POLYGROUP LIMITED PRO-SERIES ABOVE GROUND RECTANGULAR QUICK... User manual

“Splash Guard”Technology
System Info Label
WARNING: DO NOT overfill the pool and / or allow
people to lay over or sit on pool wall- DOING SO CAN
CAUSE PERMANENT INJURY! DRAIN pool to the proper
level after a heavy rain.
NOTE: DO NOT attempt to assemble this pool in
adverse weather conditions, windy conditions or when
the temperature is below 60°F.
NOTE: This is a storable pool, which should be disas-
sembled and stored when temperatures are expected
to fall below 32°F.
SAFETY INFORMATION
CONSUMER AWARENESS BOOKLETS
SITE PREPARATION
POOL INSTALLATION
DISASSEMBLY AND STORAGE
PARTS & ACCESSORIES
POOL COVER SAFETY
NOTES
2
3
4
4
7
8
9
10
2012
084-120224
Read and Follow All Safety Information and Instructions.
Keep for Future Reference.
Failure to follow these warnings and instructions can result in serious injury or
death to user, especially children.
PREVENT
DROWNING
NO DIVING!
NO JUMPING!
Watch children
at all times.
Observe all Safety Rules.
Shallow Water - You can
be permanently injured.
DANGER
DO NOT SIT ON
OR LAY OVER
POOL WALL
AVOID
ENTRAPMENT
You can be permanently
injured
Stay away from
suction fi ttings -
You may drown
WARNING
1. Children, especially children younger than five years,are at high risk of drowning. Drowning occurs
silently and quickly and can occur in as little as 2 in. (5 cm) of water.
2. Keep children in your direct sight,stay close, and actively supervise them when they are in or near this
pool and when you are filling and emptying this pool.
3.When searching for a missing child, check the pool first, even if the child is thought to be in the house.
4.Very Important: Swimming pool barriers, which restrict access to the pool by small children, may be
required by law. A barrier is necessary to provide protection against potential drowning and near
drowning.Barriers are not a substitute for constant supervision of children. Check state or local laws
and codes before setting up pool.
5.The use of artificial pool lighting is at the discretion of the pool owner.Lighting, when installed, should
be in accordance with Article 680 of the National Electrical Code (NEC) or its latest approved edition
and in consultation with a licensed electrical professional.
6. During nighttime pool use,artificial lighting shall be used to illuminate all safety signs, ladders, steps,
deck surfaces and walks.
7.The floor of the pool shall be visible at all times from the outside perimeter of the pool.
8. Local building codes may require obtaining a building or electrical permit. Installer shall follow
regulations on setback, barriers, devices and other conditions.
9. Post a list of emergency telephone numbers such as the nearest available police, fire, ambulance and/or
rescue unit.These numbers are to be kept near the telephone, which is closest to the pool.
10.Toys, chairs, tables or similar objects that a young child could climb shall be at least four feet (4’)
[121.92 cm] from the pool.The pump filter system shall be positioned so as to prevent it being used as a
means of access to the pool by young children.Do not leave toys inside pool when finished using, since
toys and similar items might attract a child to the pool.
11. Basic lifesaving equipment, including one of the following should be on hand at all times:
* A light, strong, rigid pole (shepherds crook) not less than twelve feet (12’) [365.76 cm] long.
* A minimum one-fourth inch (1/4”) [6.35 mm] diameter rope as long as one and one half (1-1/2) times
the maximum width of the pool or fifty feet (50’) [15.24 meters], whichever is less,which has been firmly
attached to a Coast Guard-approved ring buoy having an outside diameter of approximately fifteen
inches (15”) [38.1 cm], or similarly approved flotation device.
12. Entrapment Avoidance: There shall be no protrusions or other obstruction in the swimming area,
which may cause entrapment or entanglement of the user.If a suction outlet cover is missing or broken,
do not use the pool. Suction can cause body part entrapment, hair and jewelry entanglement, eviscera-
tion, or drowning.Repair or replace the suction outlet cover before allowing the pool to be used.
2
2
DISTRIBUTED BY: POLYGROUP LIMITED (MCO)
Avenida Xian Xing Hai, Centro Golden Dragon, 11 Andar M, Macau
Customer Service: [phone] • www.polygroup.com
PRO-SERIES ABOVE GROUND RECTANGULAR QUICK SET® SWIMMING POOL
OWNER’S MANUAL
LIMITED WARRANTY
Polygroup Limited (Macao Commercial Offshore), (hereinafter“Polygroup”) warrants to the original
purchaser only, the ProSeries™ Metal Frame Pool (frame and liner) against defects in material and work-
manship for 90 days from the date of purchase. Original Purchaser must retain proof of such purchase in
the form of an original store sales receipt and must produce such upon request by Polygroup or its
designated agents. Warranty claims cannot be processed without a valid proof of purchase.
