Polaroid FXM-3211C User manual

32” HD-LCD TV/DVD Combo with High Definition ATSC Tuner
FXM-3211C
20060516

1
Table Of Contents
Important Safety Instruction----------------------------------------------------------------------2
Product Features ------------------------------------------------------------------4
Disc Information -------------------------------------------------------------------5
Front Panel---------------------------------------------------------------------------6
Rear Panel----------------------------------------------------------------------------8
Remote Control---------------------------------------------------------------------------------9
Special Features of the DVD Disc Tray------------------------------------12
System Connections-----------------------------------------------------------------------13
Connecting to External AV Signal Source (AV1) ----------------------------------13
Connecting to External AV Signal Source (AV2) ----------------------------------14
Connecting to External AV Signal Source (Video3 /Video4) ---------------------------------15
Connecting to HDMI Output Device-------------------------------------------------------------16
Connecting to External AV Device (AV OUT) --------------------------------------------------17
Connecting to Digital Amplifier ---------------------------------------------------------------------------18
Connecting to PC ---------------------------------------------------------------------------------19
Connecting to TV Signal Input------------------------------------------------------------------20
Connecting to Power Supply--------------------------------------------------------------------20
Connecting to Earphone------------------------------------------------------------------------21
Input Source Selecting----------------------------------------------------------22
System Setup-----------------------------------------------------------------------------------24
Preparations---------------------------------------------------------------------------------------24
Setup Setting--------------------------------------------------------------------------------------24
Video Setting--------------------------------------------------------------------------------------25
Audio Setting-----------------------------------------------------------------------------------27
Feature Setting------------------------------------------------------------------------------------28
DVD Player Operation-----------------------------------------------------------30
USB and SD/MS/MMC Card Function---------------------------------------34
DVD System Setup----------------------------------------------------------------35
Troubleshooting------------------------------------------------------------------------------41
Specifications----------------------------------------------------------------------------------42

- 2 -
ImportantSafetyInstructions
CAUTION: USE OF ANY CONTROLS, ADJUSTMENTS, OR PROCEDURES OTHER THAN
THOSE SPECIFIED HEREIN MAY RESULT IN HAZARDOUS RADIATION EXPOSURE.
POWER SUPPLY:
Make sure the supplied power cord is connected to the TV/DVD Combo in the input marked "Power
In". Plug the two-prong end of the power cord to an AC110-220V outlet. If you have difficulty inserting
the plug, turn it over and reinsert it, if the unit will not the used for a long time, disconnect the plug
from the outlet.
NOTE:
Before plugging the power cord into an AC outlet, make sure that all the connections have been
made.
CAUTION: These servicing instructions are for use by qualified service personnel only. To reduce
the risk of electric shock, do not perform any servicing other than that contained in the operating
instructions unless you are qualified to do so.
Refer to service manual for servicing instructions.
The lightning flash with arrowhead symbol, within an equilateral triangle, is
intended to alert the user to the presence of un-insulated “dangerous voltage”
within the product’s enclosure that may be of sufficient magnitude to constitute a
risk of electric to persons.
The exclamation point within an equilateral triangle is intended to alert the user to
the presence of important operating and maintenance (servicing) instructions in
the literature accompanying the appliance.
CAUTION: Laser radiation when open. Do not stare into
beam.

