popstrukt NOUGAT CLK01 User manual

ASSEMBLY INSTRUCTIONS
CODE | CLK01
NOUGAT STORAGE CABINET
SERIOUS OR FATAL CRUSHING INJURIES CAN OCCUR FROM FURNITURE TIP-OVER. TO
PREVENT THIS FURNITURE FROM TIPPING OVER IT MUST BE PERMANENTLY FIXED TO THE
WALL. BASIC FIXING DEVICES FOR BRICK WALLS ARE INCLUDED. HOWEVER SINCE DIFFERENT
WALL MATERIALS REQUIRE DIFFERENT TYPES OF FIXING DEVICES USE FIXING DEVICES SUITABLE
FOR THE WALLS IN YOUR HOME. FOR ADVICE ON SUITABLE FIXING SYSTEMS, CONTACT
YOUR LOCAL SPECIALIZED HARDWARE DEALER
WARNING
LEFT BACK PANEL:
1PC
RIGHT BACK PANEL:
1PC
BASE PLATE:
1PC
SHELF:
2PCS
TOP PLATE:
1PC
FRONT
FRONT
BACK
FRONT AND BACK BASE:
2PCS
RIGHT SIDE PANEL:
1PC
LEFT SIDE PANEL:
1PC
KEYS WITH
KEYRING:
2PCS
TAILSCREW(4*10):
8PCS
DOORS PINDLE:
2PCS
HANDLE:
2PCS
SCREW
FOR HANDLE:
4PCS
DOOR PIVOT:
2PCS ADJUSTABLE FEET:
4PCS
SHELF HOLDER:
8PCS
Please visit www.popstrukt.com > Resources tab for more information. Please visit www.popstrukt.com > Resources tab for more information.

STEP 1
STEP 2
INSTALL TOP ONTO LEFT AND RIGHT SIDE PANELS AS SHOWN.
CONNECT THE LEFT AND RIGHT SIDE PANELS WITH
FRONT AND BACK BASE.
NB!!! The holes on the front base
must be positioned off center to front
of unit, for doors to function properly.
NOTE: Bend tab up on both sides.
TIP: Use the palm of your hand to
knock top into place.
INSTALL LEFT BACK PANEL OVER RIGHT PANEL
USING SELF TAPPING SCREWS WHERE SHOWN.
STEP 3
STEP 4
INSTALL RIGHT BACK PANEL FIRST USING SELF
TAPPING SCREWS WHERE SHOWN.
NOTE: Bend tab in.
NOTE: Bend tab in.
Please visit www.popstrukt.com > Resources tab for more information. Please visit www.popstrukt.com > Resources tab for more information.

FIX BASE PLATE INTO PLACE WITH TABS AS SHOWN.
STEP 5
STEP 6
INSTALL THE BASE PLATE.
STEP 7
INSTALL THE TWO SHELVES.
STEP 8
INSTALL THE DOORS AND HANDLES.
Please visit www.popstrukt.com > Resources tab for more information. Please visit www.popstrukt.com > Resources tab for more information.
NOTE: Insert base at angle as shown.
Lower rear of panel into place.
NOTE: Bend tabs
up as shown.
NOTE: Bend
tab in on both sides.
NOTE: Lip should be under
front base.
1
2
3
NB!!! Adjust adjustable feet to ensure unit and doors are level and move freely.
Bend tab up to secure pin.
Start with bottom pin

Please visit
www.popstrukt.com/instructions
section for more detailed information
and assembly videos
POPSTRUKT FURNITURE @POPSTRUKT_COM @POPSTRUKT.FURNITURE POPSTRUKT FURNITURE
Finish en klaar.
Please visit www.popstrukt.com > Resources tab for more information.
