POLINS GARDEN HOBBY 5 User manual

POLINS d.o.o.
Ive Lole Ribara bb
25250 Odzaci, Serbia
www.polins.co.rs
Phone: [phone]
Phone: [phone]
E-mail: [email protected]
ORIGINAL INSTRUCTIONS
For the use of sprayer type
GARDEN HOBBY, SPRINGER HOBBY AND DOLOMITE HOBBY
Dear customers, we thank you for the trust you have placed in us by purchasing our sprayers. Every
sprayer manufactured by us is carefully designed, tested and subject to strict quality control.
However, the service life of the sprayer will largely depend on the use and maintenance of the sprayer.
Also, your safety and the safety of your environment depend on the way you use and handle the
sprayer.
Therefore, please carefully study and get acquainted in detail with the contents of this manual, and
make sure to FULLY COMPLY WITH THE RECOMMENDATIONS AND WARNINGS listed in the instructions.
This manual applies to the hand-operated pressure sprayers manufactured by POLINS DOO for the
sprayer model:
GARDEN HOBBY 5 art: 4028
GARDEN HOBBY 8 art: 4022
GARDEN HOBBY 10 art: 4029
SPRINGER HOBBY 5 art: 4210
SPRINGER HOBBY 8 art: 4212
SPRINGER HOBBY 10 art: 4211

DOLOMITE HOBBY 5 art: 4238
DOLOMITE HOBBY 8 art: 4239
DOLOMITE HOBBY 10 art: 4240
Please keep this manual for future reference
Please pay special attention to the parts of the instruction marked with this sign:
Contents of the manual:
1. Intended use 1
2. Contents of the package 1
3. Sprayer description and technical data 1
4. Assembling the sprayer 2
5. Using the sprayer 2
6. Safety instructions 2
7. Protective measures when working with the sprayer 2
8. Environmental protection measures 3
9. Maintenance 3
10. List of original spare parts
11. 4Additional equipment 4
12. Malfunctions and how to eliminate them 4
13. Control list 4
14. Contact 4
15. Declaration of conformity 4

1. INTENDED USE
Sprayers type GARDEN HOBBY and SPRINGER HOBBY can ONLY be used for water-soluble agents
intended for plant care: herbicides, insecticides, fungicides and plants nutrition products.
Be advised that the sprayer is not intended for use by children, persons with reduced psychophysical,
sensory and intellectual abilities.
When handling the sprayer, be sure to follow the INSTRUCTIONS, PROTECTION MEASURES AND
ENVIRONMENTAL PROTECTION MEASURES.
The sprayer user is solely responsible for the consequences of improper use of the sprayer.
2. CONTENTS OF THE PACKAGE
1. Sprayer container, with pump and carrying strap
2. Sprayer hose with mounted handle
3. Instruction manual
4. Sprayer extension
3. SPRAYER DESCRIPTION AND TECHNICAL INFORMATION
Sprayers type GARDEN and SPRINGER are hand-operated pressure sprayers which function in such a way
that air pressure above the liquid inside the container suppresses the liquid into the hose, from where it
exits through the handle and the extension under pressure and is aimed at the treated surface.
The technical data for the sprayer is listed in the table below:
Technical characteristics of the sprayer: Sprayer models
useful container volume
working pressure
sprayer capacity
nozzle diameter
working temperature 5 to 35
nozzle material brass
Page 1.
4. ASSEMBLING THE SPRAYER
Sprayers are delivered in boxes and are partially disassembled, as described in Chapter 2 of this manual.
Before first use, you need to:

1. Unpack the box and remove the parts from the box.
2. Place the extension on the handle of the sprayer, located at the end of the hose and screw it
tight.
5. USING THE SPRAYER
Liquid
Solid surface solid surface
1. Turn the pump out of the sprayer and remove it.
2. Once you’ve placed the sprayer on a firm and stable surface, pour liquid with dissolved agent you’re
applying into the sprayer
3. The liquid prepared for pouring into the sprayer must not contain solid residues of the applied agent
or of another origin, so as not to clog the channels of the sprayer.
4. Do not use adhesives that are sticky or that harden in the sprayer so as not to interfere with the
function of the sprayer.
5. Close the sprayer container by screwing the body of the sprayer into the container opening.
6. Use the pump to achieve working pressure by pumping. After achieving working pressure, push the
handrail of the pump all the way, to the inside and twist it, to lock the pump.
7. You may carry the sprayer in your hand by the handrail or over your shoulder using the carrying strap.
8. Control and aim the applied agent using the handle with the extension. The length of the extension
can be adjusted by loosening the nut and extending –inserting the extension tube; the width of the jet
can be adjusted by turning the nut at the top of the nozzle.
9. When the jet weakens and ceases to be in the form of a mist made of small drops, place the sprayer
on a solid surface and re-pump it.
10. Once you have finished working with the sprayer, release the pressure out of the sprayer by pulling
the safety valve piston until all air is released (the air hissing stops).
11. Once you have finished working with the sprayer, place the sprayer upright on a solid surface,
release the pressure and unscrew the pump. Lift the handle with the extension and open the valve on
the handle. Wait a few seconds for the liquid to pour from the channels back into the container. You
may now empty the sprayer.
Page 2
12. Fill the sprayer with 2-3 liters of clean water, close it, shake it, establish working pressure in it, and
spray for 60 seconds to wash out the sprayer channels. Repeat the procedure described under 10 and
11. Wash the outside of the sprayer.

