Dell EMC PowerEdge R7415 Manual

Dell EMC PowerEdge R7415
Installation and Service Manual
Regulatory Model: E46S Series
Regulatory Type: E46S002

Notes, cautions, and warnings
NOTE: A NOTE indicates important information that helps you make better use of your product.
CAUTION: A CAUTION indicates either potential damage to hardware or loss of data and tells you how to avoid the problem.
WARNING: A WARNING indicates a potential for property damage, personal injury, or death.
©2017 - 2018 Dell Inc. or its subsidiaries. All rights reserved. Dell, EMC, and other trademarks are trademarks of Dell Inc. or its subsidiaries. Other
trademarks may be trademarks of their respective owners.
2018 - 02
Rev. A01

Contents
1 Dell EMC PowerEdge R7415 overview............................................................................................................ 8
Supported congurations for the PowerEdge R7415 system.......................................................................................8
Front view of the system.................................................................................................................................................. 9
Left control panel view............................................................................................................................................... 11
Right control panel view............................................................................................................................................ 14
Back panel features..........................................................................................................................................................15
NIC indicator codes.................................................................................................................................................... 17
Power supply unit indicator codes............................................................................................................................18
Drive indicator codes.................................................................................................................................................20
LCD panel.................................................................................................................................................................... 21
Locating the Service Tag of your system...................................................................................................................... 21
2 Documentation resources............................................................................................................................ 23
3 Technical specications............................................................................................................................... 25
System dimensions.......................................................................................................................................................... 26
Chassis weight................................................................................................................................................................. 26
Processor specications..................................................................................................................................................27
PSU specications........................................................................................................................................................... 27
System battery specications.........................................................................................................................................27
Expansion bus specications.......................................................................................................................................... 27
Memory specications.....................................................................................................................................................27
Drive specications..........................................................................................................................................................28
Drives...........................................................................................................................................................................28
Ports and connectors specications............................................................................................................................. 28
USB ports....................................................................................................................................................................28
NIC ports.....................................................................................................................................................................29
Serial connector......................................................................................................................................................... 29
VGA ports................................................................................................................................................................... 29
Internal Dual SD Module............................................................................................................................................29
Video specications.........................................................................................................................................................29
Environmental specications..........................................................................................................................................30
Particulate and gaseous contamination specications ..........................................................................................31
Standard operating temperature..............................................................................................................................32
Expanded operating temperature............................................................................................................................ 32
Thermal restriction matrix.........................................................................................................................................33
4 Initial system setup and conguration..........................................................................................................35
Setting up your system................................................................................................................................................... 35
iDRAC conguration........................................................................................................................................................ 35
Options to set up iDRAC IP address........................................................................................................................35
Log in to iDRAC..........................................................................................................................................................36
Contents 3

Options to install the operating system.........................................................................................................................36
Methods to download rmware and drivers...........................................................................................................36
Downloading drivers and rmware...........................................................................................................................37
5 Pre-operating system management applications..........................................................................................38
Options to manage the pre-operating system applications........................................................................................38
System Setup................................................................................................................................................................... 38
Viewing System Setup.............................................................................................................................................. 38
System Setup details.................................................................................................................................................39
System BIOS.............................................................................................................................................................. 39
iDRAC Settings utility................................................................................................................................................ 56
Device Settings.......................................................................................................................................................... 57
Dell Lifecycle Controller...................................................................................................................................................57
Embedded system management..............................................................................................................................57
Boot Manager...................................................................................................................................................................57
Viewing Boot Manager..............................................................................................................................................57
Boot Manager main menu.........................................................................................................................................57
One-shot BIOS boot menu.......................................................................................................................................58
System Utilities...........................................................................................................................................................58
PXE boot...........................................................................................................................................................................58
6 Installing and removing system components................................................................................................ 59
Safety instructions...........................................................................................................................................................59
Before working inside your system................................................................................................................................59
After working inside your system...................................................................................................................................59
Recommended tools........................................................................................................................................................60
Optional front bezel......................................................................................................................................................... 60
Removing the front bezel......................................................................................................................................... 60
Installing the front bezel.............................................................................................................................................61
System cover....................................................................................................................................................................62
Removing the system cover.....................................................................................................................................62
Installing the system cover....................................................................................................................................... 63
Backplane cover...............................................................................................................................................................64
Removing the backplane cover................................................................................................................................64
Installing the backplane cover.................................................................................................................................. 65
Inside the system............................................................................................................................................................. 66
Air shroud.......................................................................................................................................................................... 67
Removing the air shroud........................................................................................................................................... 67
Installing the air shroud............................................................................................................................................. 69
Cooling fans.......................................................................................................................................................................71
Removing a cooling fan..............................................................................................................................................71
Installing a cooling fan................................................................................................................................................73
Intrusion switch................................................................................................................................................................ 75
Removing the intrusion switch.................................................................................................................................75
Installing the intrusion switch................................................................................................................................... 76
Drives.................................................................................................................................................................................77
4 Contents

