this Output sensor. The label name is used for
the OPC topic name. This name must be unique. For the Edit Window,
the Label field contains a list box. Select the Output to modify from the
list. You can also change the label for the current Output.
Node –This field applies only when using the TCP/IP Receiver. The Node
List box contains a list of the TCP/IP Receivers to send the output
packet to. For the “Send All” selection, OneSix will send the packet to
all the TCP/IP Receivers.
Dual Discrete Outputs
Send when output B is written –If checked, OneSix will only send the
output packet only when the “outputB” item is written to. Output A is
first written to and the output B. If unchecked, OneSix will send the
output packet when either the “outputA” or “outputB” items are written
to. The state both outputs are sent in the same packet.
12 bit Analog Output
Scale –the scale to apply to the raw reading (12 bits: 0 to 4095).
Offset –the offset to apply to the reading after the scale is applied.
Engeering Value Scale * raw + Offset.
Units –units label for the analog output.
Train
The Train dialog is used in the processing of training the Output device to output
packets (as produced by OneSix). Follow these steps to train an Output device:
1. Select the desired Output from the list of Outputs.
2. Press and hold the button on the Output device (label as “train”).
3. Click the button on the Train window. Repeat until the LED on the
Output device is on.
The Output device is now ready to receive Output packets from OneSix.

OneSix Server Help OneSix Main Window x11
Search and Add Devices
OneSix will display the "Add Sensors" screen. Devices already in the
OneSixOPC.ini file are displayed in the top portion of the screen. Follow the setup
procedure to add more devices.
The setup screen is the method by which OneSix acquires wireless devices. The
default on the setup screen is to accept only packets that are sent in service mode
from the device (the packet is sent by pressing the service button on the device.) To
change this default, uncheck the "Service Mode Only" checkbox. OneSix will then
display all the packets it receives. When OneSix receives a packet from a new device
new, it names the device following the naming conventions detailed below, and it
displays the device's name and serial number in the window.
You have several options after the device has been displayed. The "Clear New"
button will clear all the devices that have just been received. The "Delete" button
will delete a single device. Click on a device to select it and click on "Delete" to
delete it. To edit a device, click on the device to select it and click on "Edit" to edit
the device. There is also a "Stop" button. If you click that button, OneSix will stop
listing devices in the window. When you click on the "Stop" button, it becomes a
"Receive" button. If you click on that, OneSix will start receiving packets and listing
devices again.
When you are ready, hit "OK", or "Cancel" to exit.
Edit Device
The Edit screen for a new RF device shows the device's serial number, which the
user cannot change, the device's current Label, which can be changed by the user,
and the Transmit Rate for the device. The Label cannot be the same as the label used
by any current device. The Transmit Rate is in seconds. The default value is 60.
OneSix uses the Transmit Rate to determine if a device has gone offline.
ReConfigure Net
OneSix™ clears device information from the OneSixOPC.ini file and shows the
“Add Sensors” screen. Use caution here; all changes that you have made manually
to the device information contained in the OneSixOPC.ini file will be deleted and
overwritten. OneSix™does not modify the global configuration parameters contained
in the sections Server and Logging of the OneSixOPC.ini file.
Device List
Clicking this menu option shows the “View Device List” window. OneSix™shows a
list of devices and their serial numbers.
To see the help for a device, click on the device and then click the help button.
OneSix™will display the help for the selected device.

12 xOneSix Main Window OneSix Server Help
Errors
OneSix™displays the Communication Errors window. This window shows the last
error that occurred.
Tries Count: Number of tries that have occurred before a device is considered offline.
Major Error Count: Number of errors that (after tries) took the device offline.
Last Error Code: Number error code of the last error
Last Error Device: The name of the device that had the last error.
Last Error Time: The time when the last error occurred.
Last Error Message: A description of the last error.
Click the Reset button clear the errors and reset the counts.
Tools
Traffic
The Traffic program is utility to monitor the traffic flow of sensors through the
wireless network. Use the utility to monitor the health of the sensors and make
adjustments to receivers, repeaters and sensors.
Quit
When you select this menu option, OneSix™ terminates.
Help
You select the the Help file's contents or index window or you can display the
OneSix™About window.

OneSix Server Help OneSix Server .ini File Format x13
OneSix Server .INI File Format
OneSixOPC.ini
The ONESIXOPC.INI file contains the configuration parameters for the server and
and a list of devices to process. When OneSix™searches and finds a new device it
adds the device to the INI file and assigns default initial parameters. These
parameters can be changed by using a text editor and editing the INI file. The
installation program for OneSix™Server created a short cut to the ONESIXOPC.INI
file. Double clicking will automatically start WordPad or Notepad. The following
rules must be kept when editing the INI file.
1) All device label names must be unique.
2) The NumberDevices in the [Server] section must equal the largest device
section [Devicen].
3) The must be no missing device sections [Devicen] in the list.
Note: OneSix™ looks at the ini file only at startup or after adding a new device.
Changes made to the ini file will not be reflected in OneSix™ until OneSix™ is
closed and restarted.

