OWNER’S MANUAL
OWNER’S MANUAL
MANUEL DU PROPRIÉTAIRE | MANUAL DEL PROPIETARIO
MANUALE DELL’UTENTE | BENUTZERHANDBUCH
BRUKSANVISNING | РУКОВОДСТВО ПО ЭКСПЛУАТАЦИИ
GEBRUIKERSHANDLEIDING | INSTRUKCJA OBSŁUGI
用户手册 | オーナーズマニュアル
R900 Height Module Loudspeakers
R900 Haut-parleurs du module de hauteur
Reserve™

2 3
OWNER’S MANUAL
English
English
WARNING: Listen Carefully
Polk Audio loudspeakers are capable of playing at extremely
high volume levels, which could cause serious or permanent
hearing damage. Polk Audio, Inc. accepts no liability for
hearing loss, bodily injury, or property damage resulting from
the misuse of its products. Keep these guidelines in mind and
always use good judgment when controlling volume:
• Limit prolonged exposure to volume levels that exceed
85 decibels (dB). For more information about safe volume
levels, take a look at the Occupational Health and Safety
Administration (OSHA) guidelines at
http://www.osha.gov/.
Product Disposal
Certain international, national and/or local laws and/or
regulations may apply regarding the disposal of this product.
For more information, please contact the retailer where you
purchased this product or the Polk importer/distributor in your
country. More information is also available at
www.polkaudio.com.
Expect Great Sound—The Polk Reserve Story
Thank you for purchasing the Polk Reserve Series loudspeakers!
Modern styling combined with Polk’s premium Pinnacle tweeter
and Turbine mid-range driver deliver high-resolution detail
and imaging. With our detailed, deep eortless bass, you will
enjoy a whole new listening experience. Pure and minimalist,
the Polk Reserve Series is engineered and designed with your
entertainment in mind.
Having built a reputation as the makers of great sound for more
than 45 years, Polk Audio takes pride in superior sound and build
quality, which feature many patented and award-winning audio
innovations. For Polk, building audio products isn’t just a job—it’s
a passion—to deliver great sound that is accessible for everyone.
Technical Assistance or Service
If your product was damaged during shipping, please contact
the authorized Polk Audio retailer where you purchased your
product. For technical support, FAQs, and repair information,
visit http://polk.custhelp.com. For a complete list of contact
information, visit https://www.polkaudio.com/contact-us.
Support email addresses and phone numbers vary based on
the region where your purchased your product.
Contents
Expect Great Sound — The Reserve Story ........................................2
Safety Instructions ........................................................................................3
What’s in the Box.............................................................................................4
How to Connect Your System....................................................................4
Caring for Your Reserve Loudspeaker..................................................5
R900 Speaker Positioning ..........................................................................5
Specifications ....................................................................................................9
IMPORTANT SAFETY INSTRUCTIONS
1. Read these instructions.
2. Keep these instructions.
3. Heed all warnings.
4. Follow all instructions.
5. Do not use this apparatus near water.
6. Clean only with dry cloth.
7. Do not block any ventilation openings.
Install in accordance with the manufacturer’s instructions.
8. Do not install near any heat sources such as radiators, heat
registers, stoves, or other apparatus (including amplifiers)
that produce heat.
9. Only use attachments/accessories specified by the
manufacturer.
10. Use only with the cart, stand, tripod, bracket, or
table specified by the manufacturer, or sold with
the apparatus. When a cart is used, use caution
when moving the cart/apparatus combination to
avoid injury from tip-over.
11. Refer all servicing to qualified service personnel.
Servicing is required when the apparatus has been
damaged in any way, such as power supply cord or plug is
damaged, liquid has been spilled, or objects have fallen into
the apparatus, the apparatus has been exposed to rain or
moisture, does not operate normally, or has been dropped.
Notes On Use
WARNINGS
• Avoid high temperatures. Allow for sucient heat
dispersion when installed in a rack.