This Limited Warranty applies only to the original purchaser of the product and is limited solely to the
repair or replacement of the product, to be decided in Polygroup’s sole discretion. Consequential dam-
ages, including claims for loss of water, pool chemicals, damage, or labor are not covered under this
Limited Warranty.
This Warranty will be declared invalid should the Purchaser modify or repair the product themselves or by
unauthorized persons; use non-Polygroup parts or accessories with the product; use the product in
contravention of the Manufacturers Instructions; use improper voltage; abuse the product in any way; or
through accident or negligence. Normal wear-and-tear is not covered under this Warranty, nor are acts of
God outside the control of Polygroup.
IN NO EVENT SHALL POLYGROUP,THEIR AUTHORIZED AGENTS,RELATED ENTITIES, OR EMPLOYEES BE
LIABLE TO THE BUYER OR ANY OTHER PARTY FOR DIRECT OR CONSEQUENTIAL DAMAGES.Some states or
countries, or others jurisdictions do not allow the exclusion or limitation of incidental or consequential
damages, so the above limitation or exclusion may not apply to you.
Should you encounter a problem with your Polygroup Product, please do not return the product to the
place or purchase. All Warranty claims must be made directly to Polygroup. Prior to contacting Customer
Service, please first review the Troubleshooting Guide in the Installation Manual, or review the FAQ at
www.polygroup.com .If you are still unable to correct the problem, please contact Polygroup customer
service at [phone]. Have the product type and your purchase receipt ready. Our Customer Service
Representative will assist you in resolving the problem. You may be asked to return all or part of the
product for inspection and/or repair. Do not return any product to Polygroup without a Return Authori-
zation number.

13.The pool is subject to wear and deterioration.If not maintained properly, certain types of excessive
or accelerated deterioration can lead to failure of the pool structure that might release large
quantities of water that could cause bodily harm and property damage.
14. Above ground / onground residential swimming pools are for swimming and wading only.No diving
boards, slides or other equipment are to be added to an above ground / onground pool that in any
way indicates that an above ground / onground pool may be used or intended for diving or sliding
purposes.
15. Never allow horseplay, diving or jumping into or around the pool. Serious injury, paralysis or death,
could result when this rule is disregarded. DO NOT ALLOW anyone to swim alone without supervision.
16. Safety signs shall comply with requirements of ANSI-Z535 and to use signal wording.
17.The pool is to be assembled by an adult; care should be taken in the unpacking and assembly of the
pool, this pool may contain accessible potentially hazardous sharp edges or sharp points that are a
necessary part of the function of the pool.
18. Become certified in cardiopulmonary resuscitation (CPR). In the event of an emergency, immediate
use of CPR can make a lifesaving difference.
19. Keep all electrical lines, radios, speakers and other electrical appliances away from the pool.
20. Do not place pool near or under overhead electrical lines.
21. Remove pool ladders before leaving the pool. Children as young as 2 years have climbed up ladders
and into pools and drowned.
34
4
3
NOTICE: CUSTOMERS THAT PURCHASE POOLS MAY BE REQUIRED BY LOCAL OR STATE LAW TO
INCUR ADDITIONAL EXPENSES WHEN INSTALLING A POOL, IN ORDER TO COMPLY WITH STATE OR
LOCAL LAWS REGARDING FENCING AND OTHER SAFETY REQUIREMENTS.CUSTOMERS SHOULD
CONTACT THEIR LOCAL BUILDING CODE ENFORCEMENT OFFICE FOR FURTHER DETAILS.
CONSUMER AWARENESS BOOKLETS
DANGER:
DANGER: POOL SET-UP
Contact: U.S. Consumer Product Safety Commission at www.CPSC.gov/cpscpub/pubs/pool/pdf, Pub. #362
“Safety Barrier Guidelines for Home Pools”.
Contact: ASSOCIATION OF POOL & SPA PROFESSIONALS ( formerly NSPI) at-www.apsp.org/164/index.aspx
These titles are now available:“The Sensible Way To Enjoy Your Aboveground / Inground Swimming Pool”,
“Children Aren’t Waterproof”,“Pool and Spa Emergency Procedures For Infants’,Layers of Protection”, and
the“ANSI / NSPI-8 Model Barrier Code for Residential Swimming Pools, Spas, and Hot Tubs”.
