Polar Electro CD080-A User manual

Model:
CD080-A/CD081-A/CD082-A/CD083-A/CD084-A/CD085-A/CD610-A/CD611-A/CD612-A/
CD613-A/CD614-A/CD615-A/CD086-A/CD087-A/CD088-A/CB921-A/GL185-A
600 / 400 / 150 litre series
Refrigerators/Freezers
Instruction manual
CD610-A to CD615-A_CD080-A to CD088-A_CB921-A_GL185-A_A5_v13_20230201.indb 1CD610-A to CD615-A_CD080-A to CD088-A_CB921-A_GL185-A_A5_v13_20230201.indb 1 2023/2/1 15:272023/2/1 15:27

2
EN Telephone Helpline: 1300225960
Safety Instructions
• Position on a flat, stable
surface.
• A service agent/qualified
technician should carry out
installation and any repairs
if required. Do not remove
any components or service
panels on this product.
- In Queensland the
service agent/qualified
technician MUST hold a
Gas Work Authorisation or
License for hydrocarbon
refrigerants if the
appliance gas system is
being opened or charged.
• Consult Local and National
Standards to comply with the
following:
- Health and Safety at Work
Legislation
- Fire Precautions
- Wiring Regulations
- Building Regulations
• DO NOT use jet/pressure
washers to clean the
appliance.
• DO NOT use the appliance
outside.
• DO NOT use this appliance
to store medical supplies.
• DO NOT allow oil or fat to
come into contact with the
plastic components or door
seal. Clean immediately if
contact occurs.
• DO NOT store products on
top of the appliance.
• Bottles that contain a high
percentage of alcohol
must be sealed and placed
vertically in the refrigerator.
• Always carry, store and
handle the appliance in a
vertical position and move
by holding the base of the
appliance.
• Always switch off and
disconnect the power supply
to the unit before cleaning.
• Keep all packaging away
from children. Dispose of
the packaging in accordance
with the regulations of local
authorities.
• If the power cord is damaged,
it must be replaced by a POLAR
agent or a recommended
qualified technician in order to
avoid a hazard.
• Children should be
supervised to ensure that
they do not play with the
appliance.
CD610-A to CD615-A_CD080-A to CD088-A_CB921-A_GL185-A_A5_v13_20230201.indb 2CD610-A to CD615-A_CD080-A to CD088-A_CB921-A_GL185-A_A5_v13_20230201.indb 2 2023/2/1 15:272023/2/1 15:27

3
AUEN
Telephone Helpline: 1300225960
• This appliance is not intended for use by persons (including
children) with reduced physical, sensory or mental capabilities,
or lack of experience or knowledge, unless they have been
given supervision or instruction concerning the use of the
appliance by a person responsible for their safety.
• POLAR recommend that this appliance should be periodically
tested (at least annually) by a Competent Person. Testing should
include, but not be limited to: Visual Inspection, Polarity Test,
Earth Continuity, Insulation Continuity and Functional Testing.
Caution Risk of Fire
• Do not store explosive substances such as aerosol
cans with a flammable propellant in this appliance.
Warning: Keep all ventilation openings clear of
obstruction. Unit should not be boxed in without
adequate ventilation.
• To comply with AS/NZS 60079.10.1:2009: Ensure
there are not sources of ignition in any area where
refrigerant could gather in the event of a leak.
• Electrical equipment should not be placed under the vent
or where refrigerant could gather in the event of a leak.
• Warning: Do not use mechanical devices or other means
to accelerate the defrosting process, other than those
recommended by the manufacturer.
• Warning: Do not damage the refrigerant circuit.
• Warning: Do not use electrical appliances inside the food
storage compartments of the appliance.
Product Description
• CD080-A - 150 litre Refrigerator
• CD081-A - 140 litre Freezer
• CD082-A - 400 litre Refrigerator
• CD083-A - 365 litre Freezer
• CD084-A - 600 litre Refrigerator
• CD085-A - 600 litre Freezer
• CD086-A - 150 litre Glass-Door Refrigerator
• CD087-A - 400 litre Glass-Door Refrigerator
• CD088-A - 600 litre Glass-Door Refrigerator
• CD613-A - 365 litre Freezer
• CD614-A - 600 litre Refrigerator
• CD615-A - 600 litre Freezer
• CD610-A - 150 litre Refrigerator
• CD611-A - 140 litre Freezer
• CD612-A - 400 litre Refrigerator
• GL185-A - 522 litre Bakery Refrigerator
• CB921-A - 365 litre Glass-Door Freezer
CD610-A to CD615-A_CD080-A to CD088-A_CB921-A_GL185-A_A5_v13_20230201.indb 3CD610-A to CD615-A_CD080-A to CD088-A_CB921-A_GL185-A_A5_v13_20230201.indb 3 2023/2/1 15:272023/2/1 15:27

