Porsche 911 CARRERA 4 - Guide

911
Maintenance
17_991II_GuW_23_B_WKD902012317_KW38.15-21.16.fm Seite -1 Montag, 11. Juli 2016 5:12 17

WKD 902 01 23 17 7/16
911 Carrera
911 Targa
911 Turbo
Dear Owner,
Please present this booklet to an authorized
Porsche dealer if vehicle service is required.
Services performed by your authorized Porsche
dealer will be recorded in the maintenance
record by your service advisor.
Porsche Cars North America, Inc.
Dr. Ing. h.c. F. Porsche AG is the owner of numerous
trademarks, both registered and unregistered, including without
limitation the Porsche Crest®, Porsche®, Boxster®, Carrera®,
Cayenne®, Cayman®, Macan®, Panamera®, Speedster®,
Tiptronic®, Tequipment®. VarioCam®, PCM™, PDK®, 911™,
4S®, RS®and the model numbers and the distinctive shapes of
the Porsche automobiles such as, the federally registered 911
and Boxster automobiles in the US. The third party trademarks
contained herein are the properties of their respective owners.
Porsche Cars North America, Inc. and its affiliates believes the
specifications to be correct at the time of printing.
However, specifications, standard equipment and options are
subject to change without notice. Some options may be
unavailable when a car is built. Some vehicles may be shown
with equipment that is not available in the US and Canada.
Please ask your authorized Porsche dealer for advice
concerning the current availability of options and verify the
optional equipment that you ordered.
Porsche recommends seat belt usage and observance of
traffic laws at all times.
© 2016 Dr. Ing. h.c. F. Porsche AG
17_991II_GuW_23_B_WKD902012317_KW38.15-21.16.fm Seite 0 Montag, 11. Juli 2016 5:12 17

1
Owners of the vehicle
1st owner (Last name, First name)
Address
City, State, ZIP code
2nd owner (Last name, First name)
Address
City, State, ZIP code
3rd owner (Last name, First name)
Address
City, State, ZIP code
4th owner (Last name, First name)
Address
City, State, ZIP code
5th owner (Last name, First name)
Address
City, State, ZIP code
6th owner (Last name, First name)
Address
City, State, ZIP code
17_991II_GuW_23_B_WKD902012317_KW38.15-21.16.fm Seite 1 Montag, 11. Juli 2016 5:12 17

2
Vehicle delivered
on
Mileage
Dealer No.
Your Vehicle
Authorized dealer's stamp
Affix vehicle data carrier here
17_991II_GuW_23_B_WKD902012317_KW38.15-21.16.fm Seite 2 Montag, 11. Juli 2016 5:12 17

3
Maintenance schedule
Scheduled maintenance
The recommended service intervals and scope of work apply
under normal driving conditions and do not take into account all
optional equipment.
Dusty areas require more frequent checking and possible
replacement of the air filter elements.
If the vehicle is driven on very dirty roads, the radiators and
cooling-air inlets in the front should be checked and cleaned
regularly.
Tire, clutch, brake pad and brake disk wear as well as the
condition of the engine oil, the transmission fluids and the brake
fluid (e.g. in the case of sporting events) are all largely
dependent on driving habits, and are also affected by adverse
operating conditions; this could mean shorter intervals between
servicing and replacement.
Time-dependent maintenance
Oil maintenance: If the mileage for scheduled oil maintenance is
not reached, oil maintenance must be performed after
1, 3, 5, 7 ... years at the latest.
Maintenance: If the mileage for scheduled maintenance is not
reached, maintenance must be performed after
2, 4, 6, 8 ... years at the latest.
Proper care and maintenance will preserve the value of your
Porsche and safeguard its functional capability.
This will also protect your right to make warranty claims.
The terms “inspect” and “check” include all associated work
such as checking the condition, adjustments, readjustments,
corrections and replenishment.
They do not include the repair, replacement or overhaul of
components or assemblies.
17_991II_GuW_23_B_WKD902012317_KW38.15-21.16.fm Seite 3 Montag, 11. Juli 2016 5:12 17