Competent supervision and knowledge of the safety requirements
is the only way to prevent drowning or permanent injury
in the use of this product!
Never leave young children unattended.
Do not attempt to assemble this pool in adverse weather conditions, such as in high winds, strong gusts
or when the temperature is below 60°F.
Should you encounter any problems, contact the Customer Service at [phone]
from 8 AM to 5 PM Mon. thru Fri. EST. Extended operating days and hours during peak season requirements.
RECTANGULAR FRAME POOL SETUP INSTRUCTION SHEET
SITE PREPARATION
POOL INSTALLATION
WARNING - VERY IMPORTANT! SITE MUST BE LEVEL, STABLE, COMPACTED SOIL.
• The pool must be assembled on a smooth and level site of firm soil that is free of stones, gravel, sticks,
blacktop or other oil base compounds. Do not install pool on a wooden deck or any type of wooden
surface.You can not use sand and/or uncompacted soil to provide a level surface for this pool; it will
only wash out.
• FAILURE TO FOLLOW THE INSTRUCTIONS BELOW WILL CAUSE POOL TO COLLAPSE AND WILL
VOID THE WARRANTY!
WARNING: DO NOT overfill the pool and / or allow people to lay over or sit on pool wall doing
so can cause permanent injury.DRAIN the pool to the proper level after a heavy rain.
TIP: It will be much easier to install your pool if you unfold it and let it lay in direct sunlight for about 2
hours prior to installation.This will help to insure a wrinkle-free fit because the pool material will be
more pliable allowing it to form into shape during installation.
1. Select a level area, and completely remove all debris,twigs, stones, etc. DO NOT select an area under
overhead electrical lines, trees or within 15 feet of a house, building, etc.The area should also be at least
10 feet away, and no more than 21 feet away, from a 110 volt AC outlet, protected by a Ground Fault
Circuit Interrupter.
2. Contact your local utilities, checking that no underground cables, telephone lines, gas lines, etc. run
beneath the area you have selected.
1. Carefully unfold the Quick Set® pool and inspect seams for manufacturing defects. With the sleeve rim
on the top side, lay out the pool in the area selected, making sure the pool bottom is both flat and
rectangular-shaped. Position the power filter mounting area of the pool wall so that it is 10 to 21 feet
from the electrical outlet you
plan to use for the
pool pump.You
should have at least
three people to asist
with the assembly
of this pool. Pull out
the rectangular flaps
of wall material
from the base of the
pool, (along each
end and on each side).
2. Locate the four metal (Corner Pieces) of pipe Fig. 1, then place one at every corner of the pool. Now
locate the (Horizontal Beams), insert a (O-Shape Spring) see Fig. 2 in each smaller swedged end of these
only to join the beams together in
length, Note: No O-Shaped Springs
are used in the Horizontal Beam
end attaching to the corner pieces
or in the corner pieces themselves,
please see the assembly drawing
page 5 for proper O-Shaped spring locations.
The (Horizontal Beams) for the pools ends are (the shorter ones) and (the longer ones) for the long
sides. Place half of the short ones on either (short end of the pool) and half of the long ones along each
(long side of the pool), these along with the (Corner Pieces) make up the support frame of the pool.
Begin by sliding the (Horizontal Beams) into the sleeve (making certain you work in a clockwise
FIG. 1
Button
Holes (U-Shape Pipes)
Horizontal Beams
Liner
Sleeve
Corner Piece
Swedged end
Horizontal Beams
FIG.2
Horizontal
Beams
Horizontal
Beams
Note: See
Assembly Dwg.
Page 5 for locations
of O-Shaped Springs
O-Shaped
Spring
Note: Insert First

5
5
6
6
direction around the pool with all swedged parts pointing clockwise) see Fig. 1 and refer to the
“View of All Frame Assembly Parts”shown on page 5.
5. Connect the (Horizontal Beams) together pushing the button in as you insert one beam into the other
beams end. Look through the locking hole in the beam as you join them, slightly rotate the beams until
the button aligns with the hole and pops up,locking that beams end into the other beams end. Repeat
this procedure for the remaining (Horizontal Beams) making certain the holes in the beams align with
the openings in the pool sleeve Fig. 1 these holes are used for the U-Shape Pipe (end) and (side)
supports. Next install the corner pieces (again working in a clockwise direction with swedged ends
pointing clockwise), slide them together and repeat this procedure for all corners, on the last corner it
might be necessary to lift the final joining connection at and angle to allow the pipes to fit into each
other slowly lowering the ends flat again then sliding them together until it fits in completely, this step
may require two people.Now double check all (Horizontal Beam) and (Corner Piece) connections at
this time.
