Polar Electro DB109-A User manual

Model:
DB109-A
Milk Fridge
Instruction manual
DB109-A_A5_v2_20230601.indb 1DB109-A_A5_v2_20230601.indb 1 2023/6/1 13:322023/6/1 13:32

2
EN Telephone Helpline: 1300225960
Safety Instructions
• Position on a flat, stable surface.
• A service agent/qualified technician should carry out
installation and any repairs if required. Do not remove any
components or service panels on this product.
- In Queensland the service agent/qualified technician
MUST hold a Gas Work Authorisation or License for
hydrocarbon refrigerants if the appliance gas system is
being opened or charged.
• Consult Local and National Standards to comply with the
following:
- Health and Safety at Work Legislation
- Fire Precautions
- Wiring Regulations
- Building Regulations
• DO NOT use jet/pressure washers to clean the appliance.
• DO NOT use the appliance outside.
• DO NOT use this appliance to store medical supplies.
• DO NOT allow oil or fat to come into contact with the plastic
components or door seal. Clean immediately if contact occurs.
• DO NOT store products on top of the appliance.
• POLAR milk fridges are designed for milk/drink chilling
and storage and are not recommended for the storing of
foodstuffs.
• Bottles that contain a high percentage of alcohol must be
sealed and placed vertically in the refrigerator.
• Always carry, store and handle the appliance in a vertical
position and move by holding the base of the appliance.
• Always switch off and disconnect the power supply to the unit
before cleaning.
• Keep all packaging away from children. Dispose of the
packaging in accordance with the regulations of local
authorities.
DB109-A_A5_v2_20230601.indb 2DB109-A_A5_v2_20230601.indb 2 2023/6/1 13:322023/6/1 13:32

3
AUEN
Telephone Helpline: 1300225960
• If the power cord is damaged, it must be replaced by a POLAR
agent or a recommended qualified technician in order to avoid
a hazard.
• This appliance can be used by children aged from 8 years and
above and persons with reduced physical, sensory or mental
capabilities or lack of experience and knowledge if they have
been given supervision or instruction concerning use of the
appliance in a safe way and understand the hazards involved.
• Children shall not play with the appliance.
• Cleaning and user maintenance shall not be made by children
without supervision.
• Polar recommend that this appliance should be periodically
tested (at least annually) by a Competent Person. Testing
should include, but not be limited to: Visual Inspection,
Polarity Test, Earth Continuity (Class I equipment), Insulation
Continuity and Functional Test.
Warning: Risk of Fire / flammable materials
• Do not store explosive substances such as aerosol cans with a
flammable propellant in this appliance.
Warning: Keep all ventilation openings clear of
obstruction. Unit should not be boxed in without
adequate ventilation.
• To comply with AS/NZS 60079.10.1:2009: Ensure
there are not sources of ignition in any area where
refrigerant could gather in the event of a leak.
• Electrical equipment should not be placed under the vent
or where refrigerant could gather in the event of a leak.
• Warning: Do not use mechanical devices or other means
to accelerate the defrosting process, other than those
recommended by the manufacturer.
• Warning: Do not damage the refrigerant circuit.
• Warning: Do not use electrical appliances inside the food
storage compartments of the appliance.
DB109-A_A5_v2_20230601.indb 3DB109-A_A5_v2_20230601.indb 3 2023/6/1 13:322023/6/1 13:32

4
EN Telephone Helpline: 1300225960
Introduction
Please take a few moments to carefully read through this manual. Correct maintenance and operation of
this machine will provide the best possible performance from your POLAR product.
Pack Contents
The following is included:
• POLAR Milk fridge • Keys
• Shelf • Instruction Manual
POLAR prides itself on quality and service, ensuring that at the time of unpacking the contents are
supplied fully functional and free of damage.
Should you find any damage as a result of transit, please contact your POLAR dealer immediately.
Installation
Note: Not for use in vans or trailers, food trucks or similar vehicles.
If the unit has not been stored or moved in an upright position, let it stand upright for
approximately 12 hours before operation. If in doubt allow to stand.
1. Remove the appliance from the packaging. Make sure that all protective plastic film and coatings are
thoroughly removed from all surfaces.
2. To optimize performance and longevity, ensure a minimum clearance of 2.5cm is maintained between
the unit and walls and other objects, with a minimum 20cm clearance on the top. NEVER LOCATE
NEXT TO A HEAT SOURCE.
Note: Before using the appliance for the first time, clean the shelve and interior with soapy
water then dry well.
Controller
• The controller is located at the rear of the appliance, covered with a removable cap. It has been pre-
set optimally by the manufacturer.
• As needed, the controller can be adjusted clockwise to make the appliance “Colder“ and counter-
clockwise to make the appliance “Warmer“.
• Nevertheless, we DO NOT recommend customers to make any adjustment because too cold setting
may lead to freezing. Best cooling performance can be achieved so long as the unit is optimally filled
and the internal air circulation is not obstructed.
• Internal light: Press the light switch on the rear to turn the light on/off as required.
Note: If necessary, you can insert
the pipe from a coffee machine into
the milk bottle inside the fridge
cabinet via the milk hole on the side.
Before insertion, please make sure
to remove the hole plug.
DB109-A_A5_v2_20230601.indb 4DB109-A_A5_v2_20230601.indb 4 2023/6/1 13:322023/6/1 13:32