4
EN Telephone Helpline: 1300225960
Introduction
Please take a few moments to carefully read through this manual. Correct maintenance and operation of
this machine will provide the best possible performance from your POLAR product.
Pack Contents
The following is included:
• POLAR Refrigerator / Freezer
• Shelves - Refrigerator only
CD610-A/ CD080-A x 3/ CD086-A x 3
CD612-A/ CD082-A x 4 / CD087-A x 4
CD614-A x 4 / CD084-A / CD088-A x 4
• Tray Guides - Bakery refrigerator only
GL185-A x 12
• Keys x 2
• Spacers x 2
• Instruction Manual
POLAR prides itself on quality and service, ensuring that at the time of unpacking the contents are
supplied fully functional and free of damage.
Should you find any damage as a result of transit, please contact your POLAR dealer immediately.
Installation
Note: A bracket is used to support the door during transportation. On receipt please remove the bracket.
Note: Not for use in vans or trailers, food trucks or similar vehicles.
If the unit has not been stored or moved in an upright position, let it stand upright for
approximately 12 hours before operation. If in doubt allow to stand.
1. Remove the appliance from the packaging. Make sure that all protective plastic film and coatings are
thoroughly removed from all surfaces.
2. To optimize performance and longevity, ensure a minimum clearance of 2.5cm is maintained between
the unit and walls and other objects, with a minimum 20cm clearance on the top. NEVER LOCATE
NEXT TO A HEAT SOURCE.
Note: Before using the appliance for the first time, clean the shelves and interior
with soapy water then dry well.
The appliance is supplied with feet by default. However, castors can be supplied
as an option from serial number range: 8128595-AU onwards.
Reversing the door (Excluding model
CB921-A)
Depending on the location of the appliance, it may
be necessary to change the direction the door
opens by changing the side of the door handle.
(Tip: Images in this section are for illustration only
and may slightly differ from the actual appliance
appearances.)
To reverse the door handle:
1. The door handle is on the left side. Disassemble
the right lower hinge.
Door handle
CD610-A to CD615-A_CD080-A to CD088-A_CB921-A_GL185-A_A5_v13_20230201.indb 4CD610-A to CD615-A_CD080-A to CD088-A_CB921-A_GL185-A_A5_v13_20230201.indb 4 2023/2/1 15:272023/2/1 15:27

5
AUEN
Telephone Helpline: 1300225960
2. Remove the door from the right upper hinge.
Then remove the hinge sleeve from the door
top.
3. Remove the right upper hinge and install it
on the left side. Afterwards, install the hinge
sleeve onto the hinge.
4. Reverse the door and hang it onto the left
upper hinge.
Door handle
5. Remove the pre-mounted screws on the left
lower side.
CD610-A to CD615-A_CD080-A to CD088-A_CB921-A_GL185-A_A5_v13_20230201.indb 5CD610-A to CD615-A_CD080-A to CD088-A_CB921-A_GL185-A_A5_v13_20230201.indb 5 2023/2/1 15:272023/2/1 15:27

6
EN Telephone Helpline: 1300225960
6. Install the previously removed right lower
hinge on the left side.
7. Secure the hinge in place using the previously
removed screws.
8. Now the door handle is installed on the right
side.
Operation
Control Panel
The control panel is located on the front of the
appliance.
Turn On
1. Close the door of the appliance.
2. Connect the appliance to a mains power
supply.
Set the Operating Temperature
1. Press the SET button for 3 seconds. The
display will flash.
2. Press the or buttons to display the
required temperature.
3. Press the SET button to store the temperature.
Manual Defrost
Press and hold the defrost button “aux” for
2 seconds to begin a manual defrost. The defrost
light illuminates.
Storing Food
To get the best results from your POLAR appliance,
follow these instructions:
• Only store foodstuffs in the appliance when it
has reached the correct operating temperature.
• Do not place uncovered items as below inside
the appliance, as this can lead to a damaged
and leaking evaporator, and thus void your
warranty: hot food, hot liquids, acidic fluids,
acidic products.
• Wrap or cover food where possible.
• Do not obstruct the fans inside the appliance.
• Avoid opening the doors for prolonged periods
of time.
Lock/Unlock the Doors
• A lock is fitted to the doors to ensure foodstuffs
are kept secure within your POLAR appliance.
• Use the keys provided to lock/unlock the door.
CD610-A to CD615-A_CD080-A to CD088-A_CB921-A_GL185-A_A5_v13_20230201.indb 6CD610-A to CD615-A_CD080-A to CD088-A_CB921-A_GL185-A_A5_v13_20230201.indb 6 2023/2/1 15:272023/2/1 15:27

