Polar Electro WearLink+ User manual

POLAR WEARLINK®+
HEART RATE SENSOR
WITH BLUETOOTH®
User Manual

ENGLISH
Polar WearLink®heart rate sensor
with Bluetooth®
This user manual contains instructions for Polar
WearLink®heart rate sensor with Bluetooth®.
Visit www.polar.com for a list of compatible
applications.
The latest version of this user manual can be
downloaded at www.polar.com/support. For
video tutorials, go to www.polar.com/support/
video_tutorials.
Register your Polar product at
http://register.polar.fi to ensure we can keep
improving our products and services to better
meet your needs.
Please follow the pictures on the front cover.
Heart Rate Sensor Parts
1. The plastic electrode areas on the reverse
side of the strap detect heart rate. Picture
A1.
2. The connector sends the heart rate signal
to the receiving device. Picture A2.
WearLink heart rate sensors enable training in a
group without interference from other heart rate
sensors.
Wear the Heart Rate Sensor
1. Moisten the electrode areas of the strap.
Picture B1.
2. Attach the connector to the strap. Picture
B2.
3. Adjust the strap length to fit tightly but
comfortably.
4. Tie the strap around your chest, just below
the chest muscles, and attach the hook to
the other end of the strap. Picture B3.
5. Check that the moist electrode areas are
1

firmly against your skin and that the Polar
logo of the connector is in a central and
upright position. Picture B4.
Detach the connector from the strap and rinse
the strap under running water after every use.
See detailed washing instructions in the Caring
for Your Heart Rate Sensor section.
Getting Started
When using the Polar WearLink heart rate
sensor with Bluetooth®for the first time, you
need to pair the heart rate sensor with your
receiving device. For more information on
enabling the heart rate sensor and starting the
application, consult separate user instructions
supplied by the application manufacturer.
In case the application asks for a PIN code,
please enter 0000. The PIN code is printed
also on the back of the connector.
To ensure sufficient transmission range from
your heart rate sensor to the receiving device,
keep the receiving device as close as possible to
the heart rate sensor. A good place is in a
pocket, fixed on the belt or in a small bag on
the side. Do not wear the receiving device on
your back (for example, in a back pocket or
back pack).
Caring for Your Heart Rate Sensor
The heart rate sensor is a high-tech instrument
that should be handled with care. Follow the
caring instructions to ensure reliable
measurement and to maximize the life span of
the heart rate sensor. The following instructions
will help you fulfill guarantee obligations.
Connector: Detach the connector from the strap
after every use and dry the connector with a soft
towel. Clean the connector with a mild soap and
2ENGLISH

water solution when needed. Never use alcohol
or any abrasive material (eg. steel wool or
cleaning chemicals).
Strap: Rinse the strap under running water after
every use and hang to dry. Clean the strap
gently with a mild soap and water solution when
needed. Do not use moisturizing soaps, because
they can leave residue on the strap. Do not
soak, iron, dry clean or bleach the strap. Do not
stretch the strap or bend the electrode areas
sharply.
Dry and store the strap and the connector
separately, to maximize the heart rate sensor
battery lifetime. Keep the heart rate sensor in
a cool and dry place. Do not store the heart rate
sensor wet in non-breathing material, such as a
sports bag, to prevent snap oxidation. Do not
expose the heart rate sensor to direct sunlight
for extended periods.
Check the label on your strap to see if it is
machine washable. Never put the strap or the
connector in a dryer!
Batteries
All WearLink connectors have user changeable
batteries. To change the battery yourself, follow
the instructions below, and see the markings on
the connector and picture C on the front cover
of this user manual.
1. Using a coin, open the battery cover by
turning it counterclockwise to OPEN.
2. Insert the battery (CR 2025) inside the
cover with the positive (+) side against the
cover. Make sure the sealing ring is in the
groove to ensure water resistance.
3. Press the cover back into the connector.
4. Use the coin to turn the cover clockwise to
CLOSE.
When changing the battery, make sure the
sealing ring is not damaged, in which case you
ENGLISH 3

should replace it with a new one to ensure the
water resistance of the connector.
Battery kits with sealing rings are available at
Polar retailers and authorized Polar Service
Centers. In the USA and Canada, sealing rings
are available at authorized Polar Service Centers
only.
Keep batteries away from children. If
swallowed, contact a doctor immediately.
Batteries should be disposed of in compliance
with local regulations.
Service
During the warranty period, service the product
at an authorized Polar Service Center only. The
warranty does not cover damage caused by
unauthorized service. See Limited International
Polar Guarantee.
Precautions
For allergy information, see the listed materials
in Technical Specifications. Avoid skin
reactions by wearing the heart rate sensor over a
shirt, moistened under the electrodes.
The combined impact of moisture and intense
abrasion may cause a black color to come off
the heart rate sensor’s surface, possibly
staining light-colored clothes. If you use
perfume or insect repellent on your skin, you
must ensure that it does not come into
contact with the heart rate sensor.
Using Your Heart Rate Sensor in a Water
Environment
Polar WearLink heart rate sensor with
Bluetooth®is water-resistant but does not
measure heart rate in water.
4ENGLISH

