Polycom Studio USB Video Bar Quick Tips
1.0.0 |3725-85897-001A |February 2019
The Polycom Studio USB Video Bar enables you to send and receive audio during calls and to play music when connected to a computer with a USB cable or
paired with a Bluetooth device.
Set Up Polycom Studio
Plug in the power cable and the USB cable to
start using Polycom Studio with your computer.
You can also connect an external mic or audio
input sources.
Polycom Studio Features
The following figure and table identify the parts
of the Polycom Studio USB video bar.
Reference
Feature
1
Camera
2
Microphone array
3
LED light indicators
4
Speakers
5
Privacy shutter lever
6
Remote control pairing button
7
Reset button
Status Indicators
You can get status information for you Polycom
Studio USB video bar based on the color,
position, and movement pattern of the LED
indicators.
LED Color
Position
Status
Blinking
green/white
All
Incoming call
Solid
green/amber
Middle
Outgoing call
Solid red
All
Muted
Chasing white
All
Boot initialization
Solid amber
Middle
Standing by
Blinking blue
Middle
Bluetooth
discovery mode
Solid blue for
three seconds
Middle
Bluetooth paired
Solid
white/green
Changing
Working and
tracking speaker
Solid
white/green
Middle
Working

www.polycom.com
© 2019, Polycom, Inc. All rights reserved. Polycom® and the names and marks associated with Polycom’s products are trademarks and/or service marks of Polycom, Inc.
and are registered and/or common-law marks in the United States and various other countries. All other trademarks are property of their respective owners.
Remote Control Features
Polycom Studio uses a low-energy Bluetooth
remote control that automatically pairs to your
system when you turn it on for the first time.
In addition to basic remote control functions, it
also provides the following features:
Referenc
e
Function
1
Preset 1
2
Preset 2
3
Bluetooth discovery
4
Speaker tracking with group framing
Connect Polycom Studio to a
Bluetooth Device
Pair Polycom Studio with your Bluetooth device
to use it as an external microphone and speaker
for your device.
To pair Polycom Studio with a Bluetooth
device:
On the remote control, long press Bluetooth
to enable paring mode.
The LEDs blink blue in the middle.
On your device, enable Bluetooth and select
Polycom Studio from the list of available
devices.
The middle LEDs turn solid blue for three
seconds with a notification sound.
Set Polycom Studio as the
Default Audio and Video Device
You must set Polycom Studio as the default
audio and video device for the applications you
use.
The following is a general procedure that you
can use. Your settings may be different.
To set Polycom Studio as the default device:
Go to your software’s Settings.
Find Audio Device and Video Device.
Select Polycom Studio as the device and
click Save.
Save Camera Presets
The two number buttons on the Polycom Studio
remote control serve as camera presets.
To save a camera preset:
Turn off group framing and speaker tracking
mode.
Adjust the camera.
Long press the 1or 2button on the remote
control.
The middle LED lights stay white for three
seconds with a notification sound.
Call Camera Presets
When you turn off group framing and speaker-
tracking mode, you can use the remote control
camera presets.
To call a camera preset:
Turn off group framing and speaker-tracking
mode.
Press the 1or 2button on the remote
control to use the preset angle.
Pair the Bluetooth Remote
Control with Polycom Studio
If you reset your Polycom Studio USB video bar
or replace the remote control, you must pair the
remote control to the USB video bar.
To pair the remote control with Polycom
Studio:
Long press the Remote Control Pairing
button on the bottom of the USB video bar
until the LEDs blink blue in the middle with a
notification sound.
Long press Mute on the remote control
until you hear a notification sound.
When paired, the middle LEDs remain solid
blue for three seconds with a notification
sound.

Polycom Studio Advanced Operations
If you’re the administrator for the Polycom Studio USB video bar, the following advanced operations provide you with more options to configure the system.
Download Polycom Companion
You can download Polycom Companion from Polycom Support to configure
the following additional settings and advanced features for the Polycom
Studio USB video bar:
●Audio and video configurations
●Camera control
●Wi-Fi and Bluetooth configuration
●Provisioning configuration
●Software upgrade & reset
●Downloading logs
●Audio test
To download Polycom Companion:
Go to Polycom Support and select Documents & Software.
Go to Telepresence and Video > Polycom Companion.
Select a version according to your operating system, then download the
installation package to your local disk.
Launch the installation package and follow the onscreen instructions.