14 xOneSix Server .ini File Format OneSix Server Help
The following is a list of the ONESIXOPC.INI parameters.
SERVER
[Server]-Section name.
PortType -Communication medium (AUTO, Point Host, TZR, Point View,
etc.).
PortNo -Port number.
NumberDevices -Number of devices to be processed by the server.
Tries -No. of tries during polling before a device is marked offline.
HostAdapterCheck -Enables/disables the detection of receiver. (0 or 1)
BaudRate –options are: 115,200; 38,400; 19,200; or 1200. The default is
19200. Use this parameter for receivers that use a different baud rate
than the default. Make sure the value in the ini file matches the value
set in the hardware.
DefaultTempUnits -specifies the starting units of Temperature devices
DefaultPressUnits -specifies the starting units of Pressure devices
DefaultForceUnits -specifies the starting units of Force and Scale devices
ConfigureEnable – 0 – disables the Setup Menu option on the main menu.
The user then cannot make any changes to the configuration. 1 –
(default) –enable the Setup Menu option on the main menu.
SmallINI –suppresses the listing of minor variables in order to make the ini
file smaller. Note that Windows 98 and ME have a limit of 64K bytes
for the INI file size.
DefaultThermistorCorrID –overrides the default thermistor Correction ID
(normally 128). All thermistors will be assigned this Correction ID
unless the ID is overridden in the individual device section.
ForwardAll –species if all packets are forwarded or only packets
associated with OneSix’s device list get forwarded across a TCP/IP
connection. A TCP/IP client must initiate the connection to the port
specified with the ForwardPort in the [IP Addresses] section. Each
packet has the following format: sensor packet,node number, node
description, sensor label.
ValueOffline – 0 – I/O parameters will retain the last value when the sensor
goes offline; 1 – I/O parameters will be set to a value of –999999 when
a sensor goes offline.

OneSix Server Help OneSix Server .ini File Format x15
Logging
[Logging] -section name
LogRate -0: no logging; 1-100000 logging interval in seconds. 5 sec or
greater OneSix™opens and closes the log file at every logging interval.
Less than 5 OneSix™leaves the file open until OneSix™is terminated or
“Server.Logging.LogRate” is set to 0 or 5 and greater.
LogFile -full pathname for the log file -default "ONESIX.LOG"
OfflineIndicator -character or string to indicate offline -NULL: last value
LogErrors -1 -log runtime network errors to ONESIX.ERR. 0 -do not
log errors
IP Addesses
[IP Addresses] –section name (for TCP/IP receivers)
IPWaitPort –port number that OneSix will wait for connections initiated
by an IP receiver. (default is 1060)
ForwardPort –port number that OneSix will wait for connections to
forward received packets. (default is 0 which means disabled) OneSix
will forward received packets through this connection. Each packet has
the following format: sensor packet,node number, node description,
sensor label. The INI parameter FowardAll in the [Server] section
controls what packets get sent.
DIGITAL I/O
[Devicen]-Section name.
Address –serial number of the sensor.
DeviceType -Device type. (DeviceType DIGITAL)
PollTime –the transmit interval of the sensor. (ms)
Label -Name used for the device (and Topic).
Log -Enable/disable logging of device.
OutputOnDemand -Output is initiated on demand or during poll.
DescriptionA -General purpose description.
DescriptionB -General purpose description.

16 xOneSix Server .ini File Format OneSix Server Help
TEMPERATURE Setup
(Point Temperature, DS1820/1920/18S20/18B20/1822)
[Devicen]-Section name.
Address -–serial number of the sensor.
DeviceType -Device type. (DeviceType TEMP)
PollTime -the transmit interval of the sensor. (ms)
Label -Name used for the device (and Topic).
Log -Enable/disable logging of device.
LogDecimalPlaces -Number of decimals to create when logging.
Units -See OPC tags list under input.units for description.
Cal1Raw -Two point calibration point 1.
Cal2Raw -Two point calibration point 2.
Cal1Engr -Two point calibration engineering units for point 1.
Cal2Engr -Two point calibration engineering units for point 2.
DeadBand -Dead band filtering value in ºC. (Default 0.01)
FilterElements -running macro filter of the sampled data. Syntax: [no. of
elements, type] where no. of elements is number of samples to filter;
type –“AVERAGE”, “MEDIAN” and “AVERAGEMEDIAN”.
Default is “ 0,MEDIAN” –no filtering. Example:
FilterElements 6,AVERAGE
Description -General purpose description.
CorrID –What CorrectionID to use with this device. Must be found in the
"Correction.INI" file that you write and keep in the same directory as
the OneSix.ini file. 0 is the default and means no correction; 127 is the
maximum. If the device type is a thermistor, the default CorrID is
found in the [Server] section "DefaultThermistorCorrID", which
defaults to 128.