• Keep the unit free from moisture, water, and dust.
• Do not obstruct the ventilation holes.
• Do not let foreign objects into the unit.
• Do not let insecticides, benzene, and thinner come
in contact with the unit.
• Never disassemble or modify the unit in any way.
• Ventilation should not be impeded by covering the
ventilation openings with items, such as newspapers,
tablecloths or curtains.
• Naked flame sources such as lighted candles should
not be placed on the unit.
• Do not expose the unit to dripping or splashing fluids.
• Do not place objects filled with liquids, such as vases,
on the unit.
CAUTION:
Use caution when unpacking speaker. Tweeter has a pointed tip
and may cause injury. Replace speaker grille when not in use.
A Note About Recycling:
This product’s packaging materials are recyclable
and can be reused. Please dispose of any materials
in accordance with the local recycling regulations.
When discarding the unit, comply with local rules or
regulations.
EU Declaration of Conformity
Hereby, Sound United, LLC declares that our product
is in compliance with following EU/EC Directives:
• Directive 2011/65/EU (RoHS)
• WEEE-Directive 2012/19/EU
• REACH Regulation (EC) No 1907/2006
• Packaging Directive 94/62/EC
• IEC62474
The full text of the EU declaration of conformity is available
at the following internet address:
https://www.polkaudio.com/declarations-of-conformity
Sound United, LLC 5541 Fermi Court Carlsbad, CA 92008
EU contact: Sound United Europe, A division of D&M Europe
B.V. Beemdstraat 11, 5653 MA Eindhoven, The Netherlands
UKCA Declaration of Conformity
Hereby, Sound United, LLC declares that our
product is in compliance with the following UK
regulations:
• 2012 No. 3032, The Restriction of the Use of Certain
Hazardous Substances in Electrical and Electronic Equipment
Regulations 2012
• 2013 No. 3113, The Waste Electrical and Electronic Equipment
Regulations 2013
• 2008 No. 2852, The REACH Enforcement Regulations 2008
• 2015 No. 1640, The Packaging (Essential Requirements)
Regulations 2015
• BS EN IEC62474:2019
The full text of the UKCA declaration of conformity is available
at the following internet address:
https://www.polkaudio.com/declarations-of-conformity
UK importer: D&M Audiovisual Ltd
Dale Road, Worthing, West Sussex,
BN11 2BH, United Kingdom
CAUTION
TO REDUCE THE RISK OF ELECTRIC SHOCK, DO NOT REMOVE
COVER (OR BACK). NO USER-SERVICEABLE PARTS INSIDE.
REFER SERVICING TO QUALIFIED SERVICE PERSONNEL.
The lightning flash with arrowhead symbol, within an
equilateral triangle, is intended to alert the user to the
presence of uninsulated “dangerous voltage” within
the product’s enclosure that may be of sucient
magnitude to constitute a risk of electric shock to persons.
The exclamation point within an equilateral triangle is intended
to alert the user to the presence of important
operating and maintenance (servicing) instructions in
the literature accompanying the appliance.

4 5
OWNER’S MANUAL
English
English
Binding Post
To connect wire to the binding post, unscrew the binding post
cap and insert the bare wire into the hole near the base of the
binding post. Do not insert the insulated part of the wire into
the hole as this will not give you a good connection. Tighten
the binding post cap until it seats firmly with the wire, but do
not over tighten.
Connectors
You have several options when choosing connectors for your
speaker wires, and it is really a matter of personal preference.
Three of the more commonly used are banana plugs, spade
lugs, and bare wire. If you know where you want to locate your
speakers and plan to set up your system and leave them there,
then bare wire will work fine. Just make sure there are not
stray strands of wire that could come into contact. If you like
to experiment with dierent speaker locations, spade lugs or
banana plugs oer more convenient options when it comes to
disconnecting and reconnecting wires.