- 3 -
ImportantSafetyInstructions
Note:
1. Read these instructions.
2. Keep these instructions.
3. Heed all warnings.
4. Follow all instructions.
5. Do not use near water.
6. Clean only with dry cloth.
7. Do not block any ventilation openings. Maintain well ventilated conditions around the product.
Do not put product on bed, sofa or anything that blocks ventilation. Install in accordance with
the manufacturer’s instructions.
8. Do not install near any heat sources such as radiators, heat registers, stoves, or other apparatus
(including amplifiers) that produce heat.
9. Do not defeat the safety purpose of the polarized or grounding-type plug. A polarized plug has
two blades with one wider than the other. If the provided plug does not fit into your outlet, consult
an electrician for replacement of the obsolete outlet.
10. Protect the power cord from being walked on or pinched particularly at plugs, convenience
receptacles, and the point where they exit from the apparatus.
11. Only use attachments/accessories specified by the manufacturer.
12. Use only with the cart, stand, tripod, bracket, or table specified by the
manufacturer, or sold with the apparatus. When a cart is used, use
caution when moving the cart/apparatus combination to avoid injury
from tip-over.
13. Unplug this apparatus during lightning storms or when unused for long periods of time.
14. Refer all servicing to qualified service personnel. Servicing is required when the apparatus has
been damaged in any way, such as power-supply cord or plug is damaged, liquid has been
spilled or objects have fallen into the apparatus, the apparatus has been exposed to rain or
moisture, does not operate normally, or has been dropped.
15. Apparatus shall not be exposed to dripping or splashing and no objects filled with liquids, such
as vases, shall be placed on the apparatus.
Note: Never touch the color TFT LCD screen with your hand.
Copyright Protection
This product incorporates copyright protection technology that is protected by U.S. patents and
other intellectual property rights. Use of this copyright protection technology must be authorized by
Macrovision, and is intended for home and other limited viewing uses only unless otherwise
authorized by Macrovision. Reverse engineering or disassembly is prohibited.
IMPORTANT FOR LASER PRODUCTS
1. CLASS 1 LASER PRODUCT
2. DANGER: Visible laser radiation when open and interlock
failed or defeated. Avoid direct exposure to beam.
3. CAUTION: Do not open the top cover. There are no user
serviceable parts inside the unit. Leave all servicing to
q
ualified service
p
ersonnel.

- 4 -
ProductFeatures
This product is designed with a moveable DVD Disc Tray. The Disc Tray can be installed in
three different positions. The moveable Disc Tray offers you the flexibility to choose which
direction to insert your DVD in order to maximize your space. The unit incorporates
high-resolution LCD display, DVD player and TV receiver in one system.
Multiple Video Input Modes
TV mode
AV1 (Composite 1)
AV2 (Composite 2)
AV3 (Component 1)
AV4 (Component 2)
VGA
HDMI
DVD
High Quality Features
Movable DVD Disc Tray
The unit is designed with a movable DVD Disc
Tray. The tray can be installed in three different
positions; on top, on bottom, or on the side of
the LCD. The movable DVD Disc Tray offers
you the flexibility to choose which direction to
insert your DVD in order to maximize your
space.
TV Signal Input
Supports ATSC and NTSC signals so you can
receive more TV programs.
TV Function
Auto program scan and manual program
searching, provide you more convenience.
Channel Edit Function
Supports channel edit function, you can edit the
channel for your preference.
Special Function
Supports V-CHIP, CCD and sleep timer setting
functions.
USB and CARD PORTS
Designed with USB and SD/MS/MMC card port,
can be connected to USB device or
SD/MS/MMC Card.
HighResolution
Adopt an MPEG2 decoding format to achieve
horizontal resolution more than 500 lines.
Superior sound
Supports SRS and SAP function, reproduce
high quality sound.
LCD (Liquid Crystal Display)
Designed with 31.5" LCD display
Stereo amplifier
Built-in 2x10w speakers provide high quality
sound.
AV And VGA Input
Can be connected to external audio and video
signal source and PC.
Color Separation Function
Built-in 3D Y/C chroma chip to separates luma
and chroma effectively.
Multi-audio and Multi-video modes
Supports Multi-audio and multi-video modes,
provide more selections.
Advanced Playing Features
Compatibility
DVD, CD, CD-R, CD-RW and JPEG discs
compatible.
All Playback Functions
Fast forward and reverse, slow playback and
repeat playback.
Special playback.
Support multi-angle, multi-language and
multi-subtitle playback.