5
AUEN
Telephone Helpline: 1300225960
Cleaning, Care & Maintenance
• Switch off and disconnect from the power supply before cleaning.
• Clean the interior of the appliance as often as possible.
• Do not use abrasive cleaning agents. These can leave harmful residues.
• Clean the door seal with warm soapy water.
• Always wipe dry after cleaning.
• If left unused for any length of time, store the appliance with the door ajar.
Refrigerating tips:
• Condensation and ice will form with frequent and prolonged opening of the doors.
• Operating outside of the recommend temperature range and placing next to a heat source will also
increase the amount of ice and internal/external condensation. If external condensation occurs wipe
the surface down with a cloth.
• Excessive ice will result in longer running times that will increase energy consumption and increase
the deterioration of components.
• If the gasket or seal is damaged or deformed, energy consumption will increase. To restore efficiency,
replace gasket.
Troubleshooting
A qualified technician must carry out repairs if required.
Fault Probable Cause Solution
The appliance is not
working
The unit is not switched on Check the unit is plugged in correctly and
switched on
Plug or lead is damaged Replace Plug or lead
Mains power supply fault Check mains power supply
Fridge cabinet is not
cold enough
Temperature set incorrectly Check temperature and reset if necessary
Condenser blocked with dust Consult a qualified Technician
Door is opened too often Only open when necessary
Appliance is located near a heat
source or air flow to the condenser
is being interrupted
Move the appliance to a more suitable
location
Ambient temperature is too high Increase ventilation or move appliance to a
cooler position
Appliance is overloaded Reduce the amount stored in the appliance
The appliance is
unusually loud
The appliance is not installed in a
level or stable position
Check installation position and change if
necessary
DB109-A_A5_v2_20230601.indb 5DB109-A_A5_v2_20230601.indb 5 2023/6/1 13:322023/6/1 13:32

6
EN Telephone Helpline: 1300225960
Technical Specifications
Note: Due to our continuing program of research and development, the specifications herein may be
subject to change without notice.
Model Voltage Power Current Temperature
Range
Net
Capacity Refrigerant Dimensions H x W x D mm
Weight
(kg)
DB109-A 220-240V~
50Hz
85W 0.45A 0°C - 4°C 16L R600a 13g 452 x 312 x 379 18.3
Electrical Wiring
The plug is to be connected to a suitable mains socket.
POLAR appliances are wired as follows:
• Live wire (coloured brown) to terminal marked L
• Neutral wire (coloured blue) to terminal marked N
• Earth wire (coloured green/yellow) to terminal marked E
This appliance must be earthed.
If in doubt consult a qualified electrician.
Electrical isolation points must be kept clear of any obstructions. In the event of any emergency
disconnection being required they must be readily accessible.
Compliance
The product must not be disposed of as household waste. To help prevent possible harm to human
health and/or the environment, the product must be disposed of in an approved and environmentally safe
recycling process. For further information on how to dispose of this product correctly, contact the product
supplier, or the local authority responsible for waste disposal in your area.
POLAR parts have undergone strict product testing in order to comply with regulatory
standards and specifications set by international, independent, and federal authorities.
POLAR products have been approved to carry the following symbol:
All rights reserved. No part of these instructions may be produced or transmitted in any form or by any means, electronic,
mechanical, photocopying, recording or otherwise, without the prior written permission of POLAR.
Every effort is made to ensure all details are correct at the time of going to press, however, POLAR reserve the right to
change specifications without notice.
DB109-A_A5_v2_20230601.indb 6DB109-A_A5_v2_20230601.indb 6 2023/6/1 13:322023/6/1 13:32