4
Oil maintenance
As per fixed service reminder indicator, at the latest after 10,000 mls or 1 year.
If the mileage for scheduled maintenance is not reached, oil maintenance must be performed after 1 year at the latest.
911 Carrera, 911 Targa 911 Turbo every 10,000 mls/1 year every 30,000 mls/4 years
Drain engine oil b b b
Replace oil filter bbb
Underbody panels: Visual inspection for completeness, secure installation and damage b b b
Visual inspection for leaks from underneath (oils and fluids) bbb
Tires: Check condition b b b
Brake lines: Visual inspection for damage, correct routing and corrosion bbb
Brake hoses: Visual inspection for damage b b b
Fill in engine oil bbb
Replace spark plugs b b b
Reset maintenance interval bbb
17_991II_GuW_23_B_WKD902012317_KW38.15-21.16.fm Seite 4 Montag, 11. Juli 2016 5:12 17

5
Maintenance
At 20,000, 40,000, 60,000, 80,000 mls etc.
If the mileage for scheduled maintenance is not reached, maintenance must be performed every 2 years at the latest.
911 Carrera, 911 Targa 911 Turbo every 20,000 mls/2 years every 30,000 mls/4 years every 40,000 mls/4 years every 60,000 mls/6 years every 80,000 mls/4 years every 120,000 mls/12 years
Electrics
Windshield wiper/washer system, headlight cleaning system: check function bbb
Horn: check function b b b
Tires: check tire pressure (TPMS) bbb
Diagnostic system: read out fault memory; reset maintenance interval b b b
Check actuator travel of brake shoes bbb
Inside the
vehicle
Particle filter: replace filter element b b b
Seat belts: check function and condition bb b
Door locks: check function b b b
Luggage compartment
Check front lid lock and safety hook of the front lid to ensure that they are secure
and function properly bbb
Replace air intake pre-filter b b b
Windshield wiper/washer system: check fluid level; check window cleaner and
antifreeze, depending on time of year, only use windshield cleaners approved by
Porsche
bbb
17_991II_GuW_23_B_WKD902012317_KW38.15-21.16.fm Seite 5 Montag, 11. Juli 2016 5:12 17

6
Vehicle exterior
Check wiper blades b b b
Headlights: check adjustment bbb
Radiators and air intakes: visual inspection for external contamination and blockage b b b
Brake system: check brake pads and brake discs for wear (remove wheels) bb b
Brake system: check brake pads and brake discs for wear (without removing wheels) b b b
Service and maintain convertible top; check and clear convertible top drains bbb
Service and maintain Targa roof b b
Under the vehicle
Drain engine oil bbb
Underbody panels: visual inspection for completeness, secure installation and
damage b b b
Tires: check condition bbb
Visual inspection for leaks from underneath (oils and other fluids) b b b
Brake lines: visual inspection for damage, routing and corrosion bbb
Brake hoses: visual inspection for damage b b b
Steering gear: visual inspection of the bellows for damage bb b
Tie rod joints: check play and dust bellows b b b
Drive shafts: visual inspection of the boots for leaks and damage bbb
Axle joints: check the play and visually inspect the dust boots for damage b b b
Ancillary unit mounts and chassis: visual inspection of all rubber mountings and
boots for damage bb b
911 Carrera, 911 Targa 911 Turbo every 20,000 mls/2 years every 30,000 mls/4 years every 40,000 mls/4 years every 60,000 mls/6 years every 80,000 mls/4 years every 120,000 mls/12 years
17_991II_GuW_23_B_WKD902012317_KW38.15-21.16.fm Seite 6 Montag, 11. Juli 2016 5:12 17

7
Under the vehicle
Rear axle steering: check bellows, dust boots and play on joints b b b
Exhaust system: visual inspection for leaks and damage, check engine mount bb b
Replace spark plugs b b b
Controlled all-wheel drive: change oil bb b
Front axle final drive: change oil b b b
Manual transmission: change oil bb
PDK: change transmission oil b b b
PDK: change clutch fluid bb b
Engine compartment
Replace oil filter b b b
Fill in engine oil bbb
Coolant: check level and antifreeze b b b
PDCC: check fluid level bbb
PDCC: replace reservoir b b b
Check drive belt bb b
Replace drive belt b b b
Fuel lines and connections: visual inspection bb b
Replace filter elements of air cleaner b b b
Check intercooler for debris bb
911 Carrera, 911 Targa 911 Turbo every 20,000 mls/2 years every 30,000 mls/4 years every 40,000 mls/4 years every 60,000 mls/6 years every 80,000 mls/4 years every 120,000 mls/12 years
17_991II_GuW_23_B_WKD902012317_KW38.15-21.16.fm Seite 7 Montag, 11. Juli 2016 5:12 17

