Polar Electro FA854 User manual

Model • Modèle • Modell • Modello • Modelo • Malli:
FA854/FA855/FA856/FA857/DA680
NL RVS opzetvitrine /
bereidingsvitrine met
keeling
Handleiding
8IT Banchi refrigeratori per
preparazione /servizio con
piano di lavoro in acciaio
inossidabile
Manuale di istruzioni
26
FR Plan de travail de comptoir
de distribution / de
préparation inox réfrigéré
Mode d'emploi
14 ES
Frigoríficos para preparados
/ aperitivos de mostrador
de acero inoxidable
Manual de instrucciones
32
DE Edelstahl-Tischkühlgeräte
zum Servieren
Bedienungsanleitung
20 PT Bancadas refrigeradas
pizza/saladette em aço
inoxidável
Manual de instruções
38
Stainless Steel Counter
Top Servery/Prep
Refrigerators
Instruction manual
FA854_FA855_ FA856_FA857_DA680 _ML_A5_v1_20190708.indb 1 2019/7/8 11:58

2
UK
Safety Tips
• Position on a flat, stable surface.
• A service agent/qualified technician should carry out
installation and any repairs if required. Do not remove any
components or service panels on this product.
• Consult Local and National Standards to comply with the
following:
- Health and Safety at Work Legislation
- BS EN Codes of Practice
- Fire Precautions
- IEE Wiring Regulations
- Building Regulations
• DO NOT use jet/pressure washers to clean the appliance.
• DO NOT use the appliance outside.
• DO NOT use this appliance to store medical supplies.
• DO NOT use electrical appliances inside the appliance
(e.g. heaters, ice cream makers, etc.)
• Always carry, store and handle the appliance in a vertical
position and move by holding the base of the appliance.
• Always switch off and disconnect the power supply to the unit
before cleaning.
• Keep all packaging away from children. Dispose of the
packaging in accordance with the regulations of local
authorities.
• If the power cord is damaged, it must be replaced by a POLAR
agent or a recommended qualified technician in order to avoid
a hazard.
• This appliance is not intended for use by persons (including
children) with reduced physical, sensory or mental capabilities,
or lack of experience or knowledge, unless they have been
given supervision or instruction concerning the use of the
appliance by a person responsible for their safety.
FA854_FA855_ FA856_FA857_DA680 _ML_A5_v1_20190708.indb 2 2019/7/8 11:58

3
UK
• Polar recommends that this appliance should be periodically
tested (at least annually) by a Competent Person. Testing
should include, but not be limited to: Visual Inspection,
Polarity Test, Earth Continuity, Insulation Continuity and
Functional Testing.
Caution Risk of Fire
• Do not store explosive substances such as aerosol cans
with a flammable propellant in this appliance.
Warning: Keep all ventilation openings clear of
obstruction. Unit should not be boxed in without
adequate ventilation.
• Warning: Do not use mechanical devices or other means
to accelerate the defrosting process, other than those
recommended by the manufacturer.
• Warning: Do not damage the refrigerant circuit.
• Warning: Do not use electrical appliances inside the food
storage compartments of the appliance, unless they are the
type recommended by the manufacturer.
Introduction
Please take a few moments to carefully read through this manual. Correct maintenance and operation of
this machine will provide the best possible performance from your POLAR product.
Pack Contents
The following is included:
• POLAR Refrigerator
• Instruction manual
• Gastranorm spacer bar
• Adjustable feet x 4
POLAR prides itself on quality and service, ensuring that at the time of packaging the contents are
supplied fully functional and free of damage.
Should you find any damage as a result of transit, please contact your POLAR dealer immediately.
FA854_FA855_ FA856_FA857_DA680 _ML_A5_v1_20190708.indb 3 2019/7/8 11:58

