INDEX PAGE 1

LOCATION
The diagrams above indicate example locations of the electronic parking brake (A) which is labelled with the universal icon symbol:
ACTIVATION
The EPB will normally auto activate. If will also activate if seat belts are not being worn, or when luggage placed on top of seats activates the system. To
enable the system to function correctly, fasten seatbelts, and remove luggage from the seats and store it securely in the boot. Pull the switch labelled A to
manually apply the parking brake. The warning lamps on both the switch and instrument panel will light up to confirm its activation.
DEACTIVATION
The EPB will normally auto release. Depress the brake or accelerator pedal to auto release it, or press the switch (A) to manually release it. The
associated warning lamps on both the switch and dashboard instrument panel will go out to confirm its deactivation. Note: seatbelts should be fastened,
and luggage should not be placed on seats.
WHEN DRIVING AWAY
The parking brake will deactivate automatically when driving away, and it also prevents the vehicle from rolling back unintentionally for a few seconds
when starting on a gradient. This works by driving off in a normal way, the parking brake will automatically release and the vehicle will start moving in the
desired direction.
On vehicles fitted with an automatic gear box, you can apply the parking brake when stopping briefly at traffic lights etc., to avoid the vehicle creeping
forward. When you drive off the parking brake will be automatically released.
INFORMATION
Vehicle specifications are subject to change. This vehicle does not include any manufacturer handbooks or manuals.
VEHICLE INSTRUCTION CARD SUPPLEMENT
No responsibility is accepted for inaccuracies or misunderstanding caused by the wording of this guide. If in any doubt ask a member of staff for assistance.
PORSCHE VEHICLES
Where fitted, the electronic parking brake replaces the mechanical handbrake and is designed to prevent the vehicle from accidently rolling away. This
system offers convenience and safety features in addition to those normally associated with a mechanical handbrake. Please refer to the primary Vehicle
Instruction Guide for information about other operational instructions.
06-11-2016
ELECTRONIC PARKING BRAKE (EPB)
Don’t panic! Despite seeing a new light pop-up on your instrument panel, unless it is red it is likely the car is still running fine, and while there may be a
problem to attend to, proceed with confidence and patience.
RED indicates a potentially serious problem or safety issue. Attend to it! Red may also indicate an important reminder.
YELLOW or orange means something needs to be serviced or repaired soon. If it is flashing, it is important that you contact your rental agent for advice.
GREEN or blue is only telling you that a system is on or operating normally.
WARNING LIGHTS AND WHAT THEY MEAN
Deadlock / safelock messages shown on the instrument display when the engine is turned off simply indicate that once you exit the vehicle and lock the
doors, they’re effectively deadlocked and anyone left in the car wouldn’t be able to get out in the event of an emergency. The warning is nothing to worry
about and is just a standard advisory message.
DEADLOCKS
A seatbelt warning light may illuminate when the engine is turned on. This may mean that the electronic parking brake (EPB) becomes auto activated to
prevent vehicle movement. To deactivate these warning lights, and turn off the auto activation of the EPB in this instance, ensure all passengers fasten
their seatbelts, and remove any luggage from on top of the seats. For safety secure all luggage inside the boot.
SEATBELT WARNING LIGHTS
Unless indicated otherwise by road traffic signs and/or local road regulations and/or dictated by weather conditions, the Highway Code states that
provided always it is safe to do so, a passenger vehicle may be driven at the following MAXIMUM speeds (MPH):
DRIVING RESTRICTIONS AND/OR CONDITIONS
Drivers are reminded that they are responsible for the consequences arising out of their failure
to comply at all times with the requirements of any applicable Road Traffic Regulations, the
Highway Code and/or to the road conditions prevailing at the time and in the locality through
which they are driving the vehicle.
Europcar accepts no responsibility or liability for any costs, claims, penalties, fines or any other
circumstances arising out of or in connection with the driver’s failure to comply with all and any
road restrictions and/or conditions.

USEFUL INFORMATION ABOUT YOUR VEHICLE
design and production by : Drake Enterprises Limited - Phone : [phone]
CHILD SEATS
FUEL IN CASE OF BREAKDOWN DRIVER’S SEAT
Vehicle specifications are subject to change. When the engine is turned off, ensure that the starter switch is in position II when operating electrical items such
as door mirrors and windows, etc. This vehicle does not include any manufacturer handbooks or manuals.