Technical Specifications
Battery type: CR 2025
Battery sealing ring: O-ring 20.0 x 1.0 Material
FPM
WearLink with Bluetooth®battery life: 150
hours of use
Operating temperature: 32 °F to 122 °F/ 0 °C -
+50°C
Connector material: Polyamide
Strap material: 38% Polyamide, 29%
Polyurethane, 20% Elastane, 13% Polyester
Compatibility: Polar WearLink heart rate sensor
with Bluetooth®is not compatible with Polar
training computers.
When the heart rate sensor is worn directly on
the skin, underneath clothing, the operating
temperature is 14 °F to 122 °F / -10 °C to
+50 °C.
Guarantee and Disclaimer
• This guarantee does not affect the consumer’s
statutory rights under applicable national or state
laws in force, or the consumer’s rights against the
dealer arising from their sales/purchase contract.
• This limited Polar international guarantee is issued
by Polar Electro Inc. for consumers who have
purchased this product in the USA or Canada. This
limited Polar international guarantee is issued by
Polar Electro Oy for consumers who have purchased
this product in other countries.
• Polar Electro Oy/Polar Electro Inc. guarantees the
original consumer/purchaser of this device that the
product will be free from defects in material or
workmanship for two (2) years from the date of
purchase.
ENGLISH 5

•The receipt of the original purchase is your proof
of purchase!
• The guarantee does not cover the battery, normal
wear and tear, damage due to misuse, abuse,
accidents or non-compliance with the precautions;
improper maintenance, commercial use, cracked,
broken or scratched cases/displays, armband,
elastic strap and Polar apparel.
• The guarantee does not cover any damage/s, losses,
costs or expenses, direct, indirect or incidental,
consequential or special, arising out of, or related to
the product.
• Items purchased second hand are not covered by
the two (2) year warranty, unless otherwise
stipulated by local law.
• During the guarantee period, the product will be
either repaired or replaced at any of the authorized
Polar Service Centers regardless of the country of
purchase.
Guarantee with respect to any product will be limited to
countries where the product has been initially
marketed.
This product is compliant with the Directives
93/42/EEC, 1999/5/EC and 2011/65/EU. The relevant
Declaration of Conformity is available at
www.support.polar.com
/declaration_of_conformity.html.
Regulatory information is available at
www.polar.com/support.
Compliance Statement
Canada
Polar Electro Oy has not approved any changes or
modifications to this device by the user. Any changes or
modifications could void the user’s authority to operate
the equipment.
Polar Electro Oy n’a approué aucune modification
apportée à l’appareil par l’utilisateur, quelle qu’en soit
la nature. Tout changement ou toute modification
peuvent annuler le droit d’utilisation de l’appareil par
l’utilisateur.
6ENGLISH

Industry Canada (IC) regulatory information
Under Industry Canada regulations, this radio
transmitter may only operate using an antenna of a type
and maximum (or lesser) gain approved for the
transmitter by Industry Canada. To reduce potential
radio interference to other users, the antenna type and
its gain should be so chosen that the equivalent
isotropically radiated power (e.i.r.p.) is not more than
that necessary for successful communication.
This device complies with Industry Canada
licence-exempt RSS standard(s). Operation is subject
to the following two conditions: (1) this device may not
cause interference, and (2) this device must accept any
interference, including interference that may cause
undesired operation of the device.
Avis de conformité à la réglementation d’Industrie
Canada
Conformément à la réglementation d'Industrie Canada,
le présent émetteur radio peut fonctionner avec une
antenne d'un type et d'un gain maximal (ou inférieur)
approuvé pour l'émetteur par Industrie Canada. Dans le
but de réduire les risques de brouillage radioélectrique
à l'intention des autres utilisateurs, il faut choisir le
type d'antenne et son gain de sorte que la puissance
isotrope rayonnée équivalente (p.i.r.e.) ne dépasse pas
l'intensité nécessaire à l'établissement d'une
communication satisfaisante.
Le présent appareil est conforme aux CNR d'Industrie
Canada applicables aux appareils radio exempts de
licence. L'exploitation est autorisée aux deux conditions
suivantes : (1) l'appareil ne doit pas produire de
brouillage, et (2) l'utilisateur de l'appareil doit accepter
tout brouillage radioélectrique subi, même si le
brouillage est susceptible d'en compromettre le
fonctionnement.
Class B digital device notice
This Class B digital apparatus complies with Canadian
ICES-003, RSS-Gen and RSS-210.
Cet appareil numérique de la classe B est conforme à
la norme NMB-003, CNR-Gen et CNR-210 du Canada.
ENGLISH 7