Banana Plugs (US only)
The binding posts have openings in the ends of their caps to
accept individual and dual banana plugs. To use banana plugs,
carefully pry out the binding post plugs to expose banana plug
holes. The binding posts can accept dual banana plugs.
Basic Speaker Hookup
Make sure that the red (+) and black (-) connectors on your
amplifier or receiver connect to the red (+) and black (-)
connectors on your speakers. During setup, slide the switch
to the proper position for wall or speaker placement.
If your speakers sound “thin,” with little bass and little or
no center image, odds are that one of the speaker wires is
connected backwards. Double check all connections.
What’s in the Box
Each box contains:
1. Loudspeaker(s)
2. Owner’s Manual
3. Registration Card
4. Magnetic grilles
(Speaker cable not included)
How to Connect Your System
To get the best sound quality, it is important to prepare your
speaker and wiring correctly.
Speaker Preparation
Remove all warning and protective labels and remove the grille
from the plastic bag. If rubber feet are included, ax them to
the bottom of the speaker to anchor and stabilize the speaker.
Wire Preparation
Follow the hookup directions included with your receiver/
amplifier. Strip 0.5" (12.7 mm) of insulation from each of the
two conductors of the wire to expose the bare metal, and twist
each of the individual conductors into single unfrayed strands.
Note that one of the terminals on the rear of each speaker is
marked red (+) and the other is black (–). Make sure that you
connect the wire from the positive (+) terminal of your amplifier
or receiver to the red (+) terminal on your speaker and the wire
from the negative (–) terminal of your amplifier or receiver to
the black (–) terminal on your speaker. Most wire has some
indicator (such as color-coding, ribbing or writing) on one of
the two conductors to help you maintain consistency.
These recommendations are for all connections from the
amplifier/receiver to each speaker:
A/V Receiver Setup
To ensure your speakers are set up correctly, follow your
onscreen setup instructions. After installation, if setup is correct,
you will hear a test tone from each of the speakers.
Caring for Your Reserve Loudspeaker
You bought Polk quality for a reason. Keep your speakers
looking good for years to come with these simple tips.
To clean the panels, use a soft damp cloth. Do not use furniture
polish or harsh detergents on veneer.
Runs Minimum Wire Gauge
Lengths up to 25' (5 m) 16
Lengths greater than 25' (5 m)
but less than 50' (15 m)
14
Lengths greater than 50' (15 m)
but less than 75' (25 m)
12
Lengths greater than 75' (25 m) 10
R900 Speaker Positioning
The R900 speaker is designed to be physically placed on the
R200, R500, R600 and R700 as a height speaker. It can also be
mounted on any wall (do not mount on ceiling). This enables
you to utilize Atmos, IMAX and DTS:X audio codecs. Once you
decide where you want to place your speaker, flip the switch
near the binding posts to the proper position, wall or speaker.
To maximize the sound quality of your speaker system, correct
placement is important.
Wall-mounting Options
Use a level and tape to place the wall-mounting template on
the wall at the desired location. Use a #10 screw (not included)
or a 3/8” x 16 thread wall mount (included) to secure the
speakers to the wall.