Removing a drive blank..............................................................................................................................................77
Installing a drive blank................................................................................................................................................78
Removing a drive carrier........................................................................................................................................... 79
Installing a drive carrier............................................................................................................................................. 80
Removing the drive from the drive carrier.............................................................................................................. 81
Installing a drive into the drive carrier...................................................................................................................... 81
System memory............................................................................................................................................................... 82
General memory module installation guidelines......................................................................................................84
Mode-specic guidelines.......................................................................................................................................... 85
Removing a memory module....................................................................................................................................85
Installing a memory module...................................................................................................................................... 86
Processors and heat sinks...............................................................................................................................................87
Removing a heat sink.................................................................................................................................................87
Removing the AMD processor................................................................................................................................. 88
Installing the AMD processor.................................................................................................................................... 91
Installing the heat sink...............................................................................................................................................94
Rear drive cage................................................................................................................................................................ 96
Removing the rear drive cage.................................................................................................................................. 96
Installing the rear drive cage.....................................................................................................................................97
Drive backplane................................................................................................................................................................ 97
Removing the drive backplane ................................................................................................................................99
Installing the drive backplane..................................................................................................................................100
Removing the rear drive backplane........................................................................................................................ 101
Installing the rear drive backplane.......................................................................................................................... 102
Expansion cards and expansion card risers.................................................................................................................103
Expansion card installation guidelines.................................................................................................................... 103
Removing expansion card from the expansion card riser....................................................................................106
Installing expansion card into the expansion card riser........................................................................................107
Removing an expansion card.................................................................................................................................. 109
Installing an expansion card..................................................................................................................................... 110
Removing expansion card risers..............................................................................................................................112
Installing the expansion card risers..........................................................................................................................114
Optional IDSDM or vFlash module................................................................................................................................116
Removing the MicroSD card....................................................................................................................................116
Installing the MicroSD card...................................................................................................................................... 117
Removing the IDSDM or vFlash module.................................................................................................................117
Installing the IDSDM or vFlash module...................................................................................................................118
LOM riser card.................................................................................................................................................................119
Removing the LOM riser card................................................................................................................................. 119
Installing the LOM riser card................................................................................................................................... 122
Mini PERC card...............................................................................................................................................................124
Removing the mini PERC card................................................................................................................................124
Installing the mini PERC card..................................................................................................................................125
Cable routing................................................................................................................................................................... 127
System battery................................................................................................................................................................132
Contents 5

Replacing the system battery................................................................................................................................. 132
Optional internal USB memory key...............................................................................................................................133
Replacing optional internal USB memory key....................................................................................................... 134
Optional optical drive..................................................................................................................................................... 134
Removing the optical drive......................................................................................................................................134
Installing the optical drive........................................................................................................................................ 136
Power supply units..........................................................................................................................................................137
Hot spare feature......................................................................................................................................................138
Removing a power supply unit blank......................................................................................................................138
Installing a power supply unit blank........................................................................................................................ 138
Removing a power supply unit................................................................................................................................139
Installing a power supply unit.................................................................................................................................. 140
Removing a non-redundant cabled AC power supply unit...................................................................................141
Installing a non-redundant cabled AC power supply unit.....................................................................................142
Wiring instructions for a DC power supply unit.................................................................................................... 143
Power interposer board................................................................................................................................................. 145
Removing the power interposer board.................................................................................................................. 145
Installing the power interposer board.....................................................................................................................146
Control panel................................................................................................................................................................... 147
Removing the left control panel..............................................................................................................................147
Installing the left control panel................................................................................................................................148
Removing the right control panel........................................................................................................................... 149
Installing the right control panel............................................................................................................................. 150
System board...................................................................................................................................................................151
Removing the system board.................................................................................................................................... 151
Installing the system board......................................................................................................................................153
Restoring the Service Tag using Easy Restore...........................................................................................................155
Manually update the Service Tag........................................................................................................................... 155
Trusted Platform Module...............................................................................................................................................155
Upgrading the Trusted Platform Module...............................................................................................................155
Initializing TPM for BitLocker users........................................................................................................................157
7 Using system diagnostics........................................................................................................................... 158
Dell Embedded System Diagnostics.............................................................................................................................158
Running the Embedded System Diagnostics from Boot Manager.....................................................................158
Running the Embedded System Diagnostics from the Dell Lifecycle Controller..............................................158
System diagnostic controls..................................................................................................................................... 159
8 Jumpers and connectors ........................................................................................................................... 160
System board jumpers and connectors........................................................................................................................161
System board jumper settings...................................................................................................................................... 162
Disabling forgotten password........................................................................................................................................163
9 Getting help............................................................................................................................................... 164
Contacting Dell............................................................................................................................................................... 164
Documentation feedback.............................................................................................................................................. 164
6 Contents