USA
Polar Electro Oy has not approved any changes or
modifications to this device by the user. Any changes or
modifications could void the user’s authority to operate
the equipment.
FCC regulatory information
This device complies with part 15 of the FCC rules.
Operation is subject to the following two conditions: (1)
This device may not cause harmful interference, and
(2) This device must accept any interference received,
including interference that may cause undesired
operation.
Note: This equipment has been tested and found to
comply with the limits for a Class B digital device,
pursuant to part 15 of the FCC Rules. These limits are
designed to provide reasonable protection against
harmful interference in a residential installation. This
equipment generates, uses and can radiate radio
frequency energy and, if not installed and used in
accordance with the instructions, may cause harmful
interference to radio communications. However, there
is no guarantee that interference will not occur in a
particular installation.
If this equipment does cause harmful interference to
radio or television reception, which can be determined
by turning the equipment off and on, the user is
encouraged to try to correct the interference by one or
more of the following measures:
1. Reorient or relocate the receiving antenna.
2. Increase the separation between the equipment
and receiver.
3. Connect the equipment into an outlet on a circuit
different from that to which the receiver is
connected.
4. Consult the dealer or an experienced radio/ TV
technician for help.
This product emits radio frequency energy, but the
radiated output power of this device is far below the
FCC radio frequency exposure limits. This equipment
complies with FCC RF radiation exposure limits forth
for an uncontrolled environment. Nevertheless, the
8ENGLISH

device should be used in such a manner that the
potential for human contact with the antenna during
normal operation is minimized.
This crossed out wheeled bin marking shows that Polar
products are electronic devices and are in the scope of
Directive 2002/96/EC of the European Parliament and
of the Council on waste electrical and electronic
equipment (WEEE) and batteries and accumulators
used in products are in the scope of Directive
2006/66/EC of the European Parliament and of the
Council of 6 September 2006 on batteries and
accumulators and waste batteries and accumulators.
These products and batteries/accumulators inside Polar
products should thus be disposed of separately in EU
countries.
This marking shows that the product is protected
against electric shocks.
Bluetooth QD ID: B014698
Copyright 2013 Polar Electro Oy, FIN-90440
KEMPELE, Finland.
Polar Electro Oy is a ISO 9001:2008 certified
company.
All rights reserved. No part of this manual may be used
or reproduced in any form or by any means without
prior written permission of Polar Electro Oy. The names
and logos marked with a ™ symbol in this user manual
or in the package of this product are trademarks of
Polar Electro Oy. The names and logos marked with a ®
symbol in this user's manual or in the package of this
product are registered trademarks of Polar Electro Oy,
except Windows which is a registered trademark of
Microsoft Corporation.
ENGLISH 9

Disclaimer
Polar Electro Inc./Polar Electro Oy disclaims any and all
liabilities related to or arising from third parties'
products or services, which use the data generated by a
Polar product. Polar Electro Inc./Polar Electro Oy
disclaims any and all liabilities related to or arising
from the functioning / malfunctioning of third party
product or service, its interoperability with a Polar
product, safety of a third party product or service as
well as any other liabilities related to or arising from a
third party product or service. Polar Electro Inc/Polar
Electro Oy shall not be liable for any data transfer fees
or any other fees which might be due to or related to
the use of this Polar product.
This product is protected by the incorporeal rights of
Polar Electro Oy as defined by the following documents:
FI110915, US7324841, EP1362829, FI23471, US
D492783S, US D492784S, US D492999S,
EU00046107-0001, EU00046107-0002,
EU00046107-0003, FI96380, US5611346,
EP0665947, JP3568954, FI115084, US7418237,
EP1543769. Other patents pending.
www.polar.com
10 ENGLISH

Manufactured by
Polar Electro Oy
Professorintie 5
FIN-90440 KEMPELE
Tel [phone]
Fax [phone]
www.polar.com