On Wall On Speaker
DOLBY ATMOS® 5.2 Configuration
SPEAKER PLACEMENT IN LISTENING AREA
Subwoofer Center
Channel Front (L/R) Surround (L/R)
R700
R500R200
R100
R600
Primary Speakers
Front (L/R)
Surround (L/R)
PRIMARY

6 7
OWNER’S MANUAL
English
English
DOLBY ATMOS® 5.2.4 Configuration
SPEAKER PLACEMENT IN LISTENING AREA
DOLBY ATMOS® 7.2 Configuration
SPEAKER PLACEMENT IN LISTENING AREA
Subwoofer Subwoofer
Center
Channel
Center
Channel
Surround
Back (L/R)
Stackable
Height
Wall
Mountable
Height
Front (L/R) Front (L/R)
Surround (L/R) Surround (L/R)
Primary Speakers
Front (L/R)
Surround Rear (L/R)
Wall Mountable
Height Option
Mount R900 above Front (L/R)
and Surround Rear (L/R)
Stackable Height
Option
Add R900 on top of Front (L/R)
and Surround Rear (L/R)
R500R200R 600 R700
R900
+
R900
+
R900
+
R900
+
R900
PRIMARY
WALL
MOUNTABLE
HEIGHT
STACKABLE
HEIGHT
R700
R500R200
R100
R600
Primary Speakers
Front (L/R)
Surround (L/R)
Surround Rear (L/R)
PRIMARY
R700
R500R200
R100
R600

8 9
OWNER’S MANUAL
English
English
Reserve R900 Height Module Speaker Specifications
Tweeter 0.75 in (19 mm) ring radiator
Mid-range/mid-bass 4 in (102 mm) turbine cone
Overall frequency response 50 Hz–50 kHz
Frequency response (-3 dB limits) 70 Hz–32 kHz
Recommended amplifier power 45–100W
Amplifier output compatibility
Minimum impedance
8Ω/ 6Ω/ 4Ω
4.2Ω
Sensitivity (2.83V/1m) 85.5 dB SPL
Crossover Frequency
Tweeter/mid-range 2100 Hz
Dimensions and Weight Attributes
Product dimensions (W x H x D)
(greatest overall depth, grille)
6.5 x 6.2 x 12.6 in
166 x 158.3 x 320 mm
Product weight 6.6 lbs/3 kg
Shipping weight 16 lbs/7.3 kg
Cabinetry
Mid-bass/woofer enclosure type Sealed
Available finishes Black/brown/white
Feet Wall-mountable
Binding posts Single nickel-plated, 5-way
Certifications (non-safety and regulatory)
Hi-res certified Yes
DOLBY ATMOS® 7.2.4 Configuration
SPEAKER PLACEMENT IN LISTENING AREA
Subwoofer Center
Channel
Stackable
Height
Wall
Mountable
Height
Surround (L/R)Front (L/R)
Surround
Back (L/R)
Primary Speakers
Front (L/R)
Surround (L/R)
Surround Rear (L/R )
Wall Mountable
Height Option
Mount R900 above Front (L/R),
and Surrounds (L/R)
Stackable Height
Option
Add R900 on top of Front (L/R),
and Surrounds (L/R)
R500R200 R600 R700
R900
+
R900
+
R900
+
R900
+
R900
PRIMARY
WALL
MOUNTABLE
HEIGHT
STACKABLE
HEIGHT
R700
R500R200
R100
R600

10 11
OWNER’S MANUAL
English
English
Limited 5-Year Warranty
(United States and Canada)
Polk Audio, LLC warrants to the original purchaser only that
this Polk Audio Loudspeaker Product (the “Product”) will be
free from defects in materials and workmanship for a period
of five (5) years from the date of original retail purchase from
a Polk Audio Authorized Dealer. However, this Warranty will
automatically terminate prior to the expiration of the five (5)
years if the original retail purchaser sells or otherwise transfers
the Product to any other party. The original retail purchaser
shall hereinafter be referred to as “you.” To allow Polk Audio to
oer the best possible warranty service, please visit the website
on the Product Registration Card(s) and fill out the form within
ten (10) days of the date of purchase.
Defective Products must be shipped, together with proof of
purchase, prepaid insured to the Polk Audio Authorized Dealer
from whom you purchased the Product, or an authorized
service center. Products must be shipped in the original
shipping container or its equivalent; in any case the risk of loss
or damage in transit is to be borne by you. If upon examination
at the Factory or Polk Audio Authorized Dealer it is determined
that the unit was defective in materials or workmanship at
any time during this Warranty period, Polk Audio or the Polk
Audio Authorized Dealer will, at its option, repair or replace
this Product at no additional charge, except as set forth below.
All replaced parts and Products become the property of Polk
Audio. Products replaced or repaired under this warranty will be
returned to you, within a reasonable time, freight prepaid.