7
AUEN
Telephone Helpline: 1300225960
Cleaning, Care & Maintenance
• Switch off and disconnect from the power supply before cleaning.
• Clean the interior of the appliance as often as possible.
• Do not use abrasive cleaning agents. These can leave harmful residues.
• Clean the door seal with warm soapy water.
• Always wipe dry after cleaning.
• Do not allow water used in cleaning to run through the drain hole into the evaporation pan.
• Take care when cleaning the rear of the appliance. Sharp edges can cut.
Condensation and ice will form with frequent and prolonged opening of the doors.
Operating outside of the recommend temperature range and placing next to a heat source
will also increase the amount of ice and internal/external condensation. If external
condensation occurs wipe the surface down with a cloth.
Excessive ice will result in longer running times that will increase energy consumption and
increase the deterioration of components.
Cleaning the Condenser
Periodically cleaning the condenser can extend the life of the appliance.
POLAR recommend that a POLAR agent or qualified technician should clean the condenser.
Troubleshooting
A qualified technician must carry out repairs if required.
Fault Probable Cause Solution
The appliance is
not working
The unit is not switched on Check the unit is plugged in correctly and
switched on
Plug or lead is damaged Replace Plug or lead
Mains power supply fault Check mains power supply
The appliance
turns on, but the
temperature is too
high/low
Too much ice on the evaporator Defrost the appliance
Condenser blocked with dust Clean the condenser
Doors are not shut properly Check doors are shut and seals are not damaged
Appliance is located near a
heat source or air flow to the
condenser is being interrupted
Move the refrigerator to a more suitable location
Ambient temperature is too high Increase ventilation or move appliance to a cooler
position
Unsuitable foodstuffs are being
stored in the appliance
Remove any excessive hot foodstuffs or blockages
to the fan
Appliance is overloaded Reduce the amount of food stored in the
appliance
The appliance is
leaking water
The appliance is not properly
levelled
Adjust the screw feet to level the appliance (if
applicable)
The discharge outlet is blocked Clear the discharge outlet
CD610-A to CD615-A_CD080-A to CD088-A_CB921-A_GL185-A_A5_v13_20230201.indb 7CD610-A to CD615-A_CD080-A to CD088-A_CB921-A_GL185-A_A5_v13_20230201.indb 7 2023/2/1 15:272023/2/1 15:27

8
EN Telephone Helpline: 1300225960
Fault Probable Cause Solution
The appliance is
leaking water
Movement of water to the drain is
obstructed
Clear the floor of the appliance (if
applicable)
The water container is damaged Call POLAR agent or qualified Technician
The appliance is
unusually loud
Loose nut/screw Check and tighten all nuts and screws
The appliance has not been
installed in a level or stable
position
Check installation position and change if
necessary
The lamp does not
illuminate
Lamp needing replacing Call POLAR agent or qualified Technician
Technical Specifications
Note: Due to our continuing program of research and development, the specifications herein may be
subject to change without notice.
Model Voltage Power Current Temperature
Range
Gross
Capacity
(L)
Net usable
capacity
(L)
Refrigerant Dimensions
H x W x D mm
Weight
(kg)
CD610-A
CD080-A
220-
240V~
50Hz
100W 0.7A -2°C ~ +8°C 150 64 R600a 855 x 600 x
595
44
CD611-A
CD081-A
105W 0.8A -10°C ~ -25°C 140 78 R600a 855 x 600 x
595
44.5
CD612-A
CD082-A
130W 0.8A -2°C ~ +8°C 400 238 R600a 1855 x 600 x
595
69
CD613-A
CD083-A
150W 0.9A -10°C ~ -25°C 365 258 R600a 1855 x 600 x
595
71
CD614-A
CD084-A
130W 0.9A -2°C ~ +8°C 600 419 R600a 1895 x 777 x
705
90
CD615-A
CD085-A
300W 1.4A -10°C ~ -25°C 600 469 R600a 1890 x 777 x
705
94
GL185-A 130W 0.9A -2°C ~ +8°C 522 410 R600a 1720 x 777 x
725
90
CD086-A 105W 0.7A 2°C ~ 8°C 150 118 R600a 855 x 600 x
619
47
CD087-A 130W 0.8A 2°C ~ 8°C 400 246 R600a 1855 x 600 x
620
72
CD088-A 130W 0.9A 2°C ~ 8°C 600 414 R600a 1890 x 777 x
730
93
CB921-A 380W 2.5A -10°C ~ -25°C 365 340 R290 1855 x 600 x
620
76
Note: For optimal product performance and efficiency, please ensure to mind the net usable capacity (load
limit) when filling.
CD610-A to CD615-A_CD080-A to CD088-A_CB921-A_GL185-A_A5_v13_20230201.indb 8CD610-A to CD615-A_CD080-A to CD088-A_CB921-A_GL185-A_A5_v13_20230201.indb 8 2023/2/1 15:272023/2/1 15:27