4
UK
Installation
Note: If the unit has not been
stored or moved in an upright
position, let it stand upright for
approximately 12 hours before
operation. If in doubt allow to
stand.
1. Remove the appliance from the packaging.
Make sure that all protective plastic film and
coatings are thoroughly removed from all
surfaces.
2. Maintain a distance of 20cm (7 inches)
between the unit and walls or other objects for
ventilation. NEVER LOCATE NEXT TO OR
NEAR A HEAT SOURCE.
Note: Before using the appliance
for the first time, clean the
shelves and interior with soapy
water.
• Level the appliance by adjusting the screw
feet.
Operation
Storing Food
To get the best results from your POLAR appliance,
follow these instructions:
• Only store foodstuffs in the appliance when it
has reached the correct operating temperature.
• Ensure gastronorm bays are full at all times,
even if the gastronorms are unused or empty.
Empty bays will greatly reduce efficiency of the
appliance.
• Use the spacer bars provided to fill any gaps
(they are not required to support each GN
pans).
• Do not obstruct the fans inside the appliance.
Turn On
1. Ensure the power switch is set to [O] and turn
on at the socket.
2. Switch on the power switch [I]. The current
temperature within the appliance is displayed.
Set the Operating Temperature
1. Press the SET button. The display will flash.
2. Press the or buttons to display the
required temperature.
3. Press the SET button to store the temperature.
Manual Defrost
Press and hold the defrost button “aux” for 2
seconds to begin a manual defrost. The defrost
light illuminates.
FA854_FA855_ FA856_FA857_DA680 _ML_A5_v1_20190708.indb 4 2019/7/8 11:58

5
UK
Cleaning, Care & Maintenance
• Switch off and disconnect from the power supply before cleaning.
• Clean the interior of the appliance as often as possible.
• Do not use abrasive cleaning agents. These can leave harmful residues.
• Clean the door seal with warm soapy water.
• Always wipe dry after cleaning.
• Do not allow water used in cleaning to run through the drain hole into the evaporation pan.
• Take care when cleaning the rear of the appliance. Sharp edges can cut.
• A POLAR agent or qualified technician must carry out repairs if required.
Cleaning the Condenser Filter
• The condenser is part of the refrigeration system. The
condenser filter requires monthly cleaning.
• Always disconnect power supply before carrying out Routine
Maintenance.
• Failure to clean the condenser filter will reduce the
performance and life of your Polar unit and may invalidate
your warranty.
• These models have a removable filter which can be cleaned
with a vacuum cleaner.
Troubleshooting
If your POLAR appliance develops a fault, please check the following table before making a call to the
Helpline or your POLAR dealer.
Fault Probable Cause Solution
The appliance is not
working
The unit is not switched on Check the unit is plugged in correctly and
switched on
Plug and lead are damaged Call POLAR agent or qualified Technician
Fuse in the plug has blown Replace the fuse
Power supply Check power supply
Internal wiring fault Call POLAR agent or qualified Technician
FA854_FA855_ FA856_FA857_DA680 _ML_A5_v1_20190708.indb 5 2019/7/8 11:58

6
UK
Fault Probable Cause Solution
The appliance
turns on, but the
temperature is too
high/low
Too much ice on the evaporator Defrost the appliance
Condenser blocked with dust Clean the Condenser
Doors are not shut properly Check doors are shut and seals are not
damaged
Appliance is located near a heat
source or air flow to the condenser
is being interrupted
Move the appliance to a more suitable
location
Ambient temperature is too high Increase ventilation or move appliance to a
cooler position
Unsuitable foodstuffs are being
stored in the appliance
Remove any excessive hot foodstuffs or
blockages to the fan
Appliance is overloaded Reduce the amount of food stored in the
appliance
The appliance is
leaking water
The appliance is not properly
levelled
Adjust the screw feet to level the appliance
(if applicable)
The discharge outlet is blocked Clear the discharge outlet
Movement of water to the drain is
obstructed
Clear the floor of the appliance (if
applicable)
The water container is damaged Call POLAR agent or qualified Technician
The drip tray is overflowing Empty the drip tray (if applicable)
The appliance is
unusually loud
Loose nut/screw Check and tighten all nuts and screws
The appliance has not been installed
in a level or stable position
Check installation position and change if
necessary
Technical Specifications
Model Voltage Power Current Temperature
Range Capacity Refrigerant Dimensions H x W x D mm Weight (kg)
FA854 230V 50Hz 110W 0.8A 2°C - 8°C 5 x gastronorm 1/4
Container
R600a 45g 274 x 1200 x 335 25
FA855 230V 50Hz 110W 0.8A 2°C - 8°C 7 x gastronorm 1/4
Container
R600a 45g 274 x 1500 x 335 29
FA856 230V 50Hz 122W 0.8A 2°C - 8°C 8 x gastronorm 1/4
Container
R600a 45g 274 x 1800 x 335 32
FA857 230V 50Hz 122W 0.8A 2°C - 8°C 10 x gastronorm 1/4
Container
R600a 45g 274 x 2000 x 335 34
DA680 230V 50Hz 110W 0.8A 2°C - 8°C 6 x gastronorm 1/4
Container
R600a 45g 274 x 1400 x 335 27
FA854_FA855_ FA856_FA857_DA680 _ML_A5_v1_20190708.indb 6 2019/7/8 11:58