6. SAFETY INSTRUCTIONS
1. Do not use the sprayer for purposes other than plant care.
2. Do not pour liquid into the container over the last quantity mark
3. Use only water-soluble plant care products.
4. Do not use: acids, alkalis, oils, paints, adhesives, liquids, fuels, thinners and the like.
5. Do not use the sprayer if the temperature of the liquid or the environment is lower than 5 OC (close
to freezing point) or higher than 35OC (warmer than hands).
6. When establishing working pressure (pumping), check whether you have reached the pressure that
gives the jet appearance of fog by briefly opening the switch. When you achieve such a jet shape, stop
pumping.
7. In the event of the safety valve opening, stop pumping and pull the body of the safety valve to release
some pressure from the sprayer.
8. Do not establish pressure in the sprayer in any other way besides pumping using the built - in pump
by hand (such as : pumps that are not the original part of the sprayer, compressors, water supply
networks, pressure washers, pressure washers from another pressure vessel and the like).
9. Do not transport or store a pre-filled sprayer or sprayer under pressure.
10. Do not repair the sprayer with parts that are not on the original list spare parts or using parts from
other manufacturers.
11. Do not make any modifications to the sprayer.
12. Do not store the sprayer in areas where the freezing of the liquid in the spray channels or in the
spray tank can occur.
13. In the event that liquid remains in the sprayer and freezes, this sprayer should no longer be used.
14. Never open a sprayer under pressure, follow the instructions under point 10 in the chapter USING
THE SPRAYER.
7. PROTECTIVE MEASURES WHEN WORKING WITH THE SPRAYER
Agents used for plant care are usually harmful to health; therefore, it is necessary to adhere to the
following measures when using the sprayer:
1. Be sure to read and follow the manufacturer's recommendations listed on the packaging or in the
instructions for the product that you are using.

2. To avoid the possibility of injury, handle the sprayer carefully; carry it only by holding on to the built-
in handrail and the carrying strap taking care not to drop it.
3. Make sure to wear protective equipment (protective goggles, gloves, protective suit and protective
footwear).
4. Do not apply agents if it is very cold, very hot or if a strong wind is blowing.
5. Do not consume food and drinks or smoke while using the sprayer.
6. Prior to any action of inspection, adjustment or maintenance of the sprayer, make sure you’ve taken
all measures as listed in the chapter USING THE SPRAYER under points 10 and 11. If you haven’t, carry
them out, and then proceed with the planned action.
7. After any contact with the sprayer, wash your face, face and hands and be sure to change your
clothes.
8. ENVIRONMENTAL PROTECTION MEASURES
1. Make sure to follow the manufacturer's instructions for product concentration, quantity and time of
application, storage and procedure with the remaining product.
2. Prepare only the amount of product you intend to use, place the sprayer upright on a stable surface
and fill carefully. Then close the container tightly.
3. Limit the application of product only to the areas for which it is intended and do not allow product to
disperse to or near watercourses, public areas, places of residence.
4. When applying agents, move away others persons, animals and technical product from the place you
are treating.
5. Dispose of the liquid leftover from use, maintenance, rinsing and washing of the sprayer in
accordance with the manufacturer's instructions.
6. Dispose of the remaining packaging of the product in accordance with the manufacturer's
instructions.
7. Do not store or transport the sprayer filled with prepared agent and which has not been handled in
accordance with the instructions listed in the chapter USING THE SPRAYER.
8. Do not dispose of an expired sprayer and parts remaining after the replacement of worn out parts in
the environment or in municipal waste, but rather hand them over to a professional waste manager.

9. MAINTENANCE
1. If you notice a malfunction while operating the sprayer, stop working with it and rectify the fault. Be
sure to observe all protective measures listed in the SAFETY MEASURES WHEN WORKING WITH THE
SPRAYER and ENVIRONMENTAL PROTECTION MEASURES sections.
2. After you finish operating the sprayer, always follows the instructions listed in the section USING THE
SPRAYER.
3. Do not store the sprayer under pressure, with residual agent or in a place where the agent you are
applying could freeze inside the sprayer.
4. After every 20 fillings of the sprayers, pour 10 drops of machine oil into the sprayer pump in the place
marked in the picture.
5. After every 20 fillings of the sprayer, or in the event of a malfunction, disassemble the handle and
clean the sprayer filter.
6. Once a year or in the event of a malfunction, disassemble the parts of the safety valve, wash them,
lubricate the gasket on the piston on the valve using machine lubricant and then assemble the safety
valve. After assembling the safety valve, check if the piston is mobile by pulling on it.
7. Once a year, check the mechanical completeness of the sprayer, if you determine that some parts are
missing or damaged, stop using the sprayer.
10. LIST OF ORIGINAL SPARE PARTS
For sprayer repairs, original spare parts can be procured and delivered, as follows:
Sprayer pump art: 4008
Handle art: 4001
Adjustable nozzle art: 4002
Gasket set
GARDEN art: 4006
Pressure hose art: 4004