This warranty does not include service or parts to repair
damage caused by accident, disaster, misuse, abuse,
negligence, inadequate packing or shipping procedures,
commercial use, voltage inputs in excess of the rated maximum
of the unit, cosmetic appearance of cabinetry not directly
attributable to defect in materials or workmanship, or service,
repair, or modification of the Product which has not been
authorized or approved by Polk Audio. This warranty shall
terminate if the Serial number on the Product has been
removed, tampered with or defaced. This warranty is in lieu
of all other expressed Warranties. If this Product is defective
in materials or workmanship as warranted above, your sole
remedy shall be repair or replacement as provided above. In no
event will Polk Audio, LLC be liable to you for any incidental or
consequential damages arising out of the use or inability to use
the Product, even if Polk Audio, Inc. or a Polk Audio Authorized
Dealer has been advised of the possibility of such damages,
or for any claim by any other party. Some states do not allow
the exclusion or limitation of consequential damages, so the
above limitation and exclusion may not apply to you. All implied
warranties on this Product are limited to the duration of this
expressed Warranty. Some states do not allow limitation on how
long an implied Warranty lasts, so the above limitations may not
apply to you. This Warranty gives you specific legal rights, and
you also may have other rights which vary from state to state.
This Warranty applies only to Products purchased in the United
States of America, its possessions, and U.S. and NATO armed
forces exchanges and audio clubs. The Warranty terms and
conditions applicable to Products purchased in other countries
are available from the Polk Audio Authorized Distributors in
such countries.
Dolby,DolbyAtmos, and the double-D symbol areregistered
trademarks ofDolbyLaboratories Licensing Corporation.
Manufactured under license fromDolbyLaboratories.
Confidentialunpublished works.Copyright © 2012–
2020DolbyLaboratories. Allrights reserved.
© Copyright 2022 Polk Audio, LLC. All Rights Reserved. Polk
and Polk Audio are registered trademarks of Polk Audio, LLC.
Polk Reserve and Power Port are trademarks of Polk Audio,
LLC.

94 95
中文
中文
用户手册
Dolby、Dolby Atmos 和双 D 标志是 Dolby Laboratories Licensing
Corporation 的注册商标。由杜比实验室许可制造。保密的未发行产品。©
2012–2020 杜比实验室。版权所有。
© 版权所有 2022 Polk Audio, LLC. 保留所有权利。Polk 和 Polk Audio
是美国普乐之声有限责任公司 Polk Audio, LLC. 的注册商标。 Polk
Reserve 和 Power Port 是美国普乐之声有限责任公司 Polk Audio, LLC.
的商标。
「产品中有害物质的名称及含量」
零部件名称 对象零部件
有害物质
铅
(Pb)
汞
(Hg)
镉
(Cd)
六价铬
(Cr6+)
多溴联苯
(PBB)
多溴二苯醚
(PBDE)
箱体 木箱、塑胶布框 、风管、饰圈 ○ ○ ○ ○ ○ ○
输入板 塑胶板，接线端子组件 ○ ○ ○ ○ ○ ○
喇叭单元 低音扬声器、高音扬声器、安装硬件 ○ ○ ○ ○ ○ ○
电路板组件 分频器PCBA，线束 ○ ○ ○ ○ ○ ○
备注：本表格依据SJ/T 11364的规定编制。
○：在该零部件的所有均质材料中的有害物质的含量不超过在GB/T 26572标准规定的限量要求
×：在该零部件中至少一种均质材料中的有害物质的含量超过在GB/T 26572标准规定的限量要求(×判定：包括EU RoHS的豁免项目)
此标志是根据2016年1月6日颁布的「电器电子产品有害物质限制使用管理 办法」，以及「电子电气产品有害物质限制使用标识要求」，适
用于在中 国销售的电子电气产品的环保使用期限。 在此产品相关的安全和使用上遵守注意事项，在从生产日期起计算的此年 限内，产品
中的有害物质不会往外泄漏，或者引起突然变异而给环境污染，人体或财产带来重大影响。另外，包装在一起的电池等消耗品的环保期限
是技术寿命5年。适当地使用完后废弃的情况，请协助遵守各自治体的电子电气产品回收·再利用相关的法律·规定。
中国 RoHS 声明
制造商: Dongguan Meiloon Acoustic Equipment Co., Ltd.