Accessing system information by using QRL..............................................................................................................164
Quick Resource Locator for PowerEdge R7415................................................................................................... 165
Receiving automated support with SupportAssist ....................................................................................................165
Contents 7

Dell EMC PowerEdge R7415 overview
The PowerEdge R7415 is a 2U, single socket rack system and support these congurations:
• One AMD EPYC™processor
• Sixteen DIMM slots
• Two redundant power supply units (PSU) or single cabled PSU
• 8 x 3.5 inch, 12 x 3.5 inch, 12 x 3.5 inch + 2 x 3.5 inch (rear), or 24 x 2.5 inch SAS, SATA, or NVMe drives (up to 12 SAS/SATA/NVMe
+ 12 NVMe drives)
NOTE: Hot swap for the NVMe drives is supported for your system. For more information on correct usage and technical
specications, see the Dell PowerEdge Express Flash NVMe PCIe SSD 2.5 inch Small Form Factor User's Guide at Dell.com/
support/manuals > All Products > Server, Storage, & Networking > Dell Adapters page.
NOTE: All instances of SAS, SATA hard drives, SSDs and NVMe drives are referred to as drives in this document, unless specied
otherwise.
Topics:
• Supported congurations for the PowerEdge R7415 system
• Front view of the system
• Back panel features
• Locating the Service Tag of your system
Supported congurations for the PowerEdge R7415
system
The Dell EMC PowerEdge R7415 system supports the following congurations:
1
8 Dell EMC PowerEdge R7415 overview

Figure 1. Supported congurations for a PowerEdge R7415 system with rear drive
Front view of the system
The front view displays the features available on the front of the system.
Figure 2. Front view of 12 x 3.5 inch system
Dell EMC PowerEdge R7415 overview 9

Figure 3. Front view of 24 x 2.5 inch system
Figure 4. Front view of 8 x 3.5 inch system
Table 1. Features available on the front of the system
Item Ports, panels, and slots Icon Description
1 Left control panel N/A Contains the system health and system ID, status LED, and the
iDRAC Quick Sync 2 (wireless) indicator.
NOTE: The iDRAC Quick Sync 2 indicator is available only on
certain congurations.
• Status LED: Enables you to identify any failed hardware
components. There are up to ve status LEDs and an overall
system health LED (Chassis health and system ID) bar. For more
information, see the Status LED indicators section.
• Quick Sync 2 (wireless): Indicates a Quick Sync enabled system.
The Quick Sync feature is optional. This feature allows
management of the system by using mobile devices. This feature
aggregates hardware or rmware inventory and various system
level diagnostic and error information that can be used in
troubleshooting the system. For more information, see the
Integrated Dell Remote Access Controller User’s Guide at
Dell.com/idracmanuals.
2 Drive slots [3.5 inch or 2.5
inch drives]
N/A Enable you to install drives that are supported on your system. For
more information about drives, see the Technical specications
section.
3 Right control panel N/A Contains the power button, USB port, iDRAC Direct port, VGA port.
4 Information tag N/A The Information Tag is a slide-out label panel that contains system
information such as Service Tag, NIC, MAC address, and so on. If you
10 Dell EMC PowerEdge R7415 overview

Item Ports, panels, and slots Icon Description
have opted for the secure default access to iDRAC, the Information
tag also contains the iDRAC secure default password.
5 Optical drive (optional) N/A One optional slim SATA DVD-ROM drive or DVD+/-RW drive.
NOTE: DVD devices are data only.
Left control panel view
Figure 5. Left control panel without optional iDRAC Quick Sync 2.0 indicator
Figure 6. Left control panel with optional iDRAC Quick Sync 2.0 indicator
Table 2. Left control panel
Item Indicator, button, or
connector
Icon Description
1 Status LED indicators N/A Indicate the status of the system. For more information, see the
Status LED indicators section.
2 System health and system
ID indicator
Indicate the system health. For more information, see the System
health and system ID indicator codes section.
3 iDRAC Quick Sync 2
wireless indicator (optional)
Indicates if the iDRAC Quick Sync 2 wireless option is activated. The
Quick Sync 2 feature allows management of the system using mobile
devices. This feature aggregates hardware/rmware inventory and
various system level diagnostic/error information that can be used in
troubleshooting the system. You can access system inventory, Dell
Lifecycle Controller logs or system logs, system health status, and
also congure iDRAC, BIOS, and networking parameters. You can also
launch the virtual Keyboard, Video, and Mouse (KVM) viewer and
Dell EMC PowerEdge R7415 overview 11