No responsibility is accepted for inaccuracies or misunderstanding caused by the wording of this guide. If in any doubt ask a member of staff for assistance.
Use hazard lights. Attempt to park
in a safe position.
Use an emergency phone rather
than a mobile as emergency
services will then know the location
of the vehicle.
Never use a child seat in a front
passenger seat which is fitted with
an active airbag (SRS). Follow all
fitting instructions carefully.
Check seat positioning and security
before use.
VEHICLE INSTRUCTION CARD
TYRE PRESSURES (COLD)
CONTROLS
When parked, the parking brake should be
fully applied with the vehicle left in first or
reverse gear for vehicles equipped with manual
transmission or P (Park) for vehicles with
automatic transmission.
CAUTION!
For assistance after an accident/incident, please call 0800 0280 999
For assistance after a breakdown or help with tyres or windscreens please refer to the numbers on the tax disc holder.
TYRE HELPLINE
In the event of having a punctured tyre
please call the Europcar Tyre Helpline
0800 0280 999 for ANY assistance.
NOTE: Vehicles are not usually supplied
with a tyre repair kit (for vehicles that use
this in lieu of a spare wheel).
PORSCHE 718 CAYMAN 2 SEATS
2 DOOR COUPE
Key / remote control operated central locking. Press central locking switch on centre console to lock the doors from the
inside. (Some vehicles may feature a keyless entry system). Doors will auto lock when the vehicle is in motion.
Fitted with a remote anti-theft alarm. Passive arming of electronic engine immobiliser after removal of the key from the starter
switch.
Centrally locked. Use the remote control to unlock / open. Remote release. Luggage can be stored in both rear tailgate and
front bonnet compartments.
Electric internal adjustment operated via a control knob on the driver’s door.
Electric front operated via control buttons on the driver’s door.
If fitted. Electric tilt / slide operated by roof mounted switchgear.
Ensure gear selector is in neutral (or N or P if automatic) and electronic parking brake is on (the electronic parking brake
switch is located on the lower dashboard between the right side of the steering wheel and the driver’s door). Place ignition
key in starter key slot. Use a normal starting routine or press the key in to start/stop the engine. Select desired gear. Release
electronic parking brake and brake pedal and gently press the accelerator to move the vehicle. Vehicles are fitted with
engine start-stop technology which automatically stops the engine when the vehicle is not moving and gears are in neutral
and foot pedals ate not depressed - just touch the foot pedals to auto restart the engine. If activated: the electronic parking
brake will automatically deactivate as you drive off.
Centrally locked. Located under flap on rear offside. Press the remote release switch. Lift the edge of the flap to open it and
twist off the cap anticlockwise.
Pull bonnet release lever located to the lower right of the instrument panel. Unhook catch under bonnet.
The tools and jack are stored in compartments within the boot. Move the vehicle to firm / level ground. Turn the engine off,
select first gear (manual) or P (automatic). Apply the handbrake or parking brake. Loosen the wheel nuts (do not remove
them). Only use the specific reinforced jack points on the underside of the vehicle. Crank the jack to lift the vehicle. Undo
wheel nuts and change the wheel. Lower the vehicle. Tighten the wheel nuts. For any assistance in the event of having a
punctured tyre, or should the vehicle not be supplied with a spare wheel and tyre or a tyre repair kit, please call the
Europcar Tyre Helpline 0800 0280 999.
To change gears using the steptronic gear lever: Select Nfor neutral, Pwhen leaving the vehicle, Rfor reversing (the vehicle
must be at a complete standstill before this gear can be selected). For normal driving select Dwhere the transmission will
use all available forward gears automatically (a ‘kickdown ‘ facility is provided when the accelerator is pressed all the way to
the floor past the normal acceleration point forcing the transmission to select a lower gear to obtain maximum acceleration.
Release pressure on the accelerator to return to normal accelerator use). Use M+ or M- to manually select gears using the
tiptronic gear selector. Whenever the vehicle is at a standstill apply the electronic parking brake.