卖方: Shanghai Tianlong Marantz Electronics Co., Ltd.
地址: Shanghai Dianyin Marantz Electronics Co., Ltd. Room 1705, City Headquarters Building, 168 Xizang
Middle Road, Huangpu District, Shanghai
查看产品说明书 &
电子保修卡注册

Sound United, LLC
5541 Fermi Court
Carlsbad, CA 92008
U.S.A.
EU Contact:
Sound United Europe,
A division of D&M Europe B.V.
Beemdstraat 11, 5653 MA
Eindhoven, The Netherlands
UK Importer:
D&M Audiovisual Ltd
Dale Road, Worthing,
West Sussex, BN11 2BH
United Kingdom
Share Photos | Partager Des Photos | Compartir Fotos
Fotos Teilen | Condividi Foto | Dela Foton | Deel foto’s
Prześlij zdjęcia | обмениваться фотографиями
写真を共有する | 分享图片
#PolkAudio

DO NOT PRINT THIS PAGE
Printing Specification
Rev Date Update Description
B6.10.21
Update diagrams for every language,
align style with main manual, update
Limited Warranty and Copyright
language, update TOC per language,
UKCA, CE, RoHS
C2022.12.14
Updated UK Importer Address, remove
warranty language from Spanish
section, update fonts, adjust layout
Specs Notes
Date 2022 14 Dec
Drawing #
File Name Polk_Reserve_Owners_R900_10June2021-
MULTI
Page Size 8.5 x 11
Pages 100
Scale Full Size 100%
Created By JB
Colors
3Color:
Black (neutral Black), Polk Brick Red
(PMS7599C), Polk Red (PMS7626C)
Paper Tortilla smooth/80T (uncoated stock)
98 opacity, 10.6 caliper, 150 smoothness
Printing Offset Lithography
Binding Saddle Stitch
Notes
Project Name
Reserve R900 Owner’s Manual

Flagship-quality sound, elegant and refined looks, true value
www.polkaudio.com
FPO
TOWER SPEAKERS
RESERVE™
RESERVE™

High Resolution Pinnacle Ring Radiator Tweeter
Over 40 years of tweeter innovation, design and prototyping has
led to the development of the new 1” high definition Pinnacle
ring radiator tweeter. Developed by Polk Audio, it delivers ultra-
clear, crisp highs without unwanted coloration or distortions.
The Pinnacle tweeter features a finely tuned waveguide that
dramatically improves the dispersion of high frequency energy
ensuring a broad “sweet spot” while the critically damped rear-
chamber helps defeat any unwanted resonances.
Vertical Transducer Array
A vertical transducer array allows flexible placement either on a
wall or placed directly on top of a compatible Reserve speaker. A
vertical dispersion pattern directs sound perfectly to the correct
area of the ceiling into the optimal listening area. You will enjoy
exceptionally realistic overhead sound in a comfortable and
convenient listening area without the hassle of installing speakers
in your ceiling.
Completely Sealed Enclosure
The R900 features a fully sealed enclosure to prevent resonances
and distortions.
Timbre Matched for Unmatched- Performance
Designed with the same driver components of the Reserve series
speakers, you can mix and match to create the ultimate home
theater set up.