Item Indicator, button, or
connector
Icon Description
virtual Kernel based Virtual Machine (KVM), on a supported mobile
device. For more information, see the Integrated Dell Remote Access
Controller User's Guide at Dell.com/idracmanuals.
Status LED indicators
NOTE: The indicators display solid amber if any error occurs.
Table 3. Status LED indicators and descriptions
Icon Description Condition Corrective action
Drive indicator The indicator turns solid amber if
there is a drive error. • Check the System Event Log to determine if the drive
has an error.
• Run the appropriate Online Diagnostics test. Restart
the system and run embedded diagnostics (ePSA).
• If the drives are congured in a RAID array, restart the
system, and enter the host adapter conguration
utility program.
Temperature
indicator
The indicator turns solid amber if the
system experiences a thermal error
(for example, the ambient
temperature is out of range or there is
a fan failure).
Ensure that none of the following conditions exist:
• A cooling fan has been removed or has failed.
• System cover, air shroud, memory module blank, or
back ller bracket is removed.
• Ambient temperature is too high.
• External airowis obstructed.
If the problem persists, see the Getting help section.
Electrical indicator The indicator turns solid amber if the
system experiences an electrical error
(for example, voltage out of range, or
a failed power supply unit (PSU) or
voltage regulator).
Check the System Event Log or system messages for the
specic issue. If it is due to a problem with the PSU,
check the LED on the PSU. Reseat the PSU.
If the problem persists, see the Getting help section.
Memory indicator The indicator turns solid amber if a
memory error occurs.
Check the System Event Log or system messages for the
location of the failed memory. Reseat the memory
module.
If the problem persists, see the Getting help section.
PCIe indicator The indicator turns solid amber if a
PCIe card experiences an error.
Restart the system. Update any required drivers for the
PCIe card. Reinstall the card.
If the problem persists, see the Getting help section.
NOTE: For more information about the
supported PCIe cards, see the Expansion card
installation guidelines section.
12 Dell EMC PowerEdge R7415 overview

System health and system ID indicator codes
The system health and system ID indicator is located on the left control panel of your system.
Figure 7. System health and system ID indicators
Table 4. System health and system ID indicator codes
System health and system ID indicator code Condition
Solid blue Indicates that the system is turned on, system is healthy, and system
ID mode is not active. Press the system health and system ID button
to switch to system ID mode.
Blinking blue Indicates that the system ID mode is active. Press the system health
and system ID button to switch to system health mode.
Solid amber Indicates that the system is in fail-safe mode. If the problem persists,
see the Getting help section.
Blinking amber Indicates that the system is experiencing a fault. Check the System
Event Log or the LCD panel, if available on the bezel, for specic error
message. For more information about error messages, see the Dell
Event and Error Messages Reference Guide at Dell.com/
openmanagemanuals > OpenManage software.
iDRAC Quick Sync 2 indicator codes
iDRAC Quick Sync 2 module (optional) is located on the left control panel of your system.
Figure 8. iDRAC Quick Sync 2 indicators
Table 5. iDRAC Quick Sync 2 indicators and descriptions
iDRAC Quick Sync 2 indicator
code
Condition Corrective action
O (default state) Indicates that the iDRAC Quick Sync 2
feature is turned o. Press the iDRAC Quick
Sync 2 button to turn on the iDRAC Quick
Sync 2 feature.
If the LED fails to turn on, reseat the left control panel
ex cable and check. If the problem persists, see the
Getting help section.
Solid white Indicates that iDRAC Quick Sync 2 is ready
to communicate. Press the iDRAC Quick
Sync 2 button to turn o.
If the LED fails to turn o, restart the system. If the
problem persists, see the Getting help section.
Dell EMC PowerEdge R7415 overview 13

iDRAC Quick Sync 2 indicator
code
Condition Corrective action
Blinks white rapidly Indicates data transfer activity. If the problem persists, see the Getting help section.
Blinks white slowly Indicates that rmware update is in
progress.
If the problem persists, see the Getting help section.
Blinks white vetimes rapidly and
then turns o
Indicates that the iDRAC Quick Sync 2
feature is disabled.
Check if iDRAC Quick Sync 2 feature is congured to
be disabled by iDRAC. If the problem persists, see the
Getting help section. For more information, see
Integrated Dell Remote Access Controller User's
Guide at Dell.com/idracmanuals or Dell
OpenManage Server Administrator User’s Guide at
Dell.com/openmanagemanuals.
Solid amber Indicates that the system is in fail-safe
mode.
Restart the system. If the problem persists, see the
Getting help section.