7
UK
Electrical Wiring
POLAR appliances are supplied with a 3 pin, moulded, BS1363 plug and lead, with a 13 amp fuse as
standard.
The plug is to be connected to a suitable mains socket.
POLAR appliances are wired as follows:
• Live wire (coloured brown) to terminal marked L
• Neutral wire (coloured blue) to terminal marked N
• Earth wire (coloured green/yellow) to terminal marked E
This appliance must be earthed.
If in doubt consult a qualified electrician.
Electrical isolation points must be kept clear of any obstructions. In the event of any emergency
disconnection being required they must be readily accessible.
Disposal
EU regulations require refrigeration product to be disposed of by specialist companies who remove or
recycle all gasses, metal and plastic components.
Consult your local waste collection authority regarding disposal of your appliance. Local authorities are
not obliged to dispose of commercial refrigeration equipment but may be able to offer advice on how to
dispose of the equipment locally.
Alternatively call the POLAR helpline for details of national disposal companies within the EU.
Compliance
The WEEE logo on this product or its documentation indicates that the product must
not be disposed of as household waste. To help prevent possible harm to human
health and/or the environment, the product must be disposed of in an approved and
environmentally safe recycling process. For further information on how to dispose of
this product correctly, contact the product supplier, or the local authority responsible for
waste disposal in your area.
POLAR parts have undergone strict product testing in order to comply with regulatory
standards and specifications set by international, independent, and federal authorities.
POLAR products have been approved to carry the following symbol:
All rights reserved. No part of these instructions may be produced or transmitted in any form or by any means, electronic,
mechanical, photocopying, recording or otherwise, without the prior written permission of POLAR.
Every effort is made to ensure all details are correct at the time of going to press, however, POLAR reserve the right to
change specifications without notice.
FA854_FA855_ FA856_FA857_DA680 _ML_A5_v1_20190708.indb 7 2019/7/8 11:58

8
NL
Veiligheidstips
• Plaatsen op een vlakke en stabiele ondergrond.
• De installatie en eventuele reparaties zijn door een
servicetechnicus/vaktechnicus uit te voeren. Verwijder geen
componenten of servicepanelen van dit product.
• Raadpleeg en volg de plaatselijke en nationale regelgeving op
m.b.t. tot het volgende:
- Wetgeving van gezondheid en veiligheid op de werkplaats
- Werkregels
- Brandpreventie
- IEE bekabelingsnormen
- Bouwverordeningen
• Dit product NIET reinigen met spuit-/drukreinigers.
• Uitsluitend geschikt voor gebruik binnenshuis.
• Dit product NIET gebruiken voor de berging van medische
producten.
• In dit product GEEN elektrische apparaten gebruiken (zoals
bijv. verwarmers, ijsmakers, etc.).
• Dit product altijd in een verticale positie vervoeren, opbergen
en gebruiken. Het product aan de kastbasis vervoeren.
• Alvorens dit product te reinigen dient men altijd de
stroomvoorziening uit te schakelen.
• Laat verpakkingsmateriaal niet binnen handbereik van
kinderen. Verpakkingsmateriaal in overeenstemming met
de regelgeving van de plaatselijke overheden als afval laten
verwerken.
• Indien de stroomkabel beschadigd raakt, dient men deze door
een POLAR technicus of een aanbevolen vaktechnicus te laten
vervangen om gevaarlijke situaties te verhinderen.
FA854_FA855_ FA856_FA857_DA680 _ML_A5_v1_20190708.indb 8 2019/7/8 11:58