Should you encounter any problems, contact the Customer Service at [phone]
from 8 AM to 5 PM Mon. thru Fri. EST. Extended operating days and hours during peak season requirements.
Should you encounter any problems, contact the Customer Service at [phone]
from 8 AM to 5 PM Mon. thru Fri. EST. Extended operating days and hours during peak season requirements.
3. Now locate the (U-Shape) pipe frames. Each end of the (U-Shape) pipe will have a cap to be installed on
it.Locate the pipe caps and install those,push the buttons in as you insert the cap onto the pipes end
Fig. 3. Look through the holes in the cap as you install
it and slightly rotate the cap until the
buttons align with the holes and pop up,
locking the cap onto the pipes end. Now
place a (U-Shape) pipe at each of the
rectangular flaps along the base of the pool.
4. Now insert the (U-Shape) pipe sections
through the end of each rectangular flap
at the bottom of the pool Fig. 4. Note:
The ladder should be assembled prior
to raising the wall to allow helpers easy
access in and out, ladder assembly
instructions are with the ladder. Next, one or two other persons will
have to support the horizontal beam raising the pool wall from inside
the pool as another person inserts the (U-Shape) pipe supports Fig. 5. Insert the capped ends of the
(U-Shape) pipe into the holes in the horizontal beam assembly by
depressing the lower set of buttons Fig.5 pushing
the cap end entirely into the horizontal beam until
it stops. Make sure all the (U-Shape) pipes are
inserted fully and check that all connected sections
are still securely fastened.Repeat this step for the
OPPOSITE SIDE, then install the U-Shape frame
supports at both ENDS of the pool.
5. Make sure the drain fitting is plugged securely and
the cap is in place. Start filling the pool with water.
After about 1-inch of water is on the bottom, stop
filling and smooth wrinkles out of the bottom of the
pool. Pull the wall outward at the base all around
the bottom of the pool from the outside or push
outward from inside the pool removing all
wrinkles so that it fills evenly and flat.
6. NOTE: IF MORE THAN 1-2 INCHES OF WATER
COLLECTS ON ANY ONE SIDE BEFORE THE POOL
STARTS FILLING IN THE CENTER,THE POOL IS
NOT LEVEL ENOUGH, AND MUST BE CORRECTED,
SEE“SITE PREPARATION”, PAGE 4. NOTE:THE WEIGHT OF THE WATER WILL PREVENT ANY ADJUSTMENT
AFTER THIS POINT.
7. Following the instructions under “Power Filter Installation”in the “Swimming Pool Filter System”owner’s
manual, begin installing your power filter unit according to its manual.
8. Now, once this is done, continue filling the pool to the recommended level.When filling is complete
refer back to the“Swimming Pool Filter System”owner’s manual, and continue through the rest of the
installation.
VIEW OF ALL FRAME ASSEMBLY PARTS
SHOWN OUTSIDE OF SLEEVE
NOTE: No O-Shaped
Springs used in any
corner connections
Horizontal Beams
(LONG)
Liner
O-Shaped Spring
O-Shaped Spring
O-Shaped Spring
O-Shaped Spring
Sleeve
U-Shape pipe
Rectangular flap
O-Shaped Spring
O-Shaped Spring
Horizontal Beams
(SHORT)
Corner Piece
FIG.3
FIG.4
Rectangular
Flap
Pool Liner Sleeve
U-Shape Pipe
Cap
U-Shaped
Pipe
Frame
Press In
Press In
FIG.5
U-Shape
Pipe
Press buttons
here
Cap on end
Horizontal
Beam
Cap inserted
into Beam
PUSH
PUSH

7 8
Should you encounter any problems, contact the Customer Service at [phone]
from 8 AM to 5 PM Mon. thru Fri. EST. Extended operating days and hours during peak season requirements.
DISASSEMBLY AND STORAGE
1. GENERAL INFORMATION: Pool must be stored if temperatures are expected to fall below 32°F.
A. All parts should be cleaned with a mild soap and lukewarm water only - DO NOT use detergent or
hot water.
B. Make sure all parts are dry before storing to help prevent mildew from forming.
C. Store all parts in a dry heated area where temperatures do not go below 32° F or above 125° F.
D.Failure to follow the proper storage instructions could cause damage to pool parts and void warranty.
