Polarion Abyss U Series User manual

The power of the SUN... Underwater !
Pseries Xseries Cseries Useries Lseries ETC
Professional Dive Light Polarion Abyss
Abyss

POLARION Portable Searchlight
02 The power of the SUN... Underwater !
POLARION
Professional Dive Light Polarion Abyss
The Polarion Abyss™is an underwater HID searchlight capable
of operating at depths of up to 100 m (330 ft).
It is the perfect solution for both recreational and professional
diving applications.
High strength aluminum & precision manufacturing ensures
rugged, water-tight performance. 2 types of high grade
reflectors are available according to your specific needs, and
many optional accessories help you customize your light even
more. There’s also an all-new rail-type handle which gives you
expansion options like never before.
Non-contact magnetic switching ensures reliable operation
under extreme conditions, and the interchangeable battery
cartridges are double o-ring sealed for extra protection.

03
Pseries Xseries Cseries Useries Lseries ETC
Front Bezel
Battery Pack
AC Charger
Power Plug
Optional Filter
Tailcap
Rotary Switch

POLARION Portable Searchlight
04 The power of the SUN... Underwater !
Basic
Kit
Optional
Equipment
▶
AC Charger
▶
Battery Pack
▶
Soft case
▶
Shoulder Strap
▶
User Manual
▶
Main body
▶
Extra Lamp
▶
Extra Battery Pack
▶
Hard case
▶
DC Charger
▶
Filters
▶
Optional Mounting
Brackets
▶
Power Plug

05
Pseries Xseries Cseries Useries Lseries ETC
󳢯Certain specifications may change without prior notice
Item
Model
Battery
AC Charger
Main Body
Description
Abyss D / Abyss S
Specifications
Lamp Type Metal Halide HID
Lamp Power 35W
Max. Luminous Flux 3400lm
Lamp Life Up to 2500 hrs
Color Temperature
4300K or 5500K (Specify when ordering)
Illumination Distance Up to 1.2km (Abyss S)
Input Voltage DC 12V ~ 18V
Operational Current 3.5 A
Weight (with battery) 1.9kg
Dimensions (mm) 92 x 255 x 132
Water Resistance IP68(100m)
Battery Type
Li-ion Rechargeable, Cartridge Type
Battery Capacity DC 14.4V, 4400mAh
Run Time Up to 90 min
Weight (with battery) 0.5 kg
Input Voltage AC 100 ~ 240 V / 50 ~ 60 Hz
Output Voltage DC 19V
Charge Time 3 hrs ±30 min

Your Polarion searchlight is a precision made
instrument for specialized applications, so please
be aware of these cautionary statements.
06 The power of the SUN... Underwater !
POLARION Portable Searchlight
Caution
󳢯 The light becomes very hot during operation, so please be
careful when handling the light. Be sure not to touch the
hot surfaces.
󳢯 When not in use for extended periods, please store in a cool
place with at least 50% of the charge left in the battery.
󳢯 Do not aim the light at someone’s eye at close range.
󳢯 Be sure to keep the front lens clean. If it becomes dirty, use
rubbing alcohol to thoroughly clean it.
󳢯 Be sure the light is off when exchanging the battery pack.
󳢯 The front lens is made of specially tempered glass, but
should it ever break, please be careful and replace it as soon
as possible.
󳢯 Be sure to check if all caps are properly sealed and
completely tight before using the light in harsh conditions
(underwater, storms, etc). Failure to do so can not only
affect the performance of the light, but may cause the light
to fail completely under certain circumstances. Damaged
o-rings and gaskets can also lead to light failure so use
caution and maintain all seals.
󳢯 Make sure the watertight seals are properly tightened and
maintained (see page 8 for more information).
󳢯 Do not try to disassemble the light. This will void your factory
warranty.
󳢯 If water ever gets into the light, do not use it. Contact your
supplier immediately.

07
Pseries Xseries Cseries Useries Lseries ETC
■ Turning the light On/Off
󳢯 Be sure to fully charge the battery before initial use.
󳢯 Turn the rotary switch in either direction to operate the light.
󳢯 The battery charge level is displayed through the tail cap
for 5 seconds after the light is turned on.
■ Charging the Battery
Open the tail cap and remove the battery. Plug the
connector of the charging unit into the socket of the battery.
󳢯 There are a total of 6 LEDs on the battery that monitor the
battery and charging status.
󳢯 The right most LED indicates the charging status. RED
indicates that the light is charging. GREEN indicates that
the light is fully charged.
󳢯 Each of the 5 other LEDs indicate the charge level. Each
LED represents approximately 20% of the charge. So 1
LED = 20%, 2 LEDs = 40%, 3 LEDs = 60% and so on.
󳢯 The battery should fully charge in about 3 hours. If it is not
fully charged even after 5 hours, please contact your supplier.
󳢯 Be sure to completely remove the battery before charging.
󳢯 Be sure to charge the battery in a dry area. If there is any
moisture on the charger or battery, make sure it is
completely dry before charging.
󳢯 After the battery has been charged,replace the battery
inside the main body and be sure to completely tighten
the tail cap to ensure a weathertight seal.
■ When using the AC Charger
󳢯 The charger is a universal charger with an input range of 100V
~ 240V, 50 ~ 60Hz. Although it should cover most countries,
please check to see if your power source is within this range.
󳢯 Charging should be done indoors and out of the elements.
󳢯 The charger is not waterproof.
󳢯 The charger can get warm during charging, so make sure
there are no flammable materials around it.
󳢯 Charging should be done in a well ventilated area.
Operation
Charge Status LED
Red - Charging
Green - Fully Charged
Level Indicator LEDs