DECLARATION OF CONFORMITY
• Conformiteitsverklaring • Déclaration de conformité • Konformitätserklärung • Dichiarazione di conformità •
• Declaración de conformidad
Equipment Type • Uitrustingstype • Type d'équipement • Gerätetyp
• Tipo di apparecchiatura • Tipo de equipo
Model • Modèle • Modell • Modello
• Modelo
G-Series Milk Fridge
DB109 (E &-A)
Application of Territory Legislation
& Council Directives(s)
Toepassing van Europese
Richtlijn(en) • Application de la/des
directive(s) du Conseil •
Anwendbare EU-Richtlinie(n) •
Applicazione delle Direttive
• Aplicación de la(s) directiva(s) del
consejo
Machinery Directive 2006/42/EC
Supply of Machinery (Safety) Regulations 2008
(BS) EN 60335-1:2012 +A11:2014 +A13:2017 +A1:2019
+A14:2019 +A2:2019 +A15:2021
(BS) EN IEC 60335-2-89:2022 +A11:2022
(BS) EN 62233:2008
Electro-Magnetic Compatibility (EMC) Directive
2014/30/EU - recast of 2004/108/EC
Electromagnetic Compatibility Regulations 2016 (S.I.
2016/1091)
(BS) EN 55014-1:2017
(BS) EN 55014-2:2015
(BS) EN 61000-3-2: 2014
(BS) EN 61000-3-3: 2013
Eco-design energy-related products Directive
2009/125/EC; Regulation (EU)
2019/2024 - Ecodesign direct sales refrigerators
ISO 23953-1:2015
ISO 23953-2:2015
Restriction of Hazardous Substances Directive (RoHS)
2015/863 amending Annex II to Directive 2011/65/EU
Restriction of the Use of Certain Hazardous
Substances in Electrical and Electronic
Equipment Regulations 2012 (S.I. 2012/3032)
Electrical Safety
AS/NZS 60335.1:2020 +A1:2021
AS/NZS 60335.2.89:2020
Electromagnetic Compatibility
AS CISPR 14.1:2018
Producer Name • Naam fabrikant • Nom du producteur • Name des Herstellers
• Nome del produttore • Nombre del fabricante
Polar
I, the undersigned, hereby declare that the equipment specified above conforms to the above Territory Legislation, Directive(s) and
Standard(s).
Ik, de ondergetekende, verklaar hierbij dat de hierboven gespecificeerde uitrusting goedgekeurd is volgens de bovenstaande Richtlijn(en) en
Standaard(en).
Je soussigné, confirme la conformité de l'équipement cité dans la présente à la / aux Directive(s) et Norme(s) ci-dessus
Ich, der/die Unterzeichnende, erkläre hiermit, dass das oben angegebene Gerät der/den oben angeführten Richtlinie(n) und Norm(en) entspricht.
Il sottoscritto dichiara che l'apparecchiatura di sopra specificata è conforme alle Direttive e agli Standard sopra riportati.
El abajo firmante declara por la presente que el equipo arriba especificado está en conformidad con la(s) directiva(s) y estándar(es) arriba
mencionadas.
Date • Data • Date • Datum •
Data • Fecha
24th March 2023
Signature • Handtekening •
Signature • Unterschrift Firma •
Firma
Full Name • Volledige naam •
Nom et prénom • Vollständiger
Name • Nome completo •
Nombre completo
Ashley Hooper
Eoghan Donnellan
Brendan Denmeade
Position • Functie • Fonction •
Position • Qualifica • Posición
Technical & Quality
Manager
Commercial Manager/
Importer
Commercial Manager/ Responsible
Supplier
Producer Address • Adres
fabrikant • Adresse du
producteur • Anschrift des
Herstellers • Indirizzo del
produttore • Dirección del
fabricante
Fourth Way,
Avonmouth,
Bristol,
BS11 8TB
United Kingdom
Unit 9003,
Blarney Business Park,
Blarney,
Co. Cork
Ireland
15 Bagdally Road,
Campbelltown
NSW 2560
DocuSign Envelope ID: BD7CE57D-4521-4610-9736-D0D1E76E902C
DB109-A_A5_v2_20230601.indb 7DB109-A_A5_v2_20230601.indb 7 2023/6/1 13:322023/6/1 13:32

DB109-A_A5_v2_2023/06/01
http://www.polar-refrigerator.com/
DB109-A_A5_v2_20230601.indb 8DB109-A_A5_v2_20230601.indb 8 2023/6/1 13:322023/6/1 13:32