E. YOU MUST FOLLOW THE ASSEMBLY INSTRUCTIONS TO REASSEMBLE YOUR POOL NEXT SEASON. Pool
site must be cleared and leveled again before setting up your pool.
A.To drain the pool,locate the drain plug on the outside of the pool wall and remove the drain cap. A
standard garden hose will thread onto the drain fitting. Extend the hose to the area where the water
is to be drained.When you have placed the garden hose where desired, the drain plug on the inside
of the pool can be opened.
B. Once you have drained as much water as possible out of the pool, using the hose connected to the
drain fitting,open the air valve and deflate the top ring.Then, carefully push the sides of the pool wall
down to allow remaining water to run out.
C. Remove any remaining water as you wash and completely dry pool using a soft cotton cloth. Push
the drain plug into the fitting and replace the cap.
D.Frame Pools: If your pool has metal frame work, disassemble those pieces by depressing the plastic
buttons sliding those pieces apart or by removing the plastic pins holding them together again
sliding those pieces apart, clean them and wipe them dry.If in doubt of proper disassembly refer to
the pools set-up sheet and reverse those steps.Place them all together in a safe storage place for
reassembly next season. Order replacement parts for any damaged, broken, or worn parts.
E. Solar blankets,leaf covers,ladders, etc., should be cleaned and dried before storing.
2. QUICK-SET® POOL:
7 8
REPLACEMENT PARTS
KEY
30 QUICK-SET POOL CALL PARTS DEPT.FOR REPLACEMENT
097-020013 1 21 50.00
55.00
60.00
75.00
15.00
24
28
33
3
1
1
1
1
097-020014
097-020015
097-020016
096-050024
CALL PARTS DEPT.FOR REPLACEMENT
CALL PARTS DEPT.FOR REPLACEMENT
CALL PARTS DEPT.FOR REPLACEMENT
COMPLETE LADDER w/BARRIER (36”POOL)
COMPLETE LADDER w/BARRIER (42”POOL)
COMPLETE LADDER w/BARRIER(48”POOL)
COMPLETE LADDER w/BARRIER (52”POOL)
DUAL MAINTENANCE KIT (LEAF NET & VACUUM)
LEAF COVER (NOT A SAFETY COVER)
SOLAR BLANKET (NOT A SAFETY COVER)
SOLAR COVER (NOT A SAFETY COVER)
*
*
*
*
*
80
81
82
DESCRIPTION
QUICK-SET POOL
GFP ACCESSORIES
ID NUMBER QTY LBS COST
RECTANGULAR
FRAME POOL (P23) CALL PARTS DEPT.AT [phone] FOR REPLACEMENT PARTS
HORIZONTAL BEAM U-SHAPE PIPE CAP w/ 1 extra U-SHAPE PIPE
POOL
MODEL
POOL SIZE PART NO. QTY WGT
(LBS)
COST
EA.
PART NO. QTY WGT
(LBS)
COST
EA.
PART NO. QTY WGT
(LBS)
COST
EA.
P23-081436 8’ X 14’ X 36” 4 3.26 3.00 21 0.018 0.50 10 3.88 7.00
6 4.03 3.00
P23-091852 9’ X 18’ X 52” 4 3.60 3.00 25 0.018 0.50 12 5.40 7.00
8 4.12 3.00
P23-101845 10’ X 18’ X 45” 4 4.17 3.00 25 0.018 0.50 12 4.85 7.00
8 4.12 3.00
P23-122448 12’ X 24’ X 48” 6 3.51 3.00 37 0.018 0.50 18 5.14 7.00
12 3.77 3.00
P23-122452 12’ X 24’ X 52” 6 3.51 3.00 37 0.018 0.50 18 5.40 7.00
12 3.77 3.00
P23-123048 12’ X 30’ X 48” 6 3.55 3.00 41 0.018 0.50 20 5.14 7.00
14 4.12 3.00
P23-232452 23’ X 24’ X 52” 12 3.77 3.00 49 0.018 0.50 24 5.47 7.00
12 3.62 3.00
CORNER PIECE O-SHAPE SPRING PIN(w/ 1 extra) V-SHAPE SPRING PIN(w/ 1 extra)
POOL
MODEL
POOL SIZE PART NO. QTY WGT
(LBS)
COST
EA.
PART NO. QTY WGT
(LBS)
COST
EA.
PART NO. QTY WGT
(LBS)
COST
EA.