11. ADDITIONAL EQUIPMENT
You can get additional equipment for the sprayer which can enhance the usability of the sprayer. This
equipment includes:
1. Aluminum extension, length: 0.45m, 0.70m, 1.5m and 2,0m.
2. Telescopic extension, length 3,0m.
3. Handle with air gauge
4. Spray guard
Mounting the additional equipment on the sprayer is exactly the same as assembling the sprayer
described in the section ASSEMBLING THE SPRAYER.
12. MALFUNCTIONS AND HOW TO ELIMINATE THEM
MALFUNCTION DESCRIPTION
MALFUNCTION CAUSE
METHOD OF ELIMINATION
When establishing working
pressure, air runs out - you can
hear the sound of hissing air
Pump cylinder is not tight
enough
Tighten the cylinder
Loosened hose nut
Tighten the nuts
Pumping doesn’t achieve
working pressure
Worn out or out of place rubber
gaskets of the pump
Check the gaskets. Adjust them
as needed or replace them.
Before assembly, lubricate the
gaskets with machine oil.
Sprayer is under pressure, but
liquid doesn’t come out
Clogged sieve in the handle
Release the pressure from the
sprayer –point 10 of the chapter
USING THE SPRAYER, then
remove the sieve from the
sprayer handle and clean it.
Clogged nozzle
Remove the nozzle and carefully
clean it.
Page 3

13. CONTROL LIST
Sprayer type: Control:
Year of production:
14. CONTACT
POLINS DOO
Ive Lole Ribara bb
25250 Odzaci
SERBIA
Phone number + 381 25 5 743 885; tel. [phone]
www.polins.co.rs
[email protected]
15. DECLARATION OF CONFORMITY
SRB –DECLARATION OF CONFORMITY
01-002-01
Company:
POLINS DOO
Ive Lole Ribara BB
25250 Odzaci
Serbia
With full responsibility declares that the following machines:
Sprayers GARDEN HOBBY, SPRINGER HOBBY and DOLOMITE HOBBY, plastic, hand-operated pressure
sprayers for the application of water-soluble agents for plant care and protection
Types:
GARDEN HOBBY 5 art: 4028
GARDEN HOBBY 8 art: 4022
GARDEN HOBBY 10 art: 4029
SPRINGER HOBBY 5 art: 4210

SPRINGER HOBBY 8 art: 4212
SPRINGER HOBBY 10 art: 4211
DOLOMITE HOBBY 5 art: 4238
DOLOMITE HOBBY 8 art: 4239
DOLOMITE HOBBY 10 art: 4240
Are in accordance with:
Article 8 and Addendum 8 of the Machine safety regulations (“Sl. Glasnik RS,” 13/2020) which is
aligned with 2006/42/EC
Considering the following standards:
1. SRPS EN 614-1:2010
2. SRPS EN 614-2:2010
3. SRPS EN ISO 12100-1:2012.
In Odzaci, 21/11/2019
For POLINS DOO
Responsible person
Director, Djuro Milosevic
EC –DECLARATION OF CONFORMITY
01-002-01
Company:
POLINS DOO
Ive Lole Ribara BB
25250 Odzaci
Serbia
With full responsibility declares that the following machines:

Sprayers GARDEN HOBBY, SPRINGER HOBBY and DOLOMITE HOBBY, plastic, hand-operated pressure
sprayers for the application of water-soluble agents for plant care and protection
Types:
GARDEN HOBBY 5 art: 4028
GARDEN HOBBY 8 art: 4022
GARDEN HOBBY 10 art: 4029
SPRINGER HOBBY 5 art: 4210
SPRINGER HOBBY 8 art: 4212
SPRINGER HOBBY 10 art: 4211
DOLOMITE HOBBY 5 art: 4238
DOLOMITE HOBBY 8 art: 4239
DOLOMITE HOBBY 10 art: 4240
Are in accordance with:
1. 2006/42/EC
2. 2009/127/EC
Considering the following standards:
1. SRPS EN 614-1:2010
2. SRPS EN 614-2:2010
3. SRPS EN ISO 12100-1:2012.
In Odzaci, 21/11/2019
For POLINS DOO
Responsible person
Director, Djuro Milosevic
Page 4