9
AUEN
Telephone Helpline: 1300225960
Electrical Wiring
The plug is to be connected to a suitable mains socket.
POLAR appliances are wired as follows:
• Live wire (coloured brown) to terminal marked L
• Neutral wire (coloured blue) to terminal marked N
• Earth wire (coloured green/yellow) to terminal marked E
This appliance must be earthed.
If in doubt consult a qualified electrician.
Electrical isolation points must be kept clear of any obstructions. In the event of any emergency
disconnection being required they must be readily accessible.
Compliance
The WEEE logo on this product or its documentation indicates that the product must not be disposed of
as household waste. To help prevent possible harm to human health and/or the environment, the product
must be disposed of in an approved and environmentally safe recycling process. For further information
on how to dispose of this product correctly, contact the product supplier, or the local authority responsible
for waste disposal in your area.
POLAR parts have undergone strict product testing in order to comply with regulatory
standards and specifications set by international, independent, and federal authorities.
POLAR products have been approved to carry the following symbol:
All rights reserved. No part of these instructions may be produced or transmitted in any form or by any means, electronic,
mechanical, photocopying, recording or otherwise, without the prior written permission of POLAR.
Every effort is made to ensure all details are correct at the time of going to press, however, POLAR reserve the right to
change specifications without notice.
CD610-A to CD615-A_CD080-A to CD088-A_CB921-A_GL185-A_A5_v13_20230201.indb 9CD610-A to CD615-A_CD080-A to CD088-A_CB921-A_GL185-A_A5_v13_20230201.indb 9 2023/2/1 15:272023/2/1 15:27