P23-081436 8’ X 14’ X 36” 4 1.6 2.00 7 0.015 0.50 21 0.009 0.50
P23-091852 9’ X 18’ X 52” 4 1.6 2.00 9 0.015 0.50 25 0.009 0.50
P23-101845 10’ X 18’ X 45” 4 1.6 2.00 9 0.015 0.50 25 0.009 0.50
P23-122448 12’ X 24’ X 48” 4 1.6 2.00 15 0.015 0.50 37 0.009 0.50
P23-122452 12’ X 24’ X 52” 4 1.6 2.00 15 0.015 0.50 37 0.009 0.50
P23-123048 12’ X 30’ X 48” 4 1.6 2.00 17 0.015 0.50 41 0.009 0.50
P23-232452 23’ X 24’ X 52” 4 1.6 2.00 21 0.015 0.50 49 0.009 0.50
090-380118 090-380113 090-380114
090-380119
090-380120 090-380113 090-380117
090-380121
090-380122 090-380113 090-380115
090-380123
090-380120 090-380113 090-380116
090-380121
090-380120 090-380113 090-380117
090-380121
090-380124 090-380113 090-380116
090-380123
090-380121 090-380113 090-380117
090-380125
090-380110 090-380111 090-380112
090-380110 090-380111 090-380112
090-380110 090-380111 090-380112
090-380110 090-380111 090-380112
090-380110 090-380111 090-380112
090-380110 090-380111 090-380112
090-380110 090-380111 090-380112

Should you encounter any problems, contact the Customer Service at [phone]
from 8 AM to 5 PM Mon. thru Fri. EST. Extended operating days and hours during peak season requirements.
Should you encounter any problems, contact the Customer Service at [phone]
from 8 AM to 5 PM Mon. thru Fri. EST. Extended operating days and hours during peak season requirements.
9 10
10
9
POOL COVER SAFETY
VERY IMPORTANT
DANGER:
NOTES:
DO NOT USE A POOL COVER, SOLAR COVER OR SOLAR BLANKET ON THIS
POOL IF IT DOES NOT HAVE THIS TYPE OF WARNING LABEL ON THE COVER.
Competent supervision and knowledge of the safety requirements
is the only way to prevent drowning or permanent injury
in the use of this product!
Never leave young children unattended.
IF YOU ARE GOING TO USE A POOL COVER, SOLAR COVER OR SOLAR
BLANKET, PLEASE READ THIS INFORMATION.
POOL COVER WARNING
SOLAR COVER WARNING SOLAR BLANKET WARNING
!WARNING
AVOID DROWNING RISK
STAY OFF COVER - WILL NOT SUPPORT WEIGHT.
KEEP CHILDREN AWAY. CHILDREN OR OBJECTS CAN
NOT BE SEEN UNDER COVER.
REMOVE STANDING WATER - CHILD CAN DROWN ON
TOP OF COVER.
REMOVE COVER COMPLETELY BEFORE ENTRY OF
BATHERS - ENTRAPMENT POSSIBLE.
NON-SECURED OR IMPROPERLY SECURED COVERS
ARE A HAZARD.
FAILURE TO FOLLOW ALL INSTRUCTIONS MAY
RESULT IN INJURY OR DROWNING.
THIS IS NOT A SAFETY COVER.
TYPE OC COVER CLASSIFICATION.
INSTALL COVER WITH LABELS FACING UP.
USE DRAWSTRING TO SECURE COVER TO POOL.
THIS COVER MEETS REQUIREMENTS DESCRIBED
IN SPECIFICATION F-1346 (ASTM).
!WARNING
AVOID DROWNING RISK
STAY OFF COVER - WILL NOT SUPPORT WEIGHT.
KEEP CHILDREN AWAY. CHILDREN OR OBJECTS CAN
NOT BE SEEN UNDER COVER.
REMOVE STANDING WATER - CHILD CAN DROWN ON
TOP OF COVER.
REMOVE COVER COMPLETELY BEFORE ENTRY OF
BATHERS - ENTRAPMENT POSSIBLE.
NON-SECURED OR IMPROPERLY SECURED COVERS
ARE A HAZARD.
FAILURE TO FOLLOW ALL INSTRUCTIONS MAY
RESULT IN INJURY OR DROWNING.
THIS IS NOT A SAFETY COVER.
TYPE OC COVER CLASSIFICATION.
INSTALL COVER WITH LABELS FACING UP.
LAY COVER ON TOP SURFACE OF WATER.
THIS COVER MEETS REQUIREMENTS DESCRIBED
IN SPECIFICATION F-1346 (ASTM).
