Polsen SP-260 User manual

SP-260
STEREO DISTRIBUTION
SPLITTER
PRODUCT
MANUAL

2
THANK YOU FOR CHOOSING POLSEN.
Polsen’s SP-260 2×6 Stereo Distribution Switcher routes line-level
audio signals from two sources, like a mixing board or playback device,
to six pairs of speakers or headphones. The SP-260 allows you to
distribute the sound and adjust the volume for each individual zone
or location. This is ideal for ofces and homes where different audio
programs play in different rooms, or for large spaces that need more
than two speakers. The unit is equipped with balanced XLR inputs and
outputs that assure an audio signal that’s free of distortion from EMI
and RFI, even with long cable runs. For control over audio quality, the
SP-260 has level indicators that display signal strength for all input and
output channels.
PRECAUTIONS
•Please read and follow these instructions, and keep this manual in
a safe place.
• Keep this unit away from water and any ammable gases or liquids.
•Clean the unit with only a soft, dry cloth.
•Do not attempt to disassemble or repair the equipment—doing so
will void the warranty, and Polsen will not be responsible for any
damage.
•Exposure to high sound levels can cause permanent hearing loss.
Avoid listening at high volumes for extended periods of time.
•Use only parts provided by the manufacturer.
•All images are for illustrative purposes only.

3
-24 0CLIP
POWEROUTPUT 1
LINE 1
60
LINE 2
STEREO/MONO
60
3
-24 -6 0+6 CLIP
3
OUTPUT 2
LINE 1
60
LINE 2
STEREO/MONO
60
3
-24 -6 0+6 CLIP
3
OUTPUT 3
LINE 1
60
LINE 2
STEREO/MONO
60
3
-24 -6 0+6 CLIP
3
OUTPUT 4
LINE 1
60
LINE 2
STEREO/MONO
60
3
-24 -6 0+6 CLIP
3
OUTPUT 5
LINE 1
60
LINE 2
STEREO/MONO
60
3
-24 -6 0+6 CLIP
3
OUTPUT 6
LINE 1
60
LINE 2
STEREO/MONO
60
3
-24 -6 0+6 CLIP
3
CLIP-24 0
INPUT 1
LINE 1
3
INPUT 2
LINE 2
60 60
3
STEREO
DISTRIBUTION
SPLITTER
AC INPUT
R R R R R R R R
L L L L L L L L
OUTPUT 6 OUTPUT 5 OUTPUT 4 OUTPUT 3 OUTPUT 2 OUTPUT 1 LINE 2 LINE 1

4
1.
3. 4.
8. 9.
5.
7.
6.
2.
AC INPUT
R R R R R R R R
L L L L L L L L
OUTPUT 6 OUTPUT 5 OUTPUT 4 OUTPUT 3 OUTPUT 2 OUTPUT 1 LINE 2 LINE 1
-24 0CLIP
POWEROUTPUT 1
LINE 1
60
LINE 2
STEREO/MONO
60
3
-24 -6 0+6 CLIP
3
OUTPUT 2
LINE 1
60
LINE 2
STEREO/MONO
60
3
-24 -6 0+6 CLIP
3
OUTPUT 3
LINE 1
60
LINE 2
STEREO/MONO
60
3
-24 -6 0+6 CLIP
3
OUTPUT 4
LINE 1
60
LINE 2
STEREO/MONO
60
3
-24 -6 0+6 CLIP
3
OUTPUT 5
LINE 1
60
LINE 2
STEREO/MONO
60
3
-24 -6 0+6 CLIP
3
OUTPUT 6
LINE 1
60
LINE 2
STEREO/MONO
60
3
-24 -6 0+6 CLIP
3
CLIP-24 0
INPUT 1
LINE 1
3
INPUT 2
LINE 2
60 60
3
STEREO
DISTRIBUTION
SPLITTER
AC INPUT
R R R R R R R R
L L L L L L L L
OUTPUT 6 OUTPUT 5 OUTPUT 4 OUTPUT 3 OUTPUT 2 OUTPUT 1 LINE 2 LINE 1
-24 0CLIP
POWEROUTPUT 1
LINE 1
60
LINE 2
STEREO/MONO
60
3
-24 -6 0+6 CLIP
3
OUTPUT 2
LINE 1
60
LINE 2
STEREO/MONO
60
3
-24 -6 0+6 CLIP
3
OUTPUT 3
LINE 1
60
LINE 2
STEREO/MONO
60
3
-24 -6 0+6 CLIP
3
OUTPUT 4
LINE 1
60
LINE 2
STEREO/MONO
60
3
-24 -6 0+6 CLIP
3
OUTPUT 5
LINE 1
60
LINE 2
STEREO/MONO
60
3
-24 -6 0+6 CLIP
3
OUTPUT 6
LINE 1
60
LINE 2
STEREO/MONO
60
3
-24 -6 0+6 CLIP
3
CLIP-24 0
INPUT 1
LINE 1
3
INPUT 2
LINE 2
60 60
3
STEREO
DISTRIBUTION
SPLITTER