8
Additional work
every 2 years
Change brake fluid (use only original Porsche brake fluid) b b b
Prepare condition report for long-life guarantee bbb
Tire sealing compound: check use-by date and replace if necessary b b b
Test drive
Remote control, front seats, electric parking brake and foot brake (also actuation
travel), engine, clutch, steering, transmission, ParkAssist, cruise control, PSM
switch, PASM switch, Sport switch, mode-switch, lift-switch, sports exhaust system,
door mirror fold-in function, heating, air conditioning and instruments: check function
bbb
Oils, fluids: visual inspection for leaks b b b
911 Carrera, 911 Targa 911 Turbo every 20,000 mls/2 years every 30,000 mls/4 years every 40,000 mls/4 years every 60,000 mls/6 years every 80,000 mls/4 years every 120,000 mls/12 years
17_991II_GuW_23_B_WKD902012317_KW38.15-21.16.fm Seite 8 Montag, 11. Juli 2016 5:12 17

9
Service Record (Please tick relevant box!)
Sales check carried out
(free of charge)
on ___________________________
Order No. _____________________
Mileage _______________________
Stamp
Yes/No
Oil maintenance
Maintenance
Brake fluid changed
Spark plugs replaced
Air cleaner replaced
Drive belt checked
Drive belt replaced
Tire sealing compound replaced
Transmission oil changed
Oil in final drive changed
 _______________________
 _______________________
on ____________________________
Order No. ______________________
Mileage ________________________
Stamp
Yes/No
Oil maintenance
Maintenance
Brake fluid changed
Spark plugs replaced
Air cleaner replaced
Drive belt checked
Drive belt replaced
Tire sealing compound replaced
Transmission oil changed
Oil in final drive changed
 _______________________
 _______________________
on ____________________________
Order No. ______________________
Mileage ________________________
Stamp
17_991II_GuW_23_B_WKD902012317_KW38.15-21.16.fm Seite 9 Montag, 11. Juli 2016 5:12 17

10
Service Record (Please tick relevant box!)
Yes/No
Oil maintenance
Maintenance
Brake fluid changed
Spark plugs replaced
Air cleaner replaced
Drive belt checked
Drive belt replaced
Tire sealing compound replaced
Transmission oil changed
Oil in final drive changed
 ______________________
 ______________________
on ___________________________
Order No. _____________________
Mileage _______________________
Stamp
Yes/No
Oil maintenance
Maintenance
Brake fluid changed
Spark plugs replaced
Air cleaner replaced
Drive belt checked
Drive belt replaced
Tire sealing compound replaced
Transmission oil changed
Oil in final drive changed
 _______________________
 _______________________
on ____________________________
Order No. ______________________
Mileage ________________________
Stamp
Yes/No
Oil maintenance
Maintenance
Brake fluid changed
Spark plugs replaced
Air cleaner replaced
Drive belt checked
Drive belt replaced
Tire sealing compound replaced
Transmission oil changed
Oil in final drive changed
 _______________________
 _______________________
on ____________________________
Order No. ______________________
Mileage ________________________
Stamp
17_991II_GuW_23_B_WKD902012317_KW38.15-21.16.fm Seite 10 Montag, 11. Juli 2016 5:12 17

11
Service Record (Please tick relevant box!)
Yes/No
Oil maintenance
Maintenance
Brake fluid changed
Spark plugs replaced
Air cleaner replaced
Drive belt checked
Drive belt replaced
Tire sealing compound replaced
Transmission oil changed
Oil in final drive changed
 ______________________
 ______________________
on ___________________________
Order No. _____________________
Mileage _______________________
Stamp
Yes/No
Oil maintenance
Maintenance
Brake fluid changed
Spark plugs replaced
Air cleaner replaced
Drive belt checked
Drive belt replaced
Tire sealing compound replaced
Transmission oil changed
Oil in final drive changed
 _______________________
 _______________________
on ____________________________
Order No. ______________________
Mileage ________________________
Stamp
Yes/No
Oil maintenance
Maintenance
Brake fluid changed
Spark plugs replaced
Air cleaner replaced
Drive belt checked
Drive belt replaced
Tire sealing compound replaced
Transmission oil changed
Oil in final drive changed
 _______________________
 _______________________
on ____________________________
Order No. ______________________
Mileage ________________________
Stamp
17_991II_GuW_23_B_WKD902012317_KW38.15-21.16.fm Seite 11 Montag, 11. Juli 2016 5:12 17