Features
•Pinnacle Tweeter: The new ring radiator tweeter design
dramatically improves dispersion while delivering clear, crisp
and natural highs
•Turbine Cone: Delivers smooth and incredibly detailed mid-
range imaging
•Anti-diffraction Magnetic Grilles: Acoustically inert grilles offer
a clean aesthetic without sacrificing sound
•Supports the Latest Immersive Codecs: Delivers 3D audio found
in Dolby Atmos, Dolby Atmos height virtualization, DTS, DTS:X,
DTS Virtual:X and IMAX Enhanced soundtracks
•Flexible Placement: The R900 can be wall mounted or placed on
top of any compatible Reserve speaker
•Perfect Match: Designed and perfectly timber-matched
to beautifully complement the Polk Reserve line; add to
compatible bookshelf or tower speaker for a perfectly
immersive home theater experience.
Easily add next generation, 3D sound to
your home theater
Designed to perfectly complement the Reserve series, this
optional height module adds exceptionally realistic sound
without the hassle of installing speakers in the ceiling. The R900
is fully compatible with all the latest next gen home theater
codecs: Dolby Atmos, DTS, DTS:X, DTS:X Virtual, Dolby Atmos
Height Virtualization Technology, IMAX Enhanced, and Auro-3D.
Consumer Benefits
Versatile Placement
The Polk Reserve R900 height module is Dolby Atmos certified
and designed to meet DTS:X specification. With the ability to
wall mount or place on top of a compatible Reserve speaker, this
height module allows convenient flexibility. Flip the switch on the
back of the speaker to select the desired position and the speaker
will automatically adapt to the optimal performance.
New 4” Turbine Cone Midrange Driver
Using the same patented Turbine Cone as the Reserve line, this
height module is timbre matched and positioned in the array to
deliver an incredibly immersive Dolby Atmos and DTS:X experience.
R900 Height Module
SPECIFICATIONS
Transducer 0.75" Ring Radiator
4” Turbine Cone Midrange
Minimum Impedance 4.2Ω
Sensitivity 85.5dB SPL
(When wall mounted)
Frequency Response 70Hz – 32kHz
(When wall mounted)
Dimensions and
Weight
(W)166mm x (H)158.3mm x (D)320mm
(W)6.5” x (H)6.2” x (D)12.6”
6.6Ibs/3kg
Turbine Cone Drivers Pinnacle Tweeters
www.polkaudio.com
Polk Audio is a DEI Holdings, Inc. Company. Polk Audio, Polk, are registered trademarks of Polk Audio, LLC. / The terms HDMI, HDMI High-Definition Multimedia Interface, and the HDMI Logo are trademarks or registered
trademarks of HDMI Licensing Administrator, Inc. / Manufactured under license from Dolby Laboratories. Dolby, Dolby Audio, and the double-D symbol are trademarks of Dolby Laboratories Licensing Corporation.
/ For DTS patents, see http://patents.dts.com. Manufactured under license from DTS, Inc. DTS, Digital Surround, and the DTS logo are registered trademarks or trademarks of DTS, Inc. in the United States and other countries.
/ © 2020 DTS, Inc. ALL RIGHTS RESERVED. / Amazon, Alexa and all related logos are trademarks of Amazon.com, Inc. or its affiliates. / The Bluetooth® word mark and logos are registered trademarks owned
by Bluetooth SIG, Inc. and any use of such marks by Polk Audio is under license. / Other trademarks and trade names are those of their respective owners

polk .
Register your new Polk product online:
www.polkaudio.com/registration/
Register your product to add an additional five years of warranty
coverage, and create a permanent record of your purchase. By
registering, it ensures we can contact you should the need arise.
We take privacy seriously and do not share or sell registration
information (see privacy policy for more details):
www.polkaudio.com/privacy-policy
No Internet? Need help registering your product or just have questions?
Contact Polk Customer Service.
For US and Canada call:
+1 800-377-POLK (7655) or [phone]
Email: polkcs @ polkaudio.com
Outside of the US:
UK [phone]
NL [phone]
DE [phone]
Email: polk-eu @ mailmw . custhelp.com
1 11 111 11 1 1111 II I ll \ 11111111111 1 11 11 11 Ill
MODEL
HBP4466