08 The power of the SUN... Underwater !
POLARION Portable Searchlight
The Polarion Abyss™uses Gaskets and O-rings in
critical areas for optimal performance
underwater. All units are tested before they
leave the factory, but please follow these guide
lines for proper maintenance.
❶Do not disassemble the light. This can affect water
resistance significantly. It can also void your warranty.
❷When replacing the battery pack, follow the instructions
carefully and make sure the tailcap is screwed on correctly
and fully tightened before use.
❸Check the tailcap thoroughly after each charge.
❹If there is any water leak due to improper seals, stop usage
immediately. Not only can this ruin the light, but it can be
extremely dangerous. Please use caution.
❺To ensure proper performance, please keep the o-rings
well lubricated at all times. We also recommend that you
replace both o-rings every 6 months.
❻Dirt and debris can accumulate inside the switch
mechanism after continued use. Please remove the switch
and clean according to the instructions. Lubricate the
switch and reassemble.
❼Be sure to have the light tested every year to ensure peak
performance. Please contact your local dealer for details.
❽Be sure to clean the light thoroughly after each use. Be
especially thorough after marine applications. Use soap and
water to clean out any remaining salt.
Water Resistance

Your Polarion searchlight comes with a high
performance Li-ion rechargeable battery pack.
Under ideal conditions, it will have a life cycle of
approximately 500 charges. When the battery
performance is significantly reduced, you should
get a new battery.
Your Polarion searchlight is supplied with one
battery, but you can use an extra battery
(optional) for additional runtime.
❶Turn off the searchlight.
❷Remove the tail cap.
❸Remove the battery pack and replace it with the new (or
extra) battery pack. Be sure you insert the battery in the
direction of the arrow.
❹Replace the tail cap. Be sure to align the screws correctly,
and tighten it all the way. There is a weather seal at the
end, so keep turning until you can’t turn it any more. This
will ensure a tight seal.
❺When storing the battery, please keep it so that no foreign
material can get into the charging port.
< Important >
Storing a completely drained battery for extended periods will degrade the life of
the battery. If you wish to store the battery for extended periods, make sure that
the battery level is above 50% and store in a cool dry place.
Changing the Battery Pack
The life of the lamp is rated at 2000+ hours, which
will give you years of worry free operation.
However, if the need arises that you need a new
lamp, please contact your supplier.
Changing the lamp is a very delicate process and
can be very dangerous if not done correctly.
It is not a user serviceable item.
Changing the Lamp
❶
❷
❸
❹
❺
OFF
09
Pseries Xseries Cseries Useries Lseries ETC

■Attaching the Filter
󳢯Align the filter’s“bump”with the grooves in front of the
searchlight.
󳢯Push into the front lens and turn clockwise, keep turning
until you hear a“snap”. This will lock the filter in place
󳢯To remove the filter, simply turn it counter clockwise until
you again hear the“snap”. This will unlock the filter.
Keep turning counter clockwise and pull out.
‘snap’
♬
10 The power of the SUN... Underwater !
POLARION Portable Searchlight
There are various filters available for your specific
needs. Please contact your supplier for more
information.
■Optional Filters
󳢯Amber Filter (Fog) - The yellow spectrum helps you see
through thick fog and smoke.
󳢯Diffusion Filter - Useful when you need a very even, broad
light source.
󳢯Color Filters - Several colors are available for signaling or
lighting.
󳢯Titanium Filter - For extra protection of the front lens.
󳢯IR Filter - Infrared filter for various infrared applications.
󳢯U V필터 - 검시용 또는 UV파장대만 투과됩니다.
Optional Filters

■The light doesn’t turn on.
Check to see if the battery is inserted correctly. Check whether the tail cap is
aligned correctly and screwed in all the way. Check to see if the battery is
drained. If it is, recharge the battery and operate as normal.
■There is a “whine” when I turn on the light.
The“whining”sound is the ballast starting up. This is normal. The sound should
go away after a few seconds.
■The battery will not charge.
Check to see if all the plugs and connectors are tightly plugged in.
■The run time is shorter than advertised.
Check to see if the battery is fully charged. Remember, even if all 5“level
indicator LEDs”are lit, you must wait for the“charge status LED”(the right most
LED) to turn green. Your Polarion searchlight uses state-of-the-art Li-ion batteries,
but after repeated use, the batteries will slowly decrease in run time.
■While using the light on land, it turns off after 20~30 mins.
Because the Polarion Abyss™is designed for underwater use, prolonged use on
land can cause overheating. When this occurs, it simply triggers the thermal
protection circuit and will shut down. It will return to normal operation once the
light has cooled down.
■There is moisture condensation inside the light
If there is a sudden change in temperature, there can be temporary moisture that
shows up on the inside of the light, much like moisture forming on the outside of
a cold glass of water. This is normal and should go away during normal
operation. If there is more condensation than normal, open the tail cap and let
the searchlight dry for a couple of hours.
※If any of the problems listed above still persists after troubleshooting, please stop using the
light and contact your supplier. DO NOT try to service the light yourself. It will void the
warranty.
Product Warranty
Main Unit - 1 year
Battery - 6 months
The warranty does not cover normal wear and tear;
intentional misuse or tampering by the user; or acts of God.
Your supplier can provide you with information about
servicing lights that are out of warranty for a nominal fee.
Troubleshooting
11
Pseries Xseries Cseries Useries Lseries ETC

POLARION Professional Dive Light Polarion Abyss
