PortaPivot StealthPivot XL User manual

By PortaPivot
Patented technology
Watch our instruction videos on www.portapivot.com
ASSEMBLY MANUAL
PortaPivot GLASS XL
1

‘Complete’ StealthPivot XL kit is displayed,
but assembly is also possible with
‘Essential’ or ‘Basic’ kit.
Hardware
& accessories
PortaPivot GLASS XL
& StealthPivot XL Complete Kit
2

Quick Grip
Rubber hammer
Wooden wedge Bit screwdriver
Saw cut marker
(Supplied with kit)
Rigid 2mm aid
(Supplied)
• Safety glass or paneling
• ???????????????????????
Materials to be purchased locally:
Recommended tools:
3

Ø10.00Ø10.00
R10.00
14.50
R10.00
R10.00
53.00
R10.00
R3.00R3.00
R3.00
min 1/3 (-50 mm) up to 1/2 of the panel
138.00138.00
276.00
52.50
21.5021.50 233.00
276.00
(=distance from panel edge)
R3.00
detail A
cavity dimensions
4

12.50
12.5 mm is necessary for the
optional 1&2-way accessories
Panel dimension info
Top & bottom
cavity (A) are identical
4.00
4.00
11.00
(=distance from panel edge)
min 1/3 (-50 mm) up to
1/2 of the panel
A
A
panel width
panel height
thickness = 10 mm
5

Pivot axis can be anywhere from 1/3
(-50 mm) up to 1/2 of the panel.
Use 2 wooden spacers (+-15 mm thick)
on an assembly table and place the
locally purchased panel on top.
6

Degrease the panel edge first Apply the self adhesive rubber strip onto
the panel edge.
7

Degrease apply zone first Remove the backing from the adhesive
strip from the first aluminium pivot
housing (=GMHD).
Carefully slide the GMHD in place and
press it against the glass.
Make sure everything is perfectly
aligned.
8

Insert the nylon protection parts.
Carefully place the second GMHD on top.
9

1
2
334455
2
1
1
2
334455
2
1
1
2
334455
2
1
1
2
334455
2
1
1
2
334455
2
1
Insert and tighten all screws in left to
right alternating pattern.
10

differencedifference
Height from pivot to pivot in doorway
Height from pivot to pivot on door
Check the pivot height of
the door with the doorway
measurements, and
synchronize them if
necessary.
There are different
methods to do this, see
following pages.
1- or 2-way accessory
Synchronize pivot axis height in doorway
11

11 mm
DOOR
Solid floor
BOTTOM
BOTTOM
BOTTOM
Locktite
The default bottom joint dimension is 11 mm
(=distance between floor and door leaf edge).
To increase the bottom joint, you have 2 options:
2. Use supplied shims between floor and hinge
(= less stable).
1. Use (supplied) shims between hinge and door leaf.
This is the preferred method for the bottom hinge.
Adjust bottom hinge height
12

Solid ceiling
12,5 mm
DOOR
TOP
TOP
TOP
Locktite
The default top joint dimension is 12,5 mm
(=distance between ceiling and door leaf edge).
This is necessary for the optional 1-way
accessory and positioning magnets
2. Use (supplied) shims between hinge and door leaf.
To increase the top joint, you have 3 options:
1. Adjust the inbus screws to move the hinge further
away from the door leaf (loosen 4 screws first).
3. Use supplied shims between ceiling and hinge
(= less stable is not preferred at the top hinge).
Adjust top hinge height
13

Outer height from pivot to pivot
= equal to measured doorway height on the axis point !
Double check the pivot to pivot
distance with the measured doorway
height at the axis point.
Fully tighten all marked screws when
joint dimensions are as desired.
14

Remove the backing from the adhesive
strip and press the cover plates in place.
15

Only advised for central axis
s90
+90°
-90°
360°
The s90 will stop the door
in open position at +/-90°.
For unlimited 360° rotation, remove the s90 from top
and bottom pivot. This is only advised for central axis position.
Make sure the s90 is always on
the same side top and bottom!
16

TOP
TOP
Slide the 1&2-way part over the panel,
+-55 mm from the edge.
Use water to
facilitate sliding
TIP
TOP
1&2-way + magnets can be mounted
on both sides of the XL panel.
We advise to install the optional 2-way
positioning magnet(s) onto the door leaf.
(For counter magnets on the ceiling, see ‘Door
installation manual’)
17

All manuals are also available in video format on www.portapivot.com
For further instructions on how to install
the fully assembled door in your doorway,
please refer to the DOOR INSTALLATION MANUAL