9
NL
• Dit apparaat is niet bedoeld voor gebruik door personen met
lichamelijke, zintuigijike of mentale beperkingen (inclusief
kinderen) of met gebrek aan ervaring of kennis tenzij zij
hierin worden begeleid of zijn opgeleid in het gebruik van het
apparaat door een persoon, die verantwoodelijk is voor hun
veiligheid.
Voorzichtig Risico van Fire
• Laat explosieve stoffen niet opslaan: zoals spuitbussen
met een ontvlambare drijfgas in dit apparaat.
Waarschuwing: Hou alle ventilatieopeningen vrij
van obstakels. De eenheid mag niet ingesloten
worden zonder geschikte ventilatie.
• Waarschuwing: Gebruik geen mechanische apparaten of
andere middelen te gebruiken om het ontdooien , andere dan
de door de fabrikant aanbevolen versnellen.
• Waarschuwing: niet damge het koelcircuit.
• Waarschuwing: Gebruik geen elektrische apparaten binnen
het voedsel opslag comnpartments van het apparaat, tenzij ze
het type aanbevolen door de fabrikant.
Inleiding
Neem de tijd en lees deze handleiding aandachtig door. Een correct gebruik en onderhoud van deze
machine waarborgt de beste prestatie van uw POLAR product.
Verpakkingsinhoud
De verpakking bevat het volgende:
• POLAR Koelkast of vrieskast
• Handleiding
• Gastronorm aanpasbare stang
• Verstelbare poten x 4
POLAR is trots op de haar productkwaliteit en dienstverlening en controleer de inhoud van de
verpakkingen, tijdens de verpakkingsfase, op functionaliteit en schade.
Mocht u product door transport zijn beschadigd, neem dan onmiddellijk contact op met uw POLAR dealer.
FA854_FA855_ FA856_FA857_DA680 _ML_A5_v1_20190708.indb 9 2019/7/8 11:58

10
NL
Installatie
Opmerking: indien het apparaat
niet in een rechtopstaande
positie is opgeslagen of
vervoerd, dient men het
product 12 uur vóór gebruik
in de rechtopstaande positie
te plaatsen. Bij twijfel dient
men het product in een
rechtopstaande positie te
plaatsen.
1. Haal het product uit de verpakking. Zorg ervoor
dat u de beschermingsfolie en -lagen van alle
oppervlakken heeft verwijderd.
2. Voor een adequate ventilatie dient men een
afstand van 20cm aan te houden tussen dit
product of muren en andere objecten. NOOIT
PLAATSEN NAAST OF DICHTBIJ EEN
HITTEBRON.
Opmerking: Voor het eerste
gebruik van dit product dient u
de lades en de binnenzijde met
zeepwater te reinigen.
• Nivelleer het product door de verstelbare poten
aan te passen.
Bediening
Opslag van levensmiddelen
Volg de volgende aanwijzingen voor de beste
resultaten met uw POLAR product:
• Bewaar uitsluitend levensmiddelen in het
product wanneer het product de juiste
gebruikstemperatuur heeft gereikt.
• Zorg dat alle gastronorm bakken altijd vol zijn,
zelfs wanneer de gastronorms niet gebruikt of
leeg zijn. Lege bakken zullen de efficiëntie van
het product aanzienlijk verminderen.
• Gebruik de afstandhouders geleverd om
eventuele lacunes op te vullen (ze zijn niet
verplicht om elke GN pan ondersteunen)
• Niet de interne ventilatoren in het product
blokkeren.
Inschakelen
1. Controleer of stroomschakelaar in de positie [O]
staat en de steker in het stopcontact zit.
2. Zet de Power (Stroom) [I] aan. De actuele
interne temperatuur van het product wordt
weergegeven.
Werktemperatuur instellen
1. Druk op de SET knop. Het display knippert.
2. Druk op de of knoppen om de
vereiste temperatuur weer te geven.
3. Druk op de SET knop om de
temperatuurwaarde op te slaan.
Handmatig ontdooien
De knop aux indrukken en gedurende 2 seconden
ingedrukt houden om ontdooiing te starten. Het
ontdooiingslampje gaat aan.
FA854_FA855_ FA856_FA857_DA680 _ML_A5_v1_20190708.indb 10 2019/7/8 11:58