12
Service Record (Please tick relevant box!)
Yes/No
Oil maintenance
Maintenance
Brake fluid changed
Spark plugs replaced
Air cleaner replaced
Drive belt checked
Drive belt replaced
Tire sealing compound replaced
Transmission oil changed
Oil in final drive changed
 ______________________
 ______________________
on ___________________________
Order No. _____________________
Mileage _______________________
Stamp
Yes/No
Oil maintenance
Maintenance
Brake fluid changed
Spark plugs replaced
Air cleaner replaced
Drive belt checked
Drive belt replaced
Tire sealing compound replaced
Transmission oil changed
Oil in final drive changed
 _______________________
 _______________________
on ____________________________
Order No. ______________________
Mileage ________________________
Stamp
Yes/No
Oil maintenance
Maintenance
Brake fluid changed
Spark plugs replaced
Air cleaner replaced
Drive belt checked
Drive belt replaced
Tire sealing compound replaced
Transmission oil changed
Oil in final drive changed
 _______________________
 _______________________
on ____________________________
Order No. ______________________
Mileage ________________________
Stamp
17_991II_GuW_23_B_WKD902012317_KW38.15-21.16.fm Seite 12 Montag, 11. Juli 2016 5:12 17

13
Service Record (Please tick relevant box!)
Yes/No
Oil maintenance
Maintenance
Brake fluid changed
Spark plugs replaced
Air cleaner replaced
Drive belt checked
Drive belt replaced
Tire sealing compound replaced
Transmission oil changed
Oil in final drive changed
 ______________________
 ______________________
on ___________________________
Order No. _____________________
Mileage _______________________
Stamp
Yes/No
Oil maintenance
Maintenance
Brake fluid changed
Spark plugs replaced
Air cleaner replaced
Drive belt checked
Drive belt replaced
Tire sealing compound replaced
Transmission oil changed
Oil in final drive changed
 _______________________
 _______________________
on ____________________________
Order No. ______________________
Mileage ________________________
Stamp
Yes/No
Oil maintenance
Maintenance
Brake fluid changed
Spark plugs replaced
Air cleaner replaced
Drive belt checked
Drive belt replaced
Tire sealing compound replaced
Transmission oil changed
Oil in final drive changed
 _______________________
 _______________________
on ____________________________
Order No. ______________________
Mileage ________________________
Stamp
17_991II_GuW_23_B_WKD902012317_KW38.15-21.16.fm Seite 13 Montag, 11. Juli 2016 5:12 17

14
Service Record (Please tick relevant box!)
Yes/No
Oil maintenance
Maintenance
Brake fluid changed
Spark plugs replaced
Air cleaner replaced
Drive belt checked
Drive belt replaced
Tire sealing compound replaced
Transmission oil changed
Oil in final drive changed
 ______________________
 ______________________
on ___________________________
Order No. _____________________
Mileage _______________________
Stamp
Yes/No
Oil maintenance
Maintenance
Brake fluid changed
Spark plugs replaced
Air cleaner replaced
Drive belt checked
Drive belt replaced
Tire sealing compound replaced
Transmission oil changed
Oil in final drive changed
 _______________________
 _______________________
on ____________________________
Order No. ______________________
Mileage ________________________
Stamp
Yes/No
Oil maintenance
Maintenance
Brake fluid changed
Spark plugs replaced
Air cleaner replaced
Drive belt checked
Drive belt replaced
Tire sealing compound replaced
Transmission oil changed
Oil in final drive changed
 _______________________
 _______________________
on ____________________________
Order No. ______________________
Mileage ________________________
Stamp
17_991II_GuW_23_B_WKD902012317_KW38.15-21.16.fm Seite 14 Montag, 11. Juli 2016 5:12 17

