SmartConnect
Quick Setup Guide
Plug AC power cord into jack
& wall outlet.
1
Unplug handset from phone
and plug in here:
2
Plug straight
cord into phone’s
handset jack:
3
Plug cord from teleconference unit or modem
into Voice/Data port:
4
(Continued
other side.)