DECLARATION OF CONFORMITY
• Conformiteitsverklaring • Déclaration de conformité • Konformitätserklärung • Dichiarazione di conformità •
• Declaración de conformidad
Equipment Type • Uitrustingstype • Type d'équipement • Gerätetyp
• Tipo di apparecchiatura • Tipo de equipo
Model • Modèle • Modell • Modello
• Modelo
C-Series Fridge
1. Stainless Steel Under
Counter 150Ltr
2. Stainless Steel Upright
400Ltr
3. Stainless Steel Upright
600Ltr
4. White Under Counter
150Ltr
5. White Upright 400Ltr
6. White Upright 600Ltr
C-Series Freezer
7.Stainless Steel Under
Counter 140Ltr
8.Stainless Steel Upright 365Ltr
9.Stainless Steel Upright 600Ltr
10.White Under Counter
140Ltr
11.White Upright 365Ltr
12.White Upright 600Ltr
C-Series Display
13.White Under Counter Fridge
150Ltr
14.White Upright Fridge 400Ltr
15.White Upright Fridge 600Ltr
16.White Upright Freezer
365Ltr
1.
CD080
2.CD082
3.CD084
4.CD610
5.CD612
6.CD614
7.
CD081
8.CD083
9.CD085
10.CD611
11.CD613
12.CD615
(including -E
& -A models)
13.
CD086
14.CD087
15.CD088
16.CB921
Application of Territory Legislation &
Council Directives(s)
Toepassing van Europese Richtlijn(en) •
Application de la/des directive(s) du
Conseil • Anwendbare EU-Richtlinie(n) •
Applicazione delle Direttive
• Aplicación de la(s) directiva(s) del
consejo
*CB921 (&-E) –EN60335-1:2012 +A11:2014 +A13:2017
only
Machinery Directive 2006/42/EC
Supply of Machinery (Safety) Regulations 2008
EN 60335-1:2012 +A11:2014 +A13:2017 +A1:2019
+A14:2019 +A2:2019*
EN 60335-2-89:2010 +A1:2016 +A2:2017
EN 62233:2008
Electro-Magnetic Compatibility (EMC) Directive
2014/30/EU - recast of 2004/108/EC
Electromagnetic Compatibility Regulations 2016
(S.I. 2016/1091)
EN 55014-1: 2017
EN 55014-2:2015
EN 61000-3-2: 2014
EN 61000-3-3: 2013
Regulation (EU) 2015/1095 - Ecodesign professional
refrigerators
EN 16825: 2016 +A1:2019
Regulation (EU) 2019/2024 - Ecodesign direct sales
refrigerators
ISO 23953-2:2015
Restriction of Hazardous Substances Directive
(RoHS) 2015/863 amending Annex II to Directive
2011/65/EU
Restriction of the Use of Certain Hazardous
Substances in Electrical and Electronic
Equipment Regulations 2012 (S.I. 2012/3032)
Electrical Safety
IEC 60335-1:2010 +A1:2013 +A2:2016
IEC 60335-2-89:2010 +A1:2012 +A2:2015
Electromagnetic Compatibility
EN 55014-1: 2017
EN 55014-2:2015
EN 61000-3-2: 2014
EN 61000-3-3: 2013
Producer Name • Naam fabrikant • Nom du producteur • Name des Herstellers
• Nome del produttore • Nombre del fabricante
Polar
I, the undersigned, hereby declare that the equipment specified above conforms to the above Territory Legislation, Directive(s) and Standard(s).
Ik, de ondergetekende, verklaar hierbij dat de hierboven gespecificeerde uitrusting goedgekeurd is volgens de bovenstaande Richtlijn(en) en Standaard(en).
Je soussigné, confirme la conformité de l'équipement cité dans la présente à la / aux Directive(s) et Norme(s) ci-dessus
Ich, der/die Unterzeichnende, erkläre hiermit, dass das oben angegebene Gerät der/den oben angeführten Richtlinie(n) und Norm(en) entspricht.
Il sottoscritto dichiara che l'apparecchiatura di sopra specificata è conforme alle Direttive e agli Standard sopra riportati.
El abajo firmante declara por la presente que el equipo arriba especificado está en conformidad con la(s) directiva(s) y estándar(es) arriba mencionadas.
Date • Data • Date • Datum • Data •
Fecha • Data
21
st
April 2022
Signature • Handtekening • Signature •
Unterschrift Firma • Firma
Full Name • Volledige naam • Nom et
prénom • Vollständiger Name • Nome
completo • Nombre completo
Ashley Hooper
Eoghan Donnellan
Brendan Denmeade
Position • Functie • Fonction • Position •
Qualifica • Posición
Technical & Quality
Manager
Commercial Manager/
Importer
Commercial Manager/ Responsible Supplier
Producer Address • Adres fabrikant •
Adresse du producteur • Anschrift des
Herstellers • Indirizzo del produttore •
Dirección del fabricante
Fourth Way,
Avonmouth,
Bristol,
BS11 8TB
United Kingdom
Unit 9003,
Blarney Bus. Park,
Blarney,
Co. Cork
Ireland
15 Bagdally Road,
Campbelltown
NSW 2560
DocuSign Envelope ID: 16D88D10-7CC2-41A3-BAFE-78DCE2D74A26
CD610-A to CD615-A_CD080-A to CD088-A_CB921-A_GL185-A_A5_v13_20230201.indb 10CD610-A to CD615-A_CD080-A to CD088-A_CB921-A_GL185-A_A5_v13_20230201.indb 10 2023/2/1 15:272023/2/1 15:27

CD610-A to CD615-A_CD080-A to CD088-A_CB921-A_GL185-A_A5_v13_20230201.indb 11CD610-A to CD615-A_CD080-A to CD088-A_CB921-A_GL185-A_A5_v13_20230201.indb 11 2023/2/1 15:272023/2/1 15:27

CD610-A to CD615-A_CD080-A to CD088-A_CB921-A_GL185-A_A5_v13_2023/02/01
http://www.polar-refrigerator.com/
CD610-A to CD615-A_CD080-A to CD088-A_CB921-A_GL185-A_A5_v13_20230201.indb 12CD610-A to CD615-A_CD080-A to CD088-A_CB921-A_GL185-A_A5_v13_20230201.indb 12 2023/2/1 15:272023/2/1 15:27