5
OVERVIEW
1. Input Level Indicators
Displays the signal level of the connected devices.
•-24 indicates a weak signal level.
•0 indicates a strong signal level.
•Clip indicates a level that’s too high and distorted.
2. Output Level Indicators
Displays the output signal level for each individual pair of
speakers or headphones.
3. Input Volume Knobs
Adjusts the volume of the devices connected to the Line 1 and
Line 2 inputs. The volume should be set so the Clip indicator
does not light up at the loudest moments.
4. Output Volume Knobs
Adjusts the volume of each individual pair of connected
speakers or headphones.
5. Mono/Stereo Selector
Selects the playback mode of each individual pair of speakers
or headphones.
•In stereo mode, the green indicator lights up.
•In mono mode, the yellow indicator lights up.
Note:Mono mode is a good option when the input signal is
stereo, but the left and right speakers are placed far apart or in
different rooms. It’s also a good option when monitoring audio
that’s recorded on discrete channels, like dialogue.
6. Power Switch
7. AC Power Input
8. XLR Outputs
Use the balanced XLR outputs to connect the SP-260 to a
power amplifier, powered speakers, or headphone amplifier.
9. XLR Inputs
Use the balanced XLR inputs to connect line-level sources
such as a mixing board, preamp, or playback device.

6
SETTING UP THE SP-260

7
INPUT
INPUTS XLR, balanced (×2)
INPUT IMPEDANCE 44 kΩ (balanced)
22 kΩ (unbalanced)
MAX INPUT LEVEL +21 dBu
MAX GAIN +10 dB
CROSSTALK >80 dB @1 kHz
COMMON MODE
REJECTION
>40 dB @1 kHz,
22 Hz to 22 kHz
POWER
VOLTAGE 100 to 240 VAC, 50/60 Hz
POWER
CONSUMPTION
15 W
OUTPUT
TYPE XLR, balanced (×12)
MAX GAIN 0 dB
MAX GAIN
(INPUT/OUTPUT)
+10 dB
IMPEDANCE 50 Ω (balanced and unbalanced)
MAX OUTPUT LEVEL +21 dBu (balanced and
unbalanced)
CROSSTALK (L/R) >80 dB @ 1 kHz
NOISE (ALL LEVEL
CONTROLS DOWN)
-104 dBu A-weighted
SNR 97 dB @ 0 dB A-weighted
GENERAL
FREQUENCY
RESPONSE
<10 Hz to 25 kHz ± 0.5 dB
THD+N<0.008%
CONTROLS Stereo input level (×2)
Stereo output (×2)
Mono/stereo switch (×6)
Power switch
DISPLAY Input:-24 dB, 0 dB, Clip LEDs
Output:-24 dB, -6 dB,
+6 dB, clip LEDs
DIMENSIONS
(H ×W ×D)
1.7 ×19 ×6.3 in.
(44 ×483 ×160 mm)
WEIGHT 4.7 lb. (2.1 kg)
SPECIFICATIONS

8
ONE-YEAR LIMITED WARRANTY
This Polsen product is warranted to the original purchaser to be free from defects in materials and workmanship under normal
consumer use for a period of one (1) year from the original purchase date or thirty (30) days after replacement, whichever occurs
later. The warranty provider’s responsibility with respect to this limited warranty shall be limited solely to repair or replacement, at the
provider’s discretion, of any product that fails during normal use of this product in its intended manner and in its intended environment.
Inoperability of the product or part(s) shall be determined by the warranty provider. If the product has been discontinued, the warranty
provider reserves the right to replace it with a model of equivalent quality and function.
This warranty does not cover damage or defect caused by misuse, neglect, accident, alteration, abuse, improper installation or maintenance.
EXCEPT AS PROVIDED HEREIN, THE WARRANTY PROVIDER MAKES NEITHER ANY EXPRESS WARRANTIES NOR ANY IMPLIED WARRANTIES,
INCLUDING BUT NOT LIMITED TO ANY IMPLIED WARRANTY OF MERCHANTABILITY OR FITNESS FOR A PARTICULAR PURPOSE. This
warranty provides you with specic legal rights, and you may also have additional rights that vary from state to state.
To obtain warranty coverage, contact the Polsen Customer Service Department to obtain a return merchandise authorization (“RMA”)
number, and return the defective product to Polsen along with the RMA number and proof of purchase. Shipment of the defective product
is at the purchaser’s own risk and expense.
For more information or to arrange service, visit www.polsenaudio.com or call Customer Service at 212-594-2353.
Product warranty provided by the Gradus Group.
www.gradusgroup.com
Polsen is a registered trademark of the Gradus Group. ©2023 Gradus Group LLC. All Rights Reserved. GG2