15
Service Record (Please tick relevant box!)
Yes/No
Oil maintenance
Maintenance
Brake fluid changed
Spark plugs replaced
Air cleaner replaced
Drive belt checked
Drive belt replaced
Tire sealing compound replaced
Transmission oil changed
Oil in final drive changed
 ______________________
 ______________________
on ___________________________
Order No. _____________________
Mileage _______________________
Stamp
Yes/No
Oil maintenance
Maintenance
Brake fluid changed
Spark plugs replaced
Air cleaner replaced
Drive belt checked
Drive belt replaced
Tire sealing compound replaced
Transmission oil changed
Oil in final drive changed
 _______________________
 _______________________
on ____________________________
Order No. ______________________
Mileage ________________________
Stamp
Yes/No
Oil maintenance
Maintenance
Brake fluid changed
Spark plugs replaced
Air cleaner replaced
Drive belt checked
Drive belt replaced
Tire sealing compound replaced
Transmission oil changed
Oil in final drive changed
 _______________________
 _______________________
on ____________________________
Order No. ______________________
Mileage ________________________
Stamp
17_991II_GuW_23_B_WKD902012317_KW38.15-21.16.fm Seite 15 Montag, 11. Juli 2016 5:12 17

16
Service Record (Please tick relevant box!)
Yes/No
Oil maintenance
Maintenance
Brake fluid changed
Spark plugs replaced
Air cleaner replaced
Drive belt checked
Drive belt replaced
Tire sealing compound replaced
Transmission oil changed
Oil in final drive changed
 ______________________
 ______________________
on ___________________________
Order No. _____________________
Mileage _______________________
Stamp
Yes/No
Oil maintenance
Maintenance
Brake fluid changed
Spark plugs replaced
Air cleaner replaced
Drive belt checked
Drive belt replaced
Tire sealing compound replaced
Transmission oil changed
Oil in final drive changed
 _______________________
 _______________________
on ____________________________
Order No. ______________________
Mileage ________________________
Stamp
Yes/No
Oil maintenance
Maintenance
Brake fluid changed
Spark plugs replaced
Air cleaner replaced
Drive belt checked
Drive belt replaced
Tire sealing compound replaced
Transmission oil changed
Oil in final drive changed
 _______________________
 _______________________
on ____________________________
Order No. ______________________
Mileage ________________________
Stamp
17_991II_GuW_23_B_WKD902012317_KW38.15-21.16.fm Seite 16 Montag, 11. Juli 2016 5:12 17

17
Service Record (Please tick relevant box!)
Yes/No
Oil maintenance
Maintenance
Brake fluid changed
Spark plugs replaced
Air cleaner replaced
Drive belt checked
Drive belt replaced
Tire sealing compound replaced
Transmission oil changed
Oil in final drive changed
 ______________________
 ______________________
on ___________________________
Order No. _____________________
Mileage _______________________
Stamp
Yes/No
Oil maintenance
Maintenance
Brake fluid changed
Spark plugs replaced
Air cleaner replaced
Drive belt checked
Drive belt replaced
Tire sealing compound replaced
Transmission oil changed
Oil in final drive changed
 _______________________
 _______________________
on ____________________________
Order No. ______________________
Mileage ________________________
Stamp
Yes/No
Oil maintenance
Maintenance
Brake fluid changed
Spark plugs replaced
Air cleaner replaced
Drive belt checked
Drive belt replaced
Tire sealing compound replaced
Transmission oil changed
Oil in final drive changed
 _______________________
 _______________________
on ____________________________
Order No. ______________________
Mileage ________________________
Stamp
17_991II_GuW_23_B_WKD902012317_KW38.15-21.16.fm Seite 17 Montag, 11. Juli 2016 5:12 17

18
Service Record (Please tick relevant box!)
Yes/No
Oil maintenance
Maintenance
Brake fluid changed
Spark plugs replaced
Air cleaner replaced
Drive belt checked
Drive belt replaced
Tire sealing compound replaced
Transmission oil changed
Oil in final drive changed
 ______________________
 ______________________
on ___________________________
Order No. _____________________
Mileage _______________________
Stamp
Yes/No
Oil maintenance
Maintenance
Brake fluid changed
Spark plugs replaced
Air cleaner replaced
Drive belt checked
Drive belt replaced
Tire sealing compound replaced
Transmission oil changed
Oil in final drive changed
 _______________________
 _______________________
on ____________________________
Order No. ______________________
Mileage ________________________
Stamp
Yes/No
Oil maintenance
Maintenance
Brake fluid changed
Spark plugs replaced
Air cleaner replaced
Drive belt checked
Drive belt replaced
Tire sealing compound replaced
Transmission oil changed
Oil in final drive changed
 _______________________
 _______________________
on ____________________________
Order No. ______________________
Mileage ________________________
Stamp
17_991II_GuW_23_B_WKD902012317_KW38.15-21.16.fm Seite 18 Montag, 11. Juli 2016 5:12 17
